Writing Android Libraries

Presented to the Bay Area Android Group on March 25th 2015

Transcript

1. Writing Android Libraries Emanuele Zattin March 23, 2015 Bay Area Android Developer Group
2. Emanuele Zattin Born and raised in Padova, Italy Living in Copenhagen, Denmark since 2005 Automation enthusiast Jenkins CI contributor since 2010 Java developer at Realm About me
3. Embedded on-device mobile database Easy — saves app makers months of time Cross-platform — iOS & Android for now. More are coming Fast — way faster than existing solutions About Realm
4. Why would you want to write a library?
5. Modularity Why would you want to write a library?
6. Modularity Reusability Why would you want to write a library?
7. Modularity Reusability Vanity Why would you want to write a library?
8. Your code depends on Android idioms: • UI • Looper/Handler • Sensors • Native code • Many more! Why writing an Android library?
9. How hard can it be right? Just fire Android Studio up and start a new project! Step one: Getting started!
10. Android Studio supports the creation of: Step one: Getting started! Application Library New project ✓ ✗ New module ✓ ✓
11. Option 1: Android Studio 1. Create a new application project 2. Add a library module 3. Remove the application module Step one: Getting started!
12. Option 2: The Command Line $ android create lib-project -t 1 -k it.droidcon.awesomelib -p . -g -v 1.1.3 -t: target (Use android  list  targets to get a list of target ids) -k: package name -p: path to the project -g: make it a Gradle project (requires SDK >= 19) -v: version of the Android Gradle plugin to use Step one: Getting started!
13. Step one: Getting started!
14. Step two: Code, code, code!
15. API Design It’s a huge subject that goes far beyond this presentation but here are some pointers and reference: Effective Java 2, Joshua Bloch How To Design A Good API and Why it Matters, Joshua Bloch Step two: Code, code, code!
16. Characteristics of a good API (Joshua Bloch) • Easy to learn • Easy to use, even without documentation • Hard to misuse • Easy to read and maintain code that uses it • Sufficiently powerful to satisfy requirements • Easy to extend • Appropriate to audience Step two: Code, code, code!
17. Testing is universally important but even more so for libraries Step three: Test
18. Testing is universally important but even more so for libraries Testing an Android library is just like testing an Android application Step three: Test
19. Testing is universally important but even more so for libraries Testing an Android library is just like testing an Android application Yes, JUnit 3 is not so good and lacks a particularly important feature when testing libraries: parametric tests Step three: Test
20. Testing is universally important but even more so for libraries Testing an Android library is just like testing an Android application Yes, JUnit 3 is not so good and lacks a particularly important feature when testing libraries: parametric tests Luckily there’s a solution: Burst Step three: Test
21. Automate your tests! Jenkins is a wonderful tool for this. It offers more than one thousand plugins some of which specialised for Android development. Step three: Test
22. Some must-have Jenkins plugins include: Step three: Test
23. Some must-have Jenkins plugins include: • Job Config History plugin Step three: Test
24. Some must-have Jenkins plugins include: • Job Config History plugin • Git plugin Step three: Test
25. Some must-have Jenkins plugins include: • Job Config History plugin • Git plugin • Gradle plugin Step three: Test
26. Some must-have Jenkins plugins include: • Job Config History plugin • Git plugin • Gradle plugin • Android Emulator plugin Step three: Test
27. Some must-have Jenkins plugins include: • Job Config History plugin • Git plugin • Gradle plugin • Android Emulator plugin • Jenkins comes with JUnit and Matrix job support out of the box Step three: Test
28. Another useful way to test your library (and showcase it) is to write one or more example apps. Step three: Test
29. Another useful way to test your library (and showcase it) is to write one or more example apps. Running monkey on the app ensures it doesn’t suffer from crashes and ANRs Step three: Test
30. Another useful way to test your library (and showcase it) is to write one or more example apps. Running monkey on the app ensures it doesn’t suffer from crashes and ANRs A useful Gradle plugin:
 https://github.com/novoda/gradle-android-command-plugin Step three: Test
31. Aar vs Jar Step four: Publish
32. Aar vs Jar • Aar is supported by Gradle and Android Studio Step four: Publish
33. Aar vs Jar • Aar is supported by Gradle and Android Studio • Aar is not supported by Ant and Eclipse Step four: Publish
34. Aar vs Jar • Aar is supported by Gradle and Android Studio • Aar is not supported by Ant and Eclipse • Using local Aar files is not trivial Step four: Publish
35. Aar vs Jar • Aar is supported by Gradle and Android Studio • Aar is not supported by Ant and Eclipse • Using local Aar files is not trivial • Do you want to support Eclipse? Use Jar! Step four: Publish
36. The Android Gradle plugin will generate an Aar file How to generate a Jar instead?
 The Aar actually contains our Jar already! task generateJar(type: Copy) { group 'Build' description 'blah blah...' dependsOn assemble from 'build/intermediates/bundles/release/classes.jar' into 'build/libs' rename('classes.jar', 'awesome-library.jar') } Step four: Publish
37. Where to publish? Step four: Publish
38. Bintray requires a source Jar task androidSourcesJar(type: Jar) { from android.sourceSets.main.java.srcDirs } Step four: Publish
