Future-proof styling in Drupal (8)

We've all been there: lookin' a thousands line spaghetti code of CSS, scrolling up and down, trying to find all the declarations, which override each other here and there, and almost cry when we find out that changing one thing affects a lot more page elements than we expected. (In the meantime we mumble some angry words about the previous developer of the file and sometimes we realize that we are talking about ourselves…)

Slides form my workshop @ drupalaton:
http://2014.drupalaton.hu/schedule#speaker-22

Transcript

1. Future-proof styling

   in Drupal (8)
   by Tamás Hajas


   View Slide

2. There is NO
   One Right Way!


   View Slide

3. There is NO
   One Right Way!


   View Slide

4. Team


   View Slide

5. Team » Communication


   View Slide

6. Coding Standards


   View Slide

7. Drupal
   CSS Coding Standards
   https://www.drupal.org/node/1886770


   View Slide

8. CSS formatting guidelines
   CSS file organization (for Drupal 8)
   CSS architecture (for Drupal 8)


   View Slide

9. CSS formatting guidelines
   CSS file organization (for Drupal 8)
   CSS architecture (for Drupal 8)


   View Slide

10. Comment your code!


    View Slide

11. Team » Communication


    View Slide

12. “Don’t make me think!”


    View Slide

13. “code should be

    self-documenting”


    View Slide

14. /**
    * Grid container
    * Must only contain '.cell' children.
    */
    .grid {
    height: 100%;
    !
    font-size: 0;
    !
    white-space: nowrap;
    }


    View Slide

15. /**
    * Grid container
    * Must only contain '.cell' children.
    */
    .grid {
    height: 100%;
    /* Remove inter-cell whitespace */
    font-size: 0;
    /* Prevent inline-block cells wrapping */
    white-space: nowrap;
    }


    View Slide

16. Formatting tools:
    CSScomb
    .editorconfig


    View Slide

17. CSS formatting guidelines
    CSS file organization (for Drupal 8)
    CSS architecture (for Drupal 8)
    [META] Architect our CSS – http://drupal.org/node/1921610


    View Slide

18. SMACSS
    See purecss.io for kind of an implementation


    View Slide

19. SMACSS structure
    • Base
    !
    !
    !


    View Slide

20. SMACSS structure
    • Base
    • Layout
    !
    !
    !


    View Slide

21. SMACSS structure
    • Base
    • Layout
    • Module
    !


    View Slide

22. SMACSS structure
    • Base
    • Layout
    • Module
    • State


    View Slide

23. SMACSS structure
    • Base
    • Layout
    • Module
    • State
    • Theme


    View Slide

24. SMACSS-like


    View Slide

25. SMACSS structure
    • Base
    • Layout
    • Module
    • State
    • Theme


    View Slide

26. SMACSS-like categories of Drupal 8
    • Base
    • Layout
    • Component Module
    • State
    • Theme


    View Slide

27. CSS files for Drupal 8
    modules


    View Slide

28. • module_name.module.css

    (layout, component, state)
    !


    CSS files for Drupal 8 modules


    View Slide

29. • module_name.module.css

    (layout, component, state)
    • module_name.theme.css


    CSS files for Drupal 8 modules


    View Slide

30. • module_name.module.css

    (layout, component, state)
    • module_name.theme.css
    • module_name.admin.css

    (layout, component, state)
    CSS files for Drupal 8 modules


    View Slide

31. • module_name.module.css

    (layout, component, state)
    • module_name.theme.css
    • module_name.admin.css

    (layout, component, state)
    • module_name.admin.theme.css
    CSS files for Drupal 8 modules


    View Slide

32. • module_name.module.css

    (layout, component, state)
    • module_name.theme.css
    • module_name.admin.css

    (layout, component, state)
    • module_name.admin.theme.css
    • module_name.base.css
    CSS files for Drupal 8 modules


    View Slide

33. # Stylesheets override
    !
    !
    # Remove not used stylesheets
    Change record: https://drupal.org/node/1876600
    stylesheets-override:
    - system.theme.css
    !
    !
    stylesheets-remove:
    - node.module.css
    mysubtheme.info.yml


    View Slide

34. CSS files for Drupal 8
    themes


    View Slide

35. • base.css
    • layout.css
    • components.css

    (components, -state, -theme)
    CSS files for Drupal 8 themes


    View Slide

36. base
    • normalize.css
    • elements.css
    layout
    • layout.css
    • layout--rtl.css
    • …
    components
    • button.css
    • tabs.css
    • …
    (theme)
    • theme--light.css
    • theme--dark.css
    CSS files for Drupal 8 themes


    View Slide

37. base
    layout
    components
    shame.scss
    no-query.scss
    style.scss
    Possible Sass file structure
    config
    • _extendables.scss
    • _functions.scss
    • _mixins.scss
    • _variables.scss


    View Slide

38. Tip: use Sass Globbing
    @import
    "config/**/*",
    "base/**/*",
    "layout/**/*",
    "components/**/*";
    https://github.com/chriseppstein/sass-globbing


    View Slide

39. CSS formatting guidelines
    CSS file organization (for Drupal 8)
    CSS architecture (for Drupal 8)


    View Slide

40. Overly
    complex
    selectors
    CSS pitfalls:
    Relying on HTML structure
    div.block .title a:link {
    #sidebar-first & {
    .node-19 & {}
    }
    }


