Slides of my presentation made at IT Talk Dnipro during Architecture Patterns Meetup.
Slides include overview of Software Architecture basics, SOLID and Clean Architecture key principles, overview of Architecture Components by Google - including Paging Library, some code samples and links to Google youtube videos from I/O and GDD, codelabs.

Transcript

1. Architecture Components Constantine Mars Team Lead, Senior Developer @ DataArt Построение современной архитектуры мобильных приложений
2. Background Software Architecture Basics
3. Components: -Activities -Fragments -Services -Content Providers -Broadcast Receivers Android Has “Good Bones”
4. App-hopping OS may kill app at random time App components lifecycle is not under control Components should not depend on each other Can’t rely on data, stored in components There are Everyday Problems to Solve
5. Simply related to Activity Lifecycle
6. -Separation of concerns -Provide solid user experience -Keep UI lean and simple -Keep UI free of app logic -Drive UI from model -Use persistent model -Assign clear responsibilities for each model class Common Principles for staying in mind :)
7. Image from fernandocejas.com Separation of Concerns...
8. Image from fernandocejas.com Clean Architecture
9. -Modular app -Each class responsible for one well-defined function -Should be no god objects -The app should be testable Remember Good Architecture Goals...
10. Android Recommended Architecture
11. Android Recommended Architecture. Another View
12. Be together. not the same
13. “It is impossible to have one way of writing apps that will be the best for every scenario. That being said, this recommended architecture should be a good starting point for most use cases. If you already have a good way of writing Android apps, you don't need to change.” Be together. not the same
14. Building blocks Architecture Components
15. Purpose: Display data and pass on UI events Neither contain the UI data, nor directly manipulate data Examples: Activity, Fragment Views = UI Controllers = LifecycleOwners
16. Lifecycle = states + events
17. Implement Lifecycle since Beta AppCompatActivity, Fragment
18. ViewModel Data holder for Activity/Fragment Survives configuration changes NEVER references View / Activity / Fragment
19. ViewModel public class DetailActivityViewModel extends ViewModel { private WeatherEntry mWeather; public DetailActivityViewModel() {} public WeatherEntry getWeather() { return mWeather; } public void setWeather(WeatherEntry weatherEntry) { mWeather = weatherEntry; } }
20. ViewModel and Lifecycle
21. ViewModel and LifecycleOwner public class DetailActivity extends LifecycleActivity { DetailActivityViewModel viewModel; @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); ... viewModel = ViewModelProviders.of(this).get(DetailActivityViewModel.class); } ...
22. Represent data needed for the UI to display An observable data holder Lifecycle aware Automatic subscription management LiveData
23. LiveData event propagation
24. LiveData sample implementation
25. Live Data public class DetailActivityViewModel extends ViewModel { private MutableLiveData<WeatherEntry> mWeather; public DetailActivityViewModel() {} public MutableLiveData<WeatherEntry> getWeather() { return mWeather; } public void setWeather(WeatherEntry weatherEntry) { mWeather.postValue(weatherEntry); } }
26. Live Data observing public class DetailActivity extends LifecycleActivity { DetailActivityViewModel viewModel; @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); ... viewModel = ViewModelProviders.of(this).get(DetailActivityViewModel.class); viewModel.getWeather().observe(this, weatherEntry -> { if(weatherEntry!=null) { bindWeatherToUI(weatherEntry); } }); }
27. -Single source of truth -ViewModels simply request data from the repository -Is a mediator between the different data sources Repository Image from fernandocejas.com
28. Manages data from a remote data source, such as the internet May use REST, Cloud Remote Network Data Source
29. Manages local data stored in the database Model
30. Each class in the diagram only stores a reference to the class or classes directly "below it" and not any classes above it Layered architecture pattern
31. ORM by Google Room
32. -Less boilerplate compared to the built-in APIs -Compile-time validation of SQL queries -Data observation via LiveData, RxJava Room ORM purposes
33. -@Entity -@Dao -@Database Room annotations
34. Entity
35. @Entity declaration @Entity(tableName = "weather", indices = {@Index(value = {"date"}, unique = true)}) public class WeatherEntry { @PrimaryKey(autoGenerate = true) private int id; … }
36. @Entity constructors //Room constructor public WeatherEntry(int id, int weatherIconId, Date date, ...) { //Json constructor - ignored by Room @Ignore public WeatherEntry(int weatherIconId, Date date, // (!) Only one constructor should be exposed to Room ...
