Master your custom views @rmgoncalo Rui Gonçalo
Screens
Screen size: physical size (diagonal) e.g: 5.5’’
Screen size: physical size (diagonal) e.g: 5.5’’ Resolution: # of
physical pixels on a screen e.g: 1080 pixels x 1920 pixels
Screen size: physical size (diagonal) e.g: 5.5’’ Screen density: #
of pixels within a physical area e.g: 160 dots per inch (dpi) Resolution: # of physical pixels on a screen e.g: 1080 pixels x 1920 pixels
Density-independent pixel (dp): virtual pixel that abstracts different density screens
1 dp = 1 pixel on 160 dpi
None
resolution 1080x1920 density xxhdpi 300dp x 100dp 250dp x 100dp
200dp x 100dp 150dp x 100dp
300dp x 100dp 250dp x 100dp 200dp x 100dp 150dp
x 100dp
300dp x 100dp 250dp x 100dp 200dp x 100dp 150dp
x 100dp resolution 1080x1920 density xxhdpi resolution 1080x1920 density xxhdpi
resources.displayMetrics.density resolution 1080x1920 density xxhdpi
2.6 resolution 1080x1920 density xxhdpi resources.displayMetrics.density
2.6 160 * 2.6 = 416 dpi width 1080 /
2.6 ~ 411 dp height 1920 / 2.6 ~ 731 dp resolution 1080x1920 density xxhdpi resources.displayMetrics.density
2.6 300 dp * 2.6 = 780 px 250 dp
* 2.6 = 650 px 780px 650px 520px 390px 200 dp * 2.6 = 520 px 150 dp * 2.6 = 390 px 160 * 2.6 = 416 dpi width 1080 / 2.6 ~ 411 dp height 1920 / 2.6 ~ 731 dp resolution 1080x1920 density xxhdpi resources.displayMetrics.density
resources.displayMetrics.density resolution 1080x1920 density xxhdpi
3.0 160 * 3.0 = 480 dpi width 1080 /
3.0 ~ 360 dp height 1920 / 3.0 ~ 640 dp resolution 1080x1920 density xxhdpi resources.displayMetrics.density
3.0 300 dp * 3.0 = 900 px 250 dp
* 3.0 = 750 px 200 dp * 3.0 = 600 px 150 dp * 3.0 = 450 px 900px 750px 600px 450px 160 * 3.0 = 480 dpi width 1080 / 3.0 ~ 360 dp height 1920 / 3.0 ~ 640 dp resolution 1080x1920 density xxhdpi resources.displayMetrics.density
resolution 1080x1920 size (dp) 411x731 resolution 1080x1920 size (dp) 360x640
Google Pixel Nexus 5 resolution 1080x1920 size (dp) 411x731 resolution
1080x1920 size (dp) 360x640
Wide range of Android devices with different screen resolutions and
densities
<View android:layout_width=“300dp” android:layout_height=“100dp” />
/res/values-sw411dp/dimens.xml /res/layout-sw411dp <View android:layout_width=“@dimen/block_width” android:layout_height=“100dp” /> sw?
topView centerTopView centerBottomView bottomView val screenWidth = resources.displayMetrics.widthPixels val topW
= screenWidth * ( 300 / 360f ) val cTopW = screenWidth * ( 250 / 360f ) val cBottomW = screenWidth * ( 200 / 360f ) val bottomW = screenWidth * ( 150 / 360f ) val height = (100 * resources.displayMetrics.density) default view width default screen width
topView centerTopView centerBottomView bottomView topView.layoutParams = LinearLayout.LayoutParams(topW, height) centerTopView.layoutParams =
LinearLayout.LayoutParams(cTopW, height) centerBottomView.layoutParams = LinearLayout.LayoutParams(cBottomW, height) bottomView.layoutParams = LinearLayout.LayoutParams(bottomW, height)
Design for 1080x1920 480dpi (xxhdpi) take into account different screens
width (do the math) https://material.io/devices/ Don’t trust the Android emulator Google Pixel has 480 DPI instead of 416 DPI
Custom Views
class CustomView : View { } ViewGroup FrameLayout …
class CustomView : View { constructor(context: Context) : super(context) constructor(context:
Context, attrs: AttributeSet) : super(context, attrs) }
class CustomView : View { override fun onAttachedToWindow() override fun
onDetachedFromWindow() }
onMeasure() onLayout() onDraw() onAttachedToWindow() onDetachedFromWindow()
onDraw()
onDraw()
Canvas()
Canvas() Y X resources.displayMetrics .widthPixels resources.displayMetrics .heightPixels
Canvas() Y X resources.displayMetrics .widthPixels resources.displayMetrics .heightPixels Paint() - geometries
- text - bitmaps Path()
resources.displayMetrics.widthPixels ? ? ? ? ?
