Better x86 Assembly Generation with Go

Better x86 Assembly Generation with Go
Michael McLoughlin
dotGo 2019
Uber Advanced Technologies Group

View Slide

Introduction

View Slide

Assembly Language
Go provides the ability to write functions in assembly
language.
Assembly language is a general term for low-level languages
that allow programming at the architecture instruction level.

View Slide

View Slide

Should I write Go functions in Assembly?

View Slide

No

View Slide

View Slide

Go Proverbs which Might Have Been
Cgo Assembly is not Go.
My Inner Rob Pike
With the unsafe package assembly there are no
guarantees.
Made-up Go Proverb

View Slide

View Slide

We should forget about small efﬁciencies, say about
97% of the time: premature optimization is the root
of all evil. Yet we should not pass up our
opportunities in that critical 3%.
Donald Knuth, 1974

View Slide

The Critical 3%?
To take advantage of:
• Missed optimizations by the compiler
• Special hardware instructions
Common use cases:
• Math compute kernels
• System Calls
• Low-level Runtime Details
• Cryptography

View Slide

View Slide

Go Assembly Primer

View Slide

Hello, World!
package add
// Add x and y.
func Add(x, y uint64) uint64 {
return x + y
}

View Slide

Function Stubs
package add
// Add x and y.
func Add(x, y uint64) uint64
Missing function body will be implemented in assembly.

View Slide

Implementation provided in add_amd64.s.
#include "textflag.h"
// func Add(x, y uint64) uint64
TEXT ·Add(SB), NOSPLIT, $0-24
MOVQ x+0(FP), AX
MOVQ y+8(FP), CX
ADDQ CX, AX
MOVQ AX, ret+16(FP)
RET

View Slide

TEXT ·Add(SB), NOSPLIT, $0-24 ‹ Declaration
MOVQ x+0(FP), AX
MOVQ y+8(FP), CX
ADDQ CX, AX
MOVQ AX, ret+16(FP)
RET

View Slide

MOVQ x+0(FP), AX ‹ Read x from stack frame
MOVQ y+8(FP), CX ‹ Read y
ADDQ CX, AX
MOVQ AX, ret+16(FP)
RET

View Slide

MOVQ x+0(FP), AX
MOVQ y+8(FP), CX
ADDQ CX, AX
MOVQ AX, ret+16(FP)
RET

View Slide

MOVQ x+0(FP), AX
MOVQ y+8(FP), CX
ADDQ CX, AX
MOVQ AX, ret+16(FP) ‹ Write return value
RET

View Slide

Problem Statement

View Slide

24,962

View Slide

Table 1: Assembly Lines by Top-Level Packages
Lines Package
8140 crypto
8069 runtime
5686 internal
1173 math
1005 syscall
574 cmd
279 hash
36 reflect

View Slide

Table 2: Top 10 Assembly Files by Lines
Lines File
2695 internal/x/crypto/.../chacha20poly1305_amd64.s
2348 crypto/elliptic/p256_asm_amd64.s
1632 runtime/asm_amd64.s
1500 crypto/sha1/sha1block_amd64.s
1377 internal/x/crypto/curve25519/ladderstep_amd64.s
1286 crypto/aes/gcm_amd64.s
743 runtime/sys_darwin_amd64.s
727 runtime/sys_linux_amd64.s

View Slide

openAVX2InternalLoop:
// Lets just say this spaghetti loop interleaves 2 quarter rounds with 3 poly multiplications
// Effectively per 512 bytes of stream we hash 480 bytes of ciphertext
polyAdd(0*8(inp)(itr1*1))
VPADDD BB0, AA0, AA0; VPADDD BB1, AA1, AA1; VPADDD BB2, AA2, AA2; VPADDD BB3, AA3, AA3
polyMulStage1_AVX2
VPXOR AA0, DD0, DD0; VPXOR AA1, DD1, DD1; VPXOR AA2, DD2, DD2; VPXOR AA3, DD3, DD3
VPSHUFB ·rol16<>(SB), DD0, DD0; VPSHUFB ·rol16<>(SB), DD1, DD1; VPSHUFB ·rol16<>(SB), DD2, DD2; VPSHUFB ·rol16<>(S
polyMulStage2_AVX2
VPADDD DD0, CC0, CC0; VPADDD DD1, CC1, CC1; VPADDD DD2, CC2, CC2; VPADDD DD3, CC3, CC3
VPXOR CC0, BB0, BB0; VPXOR CC1, BB1, BB1; VPXOR CC2, BB2, BB2; VPXOR CC3, BB3, BB3
polyMulStage3_AVX2
VMOVDQA CC3, tmpStoreAVX2
VPSLLD $12, BB0, CC3; VPSRLD $20, BB0, BB0; VPXOR CC3, BB0, BB0
VMOVDQA tmpStoreAVX2, CC3
polyMulReduceStage
VPSHUFB ·rol8<>(SB), DD0, DD0; VPSHUFB ·rol8<>(SB), DD1, DD1; VPSHUFB ·rol8<>(SB), DD2, DD2; VPSHUFB ·rol8<>(SB),
polyAdd(2*8(inp)(itr1*1))
internal/x/.../chacha20poly1305_amd64.s lines 856-879 (go1.12)

