Automatic Printing System with Open Source Tools

It is the slides for COSCUP[1] 2013 talk, "Automatic Printing System with Open Source Tools".

It explains how to setup automatic printing system on Linux and includes some tips for it.

[1] COSCUP: http://coscup.org/

Transcript

1. 2013/08/03 @ COSCUP 2013
   Automatic Printing System
   with Open Source Tools
   Mosky
   1


   View Slide

2. This Slide
   ✤ This slide is available at:
   https://speakerdeck.com/mosky/automatic-printing-system-with-
   open-source-tools
   2


   View Slide

3. Mosky
   3


   View Slide

4. Mosky
   ✤ I am working at www.pinkoi.com .
   3


   View Slide

5. Mosky
   ✤ I am working at www.pinkoi.com .
   ✤ I've been using Ubuntu everyday since 2009.
   3


   View Slide

6. Mosky
   ✤ I am working at www.pinkoi.com .
   ✤ I've been using Ubuntu everyday since 2009.
   ✤ A speaker at PyCon TW 2013, 2012, PyCon JP 2012, ...
   3


   View Slide

7. Mosky
   ✤ I am working at www.pinkoi.com .
   ✤ I've been using Ubuntu everyday since 2009.
   ✤ A speaker at PyCon TW 2013, 2012, PyCon JP 2012, ...
   ✤ http://mosky.tw/
   3


   View Slide

8. Outline
   4


   View Slide

9. Outline
   ✤ The Motivation
   4


   View Slide

10. Outline
    ✤ The Motivation
    ✤ Setup Printing System on Linux
    4


    View Slide

11. Outline
    ✤ The Motivation
    ✤ Setup Printing System on Linux
    ✤ Convert Web to PDF
    4


    View Slide

12. Outline
    ✤ The Motivation
    ✤ Setup Printing System on Linux
    ✤ Convert Web to PDF
    ✤ The Tips
    4


    View Slide

13. The Motivation
    5


    View Slide

14. It's just out of control!
    We have to issue more than 1,000 invoices per month.
    6


    View Slide

15. It's just out of control!
    We have to issue more than 1,000 invoices per month.
    6


    View Slide

16. We love hand-made stuff.
    Pinkoi is the largest online community and marketplace for designers in Asia
    7


    View Slide

17. We love hand-made stuff.
    Pinkoi is the largest online community and marketplace for designers in Asia
    7


    View Slide

18. So we build it for ourselves
    with many cups of coffee.
    8


    View Slide

19. So we build it for ourselves
    with many cups of coffee.
    8


    View Slide

20. Setup Printing System on Linux
    9


    View Slide

21. The Check List
    10


    View Slide

22. The Check List
    ✤ A computer installed Linux and CUPS
    (Common Unix Printing System).
    10


    View Slide

23. The Check List
    ✤ A computer installed Linux and CUPS
    (Common Unix Printing System).
    ✤ http://www.cups.org/
    10


    View Slide

24. The Check List
    ✤ A computer installed Linux and CUPS
    (Common Unix Printing System).
    ✤ http://www.cups.org/
    ✤ http://localhost:631/
    10


    View Slide

25. The Check List
    ✤ A computer installed Linux and CUPS
    (Common Unix Printing System).
    ✤ http://www.cups.org/
    ✤ http://localhost:631/
    ✤ A printer which has an IP address.
    10


    View Slide

26. The Check List
    ✤ A computer installed Linux and CUPS
    (Common Unix Printing System).
    ✤ http://www.cups.org/
    ✤ http://localhost:631/
    ✤ A printer which has an IP address.
    ✤ http://192.168.2.100/
    10


    View Slide

27. The Check List
    ✤ A computer installed Linux and CUPS
    (Common Unix Printing System).
    ✤ http://www.cups.org/
    ✤ http://localhost:631/
    ✤ A printer which has an IP address.
    ✤ http://192.168.2.100/
    ✤ lpd://192.168.2.100/
    10


    View Slide

28. Setup Printer with CUPS' Driver
    11


    View Slide

29. Setup Printer with CUPS' Driver
    ✤ Find the driver for your printer:
    11


    View Slide

30. Setup Printer with CUPS' Driver
    ✤ Find the driver for your printer:
    ✤ $ lpinfo --make-and-model 'P1006' -m
    11


