Reactive Async: Expressive Deterministic Concurrency

Transcript

1. Reactive Async:
   Expressive Deterministic Concurrency
   Philipp Haller1, Simon Geries1,

   Michael Eichberg2, Guido Salvaneschi2
   1 KTH Royal Institute of Technology, Sweden
   2 TU Darmstadt, Germany


   View Slide

2. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
   Have we solved concurrent programming, yet?
   2


   View Slide

3. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
   Have we solved concurrent programming, yet?
   The problem with concurrency:
   2


   View Slide

4. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
   Have we solved concurrent programming, yet?
   The problem with concurrency:
   – It’s difficult!
   2


   View Slide

5. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
   Have we solved concurrent programming, yet?
   The problem with concurrency:
   – It’s difficult!
   – Multiple hazards:
   2


   View Slide

6. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
   Have we solved concurrent programming, yet?
   The problem with concurrency:
   – It’s difficult!
   – Multiple hazards:
   • Race conditions
   2


   View Slide

7. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
   Have we solved concurrent programming, yet?
   The problem with concurrency:
   – It’s difficult!
   – Multiple hazards:
   • Race conditions
   • Deadlocks
   2


   View Slide

8. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
   Have we solved concurrent programming, yet?
   The problem with concurrency:
   – It’s difficult!
   – Multiple hazards:
   • Race conditions
   • Deadlocks
   • Livelocks
   2


   View Slide

9. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
   Have we solved concurrent programming, yet?
   The problem with concurrency:
   – It’s difficult!
   – Multiple hazards:
   • Race conditions
   • Deadlocks
   • Livelocks
   • Violation of fairness
   2


   View Slide

10. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Non-Determinism
    3


    View Slide

11. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Non-Determinism
    • At the root of several hazards
    3


    View Slide

12. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Non-Determinism
    • At the root of several hazards
    • Example 1:
    3
    @volatile var x = 0
    def m(): Unit = {
    Future {
    x = 1
    }
    Future {
    x = 2
    }
    .. // does not access x
    }


    View Slide

13. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Non-Determinism
    • At the root of several hazards
    • Example 1:
    3
    @volatile var x = 0
    def m(): Unit = {
    Future {
    x = 1
    }
    Future {
    x = 2
    }
    .. // does not access x
    }
    What’s the value of x
    when an invocation
    of m returns?


    View Slide

14. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Reordering not always a problem!
    • Example 2:
    4


    View Slide

15. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Reordering not always a problem!
    • Example 2:
    4
    import scala.collection.concurrent.TrieMap
    val set = new TrieMap[Int, Int]
    Future {
    set.put(1, 0)
    }
    set.put(2, 0)


    View Slide

16. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Reordering not always a problem!
    • Example 2:
    4
    import scala.collection.concurrent.TrieMap
    val set = new TrieMap[Int, Int]
    Future {
    set.put(1, 0)
    }
    set.put(2, 0)
    Eventually, set contains
    both 1 and 2, always


    View Slide

17. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Reordering not always a problem!
    • Example 2:
    4
    import scala.collection.concurrent.TrieMap
    val set = new TrieMap[Int, Int]
    Future {
    set.put(1, 0)
    }
    set.put(2, 0)
    Eventually, set contains
    both 1 and 2, always
    Bottom line: it depends on the datatype


    View Slide

18. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    … and its operations!
    • Example 3:
    5


    View Slide

19. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    … and its operations!
    • Example 3:
    5
    val set = new TrieMap[Int, Int]
    Future {
    set.put(1, 0)
    }
    Future {
    if (set.contains(1)) {
    ..
    }
    }
    set.put(2, 0)


    View Slide

20. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    … and its operations!
    • Example 3:
    5
    val set = new TrieMap[Int, Int]
    Future {
    set.put(1, 0)
    }
    Future {
    if (set.contains(1)) {
    ..
    }
    }
    set.put(2, 0)
    Result depends
    on schedule!


