Deliver Python Apps with Docker

Slides was made by Anton Egorov for Pycon Russia 2016

Transcript

1. by Anton Egorov July 2016 Deliver Python Apps with Docker
2. Who am I? • Software Engineer, 10 years in web development • Scripting mostly with Python • 2 years using Docker, dockerized about 50 apps, 80% of them were Python apps • Ex Lead Developer at ostrovok.ru • CTO and Founder at sabaka.io
3. Plan • Quick introduction to Docker • App dockerization example • Production deployment notes • Treasure Goblin lives on special slides
4. Docker in a few slides
5. What is Docker? • It’s an open-source project that automates application deployment using containers • Initial release was in March 2013 • Written in Go • Works on Linux, OS X, Windows
6. Why Docker? • The best tool for software packaging • Easy to build, just follow best practices • Fast at runtime, overhead is close to nothing • You have identical installation at any environment (dev, stage, prod) • Predictable, easy to test, makes QA happy
7. Image • An image is a container basis • It’s a filesystem and a set of parameters to use at runtime (libs, bins, your software) • It doesn’t have a state and never changes • Dockerfile contains instructions to build the image
8. Container • A container is a running instance of the image • It consists of • Docker image • Execution environment • Set of instructions
9. Data Volume • Directory within one or more containers that bypasses the Union File System • Designed to persist data, independent of the container’s life cycle
10. Notes • Treat containers as read-only instances • Use data volumes to take care of persistent data
11. Layers
12. Images are layered • Docker store images in a layered file system • Each instruction from Dockerfile is a distinct read only layer • When you create a new container, you add a new, thin, writable layer
13. pull base image…
14. pull base image…
15. pull base image, done
16. build: add new layers
17. build: add new layers
18. build: add new layers
19. build: done
20. run container
21. Practice
22. Application • We have a demo Django app written in Python 3 • We are going to serve static along with the app • We don't care about HTTPS inside the container • Logging and monitoring is out of the scope of this talk
23. ls -la • Dockerfile — build instructions • .dockerignore — excludes files from the build context • demo — app source code • etc — runtime configuration files
24. Dockerfile
25. Dockerfile: libs, bins FROM ubuntu:16.04 RUN export DEBIAN_FRONTEND=noninteractive \ && apt-get update -y && apt-get upgrade -y \ && apt-get install -y nginx-light \ python3 python3-pip python3-psycopg2 \ && BUILD_DEPS='build-essential python3-dev' \ && apt-get install -y ${BUILD_DEPS} \ && pip3 install --no-cache-dir circus==0.13.0 gunicorn==19.5.0 \ && apt-get autoremove -y ${BUILD_DEPS} \ && apt-get clean \ && rm -rf /var/lib/apt/lists/* /tmp/* /var/tmp/*
26. Dockerfile best practices • Join commands sequence into one RUN instruction to reduce the number of layers • Clean build dependencies • Plan your layers to take advantage of the Docker build cache
27. Dockerfile: pip install • Container is an isolated environment, so you don't have to use python-virtualenv • We do python packages installation in a separate step to achieve caching COPY requirements.txt /opt/demo/app/
 RUN pip3 install --no-cache-dir \ -r /opt/demo/app/requirements.txt
28. Dockerfile: prepare the app • Copy the app source code and configuration files • Fix files permissions • Run validations (e.g. nginx -t) • Execute management scripts to prepare the app
29. Dockerfile: prepare the app COPY etc/ /etc/ COPY demo/ /opt/demo/app/ WORKDIR /opt/demo/app ENV STATIC_ROOT=/opt/demo/static RUN nginx -t \ && ./manage.py collectstatic \ --settings=demo.settings --no-input -v0 CMD ["circusd", "/etc/circus/web.ini"]
30. etc
31. etc/circus/web.ini [watcher:web]
 cmd=/usr/local/bin/gunicorn \ demo.wsgi:application -c /etc/gunicorn.py
 working_dir = /opt/demo/app
 copy_env = True
 user = www-data [watcher:nginx]
 cmd = /usr/sbin/nginx
 stop_signal = QUIT
 user = root
32. etc/nginx/sites-available/default server {
 listen 80;
 location / {
 include proxy_params;
 proxy_pass http://127.0.0.1:8000;
 }
 location /static/ {
 root /opt/demo/;
 access_log off;
 }
 }
33. /etc/gunicorn.py import multiprocessing
 import os

 bind = '127.0.0.1:8000'
 default_workers = multiprocessing.cpu_count() * 2 + 1
 workers = os.environ.get( 'WEB_CONCURRENCY', default_workers)
 worker_class = 'sync'
 max_requests = 300 max_requests_jitter = 300
 errorlog = '-'
34. demo/settings.py The best way to configure your app is environment (e.g. database connection) DATABASES = {
 'default': dj_database_url.config(
 env='DATABASE_URL',
 default='postgres://localhost/demo')}
35. Demo
36. docker-compose.yml web: build: . container_name: web environment: DJANGO_SETTINGS_MODULE: demo.settings_prod DATABASE_URL: postgres://postgres:secret@db/demo ALLOWED_HOSTS: "*" ports: - "80:80" db: image: postgres:9.5 environment: POSTGRES_PASSWORD: "secret" POSTGRES_DB: "demo" volumes: - /var/lib/postgresql/data
37. Build and run We can build an image using docker-compose docker-compose build Run containers docker-compose up -d Run database migrations docker exec -it web \
 /opt/demo/app/manage.py migrate
38. Production
39. Docker Registry • You can use any SaaS solution (e.g. Docker Hub, Quay, Amazon ECR, Google Container Registry) • Or deploy and configure your own Registry, it's easy and fully automated
40. Orchestration • Docker Compose is a good choice for small projects • You should automate your deployment with tools like Ansible or have a look at Docker Swarm if you want to manage a medium-sized cluster • Kubernetes and Mesosphere are complex tools with advanced features • Alternatively you can use SaaS solutions like Docker Cloud, Amazon ECS, Google Container Engine
41. Good luck!
42. Links • Demo https://github.com/satyrius/paid • Docs https://docs.docker.com/ • Best practices https://docs.docker.com/engine/ userguide/eng-image/dockerfile_best-practices/ • Circus https://circus.readthedocs.io/en/latest/for-ops/ configuration/ • Gunicorn http://docs.gunicorn.org/en/stable/ settings.html
43. Jobs • ostrovok.ru is looking for Python/Golang/iOS/ Android developers and much more
 https://jobs.lever.co/ostrovok.ru • sabaka.io is looking for DevOps/SysOps engineers and Python/Golang talents
 https://angel.co/sabaka/jobs
44. Questions? anton.egoroff@gmail.com
