HAMMER.JS add touch gestures to your page.
Multi-Touch redefined User Interface
Gestures http://www.lukew.com/ff/entry.asp?1071
where we are
where we are and we need more gestures
Gestures But…what egg use?
Demo Time Back off! I’m going to ZhuangBi!!!
What can we do with gestures?
What can we do with gestures? ✓ Carousel ✓
Slider ✓ ImagePreview ✓ Drag&Drop&Sort ✓ ListView ✓ SideNavigation ✓ Games ✓ And More…
• touchstart/gesturestart • touchmove/gesturechange • touchend/gestureend •
touchcancel Touch & Gesture Event • e.touches • e.targetTouches • e.changedTouches • e.rotation/scale • e.pageX(Y)/clientX(Y)
• touchstart/gesturestart • touchmove/gesturechange • touchend/gestureend •
touchcancel Touch & Gesture Event • e.touches • e.targetTouches • e.changedTouches • e.rotation/scale • e.pageX(Y)/clientX(Y)
None
Why HammerJs?
Why HammerJs?
Why HammerJs? ✓ Small (3.96kb) ✓ Multiple (Tap, Pan,
Rotate…) ✓ Compatible (touch, mouse, pointerEvents) ✓ Extensible (easy to define new gesture) ✓ Easy to Learn (just like iOS gestures)
Browser Support ✓ Compatible
How to use var hm = new Hammer(element, options); hm.on('tap',
function(e) { console.log(e); }); hm.on('swipe', function(e) { console.log(e.velocity); console.log(e.direction); }); hm.on('pan', function(e) { var x = e.deltaX + 'px', y = e.deltaY + 'px'; element.style.tranform = 'translate3d(' + x + ',' + y + ',0)'; }); ✓ Multiple
More Control var hm = new Hammer.Manager(element); hm.add( new Hammer.Rotate({
pointers: 2 }) ); hm.add( new Hammer.Tap({ event: 'tripleTap', taps: 3 }) ); hm.on('rotate', function(e) { console.log(e.rotation); }); hm.on('tripleTap', function(e) { console.log(e.tapCount); }); ✓ Extensible
HammerJs vs S.EventTarget var hm = new Hammer.Manager(); hm.add( new
Hammer.Tap({}) ); hm.on('tap', callback); hm.off('tap', callback); hm.emit('tap', data); var et = S.EventTarget; et.publish('select', {}); et.on('select', callback); et.detach('select', callback); et.fire('tap', data);
Recognizer ✓ Extensible
Recognizer HammerJs iOS Gesture ✓ Easy to Learn
GestureRecognizer
Recognizer Types
Recognizer States
recognizeWith var hm = new Hammer.Manager(element); hm.add( new Hammer.Rotate() );
hm.add( new Hammer.Pinch() ); hm.get('pinch').recognizeWith(hm.get('rotate'));
requireFailure var hm = new Hammer.Manager(element); var singleTap = new
Hammer.Tap({ event: 'singletap' }); var doubleTap = new Hammer.Tap({event: 'doubletap', taps: 2 }); hm.add([singleTap, doubleTap]); doubleTap.recognizeWith(singleTap); singleTap.requireFailure(doubleTap);
touch-action https://cdn.rawgit.com/hammerjs/hammer.js/master/tests/manual/touchaction.html
Hammer Inside Manager Input Recognizers TouchAction touch, mouse, pen auto,
pan-x, pan-y manipulation pan, pinch, press rotate, swipe, tap compute update add update init addEvent preventDefault emit
None
what’s next
✓ mpi/carousel ✓ mpi/slider ✓ mpi/image-‐preview ✓
mpi/drag-‐drop ✓ mpi/list-‐view ✓ mpi/side-‐nav ✓ act/xx-‐game ✓ and more… what’s next
Join us!!!
Join us!!!
Join us!!!
• http://hammerjs.github.io/ • http://www.lukew.com/ff/entry.asp?1071 • https://developer.apple.com/library/ios/documentation/EventHandling/Conceptual/ EventHandlingiPhoneOS/GestureRecognizer_basics/ GestureRecognizer_basics.html • http://www.google.com/design/spec/patterns/gestures.html#gestures-touch-
mechanics • http://www.windowsphone.com/en-us/how-to/wp7/start/gestures-flick-pan-and- stretch references
None
THE END.
