Embrace the Anarchy : Apache Kafka's Role in Modern Data Architectures

Building a flexible, scalable, real-time data architecture for the enterprise is no simple matter. Rarely does one single technology suit for all requirements, and frequently many different teams are involved which drives solutions with varying levels of [dis-]integration.
Apache Kafka is a streaming platform that acts as the 'data backbone' for the enterprise. By streaming events into Kafka as they occur, they can be used in any dependent system, in real time or batch. Search replicas, NoSQL stores, caches, graph databases - these all have their place in solving specific requirements, and all need to be fed with data! Kafka is the enabling platform that supports the real-time, high performance, scalable integration of data throughout the enterprise, whilst also providing the messaging capabilities to drive applications directly.
This talk will discuss the role and benefits of Kafka in an architecture, the Kafka ecosystem, and several design patterns used to address specific challenges that organisations face with managing their flows and availability of data.

Transcript

1. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 1
   Apache Kafka's Role in
   Modern Data Architectures
   Embrace the Anarchy :
   Robin Moffatt / Confluent
   Photo by Jaak Horn on Unsplash


   View Slide

2. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 2
   • Developer Advocate @ Confluent
   • Working in data & analytics since 2001
   • Oracle Developer Champion
   • Blogging : http://rmoff.net & http://cnfl.io/rmoff
   • Twitter: @rmoff
   • Geek stuff
   • Beer & Fried Breakfasts
   $ whoami
   https://speakerdeck.com/rmoff/


   View Slide

3. “
   @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
   Apache Kafka is a
   Streaming Platform


   View Slide

4. “
   @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
   Why do we need a
   streaming platform?


   View Slide

5. “
   @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
   One of the reasons:
   Decoupling


   View Slide

6. “
   @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
   A case in point…Analytics


   View Slide

7. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 7
   Sales DWH
   Analytics—In the beginning…


   View Slide

8. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 8
   Sales DWH
   Inventory
   And then there were more data sources…


   View Slide

9. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 9
   Sales DWH
   Inventory
   Batch Transformations … (ETL / ELT)


   View Slide

10. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 10
    Sales DWH
    Inventory Data Lake
    Add a Data Lake…


    View Slide

11. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 11
    Sales
    Inventory Data Lake
    …or Replace the Data Warehouse


    View Slide

12. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 12
    Sales
    Inventory Data Lake
    Still need to do Batch transformations…


    View Slide

13. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 13
    Want your data anytime ?
    Batch is Latency built in by Design


    View Slide

14. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 14
    Photo by Denys Nevozhai on Unsplash
    Microservices Mobile Machine

    Learning
    Internet of

    Things
    The World has Changed


    View Slide

15. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 15
    Photo by Rosie Fraser on Unsplash
    Lots of new technologies
    (whether you like it or not)


    View Slide

16. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 16
    App App App App
    search
    Hadoop
    DWH
    monitoring security
    MQ MQ
    cache
    cache


    View Slide

17. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 17
    KAFKA
    DWH Hadoop
    App
    App App App App
    App
    App
    App
    request-response
    messaging
    OR
    stream
    processing
    streaming data pipelines
    changelogs


    View Slide

18. “
    @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
    Apache Kafka is a
    Streaming Platform


    View Slide

19. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
    Three Lenses
    19


    View Slide

20. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
    01
    Messaging
    Done Right
    02
    Scalable Streaming

    Data Pipelines
    03
    Foundation for

    Stream Processing
    20
    What is Apache Kafka?


    View Slide

21. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
    Scalability True Storage Real-Time
    Processing
    21
    Lens 1: Messaging Done Right


    View Slide

22. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 22
    Lens 2: Scalable Streaming Data Pipelines


    View Slide

23. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
    Lens 3: Foundation for Stream Processing
    KSQL
    is the
    Streaming
    SQL Engine
    for
    Apache Kafka
    23


    View Slide

24. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 24
    The Streaming Platform


    View Slide

25. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 25
    The Streaming Platform
    Event-Driven
    Scalable
    Decoupled


    View Slide

26. “
    @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
    Bold claim: all your data
    is event streams


    View Slide

27. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 27
    A Customer
    Experience


    View Slide

28. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 28
    A Sale


    View Slide

29. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 29
    A Sensor
    Reading


    View Slide

30. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 30
    An Application
    Log Entry


    View Slide

31. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 31
    Databases


    View Slide

32. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 32
    Do you think that’s a table
    you are querying?


