Shiny, Let's Be Bad Guys: Exploiting and Mitigating the Top 10 Web App Vulnerabilities -- OSCON 2016 edition

Shiny, Let's Be Bad Guys: Exploiting and Mitigating the Top 10 Web App Vulnerabilities -- OSCON 2016 edition

Slides from the OSCON 2016 presentation of our tutorial that walks through the OWASP Top 10 web application vulnerabilities.

Mike Pirnat

May 16, 2016

More Decks by Mike Pirnat

Other Decks in Programming


  1. Shiny Let’s Be Bad Guys! Exploiting and Mitigating the Top

    1 0 Web App Vulnerabilities Mike Pirnat - @mpirnat OSCON 2016 Setup: https://github.com/mpirnat/lets-be-bad-guys
  2. Schedule • This session will run 1:30 PM – 5:00

    PM • 30-minute break 3:00 – 3:30 PM • Here on Level 4
  3. Shiny Let’s Be Bad Guys! Exploiting and Mitigating the Top

    1 0 Web App Vulnerabilities Mike Pirnat - @mpirnat OSCON 2016
  4. Who here makes web apps?

  5. Who here has vulnerable apps?

  6. Why it Matters • Your users • Your data •

    Your business
  7. OWASP • http://www.owasp.org • Open Web Application Security Project •

    Non-profit focused on improving software security • Documentation and tools to help learn about security and protect your apps
  8. OWASP Top Ten • Based on risk data from 8

    firms • Over 500,000 vulnerabilities, hundreds of orgs, thousands of apps • Selected & prioritized by prevalence data combined with estimates of exploitability, detectability, and impact • Updated in 2013
  9. Today • Background on a type of vulnerability • Exploit

    it! • Discuss prevention • Django & Flask specific advice where possible • Light examples where we have time
  10. Disclaimer

  11. About Django

  12. About Flask

  13. Setup: 1 Make & activate a virtualenv: # Python 3...

    $ pyvenv badguys # Python 2... $ virtualenv badguys $ cd badguys $ source bin/activate
  14. Setup: 2 Clone our repository: $ git clone https://github.com/ mpirnat/lets-be-bad-guys

    src Or pull the latest changes: $ cd src $ git pull
  15. Setup: 3 Install dependencies: $ cd src $ pip install

    -r requirements.txt
  16. Setup: 4 Start up the app: $ python manage.py runserver

  17. Find a Partner

  18. Injection

  19. Injection Attacks • When an application sends untrusted data to

    an interpreter • Can result in data loss/corruption, lack of accountability, denial of access • Can lead to complete host takeover
  20. Who can you trust?

  21. Trust No One • External users • Internal users •

  22. Attack Vectors • GET parameters • POST parameters • PATH_INFO

    • Some HTTP headers: Cookie, Host • Uploaded Files
  23. Possible Consequences • Creation of malicious SQL (or other queries)

    • Accessing private files on disk • Arbitrary code execution
  24. Real-World Examples • Sony Playstation Network • Ruby on Rails

    • HBGary • MySQL • Many, many others…
  25. SQL Injection • Unescaped user input causes the premature end

    of a SQL query and allows a malicious query to be executed... """ select * from users where username='%s'; """ • http://localhost:8000/injection/sql
  26. Accessing Private Files • File system access + unvalidated user

    input allows attackers to navigate the file system • http://localhost:8000/injection/file- access
  27. Arbitrary Code Execution • Unsafe input is dynamically evaluated or

    executed • http://localhost:8000/injection/code- execution
  28. Prevention • Validate ALL user input • Sign cookies, don’t

    accept if signature is bogus/missing • Use ORMs or bind variables when talking to the database • Don’t use eval or exec, beware of pickle, user-supplied YAML, etc.
  29. Django Advice • Make sure data types for your model

    are tight • Use Forms instead of ModelForms for stronger validation • Make new validators as needed for your application • Make sure your URL regexes for dynamic URLs are tight
  30. Django Advice • Use the ORM when you can •

