Multi-Cluster Deployment Patterns for Ingress and API Gateways

In this webinar, we will explore deployment patterns, configurations, global traffic routing policies and more for scalable, highly available, and resilient application environments using Envoy Proxy for the Edge / API Gateway across multiple clusters. We will compare the tradeoffs between the different patterns for consideration and guidance for implementation and operations.

Watch the webinar https://youtu.be/SsdaHmjgjLk

Learn more https://www.solo.io/products/gloo
Request a trial https://lp.solo.io/lp-request-a-trial-general
Questions? https://slack.solo.io

Transcript

1. Multi-Cluster API Gateway Patterns with Envoy Proxy and Gloo Christian Posta Global Field CTO – Solo.io
2. 2 | Copyright © 2020 Our customers’ challenges
3. 3 | Copyright © 2020 SERVICE MESH JOURNEY INNOVATION MODERNIZE TO MICROSERVICES SERVICE MESH MANAGEMENT ADAPTIVE SERVICE MESH
4. 4 | Copyright © 2020 December 11, 2018 2018 TOP WOMEN ENTREPRENEURS IN CLOUD INNOVATION Seventh Annual Award Honors Women Founders for Outstanding Accomplishments in Cloud and Emerging Technologies, Sponsored by Facebook, Intel, and Google. Award Winning Innovation Enterprise Credibility Key Industry Collaborations https://www.solo.io/customers/
5. 5 | Copyright © 2020 API connectivity & communication challenges SERVICE A SERVICE B SERVICE C SERVICE D SERVICE E Challenges • Entry point for services • Establishing boundary • AuthN/AuthZ • Traffic routing • Transformations • Rate limiting • Automation • Extension
6. 6 | Copyright © 2020 API connectivity & communication challenges Challenges • Discovering APIs • Documentation • Self-service sign up • Security • Internal vs External SERVICE A SERVICE B SERVICE C SERVICE D SERVICE E
7. 7 | Copyright © 2020 Solo.io solves API connectivity & communication challenges SERVICE A SERVICE B SERVICE C SERVICE D SERVICE E API portal
8. 8 | Copyright © 2020 Gloo Enterprise Features
9. 9 | Copyright © 2020 Gloo Data Plane and Control Plane EXTERNAL AUTH RATE LIMITING GLOO FILTERS ROUTER UPSTREAM EXTERNAL AUTH SERVER RATE LIMITING SERVER CACHING DATA LOSS PREVENTION LAMBDA NATS.IO TRANSFORMATION WEB APPLICATION FIREWALL (WAF)
10. 10 | Copyright © 2020 Why Gloo? Security Highly Extensible Multi-platform Web Assembly Integration Decentralized API • Basic auth • OIDC • JWT • API Keys • Custom Auth • TLS • mTLS • SNI • Let’s Encrypt • CORS • OPA • RBAC • Delegation • WAF • Data Loss Prevention • Rate Limit • Circuit Breaker
11. 11 | Copyright © 2020 API connectivity & communication challenges Challenges • Multiple clusters • Hybrid deployments • Centralized view • Consistency • Security • Configuration • Federation • Centralization vs Decentralization S E R V I C E A S E R V I C E B S E R V I C E C S E R V I C E D S E R V I C E E S E R V I C E A S E R V I C E B S E R V I C E C S E R V I C E D S E R V I C E E S E R V I C E A S E R V I C E B S E R V I C E C S E R V I C E D S E R V I C E E S E R V I C E A S E R V I C E B S E R V I C E C S E R V I C E D S E R V I C E E
12. 12 | Copyright © 2020 API Federation • Autonomous clusters • Different organizational/network/administrative boundaries • Share pieces of configuration • For those shared pieces, treat union as a single unit • Uses an orchestrator to stitch together policies for federation
13. 13 | Copyright © 2020 SERVICE A SERVICE B SERVICE C SERVICE D SERVICE E SERVICE F SERVICE G SERVICE H Solo.io solves API connectivity & communication challenges Federation
14. 14 | Copyright © 2020 Problems Solo.io solves with federation • Security (authz/authn/encryption/identity) • Service discovery • Failover / traffic shifting / transparent routing • Observability • Separate networks • Well-defined fault domains • Balance of centralized management with decentralized enforcement
15. 15 | Copyright © 2020 15 | Copyright © 2020 Envoy as the backbone of application networking
16. 16 | Copyright © 2020 Why Envoy Proxy? • Neutral Foundation (CNCF) • Large, diverse, vibrant community • Built ground up for dynamic services environment • Dynamic configuration, driven by API • Highly extensible • L7 filters (HTTP/1, HTTP/2, gRPC, redis, mysql, Kafka, etc) • Deep metrics/telemetry out of the box • Versatile deployment options
17. 17 | Copyright © 2020 Exploring Envoy failover routing capabilities: Request racing Account work load work load work load Calls http://products.service/ work load work load us-west-1 us-west-2 Timeout Race request First to return is the response to the caller
18. 18 | Copyright © 2020 Exploring Envoy failover routing capabilities: Zone aware routing (Envoy decides) Account work load work load work load Calls http://products.service/ work load work load us-west-1 us-west-2 Not enough healthy hosts in same zone Spill over to another zone
19. 19 | Copyright © 2020 Exploring Envoy failover routing capabilities: Locality aware (Control plane decides) Account work load work load work load Calls http://products.service/ work load work load us-west-1 us-west-2 Not enough healthy hosts in same zone Spill over to another zone W=1 W=1 W=1 W=5 W=5
20. 20 | Copyright © 2020 Exploring Envoy failover routing capabilities: Aggregate Cluster (for routing to gateways) Account work load work load work load Calls http://products.service/ Edge gw us-west-1 us-west-2 EDS Strict DNS
21. 21 | Copyright © 2020 21 | Copyright © 2020 Multi-cluster patterns
22. 22 | Copyright © 2020 @christianposta work load work load work load Single cluster ingress/gateway
23. 23 | Copyright © 2020 @christianposta work load work load work load work load work load work load work load work load work load Decentralized API Gateway
24. 24 | Copyright © 2020 @christianposta work load work load work load work load work load work load work load work load work load Leaf nodes/ application clusters Hybrid, two-tier gateways
25. 25 | Copyright © 2020 @christianposta work load work load work load work load work load work load work load work load work load Leaf nodes/ application clusters Hybrid, two-tier gateways with tenancy
26. 26 | Copyright © 2020 @christianposta work load Istiod work load work load work load Istiod work load work load work load Istiod work load work load API/Edge Gateway tier Access Proxy / Gateway Routing Leaf nodes/ application clusters
27. 27 | Copyright © 2020 27 | Copyright © 2020 Operating a multi-cluster topology
28. 28 | Copyright © 2020 @christianposta Access Proxy / Gateway Routing Leaf nodes/ application clusters GlooFederation Plane work load work load work load work load work load work load work load work load work load
29. 29 | Copyright © 2020 @christianposta Access Proxy / Gateway Routing Leaf nodes/ application clusters GlooFederation Plane work load work load work load work load work load work load work load work load work load
30. 30 | Copyright © 2020 @christianposta Access Proxy / Gateway Routing Leaf nodes/ application clusters GlooFederation Plane work load work load work load work load work load work load work load work load work load
31. 31 | Copyright © 2020 31 | Copyright © 2020 Demo
