RigaDevDays 2017. Pipeline as Code with Jenkins

The Butler is still young. Pipeline as Code with Jenkins
Oleg Nenashev (@oleg_nenashev) CloudBees, Inc.

© 2017 CloudBees, Inc. All Rights Reserved. 2 #RigaDevDays 2017
About me @oleg_nenashev oleg-nenashev LibreCores project St. Petersburg Polytechnic University Jenkins meetups

Oleg’s “Hall of Shame”(c) • Plugins • Jenkins Core • Remoting • Windows Service Wrapper

"Having temperature of 38°C is still better than 38°F” © My motto for this conference: https://www.pinterest.com/browserling/ weekly-programming-comic/

TODO: Oil Pipelines Image Pipelines?

Today’s Pipelines… ØJenkins Pipelines

Do you use Jenkins? About you

1. Most popular CI/CD tool in the world 2. It’s open source 3. Big community 4. Commercial support vendors 5. … Who is Mr. Jenkins? https://jenkins.io

Jenkins – Software CI/CD Server Do you agree?

Jenkins – Software CI/CD Server – Automation Framework Disclaimer: IMHO

Система Docs Plugins Configs Infra- structure Samples Demos Automation system Infra- structure Infra- structure • Framework • Orchestrator

Do you use Jenkins Pipelines? About you

Today’s Pipelines… ØWhy Jenkins Pipeline? ØWhat’s HOT in Jenkins Pipeline?
ØTBD: My Adopter Experience Disclaimer: • This presentation reflects the author’s personal opinion • It may differ from CloudBees official position

• Jenkins 101 • Configuration As Code101 • Pipeline 201 • Added-value Pipeline features in CloudBees Jenkins Enterprise What is NOT in the talk?

Frameworks are flexible… • Build chains & deps (aka pipelines) • Resource management • Environment/Tool management • …

Approach: Using “classic” Job types: • Freestyle, Matrix, JobDSL, … Classic Approaches Keywords: • Script steps to run the logic • Custom Tools Plugin to manage tools • Throttle Concurrent Builds and Lockable Resources to dispatch access to hardware • Naginator Plugin to restart builds on-demand • Parameterized Trigger / Copy artifacts to parallelize tests and to collect results JUC2015/London https://jenkins.io/solutions/embedded/

Classic Approaches Spaghetti Automation • Many job dependencies • Difficult build flow tracking • Complex configurations • Duplication • Expensive maintenance

ü Store together with the project ü Modify together with the project ü Test together with the project … as code? Automation

Система Docs Plugins Configs Infra- structure Samples Demos Automation Framework Vision Infra- structure Infra- structure SCM Infrastructure as Code Configuration as Code Documentation as Code Pipeline Libraries Pipelines

Configuration as Code in Jenkins Job Configuration System Configuration

Jenkins Configuration… as Code External Tools Jenkins CLI and REST API python- jenkins jenkins- client (java) Configuration Management systems Puppet, Ansible, Chef Docker Solutions within Jenkins project Groovy Hooks Scriptler Plugin SCM Sync Configurati on Unstable Just examples… Unsafe/ blocked

What about Jenkins Jobs?

Configuration as Code for jobs Job DSL Job Builder Plugin Jenkins Pipeline Pipeline is offered by default in Jenkins 2.0 … Groovy YAML Groovy

What is Jenkins Pipeline?

Jenkins Pipeline is a… 1. Groovy DSL for automatic flow description - defined in SCM (Jenkinsfile) - defined in Job configuration // Run on a node having the “my_fpga” label node("linux && ml509") { git url:"http://github.com/myorg/myproject.git" sh "make all" } http://bit.ly/pipeline-tutorial

Jenkins Pipeline is a… 1. Groovy DSL for automatic flow description 2. Item type Pipeline Job Multi-Branch Pipeline Organization Folder • GitHub • BitBucket* • …

Jenkins Pipeline is a… 1. Groovy DSL for automatic flow description 2. Item type 3. Pipeline as Code Ecosystem

