Building Serverless Workflows with Durable Functions

How Azure Durable Functions can help you create reliable and robust serverless workflows

Transcript

1. Order from Chaos
   Building Serverless Workflows with
   Durable Functions
   @mark_heath
   https://markheath.net


   View Slide

2. @mark_heath
   Video uploaded Virus Scan File copy
   Extract metadata
   Database
   Audit
   Transcode
   Thumbnail
   Analytics Voice detection Notification
   icons designed by Smashicons from flaticons


   View Slide

3. “Functions as
   a Service”
   (FaaS) A managed platform that
   runs your code (a function)
   in response to an event
   (trigger)
   @mark_heath


   View Slide

4. Blob
   Cosmos DB
   HTTP Request Timer
   Queue
   Azure Functions Triggers
   @mark_heath


   View Slide

5. Serverless
   @mark_heath
   Managed
   Servers
   Automatic
   Scale
   Per-Second
   Billing
   icons designed by Smashicons from flaticons


   View Slide

6. Can we build
   serverless workflows
   with Azure Functions?
   @mark_heath


   View Slide

7. @mark_heath
   Function chaining with queues
   Video
   uploaded
   Extract
   Metadata
   Virus
   Scan
   File
   Copy


   View Slide

8. @mark_heath


   View Slide

9. @mark_heath


   View Slide

10. @mark_heath
    Video uploaded Virus Scan File copy
    Extract metadata
    Database
    Audit
    Transcode
    Thumbnail
    Analytics Voice detection Notification
    icons designed by Smashicons from flaticons
    Can’t see the
    big picture?


    View Slide

11. Image from The Art of Rube Goldberg: (A) Inventive (B) Cartoon (C) Genius, Selected and with commentary by Jennifer
    George; Introduction by Adam Gopnik, Published by Abrams ComicArts.


    View Slide

12. @mark_heath
    Video uploaded Virus Scan File copy
    Extract metadata
    Database
    Audit
    Transcode
    Thumbnail
    Analytics Voice detection Notification
    icons designed by Smashicons from flaticons
    Retries and backoff


    View Slide

13. @mark_heath
    Video uploaded Virus Scan File copy
    Extract metadata
    Database
    Audit
    Transcode
    Thumbnail
    Analytics Voice detection Notification
    icons designed by Smashicons from flaticons
    Error Handling
    Stuck Workflows


    View Slide

14. @mark_heath
    Video uploaded Virus Scan File copy
    Extract metadata
    Database
    Audit
    Transcode
    Thumbnail
    Analytics Voice detection Notification
    icons designed by Smashicons from flaticons
    Waiting for
    external events


    View Slide

15. Fan-out Fan-in Workflow
    @mark_heath
    easy! difficult!


    View Slide

16. Durable Functions
    to the rescue!
    @mark_heath


    View Slide

17. Durable Functions
    • An extension to Azure Functions
    • Microsoft.Azure.WebJobs.Extensions.DurableTask NuGet package
    • C# supported, JavaScript in preview
    • Open source
    • https://github.com/Azure/azure-functions-durable-extension
    @mark_heath


    View Slide

18. Orchestrator Functions
    • Define the steps in the workflow
    • Shows the big picture
    • Calls “activity functions”
    • Or other orchestrators (“sub-orchestrations”)
    • Decides what to do next
    • Handle exceptions across all activities
    • Must adhere to strict rules
    @mark_heath


    View Slide

19. Activity Functions
    • Perform steps in the workflow
    • Can receive input data and return output data
    • Can use “bindings” to connect to external services
    • (Just like a regular Azure Function)
    @mark_heath


    View Slide

20. Task Hubs
    • Stores state associated with workflows
    • Uses an Azure Storage account behind the scenes
    • (Tables and Queues)
    • Uses an event sourcing technique
    @mark_heath


    View Slide

21. REST API
    • Query orchestration status (GET)
    • https://{yourapp}.azurewebsites.net/runtime/webhooks/durabletask/
    instances/{orchestration_id}?taskHub=DurableFunctionsHub&
    connection=Storage&code={code}
    • Send an event to an orchestration (POST)
    • https://{yourapp}.azurewebsites.net/runtime/webhooks/durabletask/
    instances/{orchestration_id}/raiseEvent/{eventName}?
    taskHub=DurableFunctionsHub&connection=Storage&code={code}
    • Terminate an orchestration (POST)
    • https://{yourapp}.azurewebsites.net/runtime/webhooks/durabletask/
    instances/{orchestration_id}/terminate?reason={text}&
    taskHub=DurableFunctionsHub&connection=Storage&code={code}