    View Slide

41. Qualified
    selectors
    CSS pitfalls:
    Relying on HTML structure
    div.block .title a:link {
    #sidebar-first & {
    .node-19 & {}
    }
    }


    View Slide

42. Context
    based
    selector
    modification
    CSS pitfalls:
    div.block .title a:link {
    #sidebar-first & {
    .node-19 & {}
    }
    }


    View Slide

43. Descendant
    selectors
    with too
    generic
    classnames
    CSS pitfalls:
    div.block .title a:link {
    #sidebar-first & {
    .node-19 & {}
    }
    }


    View Slide

44. Using ID
    selector
    for styling
    CSS pitfalls:
    div.block .title a:link {
    #sidebar-first & {
    .node-19 & {}
    }
    }


    View Slide

45. Using
    !important
    CSS pitfalls:
    div.block .title a:link {
    #sidebar-first & {
    .node-19 & {
    …!important;
    }
    }
    }


    View Slide

46. Keep specificity low!


    View Slide

47. body #content .data img:hover {}
    !
    !
    !
    !
    #content .data img
    :hover body
    0*1000 + 1*100 + 2*10 + 2*1 = 122
    0 1 2 2 » 122
    Specificity example


    View Slide

48. • Base
    • Layout
    • Component
    • State
    • Theme
    SMACSS-like categories of Drupal 8


    View Slide

49. Component
    UI Pattern
    Module
    SMACSS
    Object
    OOCSS
    Block
    BEM


    View Slide

50. Object Oriented
    Programming
    See @crell’s OOP intro: http://drupalwatchdog.com/volume-3/issue-1/object-oriented-programming-101


    View Slide

51. DRY
    http://vicvapor.com/cracked-desert-background


    View Slide

52. Don’t Repeat Yourself!
    http://vicvapor.com/cracked-desert-background


    View Slide

53. Reusable
    Repeatable
    Component


    View Slide

54. Reusable
    Repeatable
    Component
    less lines

    of code


    View Slide

55. Reusable
    Repeatable
    Component
    less lines

    of code
    more

    maintainable


    View Slide

56. „Class names should communicate
    useful information to developers.”

    – Nicolas Gallagher
    About HTML Semantics and Front-End Architecture


    View Slide

57. .red-box {}
    !
    .message--error {}


    View Slide

58. BEM


    View Slide

59. • Base
    • Layout
    • Component
    • Block

    • Element

    • Modifier

    • State

    • Theme
    John Albin: Managing complex projects with design components


    View Slide

60.









    John Albin: Managing complex projects with design components
    Component
    • Block


    View Slide

61.









    John Albin: Managing complex projects with design components
    Component
    • Element


    View Slide

62.









    John Albin: Managing complex projects with design components
    Component
    • Modifier


    View Slide

63.









    John Albin: Managing complex projects with design components
    Component
    • State


    View Slide

64. John Albin: Managing complex projects with design components
    Component
    • State
    .flover:hover {}


    View Slide

65. @media "print" {
    .flover {}
    }
    John Albin: Managing complex projects with design components
    Component
    • State


    View Slide

66. Proposal: A Style Guide for Seven
    Progress bar component


    View Slide

67. CSS architecture (for Drupal 8)
    Progress bar component

    Uploading sunset.jpg




    Uploaded 221 of 762KB
    29%


    cancel




    View Slide

68. CSS architecture (for Drupal 8)
    Progress bar component
    /**
    * Progress Bar component
    */
    .progress {}
    .progress__track {}
    .progress__bar {}
    .progress__description {}
    .progress__cancel {}
    .progress__cancel:focus,
    .progress__cancel:hover {}
    /**
    * Progress Bar small variant
    */
    .progress--small .progress__track {}
    .progress--small .progress__bar {}
    .progress--small .progress__cancel {}


    View Slide

69. Classicitis?!


    View Slide

70.

    alt="me" />


    @Stubbornella 14 minutes ago


    /* ====== media ====== */
    .media {margin:10px;}
    .media, .bd {overflow:hidden; _overflow:visible; zoom:1;}
    .media .img {float:left; margin-right: 10px;}
    .media .img img{display:block;}
    .media .imgExt{float:right; margin-left: 10px;}
    http://www.stubbornella.org/content/2010/06/25/the-media-object-saves-hundreds-of-lines-of-code/


    View Slide

71. %media {
    overflow: hidden;
    &:first-child {
    float: left;
    }
    &:last-child {
    overflow: hidden;
    }
    }
    .status {
    @extend %media
    // ...
    }
    !
    .profile {
    @extend %media
    // ...
    }
    http://ianstormtaylor.com/oocss-plus-sass-is-the-best-way-to-css


    View Slide

72. • Base
    • Layout
    • Component
    • State
    • Theme
    SMACSS-like categories of Drupal 8


    View Slide

73. „Layouts where you put your
    components.”

    – John Ferris
    https://austin2014.drupal.org/session/layout-design-patterns


    View Slide

74. There is NO
    One Right Way!


    View Slide

75. Tamás Hajas
    Drupal consultant
    Integral Vision Ltd
    integralvision.hu
    about.me/tamashajas


    View Slide