    View Slide

31. Setup Printer with CUPS' Driver
    ✤ Find the driver for your printer:
    ✤ $ lpinfo --make-and-model 'P1006' -m
    ✤ drv:///hpijs.drv/hp-laserjet_p1006-hpijs.ppd HP LaserJet
    p1006 hpijs, 3.10.2, requires proprietary plugin
    11


    View Slide

32. Setup Printer with CUPS' Driver
    ✤ Find the driver for your printer:
    ✤ $ lpinfo --make-and-model 'P1006' -m
    ✤ drv:///hpijs.drv/hp-laserjet_p1006-hpijs.ppd HP LaserJet
    p1006 hpijs, 3.10.2, requires proprietary plugin
    ✤ Add the printer with the driver we found from the above command:
    11


    View Slide

33. Setup Printer with CUPS' Driver
    ✤ Find the driver for your printer:
    ✤ $ lpinfo --make-and-model 'P1006' -m
    ✤ drv:///hpijs.drv/hp-laserjet_p1006-hpijs.ppd HP LaserJet
    p1006 hpijs, 3.10.2, requires proprietary plugin
    ✤ Add the printer with the driver we found from the above command:
    ✤ $ lpadmin -E -p -v socket:// -m -E
    11


    View Slide

34. Setup Printer with CUPS' Driver
    ✤ Find the driver for your printer:
    ✤ $ lpinfo --make-and-model 'P1006' -m
    ✤ drv:///hpijs.drv/hp-laserjet_p1006-hpijs.ppd HP LaserJet
    p1006 hpijs, 3.10.2, requires proprietary plugin
    ✤ Add the printer with the driver we found from the above command:
    ✤ $ lpadmin -E -p -v socket:// -m -E
    ✤ $ lpadmin -E -p 'hp-p1006' -v socket://192.168.2.100 -m
    drv:///hpijs.drv/hp-laserjet_p1006-hpijs.ppd -E
    11


    View Slide

35. Setup Printer with PPD
    12


    View Slide

36. Setup Printer with PPD
    ✤ Find the PPD file for your printer:
    12


    View Slide

37. Setup Printer with PPD
    ✤ Find the PPD file for your printer:
    ✤ http://www.openprinting.org/drivers
    12


    View Slide

38. Setup Printer with PPD
    ✤ Find the PPD file for your printer:
    ✤ http://www.openprinting.org/drivers
    ✤ Put the PPD file in:
    12


    View Slide

39. Setup Printer with PPD
    ✤ Find the PPD file for your printer:
    ✤ http://www.openprinting.org/drivers
    ✤ Put the PPD file in:
    ✤ /usr/share/cups/model
    12


    View Slide

40. Setup Printer with PPD
    ✤ Find the PPD file for your printer:
    ✤ http://www.openprinting.org/drivers
    ✤ Put the PPD file in:
    ✤ /usr/share/cups/model
    ✤ Add the printer with this PPD file:
    12


    View Slide

41. Setup Printer with PPD
    ✤ Find the PPD file for your printer:
    ✤ http://www.openprinting.org/drivers
    ✤ Put the PPD file in:
    ✤ /usr/share/cups/model
    ✤ Add the printer with this PPD file:
    ✤ $ lpadmin -E -p -v lpd:///lp -m -E
    12


    View Slide

42. Setup Printer with PPD
    ✤ Find the PPD file for your printer:
    ✤ http://www.openprinting.org/drivers
    ✤ Put the PPD file in:
    ✤ /usr/share/cups/model
    ✤ Add the printer with this PPD file:
    ✤ $ lpadmin -E -p -v lpd:///lp -m -E
    ✤ $ lpadmin -E -p 'hp-p1006' -v lpd://192.168.2.100/lp -m
    12