39. Bintray also requires a Javadoc Jar android.libraryVariants.all { variant -> task("javadoc${variant.name.capitalize()}", type: Javadoc) { description "Generates Javadoc for $variant.name." group 'Docs' source = variant.javaCompile.source ext.androidJar = files(plugins .findPlugin(“com.android.library") .getBootClasspath()) classpath = files(variant.javaCompile.classpath.files) + ext.androidJar exclude '**/BuildConfig.java' exclude '**/R.java' } } Step four: Publish
40. Bintray also provides a Gradle plugin for the actual publishing https://github.com/bintray/gradle-bintray-plugin The configuration is not trivial, and in the beginning it might be easier to just do the release manually on the binary website Step four: Publish
41. Annotation processing is a functionality of javac used for scanning and processing annotations at compile time Advanced Topics: Annotation Processor
42. Annotation processing is a functionality of javac used for scanning and processing annotations at compile time You can write your own annotation processor. Advanced Topics: Annotation Processor
43. Annotation processing is a functionality of javac used for scanning and processing annotations at compile time You can write your own annotation processor. Problems that annotation processing is good at solving: Advanced Topics: Annotation Processor
44. Annotation processing is a functionality of javac used for scanning and processing annotations at compile time You can write your own annotation processor. Problems that annotation processing is good at solving: • Boilerplate removal Advanced Topics: Annotation Processor
45. Annotation processing is a functionality of javac used for scanning and processing annotations at compile time You can write your own annotation processor. Problems that annotation processing is good at solving: • Boilerplate removal • Introspection removal Advanced Topics: Annotation Processor
46. Popular Android libraries using annotation processing: Advanced Topics: Annotation Processor
47. Popular Android libraries using annotation processing: • Dagger Advanced Topics: Annotation Processor
48. Popular Android libraries using annotation processing: • Dagger • Butter Knife Advanced Topics: Annotation Processor
49. Popular Android libraries using annotation processing: • Dagger • Butter Knife • Autovalue/Autoparcel Advanced Topics: Annotation Processor
50. Popular Android libraries using annotation processing: • Dagger • Butter Knife • Autovalue/Autoparcel • Realm Advanced Topics: Annotation Processor
51. Bad news! The Android API does not support the
 javax.annotation.processing package Advanced Topics: Annotation Processor
52. Create two new java sub-projects: • annotations (used both by the library and the processor) • annotations processor Advanced Topics: Annotation Processor
53. The Jar task will need to be modified: task androidJar(type: Jar) { dependsOn assemble group 'Build' description ‘blah blah’ from zipTree( 'build/intermediates/bundles/release/classes.jar') from zipTree( '../annotations-processor/build/libs/processor.jar') from zipTree( '../annotations/build/libs/annotations.jar') } Advanced Topics: Annotation Processor
54. The javadoc tasks will also have to be modified: android.libraryVariants.all { variant -> task("javadoc${variant.name.capitalize()}", type: Javadoc) { description "Generates Javadoc for $variant.name." group 'Docs' source = variant.javaCompile.source source "../annotations/src/main/java" ext.androidJar = files(plugins .findPlugin(“com.android.library") .getBootClasspath()) classpath = files(variant.javaCompile.classpath.files) + ext.androidJar exclude '**/BuildConfig.java' exclude '**/R.java' } } Advanced Topics: Annotation Processor
55. NDK Advanced Topics: Native code
56. NDK Advanced Topics: Native code
57. WARNING  [Project:  :lib]   Current  NDK  support  is  deprecated.   Alternative  will  be  provided  in  the  future. Advanced Topics: Native code
58. Advanced Topics: Native code
59. Solution 1 Ignore Google’s warning and keep using the Gradle NDK support. It works* but there is one missing feature: no ldFlags ndk  {        moduleName  "sanangeles"        cFlags  "-­‐DANDROID_NDK  -­‐DDISABLE_IMPORTGL"        ldLibs  "GLESv1_CM",  "dl",  "log"        stl  "stlport_static"   }   *for some definition of “works” Advanced Topics: Native code
60. Solution 2 Gradle native plugin Gotchas: • Requires extra logic to handle standalone toolchains • It might soon become obsolete Advanced Topics: Native code
61. How to include the native libraries in the Jar file? $ tree . !"" META-INF # $"" MANIFEST.MF !"" com # $"" amazing-library # $"" AmazingLibrary.class $"" lib !"" armeabi # $"" amazing-library.so !"" armeabi-v7a # $"" amazing-library.so $"" x86 $"" amazing-library.so Advanced Topics: Native code
62. How to generate the jar file in Gradle? task  androidJar(type:  Jar,  dependsOn:  ['assemble'])  {        group  'Build'        description  ‘blah  blah'        from  zipTree('build/intermediates/bundles/release/classes.jar')        from(file('src/main/jniLibs'))  {              into  'lib'        }   }   Advanced Topics: Native code
63. Takeaways
64. • Embrace Gradle Takeaways
65. • Embrace Gradle • Explore Gradle plugins Takeaways
66. • Embrace Gradle • Explore Gradle plugins • Automate your tests Takeaways
67. • Embrace Gradle • Explore Gradle plugins • Automate your tests • Bintray is the go-to solution for publishing Takeaways
68. • Embrace Gradle • Explore Gradle plugins • Automate your tests • Bintray is the go-to solution for publishing • Writing libraries rocks! Takeaways
69. Questions?
