Asynchronous streams in direct style with and without macros

Transcript

1. Asynchronous streams in direct style
   with and without macros
   Philipp Haller
   KTH Royal Institute of Technology

   Stockholm, Sweden
   Curry On 2019
   London, UK, July 15th, 2019


   View Slide

2. About myself
   • Associate Professor at KTH Royal Institute of Technology in Stockholm, Sweden

   • Previous positions at Typesafe Inc., Stanford University, and EPFL

   • PhD 2010 EPFL

   • Creator of Scala’s first widely-used actor library, co-author of Scala futures, Scala
   Async, spores, and others, Akka contributor

   • Research interests in programming language design and implementation, type
   systems, concurrency, and distributed programming


   View Slide

3. A simple task
   • Given an asynchronous method that returns the day of the year as a string wrapped in a future:

   def dayOfYear(): Future[String]

   • However, sometimes, for unknown reasons, dayOfYear completes the returned future with "",
   or null, or the string "nope".

   • Task: create a future which is completed either

   • with "It's !" where is the textual representation matching the month
   returned by dayOfYear, or

   • with "Not a date, mate!" when that's really the best we can do.
   "04/11" for April 11, or
   "06/13" for June 13


   View Slide

4. A first solution
   def solution() = {
   val date = """(\d+)/(\d+)""".r
   dayOfYear().flatMap { dayString =>
   dayString match {
   case date(month, day) =>
   nameOfMonth(month.toInt).map(name => s"It's $name!")
   case _ =>
   Future.successful("Not a date, mate!")
   }
   }
   }


   View Slide

5. A first solution
   def solution() = {
   val date = """(\d+)/(\d+)""".r
   dayOfYear().flatMap { dayString =>
   dayString match {
   case date(month, day) =>
   nameOfMonth(month.toInt).map(name => s"It's $name!")
   case _ =>
   Future.successful("Not a date, mate!")
   }
   }
   }
   Returns a value of
   type Future[String]


   View Slide

6. A first solution
   def solution() = {
   val date = """(\d+)/(\d+)""".r
   dayOfYear().flatMap { dayString =>
   dayString match {
   case date(month, day) =>
   nameOfMonth(month.toInt).map(name => s"It's $name!")
   case _ =>
   Future.successful("Not a date, mate!")
   }
   }
   }
   Evaluates to a value of type
   Future[String] which is completed with
   “It’s April!” when future returned by
   nameOfMonth(4) is completed with
   “April”



   View Slide

7. A first solution
   def solution() = {
   val date = """(\d+)/(\d+)""".r
   dayOfYear().flatMap { dayString =>
   dayString match {
   case date(month, day) =>
   nameOfMonth(month.toInt).map(name => s"It's $name!")
   case _ =>
   Future.successful("Not a date, mate!")
   }
   }
   }
   Evaluates to a value of
   type Future[String]


   View Slide

8. A first solution
   def solution() = {
   val date = """(\d+)/(\d+)""".r
   dayOfYear().flatMap { dayString =>
   dayString match {
   case date(month, day) =>
   nameOfMonth(month.toInt).map(name => s"It's $name!")
   case _ =>
   Future.successful("Not a date, mate!")
   }
   }
   }
   (a) flatMap returns a future f

   (b) f is completed (asynchronously) as follows:

   once dayOfYear() completes with value dayString, run
   closure { dayString => .. } which results in a future g;

   when g completes with value v,

   complete f with v


   View Slide

9. Scala Async
   • Purpose:

   Simplify asynchronous programming using futures.

   • Created by Jason Zaugg (Lightbend) and yours truly, first released in 2013

   • Stable releases for Scala 2.12 and 2.13


   View Slide

10. A solution using Scala Async
    def solution() = async {
    val date = """(\d+)/(\d+)""".r
    await(dayOfYear()) match {
    case date(month, day) =>
    s"It's ${await(nameOfMonth(month.toInt))}!"
    case _ =>
    "Not a date, mate!"
    }
    }
    async { }
    creates a future which is
    completed asynchronously
    with result of
    await(f)
    suspends current
    async block until f is
    completed with value v
    which is returned
    A simple, sequential
    program!


