  1. Fundamentals of React Native
    Mustafa Berkay Mutlu
    31.05.2017

    View Slide

  2. What is React Native
    React is a framework created by Facebook for data driven web interfaces.
    The key point with React Native is that it aims to primarily bring the power of the React programming
    model to mobile app development. React Native is like React, but it uses native components instead of
    web components as building blocks.
    ● Started as Facebook’s internal hackathon project, in the summer of 2013
    ● The first public preview was in January of 2015 at React.js Con.
    ● Supportted minimum SDK versions: Android 4.1 (API 16) and iOS 8.0

    View Slide

  3. Github Stats

    View Slide

  4. Who's using React Native
    ● Facebook (iOS & Android)
    ● Facebook Ads Manager (iOS &
    Android)
    ● F8 (iOS & Android)
    ● Instagram (iOS & Android)
    ● AirBnb (iOS & Android)
    ● Walmart (iOS & Android)
    ● Tesla (iOS & Android)
    ● Baidu Mobile (iOS & Android)
    ● Bloomberg (iOS & Android)
    ● Vogue (iOS)
    ● li.st (Android)
    ● Discord (iOS)
    ● Gyroscope (iOS)
    ● Delivery.com (iOS & Android)
    ● Flare by GoDaddy (iOS & Android)
    ● SoundCloud Pulse (iOS)

    View Slide

  5. What You’ll Need to Start
    Android
    ● Node
    ● Python2
    ● Java 8
    ● Android Studio
    ● Android Emulator
    iOS
    ● Node
    ● Watchman
    ● Xcode
    ● iOS Simulator

    View Slide

  6. IDE
    The recommended IDE is Atom, with a
    plugin on top of it, Nuclide, which adds
    support for React Native development
    and for its recommended static analysis
    tool Flow.
    Also: Windows is not supported.

    View Slide

  7. Debugging
    The Nuclide Debugger provides many capabilities
    allowing you to have a productive debug loop,
    including inspection, watches, setting breakpoints,
    step in/over/out, etc.
    ● Build upon Chrome Developer Tools
    ● (For me) far behind the native development
    IDEs

    View Slide

  8. Hot Reloading
    Hot Reloading is similar in concept to
    Instant Run on Android. Every time a
    source file was saved, the changes were
    deployed immediately on the device where
    the app was running, thus greatly expediting
    the feedback loop.

    View Slide

  9. Native Coding
    There are certain features that cannot be implemented solely in JavaScript, native code is needed for:
    ● push notifications
    ● deep linking
    ● native UI components that need to be exposed to React
    Overall approximately 80% of the code is shared between iOS and Android and written in JavaScript.

    View Slide

  10. Misconceptions
    No.
    The JavaScript communicates with native components (Java on Android, Objective C on iOS).
    The communication occurs through the so-called "bridge". If at any time you feel that this communication
    slows things down too much, you can choose to implement the Javascript functionality in Java or
    Objective C in order to run purely native. In this case, you are writing directly in native code, so there's no
    Javascript to native compilation.
    Does the JS code compiled to native code?

    View Slide

  11. Misconceptions
    No.
    The JavasScript runs in a JavaScript Virtual Machine.
    Does the JS runs in a WebView?

    View Slide

  12. Misconceptions
    Just use’em!
    You don’t have to wait for someone to write a React Native wrapper around platform API’s.
    What if I want to use the platform’s latest API’s?

    View Slide

  13. How Does It Work?

    View Slide

  14. How Does It Work (contd.)
    Main UI thread
    JavaScript Core thread
    A native background thread

    View Slide

  15. How Does It Work?

    View Slide

  16. React & React Native
    React
    import React from 'react';
    class HelloWorld extends React.Component {
    render() {
    return (


    Hello World


    );
    }
    }
    React Native
    import React from 'react';
    import {
    View,
    Text
    } from 'react-native';
    class HelloWorld extends React.Component {
    render() {
    return (


    Hello World


    );
    }
    }

    View Slide

  17. Styles
    const styles = StyleSheet.create({
    container: {
    flex: 1,
    justifyContent: 'center',
    alignItems: 'center',
    },
    message: {
    fontSize: 28,
    fontColor: '#222222',
    },
    });
    import React from 'react';
    import {
    View,
    Text,
    StyleSheet
    } from 'react-native';
    class HelloWorld extends React.Component {
    render() {
    return (


    Hello World


    );
    }
    }

    View Slide

  18. Props
    Properties (or Props for short) used for
    passing data to components.
    ● Immutable
    ● To use it, refer the this.props inside
    the render function.
    class Greeting extends Component {
    render() {
    return (
    Hello { this.props.name }!
    );
    }
    }
    export default class LotsOfGreetings extends Component {
    render() {
    return (