View Slide

// Special optimization for buffers smaller than 321 bytes
openAVX2320:
// For up to 320 bytes of ciphertext and 64 bytes for the poly key, we process six blocks
VMOVDQA AA0, AA1; VMOVDQA BB0, BB1; VMOVDQA CC0, CC1; VPADDD ·avx2IncMask<>(SB), DD0, DD1
VMOVDQA AA0, AA2; VMOVDQA BB0, BB2; VMOVDQA CC0, CC2; VPADDD ·avx2IncMask<>(SB), DD1, DD2
VMOVDQA BB0, TT1; VMOVDQA CC0, TT2; VMOVDQA DD0, TT3
MOVQ $10, itr2
openAVX2320InnerCipherLoop:
chachaQR_AVX2(AA0, BB0, CC0, DD0, TT0); chachaQR_AVX2(AA1, BB1, CC1, DD1, TT0); chachaQR_AVX2(AA2, BB2, CC2, DD2, T
VPALIGNR $4, BB0, BB0, BB0; VPALIGNR $4, BB1, BB1, BB1; VPALIGNR $4, BB2, BB2, BB2
VPALIGNR $8, CC0, CC0, CC0; VPALIGNR $8, CC1, CC1, CC1; VPALIGNR $8, CC2, CC2, CC2
VPALIGNR $12, DD0, DD0, DD0; VPALIGNR $12, DD1, DD1, DD1; VPALIGNR $12, DD2, DD2, DD2
chachaQR_AVX2(AA0, BB0, CC0, DD0, TT0); chachaQR_AVX2(AA1, BB1, CC1, DD1, TT0); chachaQR_AVX2(AA2, BB2, CC2, DD2, T
VPALIGNR $12, BB0, BB0, BB0; VPALIGNR $12, BB1, BB1, BB1; VPALIGNR $12, BB2, BB2, BB2
VPALIGNR $8, CC0, CC0, CC0; VPALIGNR $8, CC1, CC1, CC1; VPALIGNR $8, CC2, CC2, CC2
VPALIGNR $4, DD0, DD0, DD0; VPALIGNR $4, DD1, DD1, DD1; VPALIGNR $4, DD2, DD2, DD2
DECQ itr2
JNE openAVX2320InnerCipherLoop
VMOVDQA ·chacha20Constants<>(SB), TT0
VPADDD TT0, AA0, AA0; VPADDD TT0, AA1, AA1; VPADDD TT0, AA2, AA2
VPADDD TT1, BB0, BB0; VPADDD TT1, BB1, BB1; VPADDD TT1, BB2, BB2
VPADDD TT2, CC0, CC0; VPADDD TT2, CC1, CC1; VPADDD TT2, CC2, CC2

View Slide

openAVX2Tail512LoopA:
polyAdd(0*8(itr2))
polyMulAVX2

View Slide

sealAVX2Tail512LoopB:
polyAdd(0*8(oup))
polyMulAVX2

View Slide

Is this ﬁne?

View Slide

TEXT p256SubInternal(SB),NOSPLIT,$0
XORQ mul0, mul0
SUBQ t0, acc4
SBBQ t1, acc5
SBBQ t2, acc6
SBBQ t3, acc7
SBBQ $0, mul0
MOVQ acc4, acc0
MOVQ acc5, acc1
MOVQ acc6, acc2
MOVQ acc7, acc3
ADDQ $-1, acc4
ADCQ p256const0<>(SB), acc5
ADCQ $0, acc6
ADCQ p256const1<>(SB), acc7
ADCQ $0, mul0
CMOVQNE acc0, acc4
CMOVQNE acc1, acc5
CMOVQNE acc2, acc6
CMOVQNE acc3, acc7
RET
crypto/elliptic/p256_asm_amd64.s lines 1300-1324 (94e44a9c8e)

View Slide

View Slide

Go Assembly Policy
1. Prefer Go, not assembly
2. Minimize use of assembly
3. Explain root causes
4. Test it well
5. Make assembly easy to review

View Slide

Make your assembly easy to review; ideally,
auto-generate it using a simpler Go program.
Comment it well.
Go Assembly Policy, Rule IV

View Slide

Code Generation

View Slide

There’s a reason people use compilers.

