Ignite the Tour Paris: Running Docker containers on Azure: The ultimate overview

Transcript

1. Think ahead. Act now.
2. Think ahead. Act now. Pascal Naber @pascalnaber Running Docker containers on Azure: the ultimate overview
3. Azure Web App for Containers Azure Service Fabric (Mesh) Azure Batch Azure Red Hat OpenShift Azure Kubernetes Service (AKS) Azure Container Instances (ACI) Azure Container Registry (ACR) Run containers on Azure
4. Think ahead. Act now.
5. Think ahead. Act now. WHY I LIKE Containers
6. Think ahead. Act now. They are FAST
7. Think ahead. Act now. They are PORTABLE
8. Think ahead. Act now. They are ISOLATED
10. Think ahead. Act now. How HOT are containers actually?
11. https://insights.stackoverflow.com/survey/2019 2019 Developer Survey Nearly 90.000 developers
12. https://insights.stackoverflow.com/survey/2019 Nearly 90.000 developers 2019 Developer Survey
13. https://insights.stackoverflow.com/survey/2019 Nearly 90.000 developers 2019 Developer Survey
14. Azure Web App for Containers Azure Service Fabric (Mesh) Azure Batch Azure Red Hat OpenShift Azure Kubernetes Service (AKS) Azure Container Instances (ACI) Azure Container Registry (ACR) Run containers on Azure
15. Azure Web App for Containers Azure Service Fabric (Mesh) Azure Batch Azure Red Hat OpenShift Azure Kubernetes Service (AKS) Azure Container Instances (ACI) Azure Container Registry (ACR) Run containers on Azure
16. Think ahead. Act now. Azure Container Registry Private Container Image registry Based on Open Standard Helm Repo Geo replication ACR Tasks
17. Development Source code Build Pipeline Docker Images Docker Registry CI pipeline (Build) CD pipeline (Release) Development Staging Production Tag: 1.1 Staging Production Tag: 1.1 Azure Tag: 1.1 Tag: 1.1
18. Azure Web App for Containers Azure Service Fabric (Mesh) Azure Batch Azure Red Hat OpenShift Azure Kubernetes Service (AKS) Azure Container Instances (ACI) Azure Container Registry (ACR) Run containers on Azure
19. Backend process No UI Every hour, 5 minutes Project Rome v1:
20. Azure Web App for Containers Azure Service Fabric (Mesh) Azure Batch Azure Red Hat OpenShift Azure Kubernetes Service (AKS) Azure Container Instances (ACI) Azure Container Registry (ACR) Run containers on Azure
21. Azure Web App for Containers Azure Service Fabric (Mesh) Azure Batch Azure Red Hat OpenShift Azure Kubernetes Service (AKS) Azure Container Registry (ACR) Run containers on Azure Azure Container Instances (ACI)
22. Azure Container Instances (ACI) Pay for use Serverless containers Public or Private accessible For short lived workloads like Bursts Scheduled work From € 1.05 for 1 CPU with 1 GB for 24 hours To € 5.22 for 4 CPU with 14 GB for 24 hours
23. Think ahead. Act now. DEMO Azure Container Instances (ACI)
24. Project Rome Backend process No UI Every hour, 5 minutes Backend process & Front end With public available UI Run Continuously Over SSL with authentication Regularly new releases No downtime Auto scaling v2: v1:
25. Azure Container Instances (ACI) Pay for use Serverless containers Public or Private accessible 1 container instance only No High Availability No zero-downtime deployment No scale out Limited scale up No autoscaling No out of the box SSL support No cache for pulled containers Pay extra for Windows containers For short lived workloads like Bursts Scheduled work
26. Think ahead. Act now. Azure Service Fabric (Mesh) Azure Batch Azure Red Hat OpenShift Azure Kubernetes Service (AKS) Azure Container Registry (ACR) Azure Container Instances (ACI) Run containers on Azure Azure Web App for Containers
27. WebApp for Container Pay for Hostingplan as long as it exists Scale up Scale out Auto scaling Zero-downtime deployment SSL by default Authentication Identity Custom domains Hostingplan From € 3.59 for 1 CPU with 3.5 GB for 24 hours To € 14.37 for 4 CPU with 14 GB for 24 hours
28. WebApp for Container - Scaling
29. Think ahead. Act now. WebApp for Container - Scaling
30. WebApp for Container – Zero-downtime deployment Deployment slots webapp staging Release Pipeline production 1. deploy 3. swap 2. ready? Container Registry https://myapp.azurewebsites.net https://myapp-staging.azurewebsites.net
31. WebApp for Container != WebApp WebApp WebApp for Container
32. Think ahead. Act now. DEMO Azure Webapp for Container
33. Think ahead. Act now. Project Rome Level 7 Firewall for all traffic Lots of containers Better density of our resources Make use of some CNCF projects - Mesh: Istio - Logging: Prometheus, Jaeger - Service discovery: CoreDNS - Messaging: NATS v3: v2: Backend process & Front end With public available UI Run Continuously Over SSL with authentication Regularly new releases No downtime Auto scaling
34. Firewall Application Gateway & Firewall traffic https://myapp.azurewebsites.net
35. Firewall Application Gateway & Firewall vnet App Service Environment Certificate DevOps Agent Azure Container Instances traffic AKS https://myapp.azurewebsites.net
36. WebApp for Container Pay for Hostingplan as long as it exists Scale up Scale out Auto scaling Zero downtime deployment SSL by default Authentication Identity Custom domains Scaling out is slow No optimal use of resources No firewall possibility (yet) Limited logging possibilities No health check functionality (yet) Only support for port 80 & 443 Not suitable for lots of containers Not portable Cannot debug