    View Slide

21. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Important Questions
    6


    View Slide

22. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Important Questions
    Q1:

    How do we know we have written a deterministic
    concurrent program?
    6


    View Slide

23. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Important Questions
    Q1:

    How do we know we have written a deterministic
    concurrent program?
    – What about Heisenbugs?
    6


    View Slide

24. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Important Questions
    Q1:

    How do we know we have written a deterministic
    concurrent program?
    – What about Heisenbugs?
    • No race in 1’000’000 runs, race in run 1’000’001
    6


    View Slide

25. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Important Questions
    Q1:

    How do we know we have written a deterministic
    concurrent program?
    – What about Heisenbugs?
    • No race in 1’000’000 runs, race in run 1’000’001
    6
    Goal: simple criteria that guarantee determinism


    View Slide

26. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Important Questions
    7


    View Slide

27. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Important Questions
    Q2:

    How do we ensure expressivity while providing
    determinism?
    7


    View Slide

28. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Important Questions
    Q2:

    How do we ensure expressivity while providing
    determinism?
    – Draconian restrictions undesired!
    7


    View Slide

29. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Important Questions
    Q2:

    How do we ensure expressivity while providing
    determinism?
    – Draconian restrictions undesired!
    7
    Goal: reconcile determinism and expressivity


    View Slide

30. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Approach
    8


    View Slide

31. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Approach
    • Extend a future-style programming model with:
    8


    View Slide

32. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Approach
    • Extend a future-style programming model with:
    – Lattice-based datatypes
    8


    View Slide

33. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Approach
    • Extend a future-style programming model with:
    – Lattice-based datatypes
    – Quiescence
    8


    View Slide

34. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Approach
    • Extend a future-style programming model with:
    – Lattice-based datatypes
    – Quiescence
    8
    Crucial for
    determinism!


    View Slide

35. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Approach
    • Extend a future-style programming model with:
    – Lattice-based datatypes
    – Quiescence
    – Resolution of cyclic dependencies
    8
    Crucial for
    determinism!


    View Slide

36. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Approach
    • Extend a future-style programming model with:
    – Lattice-based datatypes
    – Quiescence
    – Resolution of cyclic dependencies
    8
    Crucial for
    determinism!
    Increases
    expressivity!


    View Slide

37. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Approach
    • Extend a future-style programming model with:
    – Lattice-based datatypes
    – Quiescence
    – Resolution of cyclic dependencies
    • Evaluation of expressivity and performance
    – Case study: static analysis of JVM bytecode
    8
    Crucial for
    determinism!
    Increases
    expressivity!


    View Slide

38. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Programming Model
    9


    View Slide

39. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Programming Model
    Programming model based on two core abstractions:

    cells and cell completers
    9


    View Slide

40. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Programming Model
    Programming model based on two core abstractions:

    cells and cell completers
    – Cell = shared “variable”
    9


    View Slide

41. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Programming Model
    Programming model based on two core abstractions:

    cells and cell completers
    – Cell = shared “variable”
    9
    Concurrently
    read and written


    View Slide

42. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Programming Model
    Programming model based on two core abstractions:

    cells and cell completers
    – Cell = shared “variable”
    – Cell[K,V]: read-only interface; read values of type V
    (akin to Future[V])
    9
    Concurrently
    read and written


    View Slide

43. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Programming Model
    Programming model based on two core abstractions:

    cells and cell completers
    – Cell = shared “variable”
    – Cell[K,V]: read-only interface; read values of type V
    (akin to Future[V])
    – CellCompleter[K,V] : write values of type V to its
    associated cell (akin to Promise[V])
    9
    Concurrently
    read and written


    View Slide

44. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Programming Model
    Programming model based on two core abstractions:

    cells and cell completers
    – Cell = shared “variable”
    – Cell[K,V]: read-only interface; read values of type V
    (akin to Future[V])
    – CellCompleter[K,V] : write values of type V to its
    associated cell (akin to Promise[V])
    – V must have an instance of a lattice type class
    9
    Concurrently
    read and written


    View Slide

45. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Programming Model
    Programming model based on two core abstractions:

    cells and cell completers
    – Cell = shared “variable”
    – Cell[K,V]: read-only interface; read values of type V
    (akin to Future[V])
    – CellCompleter[K,V] : write values of type V to its
    associated cell (akin to Promise[V])
    – V must have an instance of a lattice type class
    9
    Monotonic
    updates
    Concurrently
    read and written