    View Slide

33. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 33
    The Table Stream Duality
    Account ID Balance
    12345 €50
    Account ID Amount
    12345 + €50
    12345 + €25
    12345 -€60
    Account ID Balance
    12345 €75
    Account ID Balance
    12345 €15
    Time
    Stream Table


    View Slide

34. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 34
    The truth is the log.
    The database is a cache
    of a subset of the log.
    —Pat Helland
    Immutability Changes Everything
    http://cidrdb.org/cidr2015/Papers/CIDR15_Paper16.pdf
    Photo by Bobby Burch on Unsplash


    View Slide

35. “
    @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
    A Brief Look at
    Kafka's Technology


    View Slide

36. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 36
    Apache Kafka
    Reads are a single seek & scan
    Writes are
    append only
    Kafka
    A Distributed Commit Log. Publish and subscribe to

    streams of records. Highly scalable, high throughput.

    Supports transactions. Persisted data. Stream processing.
    Producer & Consumer APIs
    Open-source client libraries for numerous
    languages, to directly integrate with your
    applications.


    View Slide

37. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 37
    Apache Kafka
    Orders
    Table
    Customers
    Kafka Streams API
    Kafka Connect API
    Reliable and scalable integration of Kafka
    with other systems – no coding required.
    Kafka Streams API
    Write standard Java applications & microservices

    to process your data in real-time


    View Slide

38. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
    Declarative
    Stream
    Language
    Processing
    KSQL
    is a


    View Slide

39. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
    KSQL
    is the
    Streaming
    SQL Engine
    for
    Apache Kafka


    View Slide

40. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 40
    KSQL in Development and Production
    Interactive KSQL

    for development and testing
    Headless KSQL

    for Production
    Desired KSQL queries
    have been identified
    REST
    “Hmm, let me try

    out this idea...”


    View Slide

41. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 41
    • Log data monitoring, tracking and alerting
    • syslog data
    • Sensor / IoT data
    CREATE STREAM SYSLOG_INVALID_USERS AS
    SELECT HOST, MESSAGE
    FROM SYSLOG
    WHERE MESSAGE LIKE '%Invalid user%';
    http://cnfl.io/syslogs-filtering / http://cnfl.io/syslog-alerting
    KSQL for Real-Time Monitoring


    View Slide

42. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 42
    CREATE TABLE possible_fraud AS

    SELECT card_number, count(*)

    FROM authorization_attempts

    WINDOW TUMBLING (SIZE 5 SECONDS)

    GROUP BY card_number

    HAVING count(*) > 3;
    Identifying patterns or anomalies in real-time data,
    surfaced in milliseconds
    KSQL for Anomaly Detection


    View Slide

43. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 43
    CREATE STREAM vip_actions AS

    SELECT userid, page, action
    FROM clickstream c
    LEFT JOIN users u
    ON c.userid = u.user_id

    WHERE u.level = 'Platinum';
    Joining, filtering, and aggregating streams of event data
    KSQL for Streaming ETL


    View Slide

44. “
    @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
    What Problems does
    Kafka Solve?


    View Slide

45. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 45
    Streaming
    Platform
    “A product was viewed”
    Hadoop
    Web
    app
    Event-Centric Thinking


    View Slide

46. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 46
    Event-Centric Thinking
    Streaming
    Platform
    “A product was viewed”
    Hadoop
    Web
    app
    mobile
    app
    APIs


    View Slide

47. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 47
    Event-Centric Thinking
    mobile
    app
    web
    app
    APIs
    Streaming
    Platform
    Hadoop
    Security
    Monitoring
    Rec
    engine
    “A product was viewed”


    View Slide

48. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 48
    Producer Consumer
    System Availability and Event Buffering


    View Slide

49. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 49
    Producer Consumer
    System Availability and Event Buffering


    View Slide

50. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 50
    Consumer A
    Producer
    24hr batch
    extract
    Varying Latency Requirements / Batch vs Stream


    View Slide

51. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 51
    Producer
    24hr batch
    extract
    Consumer A
    Consumer B
    Varying Latency Requirements / Batch vs Stream


    View Slide

52. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 52
    Producer
    24hr batch
    extract
    Consumer A
    Consumer B
    Varying Latency Requirements / Batch vs Stream


    View Slide

53. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 53
    Producer
    24hr batch extract
    Realtime
    Consumer A
    Consumer B
    Varying Latency Requirements / Batch vs Stream


    View Slide

54. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 54
    Producer
    24hr batch extract
    Realtime
    Consumer A
    Consumer B
    Varying Latency Requirements / Batch vs Stream