37. Dao
38. @Dao declaration @Dao public interface WeatherDao { @Query("SELECT * FROM weather") List<WeatherEntry> getAll(); @Insert(onConflict = OnConflictStrategy.REPLACE) void insertAll(WeatherEntry... weatherEntries); @Delete void delete(WeatherEntry weatherEntry); }
39. Database
40. @Database declaration @Database(entities = {WeatherEntry.class}, version = 1) @TypeConverters(DateConverter.class) public abstract class AppDatabase extends RoomDatabase { public abstract WeatherDao weatherDao(); }
41. @Database - a singleton private static final String DATABASE_NAME = "weather"; private static final Object LOCK = new Object(); private static volatile AppDatabase sInstance; public static AppDatabase getInstance(Context context) { if (sInstance == null) { synchronized (LOCK) { if (sInstance == null) { sInstance = Room.databaseBuilder(context.getApplicationContext(), AppDatabase.class, AppDatabase.DATABASE_NAME).build(); } }} return sInstance; }
42. Type converters class DateConverter { @TypeConverter public static Date toDate(Long timestamp) { return timestamp == null ? null : new Date(timestamp); } @TypeConverter public static Long toTimestamp(Date date) { return date == null ? null : date.getTime(); } }
43. Alternatives
44. Repository
45. Repository pattern public class WeatherRepository { public synchronized static WeatherRepository getInstance(); public synchronized void initializeData(); private void deleteOldData(); private boolean isFetchNeeded(); private void startFetchWeatherService(); }
46. Repository - fetch data from network mWeatherNetworkDataSource = weatherNetworkDataSource; LiveData<WeatherEntry[]> networkData = mWeatherNetworkDataSource.getCurrentWeatherForecasts(); networkData.observeForever(newForecastsFromNetwork -> { mExecutors.diskIO().execute(() -> { mWeatherDao.bulkInsert(newForecastsFromNetwork); Log.d(LOG_TAG, "New values inserted"); }); });
47. Repository - use LiveData private WeatherNetworkDataSource(Context context, AppExecutors executors) { mContext = context; mExecutors = executors; mDownloadedWeatherForecasts = new MutableLiveData<WeatherEntry[]>(); }
48. Check when to fetch private boolean isFetchNeeded() { Date today = CustomDateUtils.getNormalizedUtcDateForToday(); int count = mWeatherDao.countAllFutureWeather(today); return (count < WeatherNetworkDataSource.NUM_DAYS); }
49. Check when to fetch public synchronized void initializeData() { if (mInitialized) return; mInitialized = true; mExecutors.diskIO().execute(() -> { if (isFetchNeeded()) { startFetchWeatherService(); } }); }
50. And again - observe LiveData public class DetailActivity extends LifecycleActivity { DetailActivityViewModel viewModel; @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); ... viewModel = ViewModelProviders.of(this).get(DetailActivityViewModel.class); viewModel.getWeather().observe(this, weatherEntry -> { if(weatherEntry!=null) { bindWeatherToUI(weatherEntry); } }); }
51. The whole picture for sample project
52. Paging Library
53. Paging Library flow
54. Data source KeyedDataSource - if you need to use data from item N to fetch item N+1. TiledDataSource - if you need to fetch pages in range of data from any location you choose in your data store
55. DAO for KeyedDataSource @Dao interface UserDao { @Query("SELECT * from user ORDER BY name DESC LIMIT :limit") public abstract List<User> userNameInitial(int limit); @Query("SELECT * from user WHERE name < :key ORDER BY name DESC LIMIT :limit") public abstract List<User> userNameLoadAfter(String key, int limit); @Query("SELECT * from user WHERE name > :key ORDER BY name ASC LIMIT :limit") public abstract List<User> userNameLoadBefore(String key, int limit); }
56. KeyedDataSource implementation public class KeyedUserQueryDataSource extends KeyedDataSource<String, User> { @Override public boolean isInvalid() { return super.isInvalid(); } @Override public String getKey(@NonNull User item) { return item.getName(); } @Override public List<User> loadInitial(int pageSize) { return mUserDao.userNameInitial(pageSize); } @Override public List<User> loadBefore(@NonNull String userName, int pageSize) { return mUserDao.userNameLoadBefore(userName, pageSize); } @Override public List<User> loadAfter(@Nullable String userName, int pageSize) { return mUserDao.userNameLoadAfter(userName, pageSize); } }
57. TiledDataSource implementation @Dao interface UserDao { @Query("SELECT * FROM user ORDER BY mAge DESC") public abstract TiledDataSource<User> loadUsersByAgeDesc(); }
58. TiledDataSource - under the hood @Dao interface UserDao { @Query("SELECT COUNT(*) from user") public abstract Integer getUserCount(); @Query("SELECT * from user ORDER BY mName DESC LIMIT :limit OFFSET :offset") public abstract List<User> userNameLimitOffset(int limit, int offset); }
