[BRUG Minsk, May 2017] Action Cable. Making Better

Video: https://www.youtube.com/watch?v=D7TZH3_gh6M

Links:

- Action Cable PRs – https://github.com/rails/rails/pulls?q=is%3Aopen+is%3Apr+author%3Apalkan+label%3Aactioncable

- AnyCable – http://anycable.io

- LiteCable – https://github.com/palkan/litecable

- ACLI – https://github.com/palkan/acli

- Plezi – http://www.plezi.io

Transcript

1. View Slide

2. View Slide

3. Evil Martians


   View Slide

4. Evil Martians


   View Slide

5. What is
   Action Cable?


   View Slide

6. Action Cable
   RailsConf 2015 April, 21


   View Slide

7. Action Cable
   RailsConf 2015


   View Slide

8. Action Cable in a Nutshell
   Server
   Client
   WebSocket
   Client
   WebSocket
   stream C
   Broadcaster
   stream B
   stream A
   stream B
   channel X
   channel Y
   channel Z


   View Slide

9. Action Cable Channel
   class AnswersChannel < ApplicationCable::Channel
   def subscribed
   reject_subscription unless current_user.admin?
   end
   def follow(params)
   stream_from "questions/#{params['id']}"
   end
   end


   View Slide

10. The Good Parts


    View Slide

11. Good Parts
    • Easy configuration


    View Slide

12. Good Parts
    • Easy configuration
    • Application logic access through
    channels


    View Slide

13. Good Parts
    • Easy configuration
    • Application logic access through
    channels
    • JavaScript client that just works


    View Slide

14. Bad Parts?


    View Slide

15. Performance


    View Slide

16. Memory Cable


    View Slide

17. Memory Cable
    20k connections
    MB
    0
    375
    750
    1 125
    1 500
    1 875
    2 250
    2 625
    3 000
    Go Erlang ActionCable (2x) ActionCable (16x)


    View Slide

18. WebSocket Shootout


    View Slide

19. WebSocket Shootout
    Client
    Server
    broadcast
    to all
    message
    send message back


    View Slide

20. WebSocket Shootout
    Broadcast RTT
    0s
    1s
    2s
    3s
    4s
    5s
    6s
    7s
    8s
    9s
    10s
    Number of connections
    1000 2000 3000 4000 5000 6000 7000 8000 9000 10000
    Go Erlang ActionCable
    Running on AWS EC2 c3.4xlarge (16 vCPU, 30 GiB RAM)


    View Slide

21. WebSocket Shootout


    View Slide

22. Testing


    View Slide

23. Testing Cable


    View Slide

24. Extensibility


    View Slide

25. • Server Abstraction
    Extended Cable


    View Slide

26. • Server Abstraction
    • Protocol Extensions (e.g.
    serialization, authentication,
    presence feature)
    Extended Cable


    View Slide

27. Other
    • Fallbacks / Transport
    • Rails-ness
    • Consistency


    View Slide

28. Consistency


    View Slide

29. Consistency?


    View Slide

30. How to Make it
    Better?


    View Slide

31. Testing Cable
    , 2016


    View Slide

32. Testing Cable
    class ServiceTest < ActionCable::TestCase
    def test_assert_transmited_message
    Service.broadcast 'messages', 'hi!'
    assert_broadcast_on('messages', text: 'hi!')
    end
    def test_assert_broadcast_on_again
    assert_broadcast_on('messages','h!') do
    Service.broadcast 'messages', text: 'h!'
    end
    end
    end


    View Slide

33. Testing Cable
    class ChannelTest < ActionCable::Channel::TestCase
    def test_subscribed_with_room_number
    subscribe room_number: 1
    assert subscription.confirmed?
    assert "chat_1", streams.last
    end
    def test_perform_speak
    subscribe room_number: 1
    perform :speak, message: "Hello"
    assert_equal "Hello",
    transmissions.last["message"]["text"]
    end
    end


    View Slide

34. PRs Cable


    View Slide

35. PRs Cable


    View Slide

36. AnyCable


    View Slide

37. View Slide

38. Server
    Channels
    Streams
    Client (Protocol)
    Action Cable AnyCable


    View Slide

39. Server
    Channels
    Streams
    Client (Protocol)
    Separation of Concerns
    Action Cable AnyCable


    View Slide

40. AnyCable


    View Slide

41. gRPC


    View Slide

42. gRPC =
    Google RPC


    View Slide

43. gRPC =
    Universal RPC
    Framework


    View Slide

44. gRPC =
    protobuf + HTTP/2


    View Slide

45. AnyCable Servers
    anycable-go
    erlycable


    View Slide

46. Memory Cable
    20k connections
    MB
    0
    500
    1 000
    1 500
    2 000
    2 500
    3 000
    3 500
    4 000
    anycable-go erlycable ActionCable