37. Azure Service Fabric (Mesh) Azure Batch Azure Red Hat OpenShift Azure Container Registry (ACR) Azure Container Instances (ACI) Azure Web App for Containers Run containers on Azure Azure Kubernetes Service (AKS)
38. Kubernetes De facto standard container orchestrator Started by Google Since v1 Open Source by Large, rapidly growing ecosystem Declarative configuration
39. Google trends
40. Azure Kubernetes Service (AKS) Running containers at scale Scaling up & scaling out Autoscaling Zero downtime deployment High Availability Public & Private endpoints Health management Enormous ecosystem Portable SSL Support* Identity management* Keyvault integration*
41. Azure Kubernetes Service (AKS) master master master worker worker worker AKS 100% managed by Microsoft IaaS managed by Microsoft € 0 € … (VM pricing)
42. Azure resources for AKS MC_ignitetour_aksdemo_westeurope ignitetour
43. AKS master master master worker worker worker AKS 100% managed by Microsoft IaaS managed by Microsoft
44. AKS + ACI AKS 100% managed by Microsoft 100% managed by Microsoft worker master master master
45. Kubernetes - Ecosystem Kubernetes Ecosystem
46. Think ahead. Act now. DEMO Azure Kubernetes Service (AKS)
47. AKS as the Silver bullet Kubernetes created an ecosystem of expandable standards but this still needs configuration. For example: • Deployments • Network Policies • Role Based Access Controls • Pod Security Policies • Pod Priority and more... Common integration points can be different across cloud providers • Authentication • Logging • Metrics • Storage
48. Azure Kubernetes Service (AKS) Running containers at scale Scaling up & scaling out Autoscaling Zero downtime deployment High Availability Public & Private endpoints Health management Enormous ecosystem Portable SSL Support* Identity management* Keyvault integration* Authentication A lot of management for a couple of containers Steep learning curve Not all Azure functionality is mature (yet) • Network policies • Pod Security Policies No turnkey configuration
49. Think ahead. Act now. Azure Batch Azure Kubernetes Service (AKS) Azure Container Registry (ACR) Azure Container Instances (ACI) Azure Web App for Containers Azure Red Hat OpenShift Run containers on Azure Azure Service Fabric (Mesh)
50. Think ahead. Act now. Service Fabric Application platform providing rich programming models - Reliable services - Reliable actors - Reliable collections Service Fabric Resource Model Portable Run containers
51. Think ahead. Act now. Service Fabric powers Azure
52. Think ahead. Act now. Service Fabric Mesh Serverless Seamless integration with Azure Deploy & scale in seconds High availability Per second billing Not Portable Container only Responsibility You Azure Application Deployment Hardware OS Patching Runtime upgrades Micro-billing Capacity planning Network & Storage
53. Think ahead. Act now. container groups networks auto scale update policies volumes secrets ………. Atlas Serverless Container Platform Service Service Fabric Mesh Atlas ResourceProvider App service RP Azure functions RP ACI RP Future serverless multitenant Services App Package Functions definition App model Service Fabric Mesh - Evolution n AKS Virtual Nodes ACI API
54. Think ahead. Act now. Specification for building cloud native applications Agnostic application model Codename: Hydra By Microsoft and Alibaba Cloud Announced 16 October 2019 Inspired by Service Fabric Resource Model https://openappmodel.io/
55. Think ahead. Act now. Rudr Kubernetes implementation of
57. Azure Service Fabric (Mesh) Azure Batch Azure Kubernetes Service (AKS) Azure Container Registry (ACR) Azure Container Instances (ACI) Azure Web App for Containers Run containers on Azure Azure Red Hat OpenShift
58. Azure Red Hat OpenShift Based on, and extends Kubernetes No virtual machine operation or patching Enterprise minded Support from RedHat Build in: Small cluster - 1st year: 4.502,40 OpenShift Kubernetes (DIY) Container Registry Docker, Azure Container Registry Monitoring Prometheus Log aggregator EFK stack Certificate management cert-manager CI/CD Jenkins/Azure DevOps Authentication dex
59. Azure Service Fabric (Mesh) Azure Kubernetes Service (AKS) Azure Container Registry (ACR) Azure Container Instances (ACI) Azure Web App for Containers Azure Red Hat OpenShift Run containers on Azure Azure Batch
60. Azure Batch For large-scale parallel and high-performance computing (HPC) batch jobs Native imperative Batch Shipyard declarative yaml Task Task Task Compute node Compute node Compute node Azure Batch Job Pool Azure Storage https://github.com/Azure/batch-shipyard
61. pool.yaml job.yaml Azure Batch config.yaml credentials.yaml
62. Azure Web App for Containers Azure Service Fabric (Mesh) Azure Batch Azure Red Hat OpenShift Azure Kubernetes Service (AKS) Azure Container Instances (ACI) Azure Container Registry (ACR) Run containers on Azure
63. Think ahead. Act now. Pascal Naber Coding Azure Architect Xpirit Netherlands @pascalnaber http://pascalnaber.wordpress.com https://github.com/pascalnaber/ignitetourparis2019