    View Slide

46. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Example
    10


    View Slide

47. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Example
    • Given a social graph
    10


    View Slide

48. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Example
    • Given a social graph
    – vertex = user
    10


    View Slide

49. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Example
    • Given a social graph
    – vertex = user
    • Traverse graph and collect IDs of “interesting” users
    10


    View Slide

50. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Example
    • Given a social graph
    – vertex = user
    • Traverse graph and collect IDs of “interesting” users
    • Graph large => concurrent traversal
    10


    View Slide

51. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Solution
    11


    View Slide

52. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Solution
    • Collect IDs of interesting users in a cell
    11


    View Slide

53. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Solution
    • Collect IDs of interesting users in a cell
    • Cell contains set of integers
    11


    View Slide

54. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Solution
    • Collect IDs of interesting users in a cell
    • Cell contains set of integers
    11
    OK: subsets of the set of
    all integers form a lattice


    View Slide

55. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Cell with User IDs
    (code simplified)
    12


    View Slide

56. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Cell with User IDs
    (code simplified)
    12
    val userIDs = CellCompleter[Set[Int]]


    View Slide

57. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Cell with User IDs
    (code simplified)
    12
    implicit object IntSetLattice extends Lattice[Set[Int]] {
    val empty = Set()
    def join(left: Set[Int], right: Set[Int]) = left ++ right
    }
    val userIDs = CellCompleter[Set[Int]]


    View Slide

58. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Cell with User IDs
    (code simplified)
    12
    implicit object IntSetLattice extends Lattice[Set[Int]] {
    val empty = Set()
    def join(left: Set[Int], right: Set[Int]) = left ++ right
    }
    val userIDs = CellCompleter[Set[Int]]
    Bounded

    join-semilattice


    View Slide

59. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Cell with User IDs
    (code simplified)
    12
    implicit object IntSetLattice extends Lattice[Set[Int]] {
    val empty = Set()
    def join(left: Set[Int], right: Set[Int]) = left ++ right
    }
    // add a user ID
    userIDs.putNext(Set(theUserID))
    val userIDs = CellCompleter[Set[Int]]
    Bounded

    join-semilattice


    View Slide

60. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Reading Results
    13


    View Slide

61. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Reading Results
    • Problem: when reading a cell’s value, how do we
    know this value is not going to change any more?
    13


    View Slide

62. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Reading Results
    • Problem: when reading a cell’s value, how do we
    know this value is not going to change any more?
    – There may still be ongoing concurrent activities
    13


    View Slide

63. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Reading Results
    • Problem: when reading a cell’s value, how do we
    know this value is not going to change any more?
    – There may still be ongoing concurrent activities
    – Manual synchronization (e.g., latches) error-prone
    13


    View Slide

64. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Reading Results
    • Problem: when reading a cell’s value, how do we
    know this value is not going to change any more?
    – There may still be ongoing concurrent activities
    – Manual synchronization (e.g., latches) error-prone
    • Solution:
    13


    View Slide

65. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Reading Results
    • Problem: when reading a cell’s value, how do we
    know this value is not going to change any more?
    – There may still be ongoing concurrent activities
    – Manual synchronization (e.g., latches) error-prone
    • Solution:
    13
    Koyaanisqatsi


    View Slide

66. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Reading Results
    • Problem: when reading a cell’s value, how do we
    know this value is not going to change any more?
    – There may still be ongoing concurrent activities
    – Manual synchronization (e.g., latches) error-prone
    • Solution:
    13
    Koyaanisqatsi


    View Slide

67. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Reading Results
    • Problem: when reading a cell’s value, how do we
    know this value is not going to change any more?
    – There may still be ongoing concurrent activities
    – Manual synchronization (e.g., latches) error-prone
    • Solution:
    13
    Quiescence


    View Slide

68. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Quiescence
    14


    View Slide

69. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Quiescence
    • Intuitively: situation when values of cells are
    guaranteed not to change any more
    14


    View Slide

70. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Quiescence
    • Intuitively: situation when values of cells are
    guaranteed not to change any more
    • Technically:
    14