    View Slide

11. A solution using

    Scala for-comprehensions
    def solution() = {
    val date = """(\d+)/(\d+)""".r
    for {
    dayString response case date(month, day) =>
    for (name yield s"It's $name!"
    case _ =>
    Future.successful("Not a date, mate!")
    }
    } yield response
    }
    Readability OK not great


    View Slide

12. A solution using Scala Async
    def solution() = async {
    val date = """(\d+)/(\d+)""".r
    await(dayOfYear()) match {
    case date(month, day) =>
    s"It's ${await(nameOfMonth(month.toInt))}!"
    case _ =>
    "Not a date, mate!"
    }
    }
    No need to name all
    intermediate results
    No need for explicit
    Future.successful()
    Fewer closures
    allocated:
    async {} = 1 closure


    View Slide

13. Let’s make our previous task
    slightly more complex!
    • Instead of converting a single string "04/11" (or "06/13" etc.), "", null, or "nope",
    we should consume a stream of multiple such strings

    • Output should be a publisher which produces a stream of results


    View Slide

14. Intermezzo: Reactive Streams
    • a.k.a. java.util.concurrent.Flow (since JDK 9)

    • Interfaces: j.u.c.Flow.{Publisher, Subscriber, Subscription}

    • Some key prior work:

    • Observer design pattern (Gamma et al. 1994)1

    • Reactive Extensions (Meijer 2012)2

    • Key innovation of Reactive Streams: backpressure control
    2Erik Meijer, Your mouse is a database, Commun. ACM 55(5) (2012) 66–73.
    1Gamma, Erich, Richard Helm, Ralph Johnson, and John Vlissides, Design Patterns:

    Elements of Reusable Object Oriented Software, Addison-Wesley Professional, 1994
    Composition of
    observable streams using
    higher-order functions


    View Slide

15. Publisher
    • A Flow.Publisher produces events of type T which are received by subscribers
    if they have expressed interest.
    public static interface Flow.Publisher {
    void subscribe(Flow.Subscriber super T> subscriber);
    }


    View Slide

16. Subscriber
    • A Flow.Subscriber s consumes events of type T from publishers to which s has
    subscribed and from which s has requested to receive (a certain number of) events.
    public static interface Flow.Subscriber {
    void onSubscribe(Flow.Subscription subscription);
    void onNext(T item);
    void onError(Throwable throwable);
    void onComplete();
    }


    View Slide

17. Subscription
    • A Flow.Subscription enables subscribers to control the flow of events received
    from publishers.
    public static interface Flow.Subscription {
    void request(long n);
    void cancel();
    }


    View Slide

18. Reactive Extensions
    • Libraries building on basic interfaces for publishers, subscribers etc.

    • Key: higher-order functions for composing publishers

    • Implementations for many languages available


    View Slide

19. TextChanges(input)
    .Select(word => Completions(word))
    .Switch()
    .Subscribe(ObserveChanges(output));
    Example from
    (Meijer 2012)
    Image source: Erik Meijer, Your mouse is a database, Commun. ACM 55(5) (2012) 66–73.

    https://queue.acm.org/detail.cfm?id=2169076


    View Slide

20. Challenges
    • Often need diagrams to understand semantics (cf. “marble diagrams” used to
    document Reactive Extensions)

    • Creation of combinators challenging

    • Stateful combinators in particular

    • Inversion of control


    View Slide

21. Back to our task
    • Instead of converting a single string "04/11" (or "06/13" etc.), "", null, or "nope",
    we should consume a stream of multiple such strings

    • Output should be a publisher which produces a stream of results

    • Problem:
    • await only takes futures as arguments, but we need to await stream events!

    • async creates a future, but we need to create a stream publisher which yields
    multiple events instead of producing just one result
    We can’t use
    async/await! :-(


    View Slide

22. scala-async + Flow = scala-async-flow
    Extension of async/await model which:

    • Provides a variant of async { … } which creates a stream publisher:

    rasync { … }

    • Generalizes await from futures to stream events: next, done, error

    • Provides additional methods for yielding events:

    yieldNext, yieldError, yieldDone


    View Slide

23. Generalizing await
    • Previously: await the completion of futures

    def await[T](future: Future[T]): T

    • Now: await events produced by different asynchronous objects

    (Future[T], Flow.Publisher[T], etc.)