    When you can’t, use extreme caution! • Use bind variables/parameters • No string concatenation/formatting of anything that came from the client
  31. Without the ORM # If it's a basic select: MyModel.objects.raw("SELECT

    ... WHERE foo = %s", params={'foo': ...}) # If it's more complicated: from django.db import connection cursor = connection.cursor() cursor.execute("UPDATE bar set bar = 1 WHERE foo < %s",  [foo]) row = cursor.fetchall()
  32. Flask Advice • Use Flask-WTF to validate form input •

    Use SQLAlchemy • Bind variables if you don’t
  33. Broken Authentication & Session Management

  34. Broken Auth & Session Management • Attacker uses leaks or

    flaws in authentication or session management to impersonate users • Roll-your-own solutions contribute to the difficulty of finding these flaws
  35. Possible Consequences • Compromised user accounts • Compromised administrative accounts

    • Unauthorized use of privileged functionality
  36. Prevention • Hash or encrypt passwords • Don’t let credentials

    be easily overwritten • Don’t put session IDs in URLs • Allow session IDs to timeout/log out • Rotate session IDs after successful login • TLS connections for passwords, session IDs
  37. Django Advice • Use django.contrib.auth • Consider https://github.com/yourlabs/ django-session-security middleware

    for timing out sessions • We’ll talk about transport layer security later on...
  38. Flask Advice • Use flask-security • Read https://pythonhosted.org/Flask- Security/ •

    Avoid overuse of cookies for storing session state
  39. Cross-Site Scripting (XSS)

  40. XSS Attacks • Cross-Site Scripting (XSS) • The most prevalent

    web app security flaw • App includes user-supplied data in content sent to the browser without properly validating or sanitizing it
  41. XSS Attacks • Stored: injected code permanently stored in database,

    message forum, comment, etc. • Reflected: injected code in live request to server, reflected back in error message or search result • DOM: injected code in browser DOM environment that causes scripts to run in unexpected ways (eg, reading from URL)
  42. Possible Consequences • Execute scripts in a victim’s browser •

    Hijack sessions • Deface sites • Insert hostile content • Redirect users • Hijack browser (install malware)
  43. Most Often Seen... • Places where user-created text is displayed

    to other users (comments, messages) • Form inputs where value is populated with user-supplied data • Script tags where user-supplied data is populated into script variables
  44. Text Real-World Example • http://es.pn/Z0jnoi

  45. XSS in Dynamic URLs • Part of the URL path

    is variable, isn’t validated, and gets included into the page: http://example.com/stuff/{$CATEGORY} • http://localhost:8000/cross-site- scripting/path-matching/your-path- here
  46. XSS in Query String Parameters • Unvalidated user input from

    a query string parameter is included in the page: http://example.com/?search={$TEXT} • http://localhost:8000/cross-site- scripting/query-params?qs=awesome
  47. XSS in Form Fields • The value part of an

    input is prematurely terminated, allowing Javascript to be injected into or adjacent to the element: <input … value="{$TEXT}"> • http://localhost:8000/cross-site- scripting/form-field
  48. Can you trust the database?

  49. Prevention • Escape all untrusted data based on the HTML

    context the data will be placed into • Whitelist input validation • Consider auto-sanitization libraries for rich content (eg, OWASP’s AntiSamy) • Update your parents’/in-laws’ browsers!
  50. Django Advice • Be careful with the safe filter, django.utils.safestring,

    etc. • Use form.as_p, form.as_table, form.as_ul when displaying a form in a template • Be careful with your own template tags; django.utils.html.escape is your friend!
  51. django.utils.html cleaned = escape(unsafe_value) cleaned = escapejs(unsafe_value) cleaned = strip_tags(unsafe_value)

    cleaned = remove_tags(unsafe_value, ['script', ...])
  52. Flask Advice • Don’t disable autoescaping • Be very careful

    with anything you bless via Markup objects, the safe filter, or blocks where autoescape is disabled
  53. Insecure Direct Object References