    View Slide

47. Action Cable CPU


    View Slide

48. anycable-go CPU


    View Slide

49. erlycable CPU


    View Slide

50. WebSocket Shootout
    Broadcast RTT
    0s
    1s
    2s
    3s
    4s
    5s
    6s
    7s
    8s
    9s
    10s
    Number of connections
    1000 2000 3000 4000 5000 6000 7000 8000 9000 10000
    ActionCable anycable-go erlycable
    Running on AWS EC2 c3.4xlarge (16 vCPU, 30 GiB RAM)


    View Slide

51. Compatibility
    Feature Status
    Connection Identifiers +
    Connection Request (cookies, params) +
    Disconnect Handling +
    Subscribe to channels +
    Parameterized subscriptions +
    Unsubscribe from channels +
    Subscription Instance Variables -
    Performing Channel Actions +
    Streaming +
    Custom stream callbacks -
    Broadcasting +


    View Slide

52. Action Cable Channel
    class ChatChannel < ApplicationCable::Channel
    def subscribed
    stream_from "chat_#{chat_id}" do |msg|
    if msg['sent_at'].present?
    delay = Time.now.to_f - msg['sent_at']
    logger.info "Message delay #{delay}s"
    end
    transmit msg
    end
    end
    end


    View Slide

53. PRs Cable


    View Slide

54. WebSocket Shootout
    Broadcast RTT
    0s
    1s
    2s
    3s
    4s
    5s
    6s
    7s
    8s
    9s
    10s
    Number of connections
    1000 2000 3000 4000 5000 6000 7000 8000 9000 10000
    ActionCable Patch 1
    Running on AWS EC2 c3.4xlarge (16 vCPU, 30 GiB RAM)


    View Slide

55. Where To
    anycable.io
    github.com/anycable
    twitter.com/any_cable
    gitter.im/anycable


    View Slide

56. PRs Cable


    View Slide

57. Server Adapter
    # config/application.rb


    # specify server adapter
    config.action_cable.server = :plezi
    # or
    config.action_cable.server = :any_cable


    View Slide

58. plezi.io
    github.com/boazsegev/iodine
    Plezi


    View Slide

59. LiteCable


    View Slide

60. • Rails-free Action Cable
    • No deps (even ActiveSupport)
    • Compatible with AnyCable
    LiteCable


    View Slide

61. LiteCable
    module Chat
    # ...
    class Channel < LiteCable::Channel::Base
    identifier :chat
    def subscribed
    stream_from "chat_#{chat_id}"
    end
    end
    end
    run Rack::Builder.new do
    map '/cable' do
    use LiteCable::Server::Middleware,
    connection_class: Chat::Connection
    run proc { |_| [200, {}, ['']] }
    end
    end


    View Slide

62. LiteCable
    github.com/palkan/litecable


    View Slide

63. • Testing Support PRs
    • AnyCable for Performance
    • LiteCable for non-Rails
    • ACLI for development/testing
    What We Have


    View Slide

64. • Action Cable CLI
    • mRuby
    • Download'n'Run
    ACLI


    View Slide

65. ACLI


    View Slide

66. What's Next?


    View Slide

67. History Stream
    class ChatChannel < ApplicationCable::Channel
    def subscribed
    stream_from "chat_#{id}",
    history: { time: 5.minutes }
    end
    end
    class ChatChannel < ApplicationCable::Channel
    def subscribed
    stream_from "chat_#{chat_id}",
    history: { size: 100 }
    end
    end


    View Slide

68. Presence
    class ChatChannel < ApplicationCable::Channel
    def subscribed
    stream_from "chat_#{id}",
    presence: { user_id: user_id }
    end
    end
    // js client
    cable.subscriptions.create(
    { channel: 'chat', id: roomId },
    {
    presenceUpdated: function(diff) { … }
    }
    )


    View Slide

69. cult of martians.com


    View Slide

70. Let's make Action Cable
    suck less!
    Vladimir Dementyev
    evilmartians.com
    @palkan
    @palkan_tula