    View Slide

43. More about lpadmin
    13


    View Slide

44. More about lpadmin
    ✤ Enable a printer:
    13


    View Slide

45. More about lpadmin
    ✤ Enable a printer:
    ✤ $ lpadmin -p -E
    13


    View Slide

46. More about lpadmin
    ✤ Enable a printer:
    ✤ $ lpadmin -p -E
    ✤ Set a printer as default:
    13


    View Slide

47. More about lpadmin
    ✤ Enable a printer:
    ✤ $ lpadmin -p -E
    ✤ Set a printer as default:
    ✤ $ lpadmin -d
    13


    View Slide

48. More about lpadmin
    ✤ Enable a printer:
    ✤ $ lpadmin -p -E
    ✤ Set a printer as default:
    ✤ $ lpadmin -d
    ✤ Remove a printer:
    13


    View Slide

49. More about lpadmin
    ✤ Enable a printer:
    ✤ $ lpadmin -p -E
    ✤ Set a printer as default:
    ✤ $ lpadmin -d
    ✤ Remove a printer:
    ✤ $ lpadmin -x
    13


    View Slide

50. Check Printer is Online
    14


    View Slide

51. Check Printer is Online
    ✤ Just print a test file:
    14


    View Slide

52. Check Printer is Online
    ✤ Just print a test file:
    ✤ $ lpr -P
    14


    View Slide

53. Check Printer is Online
    ✤ Just print a test file:
    ✤ $ lpr -P
    ✤ Check the status of printer:
    14


    View Slide

54. Check Printer is Online
    ✤ Just print a test file:
    ✤ $ lpr -P
    ✤ Check the status of printer:
    ✤ $ lpstat -a / $ lpstat -t
    14


    View Slide

55. Check Printer is Online
    ✤ Just print a test file:
    ✤ $ lpr -P
    ✤ Check the status of printer:
    ✤ $ lpstat -a / $ lpstat -t
    ✤ Troubleshooting:
    14


    View Slide

56. Check Printer is Online
    ✤ Just print a test file:
    ✤ $ lpr -P
    ✤ Check the status of printer:
    ✤ $ lpstat -a / $ lpstat -t
    ✤ Troubleshooting:
    ✤ $ nc -v
    14


    View Slide

57. Check Printer is Online
    ✤ Just print a test file:
    ✤ $ lpr -P
    ✤ Check the status of printer:
    ✤ $ lpstat -a / $ lpstat -t
    ✤ Troubleshooting:
    ✤ $ nc -v
    ✤ $ nmap -p
    14


    View Slide

58. Convert Web to PDF
    15


    View Slide

59. The Packages
    16


    View Slide

60. The Packages
    ✤ Use wkhtmltopdf to convert Web to PDF.
    16


    View Slide

61. The Packages
    ✤ Use wkhtmltopdf to convert Web to PDF.
    ✤ $ sudo apt-get install wkhtmltopdf
    16


    View Slide

62. The Packages
    ✤ Use wkhtmltopdf to convert Web to PDF.
    ✤ $ sudo apt-get install wkhtmltopdf
    ✤ https://code.google.com/p/wkhtmltopdf/
    16


    View Slide

63. The Packages
    ✤ Use wkhtmltopdf to convert Web to PDF.
    ✤ $ sudo apt-get install wkhtmltopdf
    ✤ https://code.google.com/p/wkhtmltopdf/
    ✤ If you don't have X Window, you also need xvfb.
    16


    View Slide

64. The Packages
    ✤ Use wkhtmltopdf to convert Web to PDF.
    ✤ $ sudo apt-get install wkhtmltopdf
    ✤ https://code.google.com/p/wkhtmltopdf/
    ✤ If you don't have X Window, you also need xvfb.
    ✤ $ sudo apt-get install xvfb
    16


    View Slide

65. The Usage
    17


    View Slide

66. The Usage
    ✤ with X Window:
    17


    View Slide

67. The Usage
    ✤ with X Window:
    ✤ $ wkhtmltopdf
    17


    View Slide

68. The Usage
    ✤ with X Window:
    ✤ $ wkhtmltopdf
    ✤ $ wkhtmltopdf -T 0 -L 0 -R 0 -B 0 --page-size A4 --
    encoding utf-8
    17