    View Slide

71. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Quiescence
    • Intuitively: situation when values of cells are
    guaranteed not to change any more
    • Technically:
    – No concurrent activities ongoing or scheduled
    which could change values of cells
    14


    View Slide

72. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Quiescence
    • Intuitively: situation when values of cells are
    guaranteed not to change any more
    • Technically:
    – No concurrent activities ongoing or scheduled
    which could change values of cells
    – Detected by the underlying thread pool
    14


    View Slide

73. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Revisiting the Example
    15


    View Slide

74. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Revisiting the Example
    15
    val pool = new HandlerPool
    val userIDs = CellCompleter[Set[Int]](pool)


    View Slide

75. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Revisiting the Example
    15
    // add a user ID
    userIDs.putNext(Set(theUserID))
    ..
    val pool = new HandlerPool
    val userIDs = CellCompleter[Set[Int]](pool)


    View Slide

76. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Revisiting the Example
    15
    // add a user ID
    userIDs.putNext(Set(theUserID))
    ..
    val pool = new HandlerPool
    val userIDs = CellCompleter[Set[Int]](pool)
    // register handler
    // upon quiescence: read result value of cell
    pool.onQuiescent(userIDs.cell) { collectedIDs =>
    ..
    }


    View Slide

77. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Revisiting the Example
    15
    // add a user ID
    userIDs.putNext(Set(theUserID))
    ..
    val pool = new HandlerPool
    val userIDs = CellCompleter[Set[Int]](pool)
    // register handler
    // upon quiescence: read result value of cell
    pool.onQuiescent(userIDs.cell) { collectedIDs =>
    ..
    }
    Safe to read
    from cell when pool
    quiescent!


    View Slide

78. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Handler Pools
    16


    View Slide

79. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Handler Pools
    Execution context with extensions:
    16


    View Slide

80. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Handler Pools
    Execution context with extensions:
    – Event-driven quiescence API
    16


    View Slide

81. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Handler Pools
    Execution context with extensions:
    – Event-driven quiescence API
    – Resolution of dependencies between cells
    16


    View Slide

82. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Handler Pools
    Execution context with extensions:
    – Event-driven quiescence API
    – Resolution of dependencies between cells
    16
    Dependency resolution?


    View Slide

83. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Expressing Concurrent Dataflow
    17


    View Slide

84. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Expressing Concurrent Dataflow
    • Cells provide non-blocking interface
    17


    View Slide

85. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Expressing Concurrent Dataflow
    • Cells provide non-blocking interface
    – Low level: callbacks
    17


    View Slide

86. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Expressing Concurrent Dataflow
    • Cells provide non-blocking interface
    – Low level: callbacks
    – High level: combinators
    17


    View Slide

87. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Expressing Concurrent Dataflow
    • Cells provide non-blocking interface
    – Low level: callbacks
    – High level: combinators
    17
    Like futures


    View Slide

88. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Expressing Concurrent Dataflow
    • Cells provide non-blocking interface
    – Low level: callbacks
    – High level: combinators
    • Important purpose: express concurrent dataflow
    17
    Like futures


    View Slide

89. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Expressing Concurrent Dataflow
    • Cells provide non-blocking interface
    – Low level: callbacks
    – High level: combinators
    • Important purpose: express concurrent dataflow
    17
    Like futures
    fut.map(fun).filter(pred)


    View Slide

90. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Expressing Concurrent Dataflow
    • Cells provide non-blocking interface
    – Low level: callbacks
    – High level: combinators
    • Important purpose: express concurrent dataflow
    17
    Like futures
    fut.map(fun).filter(pred)
    Futures


    View Slide

91. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Expressing Concurrent Dataflow
    • Cells provide non-blocking interface
    – Low level: callbacks
    – High level: combinators
    • Important purpose: express concurrent dataflow
    17
    Like futures
    fut
    fun
    fut’
    pred
    fut’’
    fut.map(fun).filter(pred)
    Futures