  54. Insecure Direct Object Reference • Expose a reference to an

    internal implementation object without verifying authorization • Attacker changes URL, GET/POST parameters, cookies
  55. Possible Consequences • Compromise of all data that can be

    referenced by the vulnerable parameter • Unless the namespace is sparse, an attacker can easily access all available data of that type
  56. Exercises • Manipulate parameters in the URL to access data

    that doesn’t belong to you • http://localhost:8000/direct-object- references
  57. Prevention • Implement access controls on any direct references to

    restricted resources • Implement per-user or per-session indirect object references • This can be as much about URL design as about access control!
  58. Django + Flask • Lock down views: • Use Django’s

    permissions architecture • Use Flask-Security or Flask-Login • Customize Django queryset for looking up objects that involve user ownership
  59. Custom Queryset # In models.py... class ThingyManager(models.Manager): def for_user(self, user):

    return self.get_query_set().filter(user=user) class Thingy(models.Model): objects = ThingyManager() # In views.py... class ThingyUpdateView(UpdateView): def get_queryset(self): return Thingy.objects.for_user( self.request.user)
  60. Security Misconfiguration

  61. Security Misconfiguration • Insecure application settings • Unpatched flaws •

    Unused pages
  62. Possible Consequences • Unauthorized access to some system data or

    functionality • Potential complete system compromise
  63. Exercises • Demos and discussion • http://localhost:8000/misconfiguration

  64. Text This Really Happens! • Patreon compromised via exposed Werkzeug

    Debugger • https://labs.detectify.com/2015/10/02/ how-patreon-got-hacked-publicly- exposed-werkzeug-debugger/
  65. None
  66. None
  67. None
  68. Prevention • Have a repeatable hardening process • Have a

    process for keeping on top of updates and patches • Architecture that provides secure separation between components • Periodic scans and audits
  69. Django Advice • Don’t run in debug mode in production

    • Keep your SECRET_KEY secret! • Keep Python code out of webserver’s root • Don’t run admin publicly • Don’t use the built-in admin for normal user admin tasks
  70. Flask Advice • Read http://flask.pocoo.org/docs/ security • Set app.debug =

    False to turn off debugging
  71. Gateway to Social Engineering?

  72. Sensitive Data Exposure

  73. Sensitive Data Exposure • Failure to properly protect credit cards,

    tax IDs, authentication credentials, etc. • Sensitive data deserves extra protection such as encryption at rest or in transit, special precautions when exchanged with the browser
  74. Insecure Cryptographic Storage • Not encrypting worthy data • Unsafe

    key generation & storage, failure to rotate keys • Weak algorithms • Weak or unsalted hashes
  75. Insufficient Transport Layer Protection • May not authenticate, encrypt, and

    protect the confidentiality and integrity of sensitive network traffic • May use weak algorithms • May use expired or invalid certificates • May use certificates incorrectly
  76. Possible Consequences • Compromise of all data that should have

    been encrypted • This can be highly sensitive information: credentials, credit cards, personal data, health records, etc.
  77. Possible Consequences • Expose individual users’ data • Account theft

    • Compromise an admin account?! • Poor SSL setup can facilitate phishing and man-in-the-middle attacks
  78. Attack Vectors • Attacker monitors network traffic of your users

    • Maybe in public places (Starbucks, conference wi-fi, etc.) • Maybe back end connections • Maybe inside your network (!!!)
  79. http://cdn.ttgtmedia.com/digitalguide/images/Misc/WiresharkSS3_lg.png