Branch- Source, BlueOcean, ... 89 - explicit support 42 - Pipeline- specific Documentation Samples Development Tools Jenkins Pipeline Ecosystem Plugins:

Main features Independent from node/workspace Parallelization Stages Robustness

Example. CD for Jenkins IRC Bot def imageName = 'jenkinsciinfra/ircbot’ node('docker') { checkout scm def imageTag = findTag() stage('Build ircbot’) { withMavenEnv (["BUILD_NUMBER=${env.BUILD_NUMBER}:${commit}"]) { sh 'make bot' // Make invokes Maven }} stage ('Build & Deploy container’) { def img = docker.build("${imageName}:${imageTag}”) img.push() } } https://github.com/jenkins-infra/ircbot Docker Registry Server Jenkins SCM Puppet

More about Pipeline Features • http://bit.ly/pipeline-docs • http://bit.ly/pipeline-compatibility

Jenkins & Pipeline in 2017 UX is in focus

Jenkins & Pipeline in 2017 Ø Easy to use •
Blue Ocean • Integrations

Jenkins & Pipeline in 2017 Ø Easy to use Ø
Easy to start • Declarative Pipeline • Visual Pipeline Editor • Better docs pipeline { agent label:"linux" tools { maven ”M3" } stages { stage("build") { steps { sh 'mvn clean verify' } } } post { always { junit ”target/…/*.xml" } }

Jenkins & Pipeline in 2017 Ø Easy to use Ø
Easy to start Ø Easy to reuse • Libraries # Jenkinsfile buildPlugin()

What’s HOT? Blue Ocean

BlueOcean Pipeline Editor Plugin https://jenkins.io/doc/book/blueocean/pipeline-editor/ Edit & Commit from Web UI!

More Info • Docs: https://jenkins.io/doc/book/blueocean/ • Video: http://bit.ly/blueocean-kickoff

What’s HOT? Declarative Pipeline

Syntax sugar on the top of Pipeline • “pipeline { }” closure Common configuration sections • Easy to set up • More static checks • Less flexibility 42 Declarative Pipeline https://github.com/jenkinsci/pipeline- model-definition-plugin/wiki

43 Example. Declarative Pipeline pipeline { agent label:"generic-linux" tools { maven "Maven 3.3.9" jdk "Oracle JDK 8u40" } stages { stage("build") { steps { sh 'mvn clean install -Dmaven.test.failure.ignore=true' } } } post { always { junit "path/to/xml" } failure { mail to:"[email protected]", subject:"FAILURE:${currentBuild.name}", …} } }

When to use Declarative? Just starting with Jenkins • Migrating from declarative services Have good encapsulation in Libraries • Call them from stages, use other stuff as wrappers Simple use-case • E.g. “just run Maven/Make & handle errors”

Error Handling • IMHO: Pipeline is designed for Success Path scenarios When it “Just works” When it does not

Error Handling. Top-level Scripted Pipeline Declarative Pipeline Global try/catch() L When it does not…

Obstacles • Limited functionality compared to Scripted Pipeline • Cannot put Declarative Pipeline into library • Difficult to migrate to Scripted if required # Jenkinsfile buildPlugin()

What’s HOT? Library Management

Reusing code via libraries 2015 • load() command Early 2016 • Global Pipeline Library • Pipeline Remote Loader Plugin Late 2016 • Pipeline Shared Libraries • Library management • Support of @Grab – Pipeline libs can pull common Groovy libs Library Structure:

Pipeline Shared Libraries • Libs are located in SCM • Versioning • Scopes ▸System-wide ▸Folder ▸Job

Pipeline Library Definition [1/2]

Pipeline Library Definition [2/2]

Libraries in Scripted Pipeline com.mycorp.libs.make Jenkinsfile makeProject() makeProject() implementation - global variable com.mycorp.libs.coverity com.mycorp.libs.cppunit Globally-defined library, automatic update @Library() definition

Example. Explicit Import

Example. Implicit Import

buildPlugin()

buildPlugin(). How does it work?

buildPlugin(). How does it work? … Pure Pipeline DSL

/me as a Pipeline Adopter

Pipeline Early adoption It is working! * Image: http://devopsreactions.tumblr.com/post/151281670953/trying-the-first-prototype-good-enough

