Ohio Linux Fest 2013: Provisioning VMs Quickly with Vagrant and CFEngine

713a34ab9c2701e2479a25d4d68f58b6?s=47 Nick Anderson
September 13, 2013

Ohio Linux Fest 2013: Provisioning VMs Quickly with Vagrant and CFEngine

During this hands-on tutorial you will learn how to quickly provision local test/development/demo environments using Vagrant and Virtualbox. will cover provisioning and configuring machines quickly using Vagrant and CFEngine. You will learn how Vagrant and Virtualbox can be used to bring up local development/test/demo environments. You will also learn how CFEngine can be leveraged to automate configuration of the environment after it has been initialized. You will take away a multi-vm test environment managed by CFEngine.

This tutorial targets technical people who need repeatable test environments and are comfortable using the Linux command-line. These environments can speed developer on-boarding, play a role in continuous integration, or just provide quick sandboxes for experimentation. No previous knowledge of Vagrant or CFEngine is required.

Attendees should bring a laptop with at least 10G of available disk space (SSD strongly recommended, but not required), and have current versions of Vagrant and Virtualbox installed.

713a34ab9c2701e2479a25d4d68f58b6?s=128

Nick Anderson

September 13, 2013
Tweet

More Decks by Nick Anderson

Other Decks in Technology

Transcript

  1. www.cfengine.com Vagrant & CFEngine Ohio Linux Fest 2013

  2. Before we get started Is everyone in the right place?

    Has everyone installed Virtualbox 4.2.16 or later? VirtualBox --help | grep VirtualBox Has everyone installed Vagrant 1.2.7 or later? vagrant --version
  3. Get to know each other Hi, I'm Nick SysAdmin >

    10 Years Work at CFEngine Live in Lawrence, KS Twitter: @cmdln_ IRC: nickanderson Blog: http://www.cmdln.org Who are you? What do you do? Have you used Vagrant? Have you used CFEngine? Why did you choose this session and what do you hope to get from it?
  4. 9/13/13 What is Vagrant? Tool to make working with development

    environments easy. Create, configure, destroy lightweight, reproducible, and portable environments. • Created by Mitchell Hashimoto • @mitchelh • http://www.vagrantup.com
  5. 9/13/13 Provides common environment Designers Developers Operations QA

  6. 9/13/13 Portable • VirtualBox • AWS • VMware • More

    • https://github.com/mitchellh/vagrant/wiki/Available-Vagrant-Plugins
  7. 9/13/13 How can it help? Developer on-boarding Quickly provision/decommission test

    environments in repeatable fashion Bug Validation Continuous Integration Ad-hoc Demos
  8. 9/13/13 So what's it made of?

  9. 9/13/13 Vagrantfile • Describe the type of machine(s) required for

    a project • Syntax of Vagrantfile is Ruby, but knowledge of the Ruby language is not necessary. It's mostly simple variable assignment. Vagrant.configure("2") do |config| # All Vagrant configuration is done here. The most common configuration # options are documented and commented below. For a complete reference, # please see the online documentation at vagrantup.com. # Every Vagrant virtual environment requires a box to build off of. config.vm.box = "centos-5.x-i386_nickanderson_201304271927" end
  10. 9/13/13 CFEngine Provisioner: Currently Undocumented • am_policy_hub • extra_agent_args –

    Extra arguments to pass to cf-agent executions • classes – Additional classes to define when running cf-agent • deb_repo_file – The apt repository configuration file to use for configuring the repository containing the CFEngine packages • deb_repo_line – The line that specifys the repository to use for CFEngine packages • files_path – Directory to copy on top of the default masterfiles • force_bootstrap – If true, bootstrap the host even if it has been bootstrapped before • install – Install CFEngine package from repository • mode – “bootstrap” or “single_run”, determines whether CFEngine will be bootstrapped or just executed once on the host • policy_server_address • repo_gpg_key_url – http location of GPG key used for checking package signatures • run_file – Standalone CFEngine policy file to upload and execute • upload_path – Path to upload run_file • yum_repo_file – The yum repository file to use when configuring the repository containing CFEngine packages • yum_repo_url – The url of the repository containing the CFEngine packages • package_name – The cfengine package name to install
  11. 9/13/13 CFEngine Provisioner: Example Use

  12. 9/13/13 Boxes • Predefined operating system install • Provider specific

    • http://www.vagrantbox.es • Use veewee or packer.io (build your own automatically) – Kickstart/preseed, postinstall scripts
  13. 9/13/13 Automagic • Ssh automatic port forwards • Shared project

    folder /vagrant
  14. 9/13/13 Useful Plugin • vagrant-vbguest automatically installs the host's VirtualBox

