Cassandra @ Teads

Read how we use Cassandra @ Teads: Architecture on AWS and physical nodes, tuning, issues, tools, our fork and more!

Teads is #1 in Video Ads. Read how Teads handles up to ~1 million requests/s with Apache Cassandra. How do we tuned Cassandra servers and clients. What issues we faced during the last year. How do we provision our clusters. Which tools are used: Datadog for monitoring and alerting, Cassandra reaper, Rundeck, Sumologic, cassandra_snapshotter. Why do we need a fork.

Transcript

1. Cassandra @ Lyon Cassandra Users Romain Hardouin - Cassandra architect @ Teads 2017-02-16
2. I. II. III. IV. V. VI. VII. VIII. Cassandra @ Teads About Teads Architecture Provisioning Monitoring & alerting Tuning Tools C’est la vie A light fork
3. I. About Teads
4. Teads is the inventor of native video advertising With inRead, an award-winning format* *IPA Media owner survey 2014, IAB recognized format
5. 27 offices in 21 countries 500+ Global employees 1.2B users Global reach 90+ R&D employees
6. Teads growth Tracking events
7. Advertisers (to name a few)
8. Publishers (to name a few)
9. II. Architecture
10. Custom C* 2.1.16  C* 3.0 jvm.options  C* 2.2 logback  Backports  Patches Apache Cassandra version Apache Cassandra version
11. Usage Usage Up to 940K qps: Writes vs Reads
12. Topology Topology 2 regions: EU & US  3rd region APAC coming soon 4 clusters 7 DC 110 nodes  Up to 150 with temporary DCs HP server blades 1 cluster 18 nodes
13. AWS nodes
14. i2.2xlarge 8 vCPU 61GB 2 x 800 GB attached SSD in RAID0 c3.4xlarge 16 vCPU 30GB 2 x 160 GB attached SSD in RAID0 c4.4xlarge 16 vCPU 30GB EBS 3.4 TB + 1 TB AWS instance types AWS instance types Tons of counters Big Data, wide rows Many billions keys, LCS with TTL
15. 20 x c4.4xlarge with SSD GP2  3.4 TB data 10,000 IOPS ⇒ 16KB  1 TB commitlog 3,000 IOPS ⇒ 16KB 25 tables: batch + real time Temporary DC Cheap storage, great for STCS Snapshots (S3 backup) No coupling between disks and CPU/RAM High latency => high I/O wait Throughput: 160 MB/s Unsteady performances More on EBS nodes More on EBS nodes
16. Physical nodes
17. HP Apollo XL170R Gen9 12 CPU Xeon @ 2.60GHz 128 GB RAM 3 x 1,5 TB High-end SSD in RAID0 Hardware nodes Hardware nodes For Big Data, supersedes EBS DC
18. DC/Cluster split
19. Instance type change Instance type change 20 x i2.2xlarge 20 x c3.4xlarge Counters Cheaper and more CPUs Counters Rebuild DC X DC Y
20. Workload isolation Workload isolation 20 x i2.2xlarge 20 x c3.4xlarge Counters + Big Data Counters 20 x c4.4xlarge Big Data EBS Step 1: DC split DC A DC B DC C Rebuild +
21. Workload isolation Workload isolation 20 x c4.4xlarge Big Data EBS Step 2: Cluster split Big Data AWS Direct Connect
22. Data model
23. “KISS” principle No fancy stuff  No secondary index  No list/set/tuple  No UDT
24. III. Provisioning
25. Capistrano Chef → Custom Cookbooks:  C*  C* tools  C* reaper  Datadog wrapper Chef provisioning to spawn a cluster Now Now
26. C* cookbook  michaelklishin/cassandra-chef-cookbook  + Teads custom wrapper Terraform + Chef provisioner Future Future
27. IV. Monitoring & alerting
28. Past Past OpsCenter (Free)
29. Turnkey dashboards Support is reactive Main metrics only Per host graphs  impossible with many hosts
30. Ring view More than monitoring Lots of metrics Still lacks some metrics Dashboard creation: no templates Agent is heavy Free version limitations:  Data stored in production cluster  Apache C* <= 2.1 only DataStax OpsCenter Free version (v5)
31. All metrics you want Dashboard creation • Templating  TimeBoard vs ScreenBoard Graph creation  Aggregation, trend, rate, anomaly detection No turnkey dashboards yet  May change: TLP templates Additional fees if >350 metrics  We need to increase this limit for our use case
32. Now we can easily  Find outliers  Compare a node to average  Compare two DCs  Explore a node’s metrics  Create overview dashboards  Create advanced dashboards for troubleshooting