? ? 70dp ? ? resources.displayMetrics.widthPixels
? ? ? 70dp 50dp resources.displayMetrics.widthPixels
? 110dp 20dp 70dp 50dp resources.displayMetrics.widthPixels
110dp 20dp 70dp 50dp resources.displayMetrics.widthPixels resources.displayMetrics.widthPixels-130dp
110dp 20dp 70dp 50dp resources.displayMetrics.widthPixels resources.displayMetrics.widthPixels-130dp
path.lineTo(0f, containerHeight) (0, 0) (0, containerHeight)
path.lineTo(screenWidthPx - tagWidthBigPx, containerHeight)
path.cubicTo( screenWidthPx - tagWidthSmallPx, containerHeight, screenWidthPx - tagWidthBigPx, containerHeight +
tagHeightPx, screenWidthPx - tagWidthSmallPx, containerHeight + tagHeightPx )
path.cubicTo( screenWidthPx - tagWidthSmallPx, containerHeight, screenWidthPx - tagWidthBigPx, containerHeight +
tagHeightPx, screenWidthPx - tagWidthSmallPx, containerHeight + tagHeightPx ) http://cubic-bezier.com/
x path.cubicTo( screenWidthPx - tagWidthSmallPx, containerHeight, screenWidthPx - tagWidthBigPx, containerHeight
+ tagHeightPx, screenWidthPx - tagWidthSmallPx, containerHeight + tagHeightPx )
path.cubicTo( screenWidthPx - tagWidthSmallPx, containerHeight, screenWidthPx - tagWidthBigPx, containerHeight +
tagHeightPx, screenWidthPx - tagWidthSmallPx, containerHeight + tagHeightPx ) x
path.cubicTo( screenWidthPx - tagWidthSmallPx, containerHeight, screenWidthPx - tagWidthBigPx, containerHeight +
tagHeightPx, screenWidthPx - tagWidthSmallPx, containerHeight + tagHeightPx ) x
path.lineTo(screenWidthPx, containerHeight + tagHeightPx)
path.lineTo(screenWidthPx, 0f)
path.lineTo(0f, 0f)
private val path by lazy { Path() } override fun
onDraw(canvas: Canvas) { super.onDraw(canvas) with(path) { lineTo(…) cubicTo(…) … } canvas.drawPath(path, paint) }
private val paint by lazy { Paint().apply { style =
Paint.Style.FILL color = Color.WHITE isAntiAlias = true } }
onMeasure() onLayout() onDraw() onAttachedToWindow() onDetachedFromWindow()
None
<FrameLayout android:layout_width="match_parent" android:layout_height="match_parent" android:background="@color/blue"> <FrameLayout android:layout_width="match_parent" android:layout_height="wrap_content"> <com.example.CustomView android:layout_width="match_parent" android:layout_height="wrap_content"/>
<TextView android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_gravity="end|bottom" android:layout_margin="12dp" android:text="123" android:textSize="30sp"/> </FrameLayout> </FrameLayout>
<FrameLayout android:layout_width="match_parent" android:layout_height="match_parent" android:background="@color/blue"> <FrameLayout android:layout_width="match_parent" android:layout_height="wrap_content"> <com.example.CustomView android:layout_width="match_parent" android:layout_height="wrap_content"/>