    View Slide

92. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Expressing Concurrent Dataflow
    • Cells provide non-blocking interface
    – Low level: callbacks
    – High level: combinators
    • Important purpose: express concurrent dataflow
    • Problem:
    17
    Like futures
    fut
    fun
    fut’
    pred
    fut’’
    fut.map(fun).filter(pred)
    Futures


    View Slide

93. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Expressing Concurrent Dataflow
    • Cells provide non-blocking interface
    – Low level: callbacks
    – High level: combinators
    • Important purpose: express concurrent dataflow
    • Problem:
    17
    What if the dataflow graph is cyclic?
    Like futures
    fut
    fun
    fut’
    pred
    fut’’
    fut.map(fun).filter(pred)
    Futures


    View Slide

94. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Dataflow Graphs
    18


    View Slide

95. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Dataflow Graphs
    Example:
    • Static analysis of JVM bytecode
    18


    View Slide

96. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Dataflow Graphs
    Example:
    • Static analysis of JVM bytecode
    • Task:

    Determine purity of methods
    18


    View Slide

97. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Dataflow Graphs
    Example:
    • Static analysis of JVM bytecode
    • Task:

    Determine purity of methods
    • Rules:
    18


    View Slide

98. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Dataflow Graphs
    Example:
    • Static analysis of JVM bytecode
    • Task:

    Determine purity of methods
    • Rules:
    – A method is impure if it accesses a non-final field
    18


    View Slide

99. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
    Dataflow Graphs
    Example:
    • Static analysis of JVM bytecode
    • Task:

    Determine purity of methods
    • Rules:
    – A method is impure if it accesses a non-final field
    – A method is impure if it calls an impure method
    18


    View Slide

100. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Dataflow Graphs
     Example:
     • Static analysis of JVM bytecode
     • Task:

     Determine purity of methods
     • Rules:
     – A method is impure if it accesses a non-final field
     – A method is impure if it calls an impure method
     – …
     18


     View Slide

101. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Dataflow Graphs
     Example:
     • Static analysis of JVM bytecode
     • Task:

     Determine purity of methods
     • Rules:
     – A method is impure if it accesses a non-final field
     – A method is impure if it calls an impure method
     – …
     18
     A


     View Slide

102. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Dataflow Graphs
     Example:
     • Static analysis of JVM bytecode
     • Task:

     Determine purity of methods
     • Rules:
     – A method is impure if it accesses a non-final field
     – A method is impure if it calls an impure method
     – …
     18
     A B


     View Slide

103. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Dataflow Graphs
     Example:
     • Static analysis of JVM bytecode
     • Task:

     Determine purity of methods
     • Rules:
     – A method is impure if it accesses a non-final field
     – A method is impure if it calls an impure method
     – …
     18
     A B
     “calls”


     View Slide

104. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Dataflow Graphs
     Example:
     • Static analysis of JVM bytecode
     • Task:

     Determine purity of methods
     • Rules:
     – A method is impure if it accesses a non-final field
     – A method is impure if it calls an impure method
     – …
     18
     A B
     C
     “calls”


     View Slide

105. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Dataflow Graphs
     Example:
     • Static analysis of JVM bytecode
     • Task:

     Determine purity of methods
     • Rules:
     – A method is impure if it accesses a non-final field
     – A method is impure if it calls an impure method
     – …
     18
     A B
     C
     “calls”


     View Slide

106. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Cycle Resolution
     19


     View Slide

107. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Cycle Resolution
     • What if upon quiescence cells are empty and there is a
     dependency cycle?
     19


     View Slide

108. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Cycle Resolution
     • What if upon quiescence cells are empty and there is a
     dependency cycle?
     19
     A B
     C


     View Slide

109. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Cycle Resolution
     • What if upon quiescence cells are empty and there is a
     dependency cycle?
     • Idea:

     Pluggable resolution policies
     19
     A B
     C


     View Slide

110. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Cycle Resolution
     • What if upon quiescence cells are empty and there is a
     dependency cycle?
     • Idea:

     Pluggable resolution policies
     • Example:

     Purity analysis should resolve all cells

     in cycle to “pure”, since could not show impurity
     19
     A B
     C


     View Slide

111. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Specifying Resolution Policies
     20