    Guest Additions on the guest system. • vagrant plugin install vagrant-vbguest • https://github.com/dotless-de/vagrant -vbguest
  15. 9/13/13 Getting started • vagrant box list • vagrant box

    add • vagrant init • vagrant status • vagrant up • vagrant up • vagrant status • vagrant ssh – vagrant ssh node • vagrant destroy
  16. 9/13/13 Test it out • Import vagrant basebox – Locate

    CFEngine_Training.box in resources/veewee – vagrant box add CFEngine_Training CFEngine_training.box • Create a new empty directory • vagrant init CFEngine_Training • vagrant up • vagrant ssh • vagrant destroy -f
  17. 9/13/13 Daily Use vagrant up vagrant {destroy, halt, suspend} !-2

  18. 9/13/13 This is fantastic!

  19. 9/13/13 Build base boxes for all the things!

  20. None
  21. Black Hole

  22. 9/13/13 Automating Vagrant Provisioning • Ansible • CFEngine • Chef

    • Puppet • Salt Stack • Shell Scripts • MixnMatch!
  23. 9/13/13 CFEngine • IT infrastructure automation, compliance, and knowledge management

    framework • Opensource and Commercial Software • Originally written by Mark Burgess • @markburgess_osl • http://www.cfengine.com
  24. 9/13/13 CFEngine History • First released in 1993 • CFEngine

    2 released in 1998, self healing computer immunology. Added machine learning and anomaly detection. • 2003 Promise Theory work began • 2008 CFEngine 3 released. Integrates knowledge management and discovery mechanisms.
  25. 9/13/13 CFEngine Properties • Small

  26. 9/13/13 CFEngine Properties • Small • Secure (http://web.nvd.nist.gov/view/vuln/search )

  27. 9/13/13 CFEngine Properties • Small • Secure (http://web.nvd.nist.gov/view/vuln/search ) •

    Portable
  28. 9/13/13 CFEngine Properties • Small • Secure (http://web.nvd.nist.gov/view/vuln/search ) •

    Portable • Resilient
  29. 9/13/13 CFEngine Properties • Small • Secure (http://web.nvd.nist.gov/view/vuln/search ) •

    Portable • Resilient • Declarative
  30. 9/13/13 Bootstrap a test environment

  31. 9/13/13 CFEngine Demo Time • Lets try some community contributed

    policy
  32. 9/13/13 cf-sketch • Log in to your policy hub, locate

    the design center repository and access the cf-sketch shell – vagrant ssh hub – sudo -i – cd /vagrant/resources/design-center/tools/cf-sketch – ./cf-sketch.pl
  33. 9/13/13 Configure Timezones • search time • info -v tzconfig

    • install System::tzconfig • define paramset System::tzconfig – Name: NO_Oslo_TZ – Timezone: Europe/Oslo – Zoneinfo: /usr/share/zoneinfo
  34. 9/13/13 Configure Timezones • search time • install System::tzconfig •

    define paramset System::tzconfig – Name: NO_Oslo_TZ – Timezone: Europe/Oslo – Zoneinfo: /usr/share/zoneinfo
  35. 9/13/13 Configure Timezones Cont. • search time • install System::tzconfig

    • define paramset System::tzconfig – Name: US_Central_TZ – Timezone: US/Central – Zoneinfo: /usr/share/zoneinfo
  36. 9/13/13 Activate and Deploy Timezone Configuration • activate System::tzconfig NO_Oslo_TZ

    hub • activate System::tzconfig US_Central_TZ node001 • deploy
  37. 9/13/13 Editor War! • I prefer vim, and it's fun

    to mess with the emacs people • services/editor_war.cf
  38. 9/13/13 Wage War • Remove Disallowed Packages – vagrant ssh

    hub – watch rpm -q emacs-nox – Uncomment disallowed_packages to activate policy. Watch it get fixed. • Install Required Packages – watch rpm -q vim-enhanced – Uncomment required_packages to activate policy
  39. 9/13/13 More Nodes! • Increase nodes to 2 in Vagrantfile

    • vagrant up • vagrant ssh node00{1,2}
  40. 9/13/13 The Books • Learning CFEngine 3 – Diego Zamboni

    • Vagrant Up and Running – Mitchell Hashimoto
  41. 9/13/13 Questions/Discussion?

  42. 9/13/13 Thank You!
