Porting Golang Runtime To Baremetal

Analyze biscuit and get to know how to porting golang runtime to baremetal

morimolymoly

March 10, 2019

Transcript

20 slides
  1. WHO AM I ❖ I am morimolymoly a.k.a GNM ❖

    Interests ❖ InfoSec ❖ Hypervisor ❖ Aikatsu! ❖ Details available at morimolymoly.com * GNM means “ήΩΧϫͶ͜ΈΈϝΠυ”. It sound better right?
  2. mit-pdos/biscuit ❖ POSIX compatible kernel written in Golang ❖ Secure,

    fast, USEFUL FEATURES(channels, interface, goroutine, etc…) ❖ 4-Components ❖ Bootloader(C, asm) + Kernel(Golang) + Go runtime(Golang, C, asm) + UserProgram(C) ❖ You can utilize goroutine, memory safety, etc … IN KERNEL LAND!
  3. Golang Runtime ❖ Runtime do initialization and goroutine stuff. ❖

    Kernel loads Go program into memory and call initialize function of Golang Runtime.(For Linux, ELF header’s entrypoint defines it) ❖ Initialization stage is huge. ❖ Init goroutine ❖ Get args passed by OS ❖ Init scheduler(stack, mm, GC, etc…) ❖ Runtime needs kernel!
  4. Without kernel ❖ Who loads Go Runtime? ❖ Write some

    bootloader to load runtime!(Runtime loads kernel main function) ❖ How initialize goroutine, memory, some low level stuff(Interrupt, I/O)? ❖ Replace system call with own system call ❖ Get memory map from BIOS and set it. ❖ WRITE LOW LEVEL CODE IN ASSEMBLY(ಀ͛ͪΌͩΊͩ)
  5. Boot Sequence BIOS Bootloader Runtime Biscuit ❖ Runtime and Biscuit

    build actual KERNEL ❖ BIOS gives primitive services(PS/2 Keyboard and Mouse, Serial, VGA, get memory map) to KERNEL Boot sector:0x00007c00
  6. Minimize Biscuit code and analyze it ❖ Biscuit forked golang:1.4(Above

    golang:1.5, most of runtime code is written in Go rather than C) ❖ You can see commits related to biscuit by command below ❖ git log --author="Cody Cutler" —reverse ❖ I forked and minimzed biscuit ❖ https://github.com/morimolymoly/biscuit ❖ I focused on commits before c14beb90191e74163c20c48596a5eed576fbc664(It is so primitive but there is goroutine, interface, collections…)
  7. Important Modified files under `src/runtime` ❖ src/runtime/asm_amd64.s - register ops(rdmsr,

    invlpg, change CRx), in/out, ❖ src/runtime/os_linux.c - system call implementation ❖ src/runtime/rt0_linux_amd64.s - entrypoint code ❖ src/runtime/sys_linux_amd64.s - runtime syscall wrapper
  8. Detail of runtime initialization ❖ Makefile makes main.gobin which is

    ELF binary from kernel code ❖ biscuit/kernel/chentry.c changes entrypoint of main.gobin to _rt0_hack ❖ _rt0_hack is like a _rt0_amd64_linux which is used when you launch Go program in Linux AMD64 arch ❖ _rt0_hack calls runtime·rt0_go_hack in src/runtime/asm_amd64.s ❖ runtime·rt0_go_hack init segment, interrupt, syscall table, first goroutine
  9. goroutine on Baremetal ❖ goroutine = Kernel Thread ❖ Kenel’s

    main function is also goroutine(created by runtime·newproc in rt0_go_hack) ❖ After setting up Virtual Memory(Paging, Segment), you can free to fire it! ❖ Set M(Machine), P(Processor) up.(M(Machine) and P is used in Golang runtime internal)
  10. Conclusion ❖ Sorry for ultra fast tour! ❖ HLL gives

    us new perspective of next generation Operating System ❖ e.g. Keyboard driver uses goroutine in biscuit ❖ Reading runtime is absolutely fun!(Try it ! Fork and read it for free!) ❖ Read code and hack it!
  11. References ❖ Cody Cutler, M. Frans Kaashoek, and Robert T.

    Morris. “The benefits and costs of writing a POSIX kernel in a high-level language”. In: 13th USENIX Symposium on Operating Systems Design and Implementation (OSDI 18). ❖ Yoshiki Shibukawa, “Biscuit Code Reading”. In: GoCon2018 Autumn ❖ Achilleas Anagnostopoulos, “Bare Metal Gophers: can you write an OS Kernel in Go?”. In: GolangUK2017