    • An asynchronous object must provide the following methods:
    def getCompleted: Try[T]
    def onComplete[S](handler: Try[T] => S) given (executor: ExecutionContext)


    View Slide

24. Solution using scala-async-flow
    val stream = rasync[String] {
    var dateOpt = await(dateStream)
    while (dateOpt.nonEmpty) {
    dateOpt.get match {
    case date(month, day) =>
    yieldNext(s"It's ${await(nameOfMonth(month.toInt))}!")
    case _ =>
    yieldNext("Not a date, mate!")
    }
    dateOpt = await(dateStream)
    }
    yieldDone()
    }
    Type of stream:
    Flow.Publisher[String]
    Here, we are
    awaiting a future!


    View Slide

25. Implementing scala-async-flow
    Some alternatives:

    1. Extension of Scala Async (macro for Scala 2.12 and 2.13)

    2. Direct compiler support

    3. Build on top of continuations or fibers


    View Slide

26. Library Component
    def rasync[T](body: given Flow[T] => T): Flow.Publisher[T] = {
    delegate for Flow[T] = new Flow[T]
    ...
    }
    def await[T, S](a: Async[T]) given (flow: Flow[S],
    executor: ExecutionContext): T
    def yieldNext[T](event: T) given (flow: Flow[T]) = {
    flow.yieldNext(event)
    }
    Implicit function
    type3
    3Odersky, Martin, Olivier Blanvillain, Fengyun Liu, Aggelos Biboudis, Heather Miller, and Sandro
    Stucki. Simplicitly: Foundations and applications of implicit function types. PACMPL 2(POPL):
    42:1-42:29 (2018)


    View Slide

27. Implicit Function Types
    def rasync[T](body: given Flow[T] => T): Flow.Publisher[T] = ..
    Usage:
    rasync[Int] {
    expr
    yieldNext(5)
    3
    }
    rasync[Int] { given ($f: Flow[Int]) =>
    expr
    yieldNext(5) given $f
    3
    }
    Expands to:
    def yieldNext[T](event: T) given (flow: Flow[T]) = {
    flow.yieldNext(event)
    }
    yieldNext, yieldDone, etc. have implicit parameters:


    View Slide

28. Library Component
    def rasync[T](body: given Flow[T] => T): Flow.Publisher[T] = {
    delegate for Flow[T] = new Flow[T]
    ...
    }
    def await[T, S](a: Async[T]) given (flow: Flow[S],
    executor: ExecutionContext): T
    def yieldNext[T](event: T) given (flow: Flow[T]) = {
    flow.yieldNext(event)
    }


    View Slide

29. Library Component
    def rasync[T](body: given Flow[T] => T): Flow.Publisher[T] = {
    delegate for Flow[T] = new Flow[T]
    ...
    }
    def await[T, S](a: Async[T]) given (flow: Flow[S],
    executor: ExecutionContext): T
    def yieldNext[T](event: T) given (flow: Flow[T]) = {
    flow.yieldNext(event)
    }


    View Slide

30. Library Component
    def rasync[T](body: given Flow[T] => T): Flow.Publisher[T] = {
    delegate for Flow[T] = new Flow[T]
    ...
    }
    def await[T, S](a: Async[T]) given (flow: Flow[S],
    executor: ExecutionContext): T
    def yieldNext[T](event: T) given (flow: Flow[T]) = {
    flow.yieldNext(event)
    }


    View Slide

31. Macro-based implementation
    Example program:
    def fwd(s: Flow.Publisher[Int]) = rasync {
    var x: Option[Int] = None
    x = await(s)
    x.get
    }


    View Slide

32. class StateMachine(flow: Flow[Int]) {
    var state = 0
    val result = Promise[Int]()
    var x: Option[Int] = _
    def apply(tr: Try[Int]): Unit = state match {
    case 0 =>
    x = None
    val sub = flow.pubToSub(s)
    val completed = sub.getCompleted
    if (completed == null) {
    state = 2
    sub.onComplete(evt => apply(evt))
    } else if (completed.isFailure) {
    result.complete(completed)
    } else {
    x = completed.get
    state = 1
    apply(null)
    }
    case 1 =>
    result.complete(x.get)
    case 2 =>
    if (tr.isFailure) {
    result.complete(tr)
    } else {
    x = tr.get
    state = 1
    apply(null)
    }
    }}
    Generated state
    machine


