Benchmarking Pusher using Node.js

London Node.js User Group

Transcript

1. Benchmarking Pusher using Node.js Paweł Ledwoń London Node.js User Group, Nov ’12
2. OVERVIEW Why we do this Evolution of our approach Architecture of our framework What we learned about Node.js No Memes
3. WHY?
4. FIND LIMITS ESTIMATE HARDWARE NEEDS CHECK HIGH-LOAD STABILITY TEST SOFTWARE UPDATES FIND OPTIMAL HARDWARE GAIN MORE CONFIDENCE GET NUMBERS FOR CUSTOMERS
5. PERFORMANCE is a FEATURE
6. HOW?
7. THIS IS HOW MOST TESTS LOOK LIKE 1. write a shell script to open connections 2. write another script to send messages 3. run system locally or on a benchmarking cluster 4. start generating load 5. pray for results to be good
8. WHAT IF SOMETHING BREAKS? 1. first thought: what happened? 2. you probably don’t gather enough metrics 3. you might be doing too many things at once 4. you can’t be sure your script is not the bottleneck 5. altering scripts is time-consuming and error-prone 6. distributing scripts to vary the load is awkward
9. SO MANY THINGS TO GO WRONG EC2 PERFORMANCE NODE.JS ISSUES CRAPPY IO GARBAGE COLLECTION SPOFS LOAD BALANCERS MISCONFIGURATION SLOW LIBRARIES BAD DAY LOGGING RUBY DAEMONS BUGS KERNEL …
10. HOW CAN WE DEAL WITH ISSUES? unit testing integration testing micro-benchmarking macro-benchmarking ~ ~ we know a bit about testing software, right?
11. MICRO-BENCHMARKS prove that components work avoid dependencies are usually quick and simple are use-case specific don’t test glue code don’t catch side-effects
12. MACRO-BENCHMARKS show that whole system performs test dependencies and side-effects can show things you never expected are difficult and time-consuming need systematic approach make finding some issues difficult
13. EVOLUTION monolithic script ran manually local micro-benchmarks and spreadsheets distributed version of micro-benchmarks supervised workers automatic metric recording more types of benchmarks implementing indexer ???
14. GOOD PRACTICES start with micro-benchmarks build them up to proper integration tests when in trouble, profile change one variable at a time monitor everything you can, seriously work on your graphs, text sucks
15. THE FRAMEWORK
16. api api socket socket socket
17. WORKERS do the actual work send api requests listen on WebSocket connections gather client metrics have different roles (api, socket) independent of each other live outside of Pusher’s cluster
18. api api socket socket socket api worker socket worker socket worker socket worker socket worker
19. MONITORS report metrics from the system run inside Pusher’s cluster
20. api api socket socket socket api worker socket worker socket worker socket worker socket worker monitor monitor monitor monitor monitor
21. SUPERVISOR keeps track of workers & monitors assigns roles and tasks synchronizes other processes
22. api api socket socket socket supervisor api worker socket worker socket worker socket worker socket worker monitor monitor monitor monitor monitor
23. REDIS message bus (pub/sub) one channel per process temporary storage
24. api api socket socket socket supervisor api worker socket worker socket worker socket worker socket worker monitor monitor monitor monitor monitor
25. REPORTING METRICS all workers report their data to logs JSON objects, basically no schema logs are streamed to a central place currently using just rsyslog
26. api api socket socket socket supervisor api worker socket worker socket worker socket worker socket worker monitor monitor monitor monitor monitor logs
27. INDEXER reads logs in real-time extracts and aggregates data stores indexed metrics in db… …which temporarily is Redis can update graphs using Pusher
28. api api socket socket socket supervisor api worker socket worker socket worker socket worker socket worker monitor monitor monitor monitor monitor indexer logs
29. BENCHMARK SPECIFICATION benchmark name number of connections number of channels number of connections per channel socket/api hosts, keys number of workers of each type per host list of tasks for each type of workers metrics to collect on workers monitor hosts metrics to collect on monitors steps to prepare for benchmark
30. IMPLEMENTED IN COFFEESCRIPT
31. INDEXER
32. GOALS store benchmarks as cheaply as possible potentially gigabytes of data per run separate data storage from load generation allow adding metric views without: changing benchmarking code re-running benchmarks
33. METRIC CACHE represents smallest piece of aggregated data benchmark-wide: start/finish time per-second: message latency fetches existing data on initialization three methods update – metric specific store – saves data in the db is dirty? – true if modified since last store
34. indexer log entry processor #1 processor #2 processor #3 cache #1 cache #2 cache #3 cache #4 benchmark cache per-second benchmark cache database
35. indexer log entry processor #1 processor #2 processor #3 cache #1 cache #2 cache #3 cache #4 benchmark cache per-second benchmark cache database
36. indexer log entry processor #1 processor #2 processor #3 cache #1 cache #2 cache #3 cache #4 benchmark cache per-second benchmark cache database
37. indexer log entry processor #1 processor #2 processor #3 cache #1 cache #2 cache #3 cache #4 benchmark cache per-second benchmark cache database
38. FAULT TOLERANCE what if indexer fails in the middle of file? file is potentially several GB of size re-indexing is not an option what if logs are being delayed?
39. indexer log entry processor #1 processor #2 processor #3 cache #1 cache #2 cache #3 cache #4 benchmark cache per-second benchmark cache log offset state
40. indexer log entry processor #1 processor #2 processor #3 cache #1 cache #2 cache #3 cache #4 benchmark cache per-second benchmark cache log offset state
41. RECOVERY 1. start the process 2. fetch whole state from Redis 3. restore caches 4. start reading from saved offset
42. IMPLEMENTED IN RUBY
43. NODE.JS
44. KNOW YOUR GARBAGE COLLECTOR
45. DOS AND DON’TS use short-living objects minimize # of long-living objects profile gc (--trace_gc, etc.) premature optimization buffer pools on V8 heap
46. TRUST V8
47. V8 performance of v8 is decent writing JS is much easier… …not to mention debugging see Felix Geisendörfer’s talk C++ is premature optimization
48. DON’T TRUST NPM
49. DON’T TRUST NPM … YET
50. MANY NPM MODULES untested unmaintained over-engineered npm spam obviously, there are good modules this should change with time
51. SUB-SECOND METRICS
52. 1 SECOND IS NOT GRANULAR ENOUGH we can send messages with few ms latency aggregates hide some issues garbage collection specific code inefficiencies care about percentiles, not averages
54. MONITOR EVENT LOOP
55. SIMPLE TRICK 1. use setInterval with 10ms delay 2. every tick increment value of current time window 3. show on a graph like 2 slides before visualize delays as a sub-second heatmap
56. FUTURE
57. FUTURE store more metrics test for more use-cases update graphs in real-time run benchmarks continuously generate reports automatically easier setup
58. THANKS! Paweł Ledwoń @pawel_ledwon github.com/pl
