Deep Learning for Fonts

We talk about the motivation to build a font classifier, how we did it, challenges and what we aim to achieve

Transcript

1. Deep Learning for Fonts | Fontastic
   Deep Learning for Fonts | Fontastic
   Nischal HP | @nischalhp | VP, Engineering, omni:us
   Raghotham S | @raghothams | Senior Data Scientist, Ericsson
   Research
   Strata Data Conference 2019, London
   Strata Data Conference 2019, London


   View Slide

2. Fontastic
   Fontastic
   Motivation
   Motivation


   View Slide

3. Fontastic
   Fontastic
   Existing Tools | What The Font
   Existing Tools | What The Font


   View Slide

4. Fontastic
   Fontastic
   Existing Tools | What Font is?
   Existing Tools | What Font is?


   View Slide

5. Fontastic
   Fontastic
   Existing Tools | What Font is?
   Existing Tools | What Font is?


   View Slide

6. Fontastic
   Fontastic
   Existing Tools | Matcherator
   Existing Tools | Matcherator


   View Slide

7. View Slide

8. Fontastic
   Fontastic
   What do we aim to do?
   What do we aim to do?


   View Slide

9. Deep Learning for Humans
   Deep Learning for Humans
   Fontastic
   Upcoming
   Projects


   View Slide

10. Fontastic
    Fontastic
    Agenda
    Agenda
    Data acquisition
    Model building
    Feature
    visualization


    View Slide

11. Fontastic
    Fontastic
    Data Acquisition
    Data Acquisition


    View Slide

12. Data Acquisition
    Data Acquisition
    Pass 1: Scrape Font Squirel -
    Pass 1: Scrape Font Squirel - https:/
    /www.fontsquirrel.com/
    (https:/
    /www.fontsquirrel.com/)


    View Slide

13. View Slide

14. Problems
    1. We have images of different dimensions
    2. Even with normalizing the size, we will end up with 5-10 images per
    style


    View Slide

15. Data Acquisition
    Data Acquisition
    Pass 2: Scrape DaFont -
    Pass 2: Scrape DaFont - https:/
    /www.dafont.com/ (https:/
    /www.dafont.com/)


    View Slide

16. Problems
    1. Old school fonts only, not updated frequently
    2. Supports only wide dimension, might not work well with inteded end
    use


    View Slide

17. Data Acquisition
    Data Acquisition
    Pass 3: Generate Image using PIL
    Pass 3: Generate Image using PIL
    Steps
    Steps
    1. Create 4 set of random texts
    2. Generate 4k resolution image using the TTF for every random
    text
    3. Take 10 random crop of size 256x256 px from the 4k image
    With this we have the ability to generate large number of training images


    View Slide

18. Data Acquisition
    Data Acquisition
    Pass 3: Generate Image using PIL
    Pass 3: Generate Image using PIL
    Advantages
    Advantages
    1. We control the input text
    2. We control the font style and size
    3. We control the output image
    dinemsion


    View Slide

19. Data Acquisition
    Data Acquisition
    Pass 3: Generate Image using PIL
    Pass 3: Generate Image using PIL


    View Slide

20. Data Acquisition
    Data Acquisition
    Pass 3: Generate Image using PIL + Random Crop
    Pass 3: Generate Image using PIL + Random Crop


    View Slide

21. View Slide

22. Data Acquisition
    Data Acquisition
    Pass 3: Generate Image using PIL + Random Crop
    Pass 3: Generate Image using PIL + Random Crop


    View Slide

23. Fontastic
    Fontastic
    Model Building
    Model Building


    View Slide

24. Model Building
    Model Building
    Phase I | Feasibility Check - FastAI
    Phase I | Feasibility Check - FastAI
    In [30]: PATH = "data/"
    sz=225
    arch=resnet50
    bs=28
    tfms = tfms_from_model(arch, sz, aug_tfms=transforms_side_on, max_zoom=1.1)
    data = ImageClassifierData.from_paths(PATH, tfms=tfms, bs=bs, num_workers=4)
    learn = ConvLearner.pretrained(arch, data, precompute=True, ps=0.5)
    learn.unfreeze()
    lr=np.array([1e-4,1e-3,1e-2])
    learn.fit(lr, 6, cycle_len=1)
    [0. 1.05857 0.88758 0.6628 ]
    [1. 0.69731 0.59468 0.77709]
    [2. 0.51771 0.45974 0.84326]
    [3. 0.4064 0.35457 0.86119]
    [4. 0.34457 0.32807 0.87547]
    [5. 0.26355 0.24554 0.91429]


    View Slide

25. Model Building - Feasibility Check - FastAI
    Model Building - Feasibility Check - FastAI
    In [42]: cm = confusion_matrix(y, preds)
    plot_confusion_matrix(cm, data.classes)
    [[200 0 3 3 0 3 7]
    [ 0 94 0 0 0 0 2]
    [ 3 0 423 1 0 5 0]
    [ 4 0 0 105 0 0 11]
    [ 0 0 0 0 179 0 1]
    [ 3 0 18 0 0 195 0]
    [ 3 0 0 3 2 2 206]]


    View Slide

26. Model Building - 70 Fonts - PyTorch
    Model Building - 70 Fonts - PyTorch
    Why PyTorch?
    Why PyTorch?
    Easy to customize
    Flexible to integrate with other visualization
    projects


    View Slide

27. Model Building - 70 Fonts - PyTorch
    Model Building - 70 Fonts - PyTorch
    Pretrained Model ResNet50
    Pretrained Model ResNet50
    What is pretrained model? What is transfer learning?