  80. http://echeng.com/journal/images/misc/firesheep.png

  81. Prevention • Encrypt sensitive data at rest • Encrypt offsite

    backups; manage keys separately • Use strong standard algorithms, strong keys • Hash passwords with strong standard algorithm & use appropriate salt • Protect passwords & keys from unauthorized access
  82. Prevention • Require SSL for all sensitive pages; redirect non-SSL

    requests to SSL • Set the “secure” flag on sensitive cookies • Use only strong SSL algorithms • Ensure your cert is valid, not expired, not revoked, and matches your domain • SSL/encryption on the back end too
  83. Django Advice • Use django.contrib.auth for proper password salting and

    hashing • Use bcrypt; see https://docs.djangoproject.com/en/ 1.8/topics/auth/passwords/ • Require SSL in Apache or Nginx • Require SSL using middleware: • Configure Django SecurityMiddleware–new in Django 1.8! • http://django-secure.readthedocs.org/en/v0.1.2/ • https://github.com/rdegges/django-sslify
  84. Secure Cookies # In your settings.py... SESSION_COOKIE_SECURE = True CSRF_COOKIE_SECURE

    = True
  85. Flask Advice • Salt passwords using werkzeug.security: • http://flask.pocoo.org/snippets/54/ •

    Require SSL: • https://github.com/kennethreitz/flask-sslify • https://github.com/jacobian/wsgi-sslify • Use bcrypt: https://pythonhosted.org/ passlib/
  86. Missing Function Level Access Control

  87. Missing Function Level Access Control • Application doesn’t protect its

    functions properly • Misconfiguration • Forgot proper code checks
  88. Attack Vectors • Authorized user changes a URL or parameter

    to a privileged function • Anonymous users could access private functions that aren’t protected
  89. Possible Consequences • Compromised user accounts • Compromised administrative accounts

    • Unauthorized use of privileged functionality
  90. Exercises • Manipulate the URL to access privileged functionality •

    http://localhost:8000/missing-access- control
  91. Prevention • Consider every page; public or private? • If

    authentication is required, make sure that checks are in place • If additional authorization is required, make sure that checks are in place • Deny all by default; explicitly grant access to users or roles
  92. Django + Flask • Lock down views: • Use Django’s

    permissions architecture • Use Flask-Security or Flask-Login • Don’t use Django’s built-in admin for normal user admin tasks
  93. Cross-Site Request Forgery

  94. CSRF Attacks • Cross-Site Request Forgery (CSRF) • Attacker tricks

    victim into submitting forged HTTP requests • Attack succeeds if user is authorized/ authenticated
  95. Attack Vectors • Image tags • Cross-Site Scripting (XSS) •

    Fake buttons • Phishing forms • Other techniques
  96. Possible Consequences • Cause victim to change any data the

    victim is allowed to change • Cause victim to perform any function the victim is authorized to use • Impact varies based on victim’s role • Think of some possibilities...
  97. Real-World Examples • Facebook: http://amolnaik4.blogspot.com/ 2012/08/facebook-csrf-worth- usd-5000.html • Google/Gmail: http://cryptogasm.com/2012/02/does-

  98. What if... http://example.com/transferFunds?amount=…&destinationAccount=…

  99. What if... <img src="http://example.com/transferFunds?amount=1500& destinationAccount=attackersAcct#" width="0" height="0" />

  100. CSRF via Image • Craft an “image” link that triggers

    some site functionality • http://localhost:8000/csrf/image
  101. CSRF via Form Post • Create an innocuous-looking form that

    POSTs to a vulnerable location • http://localhost:8000/csrf/third-party- site
  102. Prevention • Don’t “do” things on a GET • Include

    a unique token in a hidden field (often used in concert with a cookie) • Validate token to make sure the request is from on-site • Avoid putting the token into a query string
  103. Django Advice • Don’t change the built-in settings! • Do

    use the CSRF middleware and template tag in forms • Be VERY CAREFUL about deactivating it (csrf_exempt decorator) • Be careful about APIs (Tastypie, oauth); http://codrspace.com/vote539/csrf- protection-in-django-tastypie/
  104. Flask Advice Various CSRF solutions... • DIY/naïve: http://flask.pocoo.org/snippets/3/ • Flask-WTF:

    http://flask-wtf.readthedocs.org/ en/latest/csrf.html • Flask-SeaSurf: https://flask- seasurf.readthedocs.org/en/latest/ • Flask-csrf: http://sjl.bitbucket.org/flask-csrf/
  105. Using Known Vulnerable Components