    View Slide

33. Alternative: more powerful
    execution environment
    • OpenJDK Project Loom

    • Goal:

    JVM features for supporting lightweight, high-throughput concurrency constructs

    • Key features:

    • Delimited continuations

    • Fibers (“user-mode threads”)
    • Project under active development

    • Sponsored by OpenJDK HotSpot Group

    • Talk by Ron Pressler today at 16:15!


    View Slide

34. Continuations in Project Loom
    • A continuation turns a task into a suspendable computation

    • Suspend and resume at yield points

    • Transfer values into and out of using higher-level abstractions
    val cont = new Continuation(SCOPE, new Runnable {
    def run(): Unit = {

    }
    })


    View Slide

35. var continue = false
    val cont =
    new Continuation(SCOPE, new Runnable {
    def run(): Unit = {
    println("hello from continuation")
    while (!continue) {
    println("suspending")
    Continuation.`yield`(SCOPE)
    println("resuming")
    }
    println("all the way to the end")
    }
    })
    cont.run()
    println("isDone: " + cont.isDone())
    continue = true
    cont.run()
    println("isDone: " + cont.isDone())
    hello from continuation
    suspending
    isDone: false
    resuming
    all the way to the end
    isDone: true
    Output:
    Example


    View Slide

36. def rasync[T](body: given Flow[T] => T): Flow.Publisher[T] = {
    delegate flow for Flow[T] = new Flow[T]
    ...
    val cont = new Continuation(SCOPE, new Runnable {
    def run(): Unit = {
    try {
    val v = body
    flow.emitNext(v)
    flow.emitComplete()
    } catch {
    case NonFatal(error) =>
    flow.emitError(error)
    }
    }
    })
    ...
    flow
    }


    View Slide

37. def await[T, S](a: Async[T]) given (flow: Flow[S],
    executor: ExecutionContext): T = {
    val res = a.getCompleted
    if (res eq null) {
    a.onComplete(x => flow.resume(x))
    flow.suspend()
    a.getCompleted.get
    } else {
    res.get
    }
    }


    View Slide

38. Theoretical foundations
    Paper:

    P. Haller and H. Miller: A reduction semantics for direct-style asynchronous observables.

    Journal of Logical and Algebraic Methods in Programming 105 (2019) 75–111

    https://doi.org/10.1016/j.jlamp.2019.03.002

    • Formalization of programming model

    • Type soundness proof

    • Proof of protocol conformance

    • Describes macro-based implementation
    Example: a stream
    created with rasync { … }
    never emits a next event after
    emitting a done event


    View Slide

39. Two More Issues
    • Issue 1: Data races due to variable capture



    Idea: constrain variable capturing of closures. See:

    H. Miller, P. Haller, M. Odersky:

    Spores: A Type-Based Foundation for Closures in the Age of

    Concurrency and Distribution. ECOOP 2014

    • Issue 2: Data races due to top-level singleton objects



    Idea: ensure object-capability safety of objects created within rasync blocks. See:

    P. Haller, A. Loiko:

    LaCasa: lightweight affinity and object capabilities in Scala. OOPSLA 2016
    Example:
    var x = 5
    rasync[Int] {
    x = 10
    yieldNext(5)
    3
    }
    val y = x + 1


    View Slide

40. Open Issues
    • “Blue and red functions” problem

    • Calling a suspendible method (given Flow[T]) requires the caller to be
    suspendible, too

    • Need two variants for each higher-order function: regular and suspendible

    • Loom continuations don’t suffer from that problem; can suspend as long as there
    is an active continuation

    • Relaxing need for Flow[T] capabilities may be feasible


    View Slide

41. Resources
    • Prototype implementation:

    https://github.com/phaller/scala-async-flow

    Branch “cont” makes use of Project Loom continuations and Scala 3

    • Papers and more:

    http://www.csc.kth.se/~phaller/

    • Twitter: @philippkhaller
    Thank you!


    View Slide