    View Slide

28. Image Courtsey - https://medium.com/kansas-city-machine-learning-arti cial-
    intelligen/an-introduction-to-transfer-learning-in-machine-learning-7efd104b6026


    View Slide

29. Model Building - 70 Fonts - PyTorch
    Model Building - 70 Fonts - PyTorch
    Hyper Parameter Tuning
    Hyper Parameter Tuning
    Learning
    Rate
    In [23]: lrf.plot()


    View Slide

30. Model Building - 70 Fonts - PyTorch
    Model Building - 70 Fonts - PyTorch
    Hyper Parameter Tuning
    Hyper Parameter Tuning
    Learning Rate
    Scheduler
    In [ ]: # Get Pretrained Model
    model_ft = models.resnet50(pretrained=True)
    # Customize FC Layer
    num_frts = model_ft.fc.in_features
    model_ft.fc = nn.Linear(num_frts, len(class_names))
    model_ft = model_ft.to(device)
    criterion = nn.CrossEntropyLoss()
    # Define optimizer & LR Scheduler
    optimizer_ft = optim.SGD(model_ft.parameters(), lr=0.01, momentum=0.9)
    exp_lr_scheduler = lr_scheduler.StepLR(optimizer_ft, step_size=7, gamma=0.1)


    View Slide

31. Model Building - 70 Fonts - PyTorch
    Model Building - 70 Fonts - PyTorch
    Result - without LR nder & scheduler
    Result - without LR nder & scheduler
    0.74 f1-score after 40 epochs
    0.74 f1-score after 40 epochs


    View Slide

32. Model Building - 70 Fonts - PyTorch
    Model Building - 70 Fonts - PyTorch
    Result - with LR nder & scheduler
    Result - with LR nder & scheduler
    0.96 f1-score after 40 epochs
    0.96 f1-score after 40 epochs


    View Slide

33. Fontastic
    Fontastic
    Feature Visualization
    Feature Visualization
    Mechanism to See through the eyes of network


    View Slide

34. Feature Visualization
    Feature Visualization
    Gradcam Analysis
    Gradcam Analysis
    In [27]: import pickle
    from ipywidgets import interact, interactive, fixed, interact_manual
    import ipywidgets as widgets
    import matplotlib.pyplot as plt
    with open('./fd727d3f-73f4-4ec6-8e89-3e15fd3801b0resnet50_grad_cam', 'rb') as f:
    data = pickle.load(f)
    def show_cam(epoch_slider, image_slider, layer_slider):
    plt.imshow(data[epoch_slider][image_slider][layer_slider])


    View Slide

35. Feature Visualization
    Feature Visualization
    Gradcam Analysis
    Gradcam Analysis
    In [28]: interact(show_cam, epoch_slider=widgets.IntSlider(min=0, max=len(data)-1, step=1, value=
    0),
    image_slider=widgets.IntSlider(min=0, max=len(data[0])-1, step=1, val
    ue=0),
    layer_slider=widgets.IntSlider(min=0, max=len(data[0][0])-1, step=1,
    value=0))
    Out[28]:


    View Slide

36. Feature Visualization
    Feature Visualization
    Activation Atlas
    Activation Atlas
    Activation Atlases not only reveal visual abstractions within a model, but they can reveal
    high-level misunderstandings in a model that can be exploited. For example, by looking at
    an activation atlas we will be able to see why a picture of a baseball can switch the
    classi cation of an image from “grey whale” to “great white shark”.


    View Slide

37. Feature Visualization
    Feature Visualization
    Activation Atlas -
    Activation Atlas - https:/
    /distill.pub/2019/activation-atlas/
    (https:/
    /distill.pub/2019/activation-atlas/)


    View Slide

38. Extra
    Extra
    Remote Work
    Remote Work


    View Slide

39. Open Source
    Open Source
    https:/
    /github.com/deep-learning-for-humans/fontastic
    (https:/
    /github.com/deep-learning-for-humans/fontastic)


    View Slide

40. Fin.
    Fin.
    GH / twitter / everywhere
    GH / twitter / everywhere
    @nischalhp
    @raghothams
    https://github.com/deep-learning-for-humans/fontastic (https://github.com/deep-
    learning-for-humans/fontastic)


    View Slide