    View Slide

69. The Usage
    ✤ with X Window:
    ✤ $ wkhtmltopdf
    ✤ $ wkhtmltopdf -T 0 -L 0 -R 0 -B 0 --page-size A4 --
    encoding utf-8
    ✤ without X window:
    17


    View Slide

70. The Usage
    ✤ with X Window:
    ✤ $ wkhtmltopdf
    ✤ $ wkhtmltopdf -T 0 -L 0 -R 0 -B 0 --page-size A4 --
    encoding utf-8
    ✤ without X window:
    ✤ $ xvfb-run -a -s "-screen 0 640x480x16" wkhtmltopdf -T 0
    -L 0 -R 0 -B 0 --page-size A4 --encoding utf-8

    17


    View Slide

71. Send File to Printer
    18


    View Slide

72. Send File to Printer
    ✤ Print file:
    18


    View Slide

73. Send File to Printer
    ✤ Print file:
    ✤ $ lpr -P ...
    18


    View Slide

74. Send File to Printer
    ✤ Print file:
    ✤ $ lpr -P ...
    ✤ Show printer queue:
    18


    View Slide

75. Send File to Printer
    ✤ Print file:
    ✤ $ lpr -P ...
    ✤ Show printer queue:
    ✤ $ lpq -P
    18


    View Slide

76. Send File to Printer
    ✤ Print file:
    ✤ $ lpr -P ...
    ✤ Show printer queue:
    ✤ $ lpq -P
    ✤ $ lpq -a
    18


    View Slide

77. Send File to Printer
    ✤ Print file:
    ✤ $ lpr -P ...
    ✤ Show printer queue:
    ✤ $ lpq -P
    ✤ $ lpq -a
    ✤ Cancel print job:
    18


    View Slide

78. Send File to Printer
    ✤ Print file:
    ✤ $ lpr -P ...
    ✤ Show printer queue:
    ✤ $ lpq -P
    ✤ $ lpq -a
    ✤ Cancel print job:
    ✤ $ lprm -P ...
    18


    View Slide

79. PyCUPS
    19


    View Slide

80. PyCUPS
    ✤ PyPI
    19


    View Slide

81. PyCUPS
    ✤ PyPI
    ✤ https://pypi.python.org/pypi/pycups
    19


    View Slide

82. PyCUPS
    ✤ PyPI
    ✤ https://pypi.python.org/pypi/pycups
    ✤ Get connection:
    19


    View Slide

83. PyCUPS
    ✤ PyPI
    ✤ https://pypi.python.org/pypi/pycups
    ✤ Get connection:
    ✤ import cups
    conn = cups.Connection()
    19


    View Slide

84. PyCUPS - Get Printers
    20


    View Slide

85. PyCUPS - Get Printers
    ✤ Get printers:
    20


    View Slide

86. PyCUPS - Get Printers
    ✤ Get printers:
    ✤ conn.getPrinters()
    20


    View Slide

87. PyCUPS - Get Printers
    ✤ Get printers:
    ✤ conn.getPrinters()
    ✤ Example output:
    20


    View Slide

88. PyCUPS - Get Printers
    ✤ Get printers:
    ✤ conn.getPrinters()
    ✤ Example output:
    ✤ {u'hp': {'device-uri': u'lpd://192.168.0.100/lp',
    'printer-info': u'hp',
    # 3: prepared to print; 4: printing; 5: this device is stop
    'printer-state': 3,
    'printer-state-message': u'Data file sent successfully',
    'printer-state-reasons': [u'none'],
    ...
    'printer-uri-supported': u'ipp://localhost:631/printers/hp'}}
    20


    View Slide

89. PyCUPS - Print File
    21


    View Slide

90. PyCUPS - Print File
    ✤ Print file:
    21


    View Slide

91. PyCUPS - Print File
    ✤ Print file:
    ✤ conn.printFile(printer, filename, title, options)
    conn.printFiles(printer, filenames, title, options)
    21


    View Slide

92. PyCUPS - Print File
    ✤ Print file:
    ✤ conn.printFile(printer, filename, title, options)
    conn.printFiles(printer, filenames, title, options)
    ✤ Example:
    21