View Slide

Intrinsics
__m256d latq = _mm256_loadu_pd(lat);
latq = _mm256_mul_pd(latq, _mm256_set1_pd(1 / 180.
latq = _mm256_add_pd(latq, _mm256_set1_pd(1.5));
__m256i lati = _mm256_srli_epi64(_mm256_castpd_si2
__m256d lngq = _mm256_loadu_pd(lng);
lngq = _mm256_mul_pd(lngq, _mm256_set1_pd(1 / 360.
lngq = _mm256_add_pd(lngq, _mm256_set1_pd(1.5));
__m256i lngi = _mm256_srli_epi64(_mm256_castpd_si2

View Slide

High-level Assembler
Assembly language plus high-level language features.
Macro assemblers: Microsoft Macro Assembler (MASM),
Netwide Assembler (NASM), ...

View Slide

View Slide

PeachPy
Python-based High-Level Assembler

View Slide

What about Go?

View Slide

The avo Library

View Slide

https://github.com/mmcloughlin/avo

View Slide

Use Go control structures for assembly
generation; avo programs are Go
programs

View Slide

Register allocation: write functions with
virtual registers and avo assigns physical
registers for you

View Slide

Automatically load arguments and store
return values: ensure memory offsets are
correct for complex structures

View Slide

Generation of stub ﬁles to interface with
your Go package

View Slide

import . "github.com/mmcloughlin/avo/build"
func main() {
TEXT("Add", NOSPLIT, "func(x, y uint64) uint64")
Doc("Add adds x and y.")
x := Load(Param("x"), GP64())
y := Load(Param("y"), GP64())
ADDQ(x, y)
Store(y, ReturnIndex(0))
RET()
Generate()
}

View Slide

func main() {
x := Load(Param("x"), GP64()) ‹ Param references
y := Load(Param("y"), GP64()) ‹ Allocates register
ADDQ(x, y)
RET()
Generate()
}

View Slide

func main() {
ADDQ(x, y) ‹ ADD can take virtual registers
RET()
Generate()
}

View Slide

func main() {
ADDQ(x, y)
Store(y, ReturnIndex(0)) ‹ Store return value
RET()
Generate()
}

View Slide

func main() {
ADDQ(x, y)
RET()
Generate() ‹ Generate compiles and outputs assembly
}

View Slide

Build
go run asm.go -out add.s -stubs stubs.go

View Slide

Generated Assembly
// Code generated by command: go run asm.go -out add.s -stub
// func Add(x uint64, y uint64) uint64
MOVQ x+0(FP), AX
MOVQ y+8(FP), CX
ADDQ AX, CX
MOVQ CX, ret+16(FP)
RET

View Slide

Generated Assembly
TEXT ·Add(SB), NOSPLIT, $0-24 ‹ Computed stack sizes
MOVQ x+0(FP), AX
MOVQ y+8(FP), CX
ADDQ AX, CX
MOVQ CX, ret+16(FP)
RET

View Slide

Generated Assembly
MOVQ x+0(FP), AX ‹ Computed offsets
MOVQ y+8(FP), CX
ADDQ AX, CX
MOVQ CX, ret+16(FP)
RET

View Slide

Generated Assembly
MOVQ x+0(FP), AX ‹ Registers allocated
MOVQ y+8(FP), CX
ADDQ AX, CX
MOVQ CX, ret+16(FP)
RET

View Slide

Auto-generated Stubs
package addavo
// Add adds x and y.
func Add(x uint64, y uint64) uint64

View Slide

Go Control Structures
TEXT("Mul5", NOSPLIT, "func(x uint64) uint64")
Doc("Mul5 adds x to itself five times.")
p := GP64()
MOVQ(x, p)
for i := 0; i < 4; i++ {
ADDQ(x, p)
}
Store(p, ReturnIndex(0))
RET()

View Slide

Go Control Structures
TEXT("Mul5", NOSPLIT, "func(x uint64) uint64")
Doc("Mul5 adds x to itself five times.")
p := GP64()
MOVQ(x, p)
for i := 0; i < 4; i++ {
ADDQ(x, p) ‹ Generate four ADDQ instructions
}
Store(p, ReturnIndex(0))
RET()

