Telosys : how to generate a Python Web MVC SQL application

This presentation describe how to generate a web application based on Python Bottle and SQLAlchemy with Telosys CLI

Transcript

1. 1 Telosys tutorial for Python – MVC / SQL application
2. 2 Web browser APPLICATION ARCHITECTURE Controllers Services Views D.A.O. Entities What we want to generate :
3. 3 For this tutorial we need Python 3 with frameworks « Bottle » and « SQLAlchemy » Check « Python 3 » and « pip » are installed > python --version > pip --version Install « Bottle » > pip install bottle Install « SQLAlchemy » > pip install SQLAlchemy List installed packages > pip list PREREQUISITES
4. 4 Telosys CLI installation
5. 5 Create 2 folders : « tuto » and « tuto/project » Check Java version ( Java 1.8 or + required ) > java -version Download Telosys-CLI from https://www.telosys.org/download/telosys-cli/ in « tuto » folder Unzip Telosys-CLI in the « tuto » folder If you want Telosys to use your preferred editor just define it in the ”telosys-cli.cfg” file Example for « Notepad++ » : EditorCommand = "C:/Program Files (x86)/Notepad++/notepad++.exe" $FILE INSTALL TELOSYS-CLI Telosys-CLI files after « unzip » : Telosys-CLI is packaged in a “.zip” file
6. 6 Open a Command Prompt in « tuto » folder and run « tt » command (shell file or .bat file ) Print commands help : telosys> ? Print current directory : telosys> pwd Change current directory to « tuto /project » telosys> cd project Set home directory ( project directory ) : telosys> h . Initialize the Telosys tools in the project : telosys> init LAUNCH TELOSYS-CLI AND INITIALIZE THE PROJECT
7. 7 Step 1 - Model setup ( entities definition )
8. 8 Create a new model « students » : telosys> nm students List existing models : telosys> lm List entities defined in the current model : telosys> le Create a new entity « student » : telosys> ne student List entities : telosys> le Edit entity « student » telosys> ee student Check the current model telosys> cm HOW TO CREATE A MODEL FROM SCRATCH The current model is displayed in the prompt
9. 9 If you don’t want to create a full model from scratch you can download an existing model : http://www.telosys.org/download/models-v3/ In « /tuto/project/TelosysTools » Unzip ( « Extract here » ) List models : telosys> lm Select the « cars » model : telosys> m cars List entities : telosys> le Edit entity « Car »: telosys> ee car DOWNLOAD THE « CARS » MODEL
10. 10 Step 2 - Templates installation
11. 11 PYTHON BUNDLES AVAILABLE ON GITHUB See : https://github.com/telosys-templates-v3
12. 12 For our application we need 2 bundles of templates : • 1 bundle for the persistence layer • 1 bundle for the web MVC layer REQUIRED BUNDLES OF TEMPLATES Web browser Controllers Services Views D.A.O. Entities python-web-mvc-bottle python-persistence-sqlalchemy
13. 13 Print current GitHub store : telosys> gh List all bundles available on GitHub : telosys> lgh List bundles containing “pyt” on GitHub : telosys> lgh pyt Install bundles containing “pyt” : telosys> ib pyt List installed bundles : telosys> lb INSTALL BUNDLES OF TEMPLATES
14. 14 Step 3 - Code generation
15. 15 Select the bundle of templates for the MVC layer ( “python-web-mvc-bottle” )  select bundle containing “mvc” : telosys> b mvc Launch generation : telosys> gen * * -r ( generate all entities target files using all templates and copy static resources if any ) USE « Web MVC » FOR CODE GENERATION
16. 16 For each entity : • “form” template • “list” template « Web MVC » GENERATION RESULT A controller for each entity Home page controller & utility functions
17. 17 Select bundle containing “sqlal” : telosys> b sqlal Launch generation : telosys> gen * * -r USE « Persistence SQL Alchemy » FOR CODE GENERATION
18. 18 « Persistence SQL Alchemy » GENERATION RESULT A DAO for each entity A domain class for each entity A persistence service for each entity A unit test for each DAO
19. 19 Now let’s use the generated code…
20. 20 Initialize database and launch DAO tests 1) Create the SQLite database Launch “create_database.py” ( creates the SQLite file “database.sqlite” ) 2) Initialize the database : Launch “init_database.py” ( insert few records in each table ) 3) Launch DAO unit tests : Launch “run_tests.py”
21. 21 1) Start the web application Launch “app.py” ( creates the SQLite file “database.sqlite” ) 2) Test the application with a web browser http://localhost:3000/ Launch the generated web application
22. 22 That's it ! Now you can customize the entities or the templates…