33. Datadog’s cassandra.yaml Datadog’s cassandra.yaml - include: bean_regex: org.apache.cassandra.metrics:type=ReadRepair,name=* attribute: - Count - include: bean_regex: org.apache.cassandra.metrics:type=CommitLog,name=(WaitingOnCommit|WaitingOnSegmentAllocation) attribute: - Count - 99thPercentile - include: bean: org.apache.cassandra.metrics:type=CommitLog,name=TotalCommitLogSize - include: bean: org.apache.cassandra.metrics:type=ThreadPools,path=transport,scope=Native-Transport-Requests,name=MaxTasksQueued attribute: Value: alias: cassandra.ntr.MaxTasksQueued
34. ScreenBoard ScreenBoard
35. TimeBoard TimeBoard alpha beta gamma delta epsilon zeta eta alpha
36. Example Example Hints monitoring during maintenance on physical nodes Storage Streaming
37. Datadog Alerting Down node Exceptions Commitlog size High latency High GC High IO Wait High Pendings Many hints Long thrift connections Clock out of sync Disk space … Don’t miss this one Don’t forget /
38. V. Tuning
39. Java 8 CMS G1 → cassandra-env.sh -Dcassandra.max_queued_native_transport_requests=4096 -Dcassandra.fd_initial_value_ms=4000 -Dcassandra.fd_max_interval_ms=4000
40. GC logs enabled -XX:MaxGCPauseMillis=200 -XX:G1RSetUpdatingPauseTimePercent=5 -XX:G1HeapRegionSize=32m -XX:G1HeapWastePercent=25 -XX:InitiatingHeapOccupancyPercent=? -XX:ParallelGCThreads=#CPU -XX:ConcGCThreads=#CPU -XX:+ExplicitGCInvokesConcurrent -XX:+ParallelRefProcEnabled -XX:+UseCompressedOops jvm.options jvm.options -XX:HeapDumpPath= <dir with enough free space> -XX:ErrorFile= <custom dir> -Djava.io.tmpdir= <custom dir> -XX:-UseBiasedLocking -XX:+UseTLAB -XX:+ResizeTLAB -XX:+PerfDisableSharedMem -XX:+AlwaysPreTouch ... Backport from C* 3.0
41. num_tokens: 256 native_transport_max_threads: 256 or 128 compaction_throughput_mb_per_sec: 64 concurrent_compactors: 4 or 2 concurrent_reads: 64 concurrent_writes: 128 or 64 concurrent_counter_writes: 128 hinted_handoff_throttle_in_kb: 10240 max_hints_delivery_threads: 6 or 4 memtable_cleanup_threshold: 0.6, 0.5 or 0.4 memtable_flush_writers: 4 or 2 trickle_fsync: true trickle_fsync_interval_in_kb: 10240 dynamic_snitch_badness_threshold: 2.0 internode_compression: dc AWS nodes AWS nodes Heap c3.4xlarge: 15 GB i2.2xlarge: 24 GB
42. EBS volume != disk compaction_throughput_mb_per_sec: 32 concurrent_compactors: 4 concurrent_reads: 32 concurrent_writes: 64 concurrent_counter_writes: 64 trickle_fsync_interval_in_kb: 1024 AWS nodes AWS nodes Heap c4.4xlarge: 15 GB
43. num_tokens: 8 initial_token: ... native_transport_max_threads: 512 compaction_throughput_mb_per_sec: 128 concurrent_compactors: 4 concurrent_reads: 64 concurrent_writes: 128 concurrent_counter_writes: 128 hinted_handoff_throttle_in_kb: 10240 max_hints_delivery_threads: 6 memtable_cleanup_threshold: 0.6 memtable_flush_writers: 8 trickle_fsync: true trickle_fsync_interval_in_kb: 10240 Hardware nodes Hardware nodes More on this later Heap: 24 GB
44. Why 8 tokens? Better repair performance, important for Big Data Evenly distributed tokens, stored in a Chef data bag Hardware nodes Hardware nodes ./vnodes_token_generator.py --json --indent 2 --servers hosts_interleaved_racks.txt 4 { "192.168.1.1": "-9223372036854775808,-4611686018427387905,-2,4611686018427387901", "192.168.2.1": "-7686143364045646507,-3074457345618258604,1537228672809129299,6148914691236517202", "192.168.3.1": "-6148914691236517206,-1537228672809129303,3074457345618258600,7686143364045646503" } https://github.com/rhardouin/cassandra-scripts Watch out! Know the drawbacks
45. Small entries, lots of reads compression = { 'chunk_length_kb': '4', 'sstable_compression': 'org.apache.cassandra.io.compress.LZ4Compressor' } + nodetool scrub (few GB) Compression Compression
46. Disabled on 2 small clusters dynamic_snitch: false Less hop count Dynamic Snitch Dynamic Snitch
47. Client side latency Dynamic Snitch Dynamic Snitch P95 P75 Mean
48. Which node to decommission? Downscale Downscale
49. Clients
50. Scala apps DataStax driver wrapper Spark & Spark streaming DataStax Spark Cassandra Connector
51. DataStax driver policy LatencyAwarePolicy TokenAwarePolicy → LatencyAwarePolicy  Hotspots due to premature nodes eviction  Needs thorough tuning and steady workload  We drop it TokenAwarePolicy  Shuffle replicas depending on CL
52. For cross-region scheduled jobs VPN between AWS regions 20 executors with 6GB RAM output.consistency.level = (LOCAL_)ONE output.concurrent.writes = 50 connection.compression = LZ4
