angular/router

The New Angular Router

Transcript

1. angular/router The New Angular Router
2. Hi, I’m Nikas Front end dev @ Wix.com/app-market @nikaspran github/nikaspran nikas.praninskas.com
3. The next 45 minutes of your life Prior art What is the New Angular Router? Migration Current state of affairs
4. Disclaimer: everything is Work In Progress
5. Prior art
6. What ARE frogs Routers?
7. Deep linking is awesome share information know at a glance contextualize bookmark The ability to
8. Don’t break the back button The back button is free and obvious It is very easy to be annoying if you break navigation
9. Structure for your app Forces you to modularize Makes apps easy to understand
10. ngRoute The default Angular 1 routing solution
11. ngRoute - very simple .config(function($routeProvider){ $routeProvider .when('/user/:id', { templateUrl: 'user.html', controller: 'UserCtrl', resolve: {...} }) .when('/user/:id/edit', { templateUrl: 'userEdit.html', controller: 'UserEditCtrl' }); }); One view per app One URL, one view <a href="user/123"></a> <a href="user/123/edit"></a> <div ng-view></div>
12. Good things come to those who wait .when('/user/:id', { ..., resolve: { user: function($q) { var data = $q.defer(); //get user data from API return data.promise; } } }) Inject into controller from configuration Waits until promises resolve
13. Simple, but too simple Difficult to do things like modals sidebars deep routes parallel views complex apps
14. UI Router The de facto Angular 1 routing solution
15. UI Router - much more powerful <a ui-sref="layout.user"></a> <a ui-sref="layout.user.edit( {id: 123})"></a> <div ui-view="sidebar"></div> <div ui-view="content"></div> State based routing .config(function($stateProvider){ $stateProvider .state('layout', { abstract: true, templateUrl: 'layout.html' }) .state('layout.user', { views: { sidebar: { templateUrl: 'sidebar.html', controller: 'SidebarCtrl', resolve: {...} }, content: {...} } }) });
16. States are intuitive States describe architecture Not everything has to have a URL Easy to link to parts of your application
17. Lots of utility <a ui-sref="user.edit({id: 123})"></a> <a href="/base/user/123"></a>
18. <ui-sref-active> $state.is() $state.go() $state.href() $state.includes() Lots of utility …
19. Customizability is very important and UI Router does a pretty good job: christopherthielen/ui-router-extras onEnter, onExit, $stateChange*, ...
20. …up to a point Do something complex enough and you start fighting the router
21. Something complex enough
22. Same URL, different background state
23. Multiple paths that preserve history 1. Open App Market 2. Click App icon Use direct link to App (eg. via social) wix.com/app-market/:appName/overview
24. we spent way too much time fighting our tools at the time, we did a fork still not obvious how to do it all
25. Angular 2 is coming Can we do better with a clean slate?
26. Introducing The New Angular Router
27. Introducing The New Angular Router
28. Introducing Component Router
29. Goals
30. Be customizable… Let people do complex interesting surprising amazing things
31. …but have great defaults Make it obvious intuitive quick easy to learn and use
32. Multiple views /foo/bar foo bar foo bar parallel nested OR
33. State-like reverse routing Automatically deep link to components <a router-link="user" router-params="{id: 123}"></a> <a href="./user/123"></a>
34. State-like reverse routing Link to multiple components at once sidebar content mainPage <a router-link="mainPage"></a>
35. Thought experiment: The router is one of the most important parts of an application
36. So… If it is designed for Angular 2
37. If it is designed for Angular 2 but also works with Angular 1
38. If it is designed for Angular 2 but also works with Angular 1 We have a migration plan! ng1 ng2
39. Proposed migration scenario ng1 ng1 ng1 ng1 ng1 ng1 Angular 1 app
40. Proposed migration scenario ng1 ng1 ng1 ng2 ng1 ng1
41. Proposed migration scenario ng1 ng2 ng1 ng2 ng2 ng1
42. Proposed migration scenario ng2 ng2 ng2 ng2 ng2 ng2 Angular 2 app
43. ま よ た ね ぃ み む ょ じ を り ぉ ね ぼ り ぉ け ば や わ ゎ お ら ゆ ろ り ぉ け ば や わ ゎ お ら ゆ じ ゃ で り ぐ き な ゕ ゟ た ょ を こ で ぷ お じ ぁ だ ど ぬ す っ ら び ぅ ぬ だ ざ ま よ た ね ぃ み む ょ じ を り ぉ ね ぼ び ぃ ぅ や こ そ ぶ や あ ゝ ぼ ゆ ぺ み ひ じ え わ ぶ す ぞ ぷ ゑ っ ぞ ほ だ Show me the code already ま よ た ね ぃ み む ょ じ を り ぉ ね ぼ ろ り ぉ け ば や わ ゎ お ら ゆ ほ ぞ ぁ ろ り ぉ け ば や わ ゎ お び ぃ ぅ や こ そ ぶ や あ ゝ ぼ ゆ ぺ み ひ じ え わ ぶ す ぞ ぷ ゑ っ ぞ ほ だ ま よ た ね ぃ み む ょ じ を ろ り ぉ け ば や わ ゎ お ら ゆ ほ び ぃ ぅ や こ そ ぶ や あ ゝ ぼ ゆ ぺ み ひ じ え わ ぶ す ぞ ぷ ゑ っ ま よ た ね ぃ み む ょ じ を り ぉ ね ぼ ろ り ぉ け ば や わ ゎ お ら ゆ ほ ぞ ぁ ろ り ぉ け ば や わ ゎ び ぃ ぅ や こ そ ぶ や あ ゝ ぼ ゆ ぺ み ぶ す ぞ ぷ ゑ っ ぞ ほ だ り ぉ け ば や わ ゎ お ら ゆ ほ ぞ ぁ ろ り ぉ け ば や わ ゎ お ぉ け ば や わ ゎ お ら ゆ ほ ろ り ぉ け ば や わ ゎ お ら ゆ け ば や わ ゎ お ら ゆ ほ ぞ ぁ ろ り ぉ け ば や わ ゎ お ら ゆ を こ で ぷ お じ ぁ だ ど う え を こ で ぷ お じ ぁ だ ど う え ぬ す っ ら び ぅ ぬ だ ざ ぬ す っ ら び ぅ ぬ だ ざ ぬ す っ ら び ぅ ぬ だ ざ ぶ す ぞ ぷ ゑ っ ぞ ほ だ ゝ ぼ ゆ ぺ み あ ゝ ぼ ゆ ぺ み あ ゝ ぼ ゆ ぺ み あ ゝ ぼ ゆ ぺ み ぬ す っ ら び ぅ ぬ す っ ら び ぅ ぬ だ ざ ぬ す っ ら び ぅ ぬ だ ざ ぬ す っ ら び ぅ ぬ だ ざ ぬ す っ ら び ぅ ぬ あ ゝ ぼ ゆ ぺ み ゝ ぼ ゆ ぺ み ま よ た ね び ぃ ぅ や こ そ ぶ ま よ た ね ぃ み
