Introduction to Proto.Actor

Transcript

1. Roger Johansson Proto.Actor Founder Twitter: @rogeralsing Github: rogeralsing Mail: rogeralsing@gmail.com Github.com/rogeralsing/presentations Proto.Actor
2. Actor Model Three axioms: Send – an actor can send messages to other actors Create – an actor can create new actors Become – an actor can decide how to handle it’s next message ”An island of consistency in a sea of concurrency” ”Shared nothing”, ”Black box” ”Location transparent”, ”Distributable by design”
3. OOP Actor Model Behavior Stateful Synchronous method calls Behavior Stateful Asynchronous message passing OOP vs. Actor Model Why Actors?? The synchronous model has worked nicely for 60 years!?
4. Moore’s Law We can no longer build faster processors Instead, we stack them next to eachother and call them ”cores” 200 300 400 500 1000 1800 2530 3200 3600 2200 2930 3000 3200 3330 3330 3150 3200 3150 3150 3150 1 1 1 1 1 1 1 1 1 2 2 4 4 8 8 16 16 32 32 64 0 10 20 30 40 50 60 70 0 500 1000 1500 2000 2500 3000 3500 4000 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 MHZ and Cores per year Mhz Cores
5. CPU
6. Core Core Core Core
7. Code Invocation The invocation will run on a single core
8. Code Invocation Buying a larger CPU will not change this
9. Code Invocation Multithreading Multithreaded systems let us utilize more than one core
10. Multithreading Multithreaded systems let us utilize more than one core Code Invocation
11. Scale out When one CPU is no longer enough
12. Standard Technologies Elasticity: Scale out: RPC HTTP Queues Scale up: Threads Promises/Futures
13. Scale up: ”actor” package ”router” package Scale out: ”remote” package Elasticity: ”cluster” package
14. Scale up and out are essentially the same That is; we want to execute code ”somewhere”, on a core, on a machine, in a cluster. Why should we have to resort to different technologies to accomplish the same thing?
15. Scale up and out are essentially the same That is; we want to execute code ”somewhere”, on a core, on a machine, in a cluster. Why should we have to resort to different technologies to accomplish the same thing?
16. Event-driven thread ActorRef PID Actor State Supervision Children Mailbox Behavior Transport
17. Thread Pool Multiplex Scheduling Actor1 Actor1 Actor2 Actor2 Actor3 Actor4 Actor4 Actor1 Cheaper than threads, no context switching Actor3 Actor4 Actor2 Actor1 Actor3 Actor2 Time
18. ”actor” package
19. Demo – Create your first actor
20. ”remote” package
21. Demo – Build a chat
22. ”router” package
23. A router delegates messages to other ”routee” actors Group routers – delegate messages to your existing actors Pool routers – delegate messages to a dedicated pool of actors Routers
24. BroadcastRouter 1 2 1 2 1 2 1 2 Router Routee2 Routee3 Routee1 Notifies all ”routees”
25. RoundRobinRouter 1 2 1 2 3 3 4 4 Router Routee1 Routee2 Routee3 Scale up! .. Or down!
26. RoundRobinRouter Scale up! Routee1 Routee2 Routee3 Routee1 Routee2 Routee3 Routee1 Routee2 Routee3 Scale out! Remote1 Remote2 Remote3 Router Router Router Router
27. ConsistentHashRouter M Y M Y X A X A Router Routee1 Routee2 Routee3 Affinity between hash index and routee
28. ConsistentHashRouter Id: 789 Payment … Id: 123 Stop … Id:456 Create … Id: 123 Create … Router
29. ConsistentHashRouter Maps hash of 123 to routee1 Id: 123 Create … Id: 123 Stop … Id:456 Create … Id: 789 Payment … Routee1 Routee2 Routee3 Router Id: 789 Payment … Id: 123 Stop … Id:456 Create … Id: 123 Create …
30. Demo – Use routers RoundRobin
31. /c2 /b2 /b1 /a1 /a2 /b3 /c3 /c4 /c5 / /c1 /b1
33. Component Consumer 1 Consumer 2
34. Component Website Businesslogic
35. Service Request Application error Supervisor Manage failures Response Validation error Client
36. Supervision Every actor is being supervised by another actor that dictates how failures should be handled A supervisor can decide to: • Force a restart • Terminate • Ignore and resume • Escalate up to it’s own supervisor
37. /c2 /b2 /b1 /a1 /a2 /b3 /c3 /c4 /c5 / Error Kernel /c1 OneForOne supervisor AllForOne supervisor /b1 /b3
38. child parent Attempts Delay
39. DB Actor DB Query DB Result DB Up DB Query DB Error Poll DB Status DB Down
43. Node A 433 Node B 24345 Node C 82327 Hash: 989123 Node E 943772 Node D 612344 Node F 987234 Grain Id: Roger Names: Roger Names: Roger Actors: Roger : User
44. The End
45. Roger Johansson Proto.Actor Founder Twitter: @rogeralsing Github: rogeralsing Mail: rogeralsing@gmail.com Github.com/rogeralsing/presentations Proto.Actor