    );
    }
    }

    View Slide

  19. ● Initialize in component constructor
    ● Update it using setState
    ● You can access previous state inside
    the setState function
    ● Unlike Props, State is mutable
    ● Each of the prop and state change
    triggers a complete re-render of the
    component
    State
    export default class MyContainerComponent extends
    Component {
    constructor() {
    super()
    this.state = {
    myText: 'Lorem ipsum dolor sit amet.'
    }
    }
    render() {
    return (

    { this.state.myText }

    );
    }
    }

    View Slide

  20. Native Modules
    Sometimes an app needs access to a platform API that React Native doesn't have a corresponding
    module for yet. Maybe you want to reuse some existing Java code without having to reimplement it in
    JavaScript. It is possible to write real native code and have access to the full power of the platform.

    View Slide

  21. Native Modules
    1. Write a Java class that extends ReactContextBaseJavaModule
    2. Override getName() method to return unique name
    3. (Optional) override getConstants()
    4. Add your native methods and annotate them with @ReactMethod
    5. Register your module inside your ReactPackage class
    6. Access your native method from JS using the name you defined in getName()

    View Slide

  22. Native Modules
    public class ToastModule extends
    ReactContextBaseJavaModule {
    private static final String DURATION_SHORT_KEY =
    "SHORT";
    private static final String DURATION_LONG_KEY =
    "LONG";
    public ToastModule(ReactApplicationContext
    reactContext) {
    super(reactContext);
    }
    @Override
    public String getName() {
    return "ToastAndroid";
    }
    @Override
    public Map getConstants() {
    final Map constants = new
    HashMap<>();
    constants.put(DURATION_SHORT_KEY,
    Toast.LENGTH_SHORT);
    constants.put(DURATION_LONG_KEY,
    Toast.LENGTH_LONG);
    return constants;
    }
    @ReactMethod
    public void show(String message, int duration) {
    Toast.makeText(getReactApplicationContext(),
    message, duration).show();
    }
    }

    View Slide

  23. Native Modules
    'use strict';
    /**
    * This exposes the native ToastAndroid module as a JS module. This has a
    * function 'show' which takes the following parameters:
    *
    * 1. String message: A string with the text to toast
    * 2. int duration: The duration of the toast. May be ToastAndroid.SHORT or
    * ToastAndroid.LONG
    */
    import { NativeModules } from 'react-native';
    module.exports = NativeModules.ToastAndroid;
    import ToastAndroid from './ToastAndroid';
    ToastAndroid.show('Awesome', ToastAndroid.SHORT);

    View Slide

  24. Native Modules
    @ReactMethod
    public void measureLayout(
    int tag,
    int ancestorTag,
    Callback errorCallback,
    Callback successCallback) {
    try {
    measureLayout(tag, ancestorTag, mMeasureBuffer);
    float relativeX = PixelUtil.toDIPFromPixel(mMeasureBuffer[0]);
    float relativeY = PixelUtil.toDIPFromPixel(mMeasureBuffer[1]);
    float width = PixelUtil.toDIPFromPixel(mMeasureBuffer[2]);
    float height = PixelUtil.toDIPFromPixel(mMeasureBuffer[3]);
    successCallback.invoke(relativeX, relativeY, width, height);
    } catch (IllegalViewOperationException e) {
    errorCallback.invoke(e.getMessage());
    }
    }
    UIManager.measureLayout(
    100,
    100,
    (msg) => {
    console.log(msg);
    },
    (x, y, width, height) => {
    console.log(x + ':' + y + ':' + width + ':' +
    height);
    }
    );

    View Slide

  25. React Navigation
    React Navigation is a navigation library
    that can deliver 60 fps animations and
    utilize native components to deliver a
    great look and feel.
    React Native Stack

    View Slide

  26. React-Navigation (contd.)
    BasicApp.js
    const BasicApp = StackNavigator({
    Main: {screen: MainScreen},
    Profile: {screen: ProfileScreen},
    });
    MainScreen.js
    class MainScreen extends React.Component {
    static navigationOptions = {
    title: 'Welcome',
    };
    render() {
    const { navigate } = this.props.navigation;
    return (
    title="Go to Jane's profile"
    onPress={() =>
    navigate('Profile', { name: 'Jane' })}
    />
    );
    }
    }
    ProfileScreen.js
    class ProfileScreen extends React.Component {
    static navigationOptions = ({navigation}) => ({
    title: navigation.state.params.name,
    });
    render() {
    const { goBack } = this.props.navigation;
    return (
    title="Go back"
    onPress={() => goBack()}
    />
    );
    }
    }

    View Slide

  27. React Native Stack
    Redux
    Redux is a predictable state container for JavaScript apps. It lets us manage the application state by using
    an immutable datastore.
    ● Might be overkill for simple apps