  106. Components  with Known Vulnerabilities • Libraries, frameworks, and other

    modules almost always run with full privilege • Hard to stay up to date on everything • Do you even know all the components in use, let alone their versions? • Components with known problems can be identified & exploited with automated tools
  107. Attack Vectors • Attacker identifies a weak component through scanning

    or manual analysis • Customize exploit as needed • More difficult the deeper the component is in the application
  108. Possible Consequences • Full range of weaknesses are possible •

    Impact could be minimal, or... • Complete host takeover! • Data compromise!
  109. None
  110. None
  111. None
  112. None
  113. None
  114. Prevention • Don’t use components you don’t write (unrealistic) •

    Keep components up to date • Identify all components and versions • Monitor security of these components
  115. Python Advice • Use pip to find old packages: pip

    list --outdated • Use requires.io to monitor dependencies
  116. Django + Flask • Keep an eye on the mailing

    lists: • https://groups.google.com/group/django- announce • http://flask.pocoo.org/mailinglist • Follow @djangoproject on Twitter
  117. Unvalidated Redirects & Forwards

  118. Redirection Abuse • Attacker tricks user into visiting a URL

    that redirects or forwards the request without validating the redirect location • Users prone to click because the link is to a legitimate site
  119. Possible Consequences • Install malware • Phishing/information disclosure • Bypass

    access controls
  120. External Redirection • Use a redirection URL to redirect to

    an external location • http://localhost:8000/redirects-and- forwards/redirects
  121. Forwards • Manipulate a forward parameter to gain access to

    privileged functionality • http://localhost:8000/redirects-and- forwards/forwards
  122. Prevention • Don’t use redirects or forwards • Don’t involve

    user-supplied data to build the redirect location • Ensure the supplied value is valid and authorized for the user
  123. Django Advice • Use django.utils.http.is_safe_url to check redirect URLs •

    Used by django.contrib.auth internally • Consider wrapping is_safe_url if you have to allow other off-domain URLs
  124. Checking Redirects from django.shortcuts import redirect from django.utils.http import is_safe_url

    def my_view(request): ... url = 'http://www.example.com/foo/bar' if is_safe_url(url, host='www.example.com'): return redirect(url) else: ...
  125. Allowing Multiple Safe Hosts from django.utils.http import is_safe_url def is_whitelisted_url(url,

    hosts): for host in hosts: if is_safe_url(url, host=host): return True return False >>> url = 'http://us.pycon.org' >>> whitelist = ['us.pycon.org', 'pycon.org', ...] >>> is_whitelisted_url(url, whitelist) True
  126. Flask Advice • Redirect back: http://flask.pocoo.org/ snippets/62/ • Redirect back,

    more selectively with whitelist, using cookies for previous URL: http://flask.pocoo.org/snippets/120/ • Can modify these approaches to suit, as with the Django example
  127. Who here has vulnerable apps?

  128. Who is ready to do something about it?

  129. Parting Thoughts

  130. Think Like a Bad Guy

  131. Don’t Stop at Ten

  132. Constant Change

  133. Think Positive

  134. Links • http://www.owasp.org • https://www.owasp.org/index.php/ Category:OWASP_Top_Ten_Project • https://docs.djangoproject.com/en/dev/ topics/security/ •

    http://flask.pocoo.org/docs/security • https://github.com/mpirnat/lets-be-bad-guys
  135. Contact Me Mike Pirnat http://mike.pirnat.com @mpirnat
