Ignite the Tour Johannesburg 2019 The Ultimate introduction to Kubernetes on Azure

Transcript

1. Think ahead. Act now.
2. Think ahead. Act now. Pascal Naber @pascalnaber The Ultimate Introduction to Kubernetes on Azure
3. Think ahead. Act now.
4. Think ahead. Act now. WHY I LIKE Containers
5. Think ahead. Act now. They are FAST
6. Think ahead. Act now. They are PORTABLE
7. Think ahead. Act now. They are ISOLATED
8. Moving to production Scaling, load balancing, fault tolerance
9. Scaling, Load balancing & Fault tolerance Server Frontend Backend
10. Scaling, Load balancing & Fault tolerance Server
11. Scaling, Load balancing & Fault tolerance Server Server Server Container orchestration
12. Server Scaling, Load balancing & Fault tolerance Server Server Container orchestration
13. Container orchestrators Cluster High Availability Hyper-Scale Hybrid Operations High Density Rolling Upgrades Stateful services Low Latency Fast startup & shutdown Container Orchestration & lifecycle management Replication & Failover Load balancing Self-healing Automated Rollback Health Monitoring Placement Constraints Microservices Service Fabric Service Fabric Mesh
14. Orchestrators cluster Node (Worker) Node (Worker) Master
15. Kubernetes Kubernetes cluster Node (Minion) Node (Minion) Master
16. Kubernetes architecture Master API Server Scheduler Controller Manager Node (Minion) etcd kubelet Kube- Proxy cAdvisor Pod Pod Pod Kubectl (CLI) Dashboard (UI) REST client (Code)
17. History of Kubernetes June 2014 First commit September 2014 July 2015 March 2018 Announced Kubernetes v1 CNCF 1st Graduate
18. Kubernetes k8s OOS Extensible Large, rapidly growing ecosystem Facilitates declarative configuration and automation Κυβερνήτης -- Greek: meaning helmsman or pilot 1 2 3 4 5 6 7 8
19. Hosting of Kubernetes Local Minikube Docker for Windows Docker for Mac Raspberry Pi Private datacenter Public Cloud GKE (26-8-2015) EKS (5-6-2018) ACS (19-4-2016) AKS (13-6-2018)
20. Think ahead. Act now. Partly managed Kubernetes Only pay for worker nodes Upgrades managed by Azure Workers are Managed IaaS Azure Kubernetes Service (AKS) Azure Kubernetes
21. Think ahead. Act now. Private preview Azure OpenShift Azure
22. Think ahead. Act now. Missing pieces? Deploy to Production
23. Install AKS ARM Ansible Terraform Portal
24. Install AKS using CLI ## Create resourcegroup az group create --name ignitetour --location eastus ## Create Kubernetes cluster az aks create -g aksdemo -n ignitetour --generate-ssh-keys ## Create Kubernetes cluster az aks create --resource-group ignitetour --name aksdemo --kubernetes-version 1.11.5 --node-vm-size Standard_DS2_v2 --node-count 3 --ssh-key-value "C:\repos\pascal\ssh\public.pub" --service-principal d6e55af7-17fc-4cf5-b140-8b37729da10e --client-secret 94bCIHcSuniCvjq9 --enable-addons http_application_routing
25. Azure resources for AKS ignitetour
26. Azure resources for AKS MC_ignitetour_aksdemo_eastus ignitetour
27. ## download & install kubectl az aks install-cli ## download credentials az aks get-credentials --resource-group ignitetour --name aksdemo ## Create clusterrolebinding to access the dashboard kubectl create clusterrolebinding kubernetes-dashboard -n kube-system --clusterrole=cluster-admin --serviceaccount=kube-system:kubernetes-dashboard Post Install steps
28. Deployment flow Create Docker Images Apply K8s deployments Push Docker Images to registry 1 2 3
29. Kubernetes concepts
30. Pod Group of 1 or more containers Shared Storage Shared Network Same IP-address Shared port-range Pod 10.0.0.1 Storage Pod 10.0.0.2 Storage Port 80 Port 8080 Port 80
31. leaderboard-api.yaml Pod Pod Pod Replica Set Deployment Label: backend Selector Label: backend Label: backend Label: backend Label: backend Selector Label: backend C:> kubectl apply –f leaderboard-api.yaml
32. C:> kubectl apply –f update.yaml Zero-downtime deployment Can be rolled back Rolling updates
33. C:> kubectl apply –f secret.yaml ## Create Secret to access Azure Container Registry kubectl create secret docker-registry clouddemoimages --docker-server=https://clouddemo.azurecr.io --docker-username=clouddemo --docker-password=kD98ddl$= --docker-email=pnaber@xpirit.com Secrets: Base64 encoded values Environment variables & Secrets
34. Health checks livenessProbe Indicates whether the Container is running Restart in case of failure Container: https://www.app-metrics.io/ HealthChecks library https://github.com/dotnet-architecture/HealthChecks readinessProbe Indicates whether the Container is ready to service requests No traffic is routed to the Pod C:> kubectl apply –f leaderboard-api.yaml
35. Resource Management requests: Minimum required resources limits: Capped resource usage 100m = 0.1 cpu 500m = 0.5 cpu 64Mi = 64 MB memory 128Mi = 128 MB memory C:> kubectl apply –f leaderboard-api.yaml