Lessons Learnt. Obstacles? • Missing integrations • Pipeline DSL !=
Groovy • Development Tools • Non-Success Path handling

Missing integration ØTools/plugins •http://bit.ly/pipeline-compatibility •Trusted pipeline libraries help much ØBuild Promotion (Promoted Builds, Release, …)

For a reason… Pipeline DSL is not Groovy

Reason 1. Context retention – CPS/NonCPS • No way to propagate any data • Solution - @NonCPS steps within the library steps

Reason 2. Script Security Script approval Groovy Sandbox Mode • Mandatory for Jenkinsfile from SCM • Mandatory for untrusted libs Limited access to Java API • Script approvals by admins • Debug fun “Run & Fail & Approve & Rerun”

Pipeline. Dev Tools IDE Integration Unit Test Framework Static Analysis Library manager Debug tools Documen- tation Easy script deployment Freestyle => Pipeline Converter Good Not enough Missing

How do I work? Intellij IDEA Filesystem SCM Plugin (with patch) Disclaimer: There may be better ways • Syntax file • Built-in documentation Jenkins Test Instance Source Code (local .git repos) • Production System Snapshot • Custom Pipeline Library Settings • Repositories for libraries • Jenkinsfile repos

Getting the Syntax File

Filesystem SCM Plugin • Pending pull request: • https://github.com/jenkinsci/filesystem_scm-plugin/pull/2 Library definition in the test instance !!!

Pipeline Testing • No test framework offered by the Jenkins project • External project: https://github.com/lesfurets/JenkinsPipelineUnit “mvn verify” has been invoked… And the execution passed… For the source Jenkinsfile…

Error Handling When it “Just works” When it does not The interesting part… Failover, repeat

Error handling. Hardware failover for (def board : boards) { echo "trying board " + board; try { node(board) { checkout scm sh ‘./bin/run.sh’ // Call passed => DONE break; } } catch (Exception ex) { if (ex.message.contains ("exit code 255")) { // Fatal error fail("Test run failed") } } } ??? • Hard to extract error cause • Try/catch handling for every case • Cannot just use existing parsers • Build Failure Analyzer • Log Parser • Warnings • Try-catch blocks pollute the code • Hard to test

Error handling. Hardware failover Declarative Pipeline Encapsulation via Libraries Simple use-case Other • Exception try/catch • timeout() wrapper • Proper failover • Logic in @NonCPS

… simplifies small jobs and complex workflows … saves much time on system maintenance … is a programming language, high barrier to entry … lacks Dev Tools and some integrations Lessons learnt. Pipeline…

What I need? Dev Tools for Pipeline • IDE, Debugger, Test Tools Community Pipeline Libraries • Support common cases without plugins • Pipeline-only plugins work too Promotion engine for Pipeline • Ideally: Merge & Integrate Promoted Builds and Release plugins

Takeaways • Jenkins is not “CRON with Web UI” • Pipeline as Code is your friend • If you use Jenkins… •Try Jenkins Pipeline •Try Declarative Pipeline •Try BlueOcean

Thank you! Contacts: E-mail: [email protected] GitHub: oleg-nenashev Twitter: @oleg_nenashev

• CloudBees website • Website: https://www.cloudbees.com • Jenkins project • Website: https://jenkins.io • Meetup: https://www.meetup.com/Jenkins-online-meetup/ • Jenkins Pipeline • Tutorial: http://bit.ly/pipeline-tutorial • Compatibility: http://bit.ly/pipeline-compatibility • Examples: https://github.com/jenkinsci/pipeline-examples • Blue Ocean • https://jenkins.io//projects/blueocean/ Useful Links

Incoming Big Events Day Of Jenkins May 30 – Gothenburg, Jun 01 – Oslo Jenkins Community Day Jul 11 – Paris Jenkins World Aug 28-31 San Francisco

Thank you! Contacts: E-mail: [email protected] GitHub: oleg-nenashev Twitter: @oleg_nenashev