View Slide

Generated Assembly
// func Mul5(x uint64) uint64
TEXT ·Mul5(SB), NOSPLIT, $0-16
MOVQ x+0(FP), AX
MOVQ AX, CX
ADDQ AX, CX
ADDQ AX, CX
ADDQ AX, CX
ADDQ AX, CX
MOVQ CX, ret+8(FP)
RET

View Slide

Generated Assembly
// func Mul5(x uint64) uint64
TEXT ·Mul5(SB), NOSPLIT, $0-16
MOVQ x+0(FP), AX
MOVQ AX, CX
ADDQ AX, CX ‹ Look, there's four of them!
ADDQ AX, CX
ADDQ AX, CX
ADDQ AX, CX
MOVQ CX, ret+8(FP)
RET

View Slide

SHA-1
Cryptographic hash function.
• 80 rounds
• Constants and bitwise functions vary
• Message update rule
• State update rule
avo can be used to create a completely unrolled
implementation.

View Slide

SHA-1 Subroutines
func majority(b, c, d Register) Register {
t, r := GP32(), GP32()
MOVL(b, t)
ORL(c, t)
ANDL(d, t)
MOVL(b, r)
ANDL(c, r)
ORL(t, r)
return r
}

View Slide

SHA-1 Subroutines
func xor(b, c, d Register) Register {
r := GP32()
MOVL(b, r)
XORL(c, r)
XORL(d, r)
return r
}

View Slide

SHA-1 Loops
Comment("Load initial hash.")
hash := [5]Register{GP32(), GP32(), GP32(), GP32(), GP32
for i, r := range hash {
MOVL(h.Offset(4*i), r)
}
Comment("Initialize registers.")
a, b, c, d, e := GP32(), GP32(), GP32(), GP32(), GP32()
for i, r := range []Register{a, b, c, d, e} {
MOVL(hash[i], r)
}

View Slide

for r := 0; r < 80; r++ {
Commentf("Round %d.", r)
...
q := quarter[r/20]
t := GP32()
MOVL(a, t)
ROLL(U8(5), t)
ADDL(q.F(b, c, d), t)
ADDL(e, t)
ADDL(U32(q.K), t)
ADDL(u, t)
ROLL(Imm(30), b)
a, b, c, d, e = t, a, b, c, d
}

View Slide

for r := 0; r < 80; r++ { ‹ Loop over rounds
...
q := quarter[r/20]
t := GP32()
MOVL(a, t)
ROLL(U8(5), t)
ADDL(e, t)
ADDL(U32(q.K), t)
ADDL(u, t)
ROLL(Imm(30), b)
a, b, c, d, e = t, a, b, c, d
}

View Slide

for r := 0; r < 80; r++ {
...
q := quarter[r/20]
t := GP32() ‹ State update
MOVL(a, t)
ROLL(U8(5), t)
ADDL(e, t)
ADDL(U32(q.K), t)
ADDL(u, t)
ROLL(Imm(30), b)
a, b, c, d, e = t, a, b, c, d
}

View Slide

SHA-1 Conditionals
u := GP32()
if r < 16 {
MOVL(m.Offset(4*r), u)
BSWAPL(u)
} else {
MOVL(W(r-3), u)
XORL(W(r-8), u)
XORL(W(r-14), u)
XORL(W(r-16), u)
ROLL(U8(1), u)
}

View Slide

SHA-1 Conditionals
u := GP32()
if r < 16 { ‹ Early rounds
MOVL(m.Offset(4*r), u) ‹ Read from memory
BSWAPL(u)
} else {
MOVL(W(r-3), u)
XORL(W(r-8), u)
XORL(W(r-14), u)
XORL(W(r-16), u)
ROLL(U8(1), u)
}

View Slide

SHA-1 Conditionals
u := GP32()
if r < 16 {
MOVL(m.Offset(4*r), u)
BSWAPL(u)
} else {
MOVL(W(r-3), u) ‹ Formula in later rounds
XORL(W(r-8), u)
XORL(W(r-14), u)
XORL(W(r-16), u)
ROLL(U8(1), u)
}

View Slide

116 avo lines to 1507 assembly lines

View Slide

Real avo Examples
With the help of Damian Gryski.
• SHA-1
• FNV-1a
• Vector Dot Product
• Marvin32
• Sip13
• SPECK
• Bloom Index
• Chaskey MAC
• Farmhash64

View Slide

Thank You
https://github.com/mmcloughlin/avo
@mbmcloughlin

View Slide

Better x86 Assembly Generation with Go

Better x86 Assembly Generation with Go

Michael McLoughlin

More Decks by Michael McLoughlin

Other Decks in Programming

Featured

Transcript