44. Angular 2.x import {ListComponent} from './list'; import {EditComponent} from './edit'; @Component({...}) @View({template: '...'}) @RouteConfig([ {path: '/', component: ListComponent}, {path: '/edit/:id', component: EditComponent} ]) class AppComponent() { ... }
45. Angular 1.x $componentMapper .setCtrlNameMapping(comp => comp + 'Ctrl'); $componentMapper .setTemplateMapping(comp => comp + '.html'); AppController.$routeConfig([ {path: '/', component: 'list'}, {path: '/edit/:id', component: 'edit'} ]); function AppController() { ... }
46. Static configuration {path: '/', component: 'list'}, {path: '/edit/:id', component: 'edit'} {path: '/', component: ListComponent}, {path: '/edit/:id', component: EditComponent} ng2 ng1 === easy to port
47. Component Router Components Outlets Instructions Pipeline
48. Component Router Components Outlets Instructions Pipeline
49. So what’s a component anyway? Template Controller Router
50. Template - ng2 @View({template: '...'}) @View({templateUrl: '...'})
51. Template - ng1 $componentMapper .setTemplateMapping(function (compName) { return templatePath; }); ./components/my-comp/my-comp.html myComp Uses component convention by default: Customize as you want:
52. “Controller” - ng2 class MyComp() {...}
53. Controller - ng1 $componentMapper .setCtrlNameMapping(function (compName) { return controllerName; }); Adds “Controller” by default: Customize as you want: MyCompController myComp
54. Router Each component can have a child router Child routers manage their sub-URLs
55. You can release it as an artifact They can mount and use it SO,if you build an amazing component with deep linking
56. Router - ng2 @RouteConfig([ {path: '/', redirectTo: '/main'}, {path: '/main', component: MainComp}, {path: '/other', components: {}, as: 'other'} ])
57. Router - ng1 function MainController($router) { $router.config([...]); } function MainController() {...}; MainController.$routeConfig([...]);
58. Component Router Components Outlets Instructions Pipeline
59. Outlet - think ui-view <div ng-outlet></div> <div ng-outlet="left"></div> {path: '/', components: { default: 'posts', left: 'users' }}
60. Component Router Components Outlets Instructions Pipeline
61. Instruction Holds all the context for a transition: Outlets, path, parameters, ...
62. Component Router Components Outlets Instructions Pipeline
63. Pipeline - it’s middleware Takes Instruction Transforms it ..with side effects $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep
64. E.g.: pipeline in Angular 1.x $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep Pipeline
65. Let’s ask the router to go somewhere $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep router.navigate('users/123')
66. Router generates the instruction $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep router.navigate('users/123') recognize(): instruction matchedUrl component router children: Instruction[]
67. Once more unto the pipeline! $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep matchedUrl component router children: Instruction[]
68. $setupRoutersStep $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep matchedUrl component router children: Instruction[] Add child instruction routers
69. $initLocalsStep $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep matchedUrl component router children: Instruction[] locals Add locals: $router, $routeParams
70. $runCanDeactivateHookStep $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep matchedUrl component router children: Instruction[] locals Visit old outlets; run canDeactivate()
71. $runCanActivateHookStep $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep matchedUrl component router children: Instruction[] locals Visit new outlets; run canActivate()
72. $loadTemplatesStep $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep matchedUrl component router children: Instruction[] locals template Load templates, add to instruction
73. $activateStep $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep matchedUrl component router children: Instruction[] locals template Recursively activate outlets (ctrl, tmpl, ...)