     View Slide

112. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Specifying Resolution Policies
     • Role of the first type parameter of Cell[K,V]
     20


     View Slide

113. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Specifying Resolution Policies
     • Role of the first type parameter of Cell[K,V]
     • Example:
     20


     View Slide

114. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Specifying Resolution Policies
     • Role of the first type parameter of Cell[K,V]
     • Example:
     20
     object PurityKey extends Key[Purity] {
     def resolve[K cells.map(cell => (cell, Pure))
     ..
     }


     View Slide

115. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Specifying Resolution Policies
     • Role of the first type parameter of Cell[K,V]
     • Example:
     20
     object PurityKey extends Key[Purity] {
     def resolve[K cells.map(cell => (cell, Pure))
     ..
     }
     resolve all
     cells to Pure


     View Slide

116. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Specifying Resolution Policies
     • Role of the first type parameter of Cell[K,V]
     • Example:
     20
     object PurityKey extends Key[Purity] {
     def resolve[K cells.map(cell => (cell, Pure))
     ..
     }
     closed strongly-
     connected component


     View Slide

117. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Purity Analysis: Set-up
     21


     View Slide

118. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Purity Analysis: Set-up
     21
     for {
     classFile method } {
     val methodCompleter = CellCompleter(pool, PurityKey)
     pool.execute {
     analyze(project, methodCompleter, classFile, method)
     }
     }
     val analysisDoneFuture = pool.quiescentResolveCells()


     View Slide

119. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Evaluation
     22


     View Slide

120. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Evaluation
     • Static analysis of JVM bytecode using the OPAL
     framework (OPen extensible Analysis Library)
     22


     View Slide

121. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Evaluation
     • Static analysis of JVM bytecode using the OPAL
     framework (OPen extensible Analysis Library)
     – New Scala-based, extensible bytecode toolkit
     22


     View Slide

122. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Evaluation
     • Static analysis of JVM bytecode using the OPAL
     framework (OPen extensible Analysis Library)
     – New Scala-based, extensible bytecode toolkit
     – Fully concurrent
     22


     View Slide

123. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Evaluation
     • Static analysis of JVM bytecode using the OPAL
     framework (OPen extensible Analysis Library)
     – New Scala-based, extensible bytecode toolkit
     – Fully concurrent
     22
     http://www.opal-project.de


     View Slide

124. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Evaluation
     • Static analysis of JVM bytecode using the OPAL
     framework (OPen extensible Analysis Library)
     – New Scala-based, extensible bytecode toolkit
     – Fully concurrent
     • Rewrote purity analysis and immutability analysis
     22
     http://www.opal-project.de


     View Slide

125. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Evaluation
     • Static analysis of JVM bytecode using the OPAL
     framework (OPen extensible Analysis Library)
     – New Scala-based, extensible bytecode toolkit
     – Fully concurrent
     • Rewrote purity analysis and immutability analysis
     • Ran analysis on JDK 8 update 45 (rt.jar)
     22
     http://www.opal-project.de


     View Slide

126. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Evaluation
     • Static analysis of JVM bytecode using the OPAL
     framework (OPen extensible Analysis Library)
     – New Scala-based, extensible bytecode toolkit
     – Fully concurrent
     • Rewrote purity analysis and immutability analysis
     • Ran analysis on JDK 8 update 45 (rt.jar)
     – 18’591 class files, 163’268 methods, 77’128 fields
     22
     http://www.opal-project.de


     View Slide

127. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Results: Immutability Analysis
     • RA about 10x faster than FPCF
     • RA = 294 LOC, FPCF = 424 LOC (1.44x)
     23
     FPCF (secs.)
     1.0
     1.5
     2.0
     2.5
     Reactive-Async (secs.)
     0.1
     0.2
     0.3
     1 Thread 2 Threads 4 Threads 8 Threads 16 Threads
     2.15
     2.20
     2.25
     2.30
     2.35
     1.15
     1.20
     1.25
     1.30
     1.35
     0.290
     0.295
     0.300
     0.105
     0.110
     0.115