    View Slide

93. PyCUPS - Print File
    ✤ Print file:
    ✤ conn.printFile(printer, filename, title, options)
    conn.printFiles(printer, filenames, title, options)
    ✤ Example:
    ✤ conn.printFile(printer, filepath,
    os.path.basename(filepath), {})
    21


    View Slide

94. PyCUPS - Get Jobs
    22


    View Slide

95. PyCUPS - Get Jobs
    ✤ Get jobs:
    22


    View Slide

96. PyCUPS - Get Jobs
    ✤ Get jobs:
    ✤ conn.getJobs(which_jobs='not-completed', my_jobs=False,
    limit=-1, first_job_id=-1, requested_attributes=None)
    22


    View Slide

97. PyCUPS - Get Jobs
    ✤ Get jobs:
    ✤ conn.getJobs(which_jobs='not-completed', my_jobs=False,
    limit=-1, first_job_id=-1, requested_attributes=None)
    ✤ The which_jobs can be 'not-completed', 'completed' or 'all'.
    22


    View Slide

98. PyCUPS - Get Jobs
    ✤ Get jobs:
    ✤ conn.getJobs(which_jobs='not-completed', my_jobs=False,
    limit=-1, first_job_id=-1, requested_attributes=None)
    ✤ The which_jobs can be 'not-completed', 'completed' or 'all'.
    ✤ It returns a dict, indexed by job id, of dicts representing job attributes.
    22


    View Slide

99. The Tips
    23


    View Slide

100. The Error Log
     24


     View Slide

101. The Error Log
     ✤ $ sudo tail -f /var/log/cups/error_log
     24


     View Slide

102. About Template (CSS)
     25


     View Slide

103. About Template (CSS)
     ✤ Use cm/mm as your unit ...
     25


     View Slide

104. About Template (CSS)
     ✤ Use cm/mm as your unit ...
     ✤ The steps of adjusting output:
     25


     View Slide

105. About Template (CSS)
     ✤ Use cm/mm as your unit ...
     ✤ The steps of adjusting output:
     ✤ Create 1x1 cm div block.
     25


     View Slide

106. About Template (CSS)
     ✤ Use cm/mm as your unit ...
     ✤ The steps of adjusting output:
     ✤ Create 1x1 cm div block.
     ✤ Print it.
     25


     View Slide

107. About Template (CSS)
     ✤ Use cm/mm as your unit ...
     ✤ The steps of adjusting output:
     ✤ Create 1x1 cm div block.
     ✤ Print it.
     ✤ Use zoom to adjust.
     25


     View Slide

108. About Template (CSS)
     ✤ Use cm/mm as your unit ...
     ✤ The steps of adjusting output:
     ✤ Create 1x1 cm div block.
     ✤ Print it.
     ✤ Use zoom to adjust.
     ✤ Avoid floating structure.
     25


     View Slide

109. Live Demo
     26


     View Slide

110. Live Demo
     27


     View Slide

111. Video Demo
     28


     View Slide

112. View Slide

113. View Slide

114. The End
     30


     View Slide

115. The End
     31


     View Slide

116. The End
     ✤ CUPS
     31


     View Slide

117. The End
     ✤ CUPS
     ✤ lpadmin, lpstat, lpr, lpq, lprm, ...
     31


     View Slide

118. The End
     ✤ CUPS
     ✤ lpadmin, lpstat, lpr, lpq, lprm, ...
     ✤ wxhtmltopdf
     31


     View Slide

119. The End
     ✤ CUPS
     ✤ lpadmin, lpstat, lpr, lpq, lprm, ...
     ✤ wxhtmltopdf
     ✤ PyCUPS
     31


     View Slide

120. The End
     ✤ CUPS
     ✤ lpadmin, lpstat, lpr, lpq, lprm, ...
     ✤ wxhtmltopdf
     ✤ PyCUPS
     ✤ Some tips
     31


     View Slide

121. The End
     ✤ CUPS
     ✤ lpadmin, lpstat, lpr, lpq, lprm, ...
     ✤ wxhtmltopdf
     ✤ PyCUPS
     ✤ Some tips
     ✤ Any Question?
     31


     View Slide