    View Slide

22. Demo Time!
    @mark_heath
    https://github.com/markheath/durable-functions-ecommerce-sample


    View Slide

23. @mark_heath
    Payment received
    Database
    Generate PDF
    Await approval Email customer
    Generate Video


    View Slide

24. [FunctionName("NewPurchaseWebhook")]
    public static async Task Run(
    [HttpTrigger(AuthorizationLevel.Function, "post", Route = null)] HttpRequest req,
    [OrchestrationClient] DurableOrchestrationClient client)
    {
    string requestBody = await new StreamReader(req.Body).ReadToEndAsync();
    var order = JsonConvert.DeserializeObject(requestBody);
    var orchestrationId = await client.StartNewAsync("O_ProcessOrder", order);
    return new OkResult();
    }
    Starter Function
    @mark_heath


    View Slide

25. Orchestrator V1
    [FunctionName("O_ProcessOrder")]
    public static async Task ProcessOrder(
    [OrchestrationTrigger] DurableOrchestrationContext ctx)
    {
    var order = ctx.GetInput();
    await ctx.CallActivityAsync("A_SaveOrderToDatabase", order);
    var pdfLocation = await ctx.CallActivityAsync("A_CreatePersonalizedPdf", order);
    var videoLocation = await ctx.CallActivityAsync("A_CreateWatermarkedVideo", order);
    await ctx.CallActivityAsync("A_SendEmail", (order, pdfLocation, videoLocation));
    return "Order processed successfully";
    }
    @mark_heath


    View Slide

26. Activity Function
    [FunctionName("A_CreatePersonalizedPdf")]
    public static string CreatePersonalizedPdf(
    [ActivityTrigger] Order order,
    TraceWriter log)
    {
    log.Info("Creating PDF");
    return $"{order.Id}.pdf";
    }
    @mark_heath


    View Slide

27. Orchestrator V2 – Parallel Tasks
    var pdfTask = ctx.CallActivityAsync("A_CreatePersonalizedPdf", order);
    var videoTask = ctx.CallActivityAsync("A_CreateWatermarkedVideo", order);
    await Task.WhenAll(pdfTask, videoTask);
    var pdfLocation = pdfTask.Result;
    var videoLocation = videoTask.Result;
    @mark_heath


    View Slide

28. Exception Handling and Retry
    try
    {
    await ctx.CallActivityAsync
    ("A_CreatePersonalizedPdf", order);
    await ctx.CallActivityWithRetryAsync
    ("A_CreateWatermarkedVideo",
    new RetryOptions(TimeSpan.FromSeconds(30), 3),
    order);
    }
    catch (Exception ex)
    {
    log.Error($"Problem creating media files", ex);
    }
    @mark_heath


    View Slide

29. Waiting for External Events
    var approvalResult = await ctx.WaitForExternalEvent(
    "OrderApprovalResult", TimeSpan.FromMinutes(30),
    "TimedOut");
    if (approvalResult == "TimedOut" ||
    approvalResult == "Rejected")
    {
    await ctx.CallActivityAsync("A_OrderNotApproved", order);
    }
    else
    {
    // order was approved
    await ctx.CallActivityAsync("A_EmailCustomer", order);
    }
    @mark_heath


    View Slide

30. Sending an External Event
    [FunctionName("ApproveOrder")]
    public static async Task ApproveOrder(
    [HttpTrigger(AuthorizationLevel.Function, "post", Route = null)] HttpRequest req,
    [OrchestrationClient] DurableOrchestrationClient client)
    {
    string requestBody = await new StreamReader(req.Body).ReadToEndAsync();
    var approvalResult = JsonConvert.DeserializeObject(requestBody);
    await client.RaiseEventAsync(approvalResult.OrchestrationId,
    "OrderApprovalResult", approvalResult);
    return new OkResult();
    }
    @mark_heath


    View Slide

31. Why Durable Functions?
    • Define the big picture in code
    • Handle errors for the workflow as a whole
    • Retry individual steps with back-off
    • Easily implement waiting for external events with timeout
    • Easily implement fan-out fan-in patterns
    • Track progress of workflows
    • Cancel workflows
    • It’s free and open source
    @mark_heath


    View Slide

32. @mark_heath


    View Slide

33. https://github.com/markheath/
    durable-functions-ecommerce-sample
    https://markheath.net
    @mark_heath
    https://skillsmatter.com/conferences/
    10107-prognet-london-2018#skillscasts


    View Slide