59. TiledDataSource - under the hood public class OffsetUserQueryDataSource extends TiledDataSource<User> { @Override public boolean isInvalid() { return super.isInvalid(); } @Override public int countItems() { return mUserDao.getUserCount(); } @Override public List<User> loadRange(int startPosition, int loadCount) { return mUserDao.userNameLimitOffset(loadCount, startPosition); } }
60. Paging Library - PagedList DataSource PagedList - loads its data in chunks (pages) from a DataSource PagedListAdapter LivePagedListProvider
61. Paging Library - LivePagedListProvider DataSource PagedList PagedListAdapter - listens to PagedList loading callbacks as pages are loaded, and uses DiffUtil on a background thread to compute fine grained updates as new PagedLists are received. LivePagedListProvider - provides a LiveData<PagedList>, given a means to construct a DataSource
62. LivePagedListProvider generation by DAO @Dao interface UserDao { @Query("SELECT * FROM user ORDER BY lastName ASC") public abstract LivePagedListProvider<Integer, User> usersByLastName(); }
63. Paging Library - PagedListAdapter DataSource PagedList PagedListAdapter - listens to PagedList loading callbacks as pages are loaded, and uses DiffUtil on a background thread to compute fine grained updates as new PagedLists are received. LivePagedListProvider
64. PagedListAdapter usage pattern - DAO @Dao interface UserDao { @Query("SELECT * FROM user ORDER BY lastName ASC") public abstract LivePagedListProvider<Integer, User> usersByLastName(); }
65. PagedListAdapter usage pattern - PagedList.Config class MyViewModel extends ViewModel { public final LiveData<PagedList<User>> usersList; public MyViewModel(UserDao userDao) { usersList = userDao.usersByLastName().create( /* initial load position */ 0, new PagedList.Config.Builder() .setPageSize(50) .setPrefetchDistance(50) .build()); } }
66. PagedListAdapter usage pattern - binding class MyActivity extends AppCompatActivity { @Override public void onCreate(Bundle savedState) { super.onCreate(savedState); MyViewModel viewModel = ViewModelProviders.of(this).get(MyViewModel.class); RecyclerView recyclerView = findViewById(R.id.user_list); UserAdapter<User> adapter = new UserAdapter(); viewModel.usersList.observe(this, pagedList -> adapter.setList(pagedList)); recyclerView.setAdapter(adapter); } }
67. PagedListAdapter implementation class UserAdapter extends PagedListAdapter<User, UserViewHolder> { public UserAdapter() { super(DIFF_CALLBACK); } @Override public void onBindViewHolder(UserViewHolder holder, int position) { User user = getItem(position); if (user != null) { holder.bindTo(user); } else { holder.clear(); } } ...
68. PagedListAdapter implementation class UserAdapter extends PagedListAdapter<User, UserViewHolder> { ... public static final DiffCallback<User> DIFF_CALLBACK = new DiffCallback<User>() { @Override public boolean areItemsTheSame( @NonNull User oldUser, @NonNull User newUser) { return oldUser.getId() == newUser.getId(); } @Override public boolean areContentsTheSame( @NonNull User oldUser, @NonNull User newUser) { return oldUser.equals(newUser); } } }
69. Paging Library flow
70. Testing Sneak peek :)
71. UI Controller - Instrumentation
72. ViewModel - JUnit
73. Repository - JUnit, MockWebServer
74. Scalability and advices Almost there...
75. What if... I use RxJava? I already have MVP? I love Kotlin? I’m working on legacy project? Typical questions
76. The Answer is...
77. Read, watch and visit... Links
78. Guide to App Architecture https://developer.android.com/topic/libraries/architecture/guide.html Architecture Components https://developer.android.com/topic/libraries/architecture/index.html I/O ‘17 Architecture Components Introduction - https://youtu.be/FrteWKKVyzI Solving the Lifecycle Problem - https://youtu.be/bEKNi1JOrNs Persistence and Offline - https://youtu.be/MfHsPGQ6bgE Architecture Components on GDD Europe - https://youtu.be/Ts-uxYiBEQ8 GDD Europe CodeLabs g.co/codelabs/gdd17 Google Github samples https://github.com/googlesamples/android-architecture-components What to read and watch :)
79. Android MVP Helper https://github.com/Ufkoku/AndroidMVPHelper Moxy https://github.com/Arello-Mobile/Moxy Mosby https://github.com/sockeqwe/mosby Clean Architecture https://github.com/android10/Android-CleanArchitecture Reark https://github.com/reark/reark MVP + Dagger2 + Rx https://android.jlelse.eu/mvp-dagger-2-rx-clean-modern-android-app-code-74f63c9a6f2f Architecture the Lost Years by Uncle Bob https://youtu.be/WpkDN78P884 Alternatives to consider
80. Where to go :)
81. Thank you! :) Constantine Mars @ConstantineMars +ConstantineMars Mobile Architecture Club
