Build serverless application on top of Kubernetes #sdmel19

Build serverless application on top of Kubernetes #sdmel19

ServerlessDays Melbourne 2019 @Melbourne Museum by toshi0607 #sdmel19

https://www.serverlessdays.me/speakers/toshinori-sugita/

YouTube is here!
https://youtu.be/K7RYOPYiitA

Toshinori Sugita

August 29, 2019
Tweet

More Decks by Toshinori Sugita

Other Decks in Technology

Transcript

  1. Build serverless application on top of Kubernetes

    ServerlessDays Melbourne 2019 @Melbourne Museum by toshi0607


    View Slide

  2. About Me

    ● Toshinori Sugita

    ○ toshi0607

    ● Tokyo, Japan

    ● Software Engineer @Merpay, Mercari

    ○ developing payment service with Go, gPRC and GKE

    ● Active in Serveless Community (JP)

    ○ Serverless Meetup Tokyo, Serverless Days Tokyo

    ● OSS Contributor

    ○ Serverless Framework, aws-lambda-go/dotnet, Knative, KEDA

    ● Author

    ○ How to deal with Knative (ja), Learning AWS Lambda with Go (ja)


    View Slide

  3. What I learned and lost in 3 weeks in Cairns

    ● lost my smartphone on the first day

    ● how to play beach volleyball

    ● blueness of the sky and the sea

    ● brownness of TimTam


    View Slide

  4. Kubernetes

    Kubernetes (K8s) is an open-source system for automating
    deployment, scaling, and management of containerized
    applications.

    ※https://kubernetes.io/

    View Slide

  5. Concept of Kubernetes

    ● apply desired state to your cluster
    defined in declarative manner

    ● controllers on K8s watch and keep
    desired state

    →reduce operational cost by auto
    recovery in trouble and auto scaling at
    high load

    ※https://kubernetes.io/docs/concepts/workloads/controllers/deployment/

    View Slide

  6. How do we build a service with K8s?

    ● write code

    ● write Dockerfile

    ● build Docker image

    ● push image to registry

    ● deploy service

    ● expose service to internet

    ● set up monitoring

    ● set up autoscaling

    →We want to focus more on writing code!


    View Slide

  7. Serverless

    ※https://github.com/cncf/wg-serverless/tree/master/whitepapers/serverless-overview
    Serverless computing refers to the concept of building and running
    applications that do not require server management. It describes a
    finer-grained deployment model where applications, bundled as one or
    more functions, are uploaded to a platform and then executed, scaled,
    and billed in response to the exact demand needed at the moment.


    View Slide

  8. Serverless

    ※https://github.com/cncf/wg-serverless/tree/master/whitepapers/serverless-overview
    the idea that consumers of serverless computing no longer need to
    spend time and resources on server provisioning, maintenance,
    updates, scaling, and capacity planning. Instead, all of these tasks and
    capabilities are handled by a serverless platform and are completely
    abstracted away from the developers and IT/operations teams.


    View Slide

  9. Serverless

    ※https://github.com/cncf/wg-serverless/tree/master/whitepapers/serverless-overview
    As a result...

    ● Developers

    ○ can focus on writing their applications’ business logic.

    ● Operations engineers

    ○ can elevate their focus to more business critical tasks.

    →We want to realize this situation on top of K8s


    View Slide

  10. Serverless

    ※https://github.com/cncf/wg-serverless/tree/master/whitepapers/serverless-overview
    A serverless computing platform may provide one or both of the
    following:

    ● Function as a Service (FaaS)

    ● Backend as a Service (BaaS)

    →K8s itself is not FaaS or BaaS. How do we build serverless
    application on top of K8s?