    View Slide

55. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 55
    Producer Consumer A
    24hr batch extract
    Realtime
    Realtime
    Consumer B
    Varying Latency Requirements / Batch vs Stream


    View Slide

56. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 56
    Technology & Code/Algo Version Changes
    Producer
    Consumer
    (v1)


    View Slide

57. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 57
    Technology & Code/Algo Version Changes
    Producer
    Consumer
    (v1)
    Consumer
    (V2)


    View Slide

58. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 58
    Technology & Code/Algo Version Changes
    Producer
    Consumer
    (V2)


    View Slide

59. “
    @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
    Architectural Patterns
    with Apache Kafka


    View Slide

60. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 60
    Photo by Christopher Burns on Unsplash
    Building for the
    Future


    View Slide

61. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 61
    Tightly-coupled =
    Inflexible


    View Slide

62. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 62
    Analytics - Database Offload
    HDFS / S3 /
    BigQuery etc
    RDBMS
    CDC


    View Slide

63. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 63
    Stream Processing with Apache Kafka and KSQL
    order events
    customer
    customer orders
    Stream
    Processing
    RDBMS CDC


    View Slide

64. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 64
    Real-time Event Stream Enrichment
    order events
    customer
    Stream
    Processing
    customer orders
    RDBMS

    CDC


    View Slide

65. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 65
    Transform Once, Use Many
    order events
    customer
    Stream
    Processing
    customer orders
    RDBMS

    New App

    CDC


    View Slide

66. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 66
    Transform Once, Use Many
    order events
    customer
    Stream
    Processing
    customer orders
    RDBMS

    HDFS / S3 / etc
    New App

    CDC


    View Slide

67. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 67
    Evolve processing from old systems to new
    Stream
    Processing
    RDBMS
    Existing
    App
    CDC
    New App



    View Slide

68. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 68
    Evolve processing from old systems to new
    Stream
    Processing
    RDBMS
    Existing
    App
    New App

    New App

    CDC


    View Slide

69. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 69
    Want your data anytime ?
    Batch is Latency built in by Design
    You say that like
    "latency" is a synonym
    for "evil"


    View Slide

70. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 70
    It's all about the Events!


    View Slide

71. “
    @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
    So…Analytics and Kafka


    View Slide

72. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 72
    The Vision!
    "One
    version
    of the
    truth"


    View Slide

73. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 73
    The Reality…


    View Slide

74. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 74
    Pragmatism is…
    "One version
    of the truth"


    View Slide

75. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 75
    Streaming Platform
    Stream
    Processing
    "One version
    of the truth"


    View Slide

76. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 76
    Streaming Platform
    M L App
    NoSQL
    Search
    Graph
    Stream
    Processing
    "One version
    of the truth"


    View Slide

77. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures
    Database Changes Log Events loT Data Web Events …
    CRM
    Data Warehouse
    Database
    Hadoop
    Data

    Integration
    …
    Monitoring
    Analytics
    Custom Apps
    Transformations
    Real-time Applications
    …
    Apache Open Source Confluent Open Source Confluent Enterprise
    Confluent Platform
    Confluent Platform
    Apache Kafka®
    Core | Connect API | Streams API
    Data Compatibility
    Schema Registry
    Monitoring & Administration
    Confluent Control Center | Security
    Operations
    Replicator | Auto Data Balancing
    Development and Connectivity
    Clients | Connectors | REST Proxy | CLI
    Apache Open Source Confluent Open Source Confluent Enterprise
    SQL Stream Processing
    KSQL
    77
    Confluent Open Source :
    Apache Kafka with a bunch of cool stuff! For free!


    View Slide

78. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 78
    Free Books!
    https://www.confluent.io/apache-kafka-stream-processing-book-bundle


    View Slide

79. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 79
    Confluent Streaming Event, Munich
    http://cnfl.io/streaming-event-munich


    View Slide

80. @rmoff
    robin@confluent.io
    https://www.confluent.io/download/
    http://cnfl.io/slack


    View Slide

81. @rmoff / Embrace the Anarchy—Apache Kafka's Role in Modern Data Architectures 81
    • CDC Spreadsheet
    • Blog: No More Silos: How to Integrate your Databases with Apache Kafka and CDC
    • #partner-engineering on Slack for questions
    • BD team (#partners / partners@confluent.io) can help with introductions on a given sales op
    Resources
    #EOF


    View Slide