36. Horizontal Pod Autoscaler Required: Resource requests & limit Heapster Scaling based on 1 or multiple items CPU Memory Custom Metrics C:> kubectl apply –f leaderboard-api.yaml
37. Horizontal Pod Autoscaler Required: Resource requests & limit Heapster C:\kubectl get hpa NAME REFERENCE TARGETS MINPODS MAXPODS REPLICAS AGE autoscaler leaderboard-api 0% / 50% 1 10 1 9m C:\kubectl get hpa NAME REFERENCE TARGETS MINPODS MAXPODS REPLICAS AGE autoscaler leaderboard-api 218% / 50% 1 10 1 10m C:\kubectl get hpa NAME REFERENCE TARGETS MINPODS MAXPODS REPLICAS AGE autoscaler leaderboard-api 218% / 50% 1 10 4 10m C:\kubectl get hpa NAME REFERENCE TARGETS MINPODS MAXPODS REPLICAS AGE autoscaler leaderboard-api 44% / 50% 1 10 7 13m C:\kubectl get hpa NAME REFERENCE TARGETS MINPODS MAXPODS REPLICAS AGE autoscaler leaderboard-api 51% / 50% 1 10 6 21m
38. How to access the Pods? From inside and outside the cluster
39. Node 1 Pod Label: backend 10.0.0.2 Pod Label: backend 10.0.0.3 Node 0 Pod Label: backend 10.0.0.1 Node 2 Pod Label: backend 10.0.0.4 Pod Label: backend 10.0.0.5 Pods are mortal
40. Service Service Type: ClusterIP Selector Label: backend Node 1 Pod Label: backend 10.0.0.2 Node 0 Pod Label: backend 10.0.0.1 Node 2 Pod Label: backend 10.0.0.4 Pod Label: backend 10.0.0.5 192.168.0.1
41. Service Service Type: LoadBalancer Selector Label: backend Node 1 Pod Label: backend 10.0.0.2 Node 0 Pod Label: backend 10.0.0.1 Node 2 Pod Label: backend 10.0.0.4 Pod Label: backend 10.0.0.5 Public ip address: 37.17.208.21 192.168.0.2
42. Frontend Backend Pod Pod Pod Pod Pod Pod Pod Pod Service Type: ClusterIP Service Type: LoadBalancer Public ip address: 37.17.208.21 C:> kubectl apply –f leaderboard-service.yaml C:> kubectl apply –f gamingwebapp.yaml 192.168.0.2 192.168.0.1
43. Too many ip-addresses. Now what? I want to access all my services through the same ip-address
44. Ingress Pod 10.0.0.1 Pod 10.0.0.2 Pod 10.0.0.3 Service Type: ClusterIP Pod 10.0.0.4 Pod 10.0.0.5 Pod 10.0.0.6 Service Type: ClusterIP Pod 10.0.0.7 Pod 10.0.0.8 Pod 10.0.0.9 Service Type: ClusterIP Service Type: LoadBalancer Public ip address: 37.17.208.21 Pod quay.io/kubernetes-ingress-controller/ nginx-ingress-controller:0.15.0 Selector Label: ingresscontroller Label: ingresscontroller Ingress host: gaming. ignitetour.cf serviceName: gamingwebapp Ingress host: erp.ignitetour.cf serviceName: erpsvc Ingress host: www. ignitetour.cf/crm serviceName: crmsvc nginx.conf gaming. ignitetour.cf 10.0.0.1 10.0.0.2 10.0.0.3 erp. ignitetour.cf 10.0.0.4 10.0.0.5 10.0.0.6 Ignitetour.cf/crm 10.0.0.7 10.0.0.8 10.0.0.9 Automatically generated Label: erp Label: frontend Label: crm Addon Http Application Routing
45. Deployment Replica set Pod Label Rolling update Health check Environment variables Secret Resource management Horizontal Pod Autoscaler Namespace Service Ingress Annotation Persistent Volume Cron Job Deamon Set Job Stateful Set Config Map
46. + = Kubeflow Azure Dev Spaces Ecosystem Cert manager
47. Helm Helm is a tool for managing packages of pre-configured Kubernetes resources https://github.com/kubernetes/helm Linkerd Logstash Magento Mariadb Mongodb Mssql-linux Mysql Neo4j Newrelic Openvpn Postgresql Presto Prometheus Rabbitmq Redis Selenium Sonarqube Spinnaker Sysdig Tensorflow Traefik Wordpress Artifactory Cert-manager Consul Cassandra Couchdb Datadog Docker-registry Drupal Elasticsearch Ethereum fluentd Gitlab Grafana Hadoop Heapster Jenkins Joomla Kafka Kibana Kong Kubeless Lamp
48. Helm # Download Helm https://github.com/kubernetes/helm/releases # To install Tiller on the cluster run helm init # Get latest version of the stable charts helm repo update # Install a chart helm install --name monitor stable/Prometheus helm install --name dashboard stable/grafana -f "C:\Demos\monitoring\values.yaml"
49. Think ahead. Act now. Starts in seconds No VM Management Billed per second Linux and Windows containers Azure Container Instances (ACI) Azure Azure Container Instances (ACI) Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod
50. Kubernetes Kubernetes cluster Node (Minion) Node (Minion) Master
51. Kubernetes on Azure Kubernetes cluster Master Azure Container Instances (ACI) Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod Pod
52. The future of infrastructure is happening now
53. Wrap up Docker Delivery of production images instead of code ready to ship Environment agnostic Development Azure Kubernetes Services Managed Master + Managed IaaS for workers Provides scaling, rolling updates, fault tolerant
54. https://pages.xpirit.com/magazine2018 https://github.com/pascalnaber/ignitetour-aks-intro @pascalnaber Pascal Naber Coding Azure Architect Xpirit Netherlands