     View Slide

128. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Results: Immutability Analysis
     • RA about 10x faster than FPCF
     • RA = 294 LOC, FPCF = 424 LOC (1.44x)
     23
     FPCF (secs.)
     1.0
     1.5
     2.0
     2.5
     Reactive-Async (secs.)
     0.1
     0.2
     0.3
     1 Thread 2 Threads 4 Threads 8 Threads 16 Threads
     2.15
     2.20
     2.25
     2.30
     2.35
     1.15
     1.20
     1.25
     1.30
     1.35
     0.290
     0.295
     0.300
     0.105
     0.110
     0.115
     box plot:
     whiskers = min/max

     top/bottom of box =

     1st and 3rd quartile
     band in box: median


     View Slide

129. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Results: Immutability Analysis
     • RA about 10x faster than FPCF
     • RA = 294 LOC, FPCF = 424 LOC (1.44x)
     23
     FPCF (secs.)
     1.0
     1.5
     2.0
     2.5
     Reactive-Async (secs.)
     0.1
     0.2
     0.3
     1 Thread 2 Threads 4 Threads 8 Threads 16 Threads
     2.15
     2.20
     2.25
     2.30
     2.35
     1.15
     1.20
     1.25
     1.30
     1.35
     0.290
     0.295
     0.300
     0.105
     0.110
     0.115
     box plot:
     whiskers = min/max

     top/bottom of box =

     1st and 3rd quartile
     band in box: median
     FPCF = OPAL’s fixed point
     computation framework


     View Slide

130. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Results: Purity Analysis
     • Best configs. (FPCF: 4 thr, RA: 16 thr): RA 1.75x faster
     • RA = 113 LOC, FPCF = 166 LOC (1.47x)
     24
     FPCF (secs.)
     0.15
     0.20
     0.25
     0.30
     0.35
     Reactive-Async (secs.)
     0.1
     0.2
     0.3
     0.4
     0.5
     1 Thread 2 Threads 4 Threads 8 Threads 16 Threads
     0.43
     0.44
     0.45
     0.09
     0.10
     0.11
     0.335
     0.340
     0.345
     0.165
     0.170
     0.175
     0.180
     0.185
     0.18
     0.19
     0.20


     View Slide

131. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Benchmarks: Monte Carlo Simulation
     • Compute Net Present Value
     • 14-16 threads: Scala futures 23-36% faster than RA
     25
     Sequential
     Reactive Async
     Scala Futures 2.11.7
     Runtime (ms)
     0
     1000
     2000
     3000
     4000
     5000
     6000
     Number of Threads
     1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
     400
     500
     600
     700
     14 15 16


     View Slide

132. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Benchmarks: Parallel Sum
     • Parallel sum of large collection of random ints
     • Performance competitive with Scala’s futures
     26
     Sequential
     Reactive Async
     Scala Futures 2.11.7
     Runtime (ms)
     0
     50
     100
     150
     200
     250
     300
     Number of Threads
     1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16


     View Slide

133. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Related Work
     • Deterministic-by-construction programming models
     – KPNs, concurrent revisions, FlowPools, LVars, etc.
     • Static vs. dynamic enforcement of determinism
     • Reactive programming models
     – Dynamic dependencies, determinism
     • See paper for discussion
     27


     View Slide

134. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Reactive Async: Conclusion
     • New concurrent programming model
     – Lattices and quiescence for determinism
     – Resolution of cyclic dependencies
     • Promising experimental results
     • Future work:
     – Optimization
     – Determinism as a statically-checked effect
     28


     View Slide

135. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Reactive Async: Conclusion
     • New concurrent programming model
     – Lattices and quiescence for determinism
     – Resolution of cyclic dependencies
     • Promising experimental results
     • Future work:
     – Optimization
     – Determinism as a statically-checked effect
     28
     https://github.com/phaller/reactive-async


     View Slide

136. Reactive Async: Expressive Deterministic Concurrency — Philipp Haller
     Reactive Async: Conclusion
     • New concurrent programming model
     – Lattices and quiescence for determinism
     – Resolution of cyclic dependencies
     • Promising experimental results
     • Future work:
     – Optimization
     – Determinism as a statically-checked effect
     28
     https://github.com/phaller/reactive-async
     Thank you!


     View Slide