<TextView android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_gravity="end|bottom" android:layout_margin="12dp" android:text="123" android:textSize="30sp"/> </FrameLayout> </FrameLayout>
override fun onMeasure(widthMeasureSpec: Int, heightMeasureSpec: Int) { val customHeightMeasuredSpec
= MeasureSpec.makeMeasureSpec( containerHeight + tagHeightPx, MeasureSpec.EXACTLY) super.onMeasure(widthMeasureSpec, customHeightMeasuredSpec) } setMeasuredDimension(measuredWidth: Int, measuredHeight: Int)
onMeasure() onLayout() onDraw() onAttachedToWindow() onDetachedFromWindow() invalidate()
None
BL BR TR TL
BL BR TR TL
BL BR TR TL
BL BR TR TL
BL BR TR TL AL AR
BL BR TR TL AL AR
BL BR TR TL AL AR
TL width center in x axis = width / 2
TLx = width / 2 - peekTopWidth / 2 TLy
= 0f TL width center in x axis = width / 2 peekTopWidth y x
BLx = (width / 2 - peekBottomWidth / 2) *
(1 - offset * 3) BL x offset = 0,1 BLx = 100 * (1 - 0,1 * 3) = 100 * 0,7 = 70 offset = 0,2 BLx = 100 * (1 - 0,2 * 3) = 100 * 0,4 = 40
BL y peekHeight BLy = if(BLx >= 0) { peekHeight
} else { ?????????? }
BL y BLy = if(BLx >= 0) { peekHeight }
else { ?????????? } peekHeight
peekHeight BLy = peekHeight - (peekHeight * offset) offset =
0,1 BLy = 100 - (100 * 0,1) = 100 - 10 = 90 offset = 0,6 BLy = 100 - (100 * 0,6) = 100 - 60 = 40
peekHeight BLy = peekHeight - (peekHeight * offset) offset =
0,1 BLy = 100 - (100 * 0,1) = 100 - 10 = 90 offset = 0,35 BLy = 100 - (100 * 0,35) = 100 - 35 = 65 offset is 0,35!!!
x x (anchorOffset, 0) (1, 1) offset = 0,35 peekHeight
peekHeight - (peekHeight * offset)
x x (anchorOffset, 0) (1, 1) To calculate the slope
of a line you need only two points from that line m = ( y2 - y1 ) / ( x2 - x1 )
x x (anchorOffset, 0) (1, 1) m = ( 1
- 0 ) / ( 1 - anchorOffset )
x x (anchorOffset, 0) (1, 1) Equation of a line
given a point and the slope y - y1 = m ( x - x1 )
x x (anchorOffset, 0) (1, 1) y - 0 =
( 1 / (1 - anchorOffset ) ) * ( x - anchorOffset )
x x (anchorOffset, 0) (1, 1) y = ( x
- anchorOffset ) / ( 1 - anchorOffset )
BLy = if(BLx >= 0) { peekHeight } else
{ if(anchorOffset = 0) { anchorOffset = offset } verticalOffset = (offset - anchorOffset) / (1 - anchorOffset) peekHeight - (peekHeight * verticalOffset) } BL y y = ( x - anchorOffset ) / ( 1 - anchorOffset )
BL BR TR TL TRx = width - TLx TRy
= TLy BRx = width - BLx BRy = BLy
ALx = BLx ALy = peekHeight ARx = BRx ARy
= peekHeight BL BR TR TL AL AR
override fun onPanelSlide(slideOffset: Float) { offset = slideOffset invalidate() }
private fun init() { setWillNotDraw(false) LayoutInflater.from(context).inflate(xml, this, true) invalidate() }
Be careful with onDraw() don’t call methods that call onDraw()
or requestLayout()
Master your custom views #19231A DARK JUNGLE GREEN @rmgoncalo Rui
Gonçalo