    View Slide

  28. React Native Stack
    CodePush
    CodePush lets you push code to your device and release an update without the work of putting the app
    on stores.
    Allowing your app to update without deploying to the app store, Code Push allows you to change the
    UI/UX, business logic fix bugs, load hot-fixes.
    ● Cannot push any code touching the native side of React Native
    ● Rollback support
    ● Supported by iOS 8+ and Android 4.1+

    View Slide

  29. React Native Stack
    Flow
    Flow is a static type checker for your JavaScript code. It does a lot of work to make you more productive.
    Making you code faster, smarter, more confidently, and to a bigger scale. Flow checks your code for
    errors through static type annotations.
    ● Open Source and maintained by Facebook

    View Slide

  30. Pros
    Code Reuse
    The list below shows the percentage of code shared between the apps for some of the Instagram
    products, which could be used as a proxy to measure how we managed to improve developer velocity:
    ● Post Promote: 99%
    ● SMS Captcha Checkpoint: 97%
    ● Comment Moderation: 85%
    ● Lead Gen Ads: 87%
    ● Push Notification Settings: 92%

    View Slide

  31. Pros
    Deployment
    One of the main advantages of React Native is the ability to push quick bug fixes over-the-air, bypassing
    app stores, which means the React Native JavaScript bundle will be hosted on a server and retrieved by
    the client directly, similar to how the web works.
    Tools like Microsoft CodePush can be used to map bundles to the correct app versions. But supporting
    multiple versions of the app at the same time is an overhead that should be considered when
    deciding to use React Native.

    View Slide

  32. Pros
    Active Development of React Native
    React Native is developed and maintained by Facebook. It has 2 weeks of release cycle and under heavy
    development. The open source community is fantastic about developing and releasing new features and
    performance tweaks.
    But upgrading your React Native version tends to be a massive pain, especially if you have a platform
    built around React Native.

    View Slide

  33. Cons
    Differences between iOS and Android
    There are enough inconsistencies between the functionality of React Native on iOS and on Android to
    make it tricky to support both platforms.
    For example, the style property “overflow” is supported on iOS but not Android. In the React Native
    documentation you can see many properties and features marked as “Android only” or “iOS only”.

    View Slide

  34. Cons
    Development and debugging
    React Native code behaves differently in debug mode vs regular mode due to the fact that React Native
    utilizes a different JavaScript engine for each of these two modes.
    When a bug is particular to regular mode, it can naturally be hard to debug because it’s irreproducible in
    debug mode.

    View Slide

  35. Cons
    Nuclide
    React Native’s offical IDE Nuclide can be considered fallen behind when we think the features the native
    IDEs offering.

    View Slide

  36. Cons
    Uncertain Roadmap and Tight Coupling
    An app built upon the React Native is very dependent to the platform. If Facebook stops maintaining
    React Native, your app’s development will stop and you will be considering a React Native replacement
    for your app.
    Facebook hasn’t made any long-term commitments to maintaining React Native for a sustained period of
    time.

    View Slide

  37. Cons
    Dependencies
    React Native has a total of 648 dependencies. Your app is built on more than 600 people’s sustained
    efforts.
    This is also a pitfall: you depend on 648 volunteers to keep maintaining their library for the lifetime of your
    app, without any formal commitment.
    Will their licenses stay compatible with your software? Hopefully.

    View Slide

  38. What Others Said About React Native
    “We found that a good use case for React Native can be found in applications that need short time
    support, for example an app for a one-shot event like a concert or a conference.
    However after our month-long investigation we can definitively say that React Native is not a mature or
    stable platform yet. For this reason, we think that React Native is not ready to be used in a long-lasting
    supported application. React Native seems to be suitable for apps with simple UI, simple animations, and
    not long life or performance-critical apps.”
    - Novoda Blog, July 5th 2016

    View Slide

  39. What Others Said About React Native
    “React Native enables quick prototyping and a very high initial velocity. Basic features are relatively easy
    to implement. If needed, they can be extended with native code and native views, and also integrate well
    with other view controllers.
    But with all the pros, there are some cons, too. It’s natural that JavaScript code is not as efficient for
    calculation-intensive tasks, and there is an overhead when JavaScript is controlling native elements.
    JavaScript has a single dedicated device thread, while native code is free to use whatever threads it
    wants. In performance, React Native stays behind an optimized native application.”
    - DevBridge Group, April 28th 2016

    View Slide

  40. Thank You
    Any questions?

    View Slide

  41. References
    ● A brief history of React Native
    ● React Native Docs
    ● Why I'm not a React Native Developer
    ● React Native at Airbnb
    ● React Native at Instagram
    ● React Native: Is it the end of native development?
    ● React-Native Stack 2017

    View Slide