53. Useless writes 99% of empty unlogged batches on one DC What an optimization!
54. VI. Tools
55. {Parallel SSH + cron} on steroids  Security  History who/what/when/why Output is kept CQL migration Rolling restart Nodetool or JMX commands Backup and snapshot jobs “Job Scheduler & Runbook Automation” We added a “comment” field
56. Scheduled range repair Segments: up to 20,000 for TB tables Hosted fork for C* 2.1 We will probably switch to TLP’s fork We do not use incremental repairs See fix in C* 4.0
57. cassandra_snapshotter  Backup on S3  Scheduled with Rundeck We created and use a fork  Some PR merged upstream  Restore PR still to be merged
58. Logs management "C* " and "out of sync" "C* " and "new session: will sync" | count ... Alerts on pattern "C* " and "[ERROR]" "C* " and "[WARN]" and not ( … ) ...
59. VII. C’est la vie
60. Cassandra issues & failures
61. OS reboot… seems harmless, right? Cassandra service enabled Want a clue? C* 2.0 + counters Upgrade to C* 2.1 was a relief Without any obvious reason
62. Upgrade 2.0 2.1 → LCS cluster suffered  High load  Pending compactions was growing Switch to off heap memtable  Less GC => less load Reduce clients load Better after sstables upgrade  Took days
63. Upgrade 2.0 2.1 → Lots of NTR “All time blocked” NTR queue undersized for our workload  128 (hard coded) We add a property to test CASSANDRA-11363 and set value higher and higher… up to 4096 NTR pool needs to be sized accordingly
64. After replacing nodes DELETE FROM system.peers WHERE peer = '<replaced node>'; Used by DataStax Driver for auto discovery
65. AWS issues & failures
66. When you have to shoot, shoot, don’t talk! The Good, the Bad and the Ugly
67. We’ll shoot your instance We shot your instance EBS volume latency spike EBS volume unreachable
68. SSD SSD
69. SSD SSD dstat -tnvlr
70. Hardware issues & failures
71. One SSD failed CPUs suddendly became slow on one server Smart Array Battery BIOS bug Yup, not a SSD...
72. VIII. A light fork
73. Why a fork? 1. Need to add a patch ASAP  High Blocked NTR CASSANDRA-11363  Require to deploy from source 2. Why not backport interesting tickets? 3. Why not add small features/fixes?  Expose tasks queue length via JMX CASSANDRA-12758 You betcha!
74. A tiny fork We keep it as small as possible to fit our needs Even smaller when we will upgrade to C* 3.0  Backports will be obsolete
75. « Hey, if your fork is tiny, is it that useful? »
76. One example: repair
77. Backport of CASSANDRA-12580 Paulo Motta: log 2 vs ln
78. Get these info without DEBUG burden Original fix One-liner fix
79. The most impressive result for a set of tables:  Before: 23 days  With CASSANDRA-12580: 16 hours Longest repair for a table: 2,5 days  Impossible to repair this table before the patch  Fit in gc_grace_seconds
80. It was a critical fix for us It should have landed in 2.1.17 IMHO*  Repair is a mandatory operation in many use cases  Paulo already made the patch for 2.1  C* 2.1 is widely used [*] Full post: http://www.mail-archive.com/user@cassandra.apache.org/msg49344.html
81. « Why bother with backports? Why not upgrade to 3.0? »
82. Because C* is critical for our business We don’t need fancy stuff (SASI, MV, UDF, ...) We just want a rock solid scalable DB C* 2.1 does the job for the time being We p la n to up grade to C * 3 .0 i n 201 7 We wi l l do th o ro ugh te s ts ; - )
83. « What about C* 2.2? »
84. C* 2.2 has some nice improvements:  Boostrapping with LCS: send source sstable level 1  Range movement causes CPU & performance impact 2  Resumable bootstrap/rebuild streaming 3 [1] CASSANDRA-7460 [2] CASSANDRA-9258 [3] CASSANDRA-8838, CASSANDRA-8942, CASSANDRA-10810 But migration path 2.2 3.0 is risky →  Just my opinion based on users mailing list  DSE never used 2.2
85. Questions?
86. Thanks! C* devs for their awesome work Zenika for hosting this meetup You for being here!