74. Final step… Update $location: http://someHost/base/users/123 … and done!
75. Pipeline - it’s customizable $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep Up to you
76. E.g.: let’s add resolve $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep resolveStep
77. Create our step factory .factory('resolveStep', function ($q, $injector) { return function resolve(instruction) { }; })
78. Recurse over instructions .factory('resolveStep', function ($q, $injector) { return function resolve(instruction) { var promises = []; return instruction.router.traverseInstruction( instruction, queueResolves ).then(function () { return $q.all(promises); }); }; })
79. Get config from instruction .factory('resolveStep', function ($q, $injector) { return function resolve(instruction) { var promises = []; function queueResolves(instruction) { var cfg = getResolveConfigFrom(instruction); } return instruction.router.traverseInstruction( instruction, queueResolves ).then(function () { return $q.all(promises); }); }; })
80. Queue the resolution .factory('resolveStep', function ($q, $injector) { return function resolve(instruction) { var promises = []; function queueResolves(instruction) { var cfg = getResolveConfigFrom(instruction); var resolve = $q.when($injector.invoke(cfg.value)); promises.push(resolve.then(function (resolved) { })); } return instruction.router.traverseInstruction( instruction, queueResolves ).then(function () { return $q.all(promises); }); }; })
81. Add it to locals .factory('resolveStep', function ($q, $injector) { return function resolve(instruction) { var promises = []; function queueResolves(instruction) { var cfg = getResolveConfigFrom(instruction); var resolve = $q.when($injector.invoke(cfg.value)); promises.push(resolve.then(function (resolved) { instruction.locals[cfg.key] = resolved; })); } return instruction.router.traverseInstruction( instruction, queueResolves ).then(function () { return $q.all(promises); }); }; })
82. Insert it into the pipeline .config(function ($pipelineProvider) { var steps = $pipelineProvider.steps; var atPosition = steps.indexOf('$runCanDeactivateHookStep) + 1; //insert resolveStep after $runCanDeactivateHookStep steps.splice(atPosition, 0, 'resolveStep'); $pipelineProvider.config(steps); })
83. End result $setupRoutersStep $initLocalsStep $runCanDeactivateHookStep $runCanActivateHookStep $loadTemplatesStep $activateStep resolveStep Part of the pipeline Called on every transition
84. > implications Standardized extension Make it suit your app Publish and prosper
85. Component Router Components Outlets Instructions Pipeline Other “stuff”
86. Sticky components This is how it currently works Under consideration and desirable
87. Dynamic loading Add new routes @ runtime: function SomeController($router) { $router.config([...]); }
88. Recursive components Not sure how practical, but why not
89. Migration
90. ng1 + ngComponentRouter ng2 ng 1.5 + new router Some things we know
91. And some we don’t ng1 + X ng1 + ngComponentRouter ng2 ng 1.5 + new router ?
92. ngRoute is too simple to worry about
93. Migration strategies from UI Router are a TODO item But one can dream…
94. Multi-components are sort of like states $router.config([{ as: 'category', path: '/:category', components: { sidebar: 'Sidebar', content: 'Category' } }]); $stateProvider .state('category', { url: '/:category', views: { sidebar: { templateUrl: '...', controller: '...' }, content: { templateUrl: '...', controller: '...' } } }); ui-router compRouter
95. Directives are sort of similar <a router-link="user" router-params="{id: 123}"></a> <a ui-sref="user({id: 123})"></a> ~== ui-router compRouter
96. What about what’s missing? Well…
97. Pipeline! e.g. we saw how to add resolve we can fake $stateChangeEvents someone write an adapter? :)
98. How can we prepare? Use similar conventions Component-like architecture Component-like file structure
99. Write unit tests UI Router configuration is testable Write now, then verify migration later http://nikas.praninskas.com/test-ui-router Component Router should be even easier
100. Current $state of affairs //TODO: draw something totally awesome like robots and lasers and stuff and maybe a cat
101. Documentation!
102. Read the source, Luke: github.com/angular/router
103. github.com/angular/angular …no wait, now it’s:
104. but only temporarily…
105. Codebase is a bit of a mess: 1.x has not worked for over a month everything in ng2 repo until build is stable still working out core issues (i.e. reverse routing)
106. When? Originally slated for 1.4
107. …but probably not anymore: :(
108. June-July? (my somewhat educated guess)
109. In place of a summary Designed from the ground up; New ideas for the future; Lessons learned from the past; Not yet ready.
110. Thank you! nikas.praninskas.com github/nikaspran @nikaspran