    View Slide

  11. Knative

    Kubernetes-based platform to build, deploy, and manage modern
    serverless workloads

    ※https://github.com/knative

    View Slide

  12. Kubernetes and Sserverless

    ※https://github.com/knative/serving/blob/master/docs/spec/motivation.md
    Knative defines serverless workloads as computing workloads that are:

    ● Stateless

    ● Amenable to the process scale-out model

    ● Primarily driven by application level (L7 -- HTTP, for example)
    request traffic


    View Slide

  13. Kubernetes and Sserverless

    ※https://github.com/knative/serving/blob/master/docs/spec/motivation.md
    ● K8s provides basic primitives like Deployment, and Service in
    support of the model

    →by standardizing on higher-level primitives which perform
    substantial amounts of automation of common infrastructure, it should
    be possible to build consistent toolkits that provide a richer
    experience than updating yaml files with kubectl.


    View Slide

  14. What is Knative?

    ● Abstract K8s resources

    ○ make K8s resources simple for developers and operators

    ● Building blocks to build your own PaaS/FaaS

    ○ Serving, Eventing (and Build)

    ● Solving mundane but difficult tasks such as:

    ○ Deploying a container

    ○ Routing and managing traffic with blue/green deployment

    ○ Scaling automatically and sizing workloads based on demand

    ○ Binding running services to eventing ecosystems

    →build platform to focus more on business value for developers and operators

    ※https://github.com/knative/docs

    View Slide

  15. Knative stack

    ※https://github.com/knative/docs/tree/master/docs
    Kubernetes

    Istio, Gloo or Ambassador

    Serving
 Build
 Eventing

    Platform

    Gateway

    Primitives


    View Slide

  16. Serverless platform on K8s

    ※https://github.com/knative/docs/tree/master/docs
    Kubernetes

    Istio, Gloo or Ambassador

    Serving
 Build
 Eventing

    Platform

    Gateway

    Primitives

    GitLab Serverless
 Your Own!

    Pivotal Function
    Service

    Cloud Run
 SAP Kyma

    Knative Lambda
    Runtimes

    Products


    View Slide

  17. Build FaaS on top of K8s with Knative

    ● develop server to pass request to function because deploying
    artifacts are a container

    ● decouple the server and function and include them into a
    single Dockerfile

    ● make CLI like faas-cli or tm to put K8s manifests and kubectl
    out of consciousness

    ● use cloudevents handler in your function


    View Slide

  18. Difference from other FaaS on top of K8s

    ● Knative itself is not FaaS/PaaS. It provides the layer between
    K8s and serverless framework

    ● multiple vendors are developing together as OSS

    ● using cloudevents for event handling

    →We can avoid vendor lock in and easily migrate to other
    Knative based FaaS/PaaS


    View Slide

  19. cloudevents

    ※https://cloudevents.io/

    View Slide

  20. pros/cons of FaaS on K8s with Knative

    ● freedom of runtime

    ○ (+) Can utilize any language, binary, non vendor SDK

    ○ (−) Must prepare library by yourself

    ● standardize packaging format

    ○ (+) Don’t use different Zip for each FaaS, but Dockerfile

    ○ (−) Must learn how to write effective Dockerfile

    →More responsibility, but can make them templated in consistent
    manner


    View Slide

  21. What is Cloud Run?

    Cloud Run is part of Google Cloud and it is a managed
    serverless platform that enables you to run stateless containers
    invocable via HTTP requests.

    ※https://cloud.google.com/run/

    View Slide

  22. Serverless options in GCP

    ※https://cloud.google.com/serverless-options/

    View Slide

  23. Summary

    ● Knative provides a solution to build severless platform on top
    of K8s

    ● Cloud Run provides a managed serveless container platform

    ● If you don’t operate K8s clusters, you can choose serverless
    service between CaaS and FaaS

    ● Knative and Cloud Run are not fully matured but have a great
    potential. I hope to make contributions


    View Slide

  24. Reference (Knative)

    ● Docs

    ○ https://github.com/knative/docs

    ● Book

    ○ 『Getting Started with Knative』 free!

    ○ https://content.pivotal.io/ebooks/getting-started-with-knative

    ● Tutorial

    ○ https://github.com/meteatamel/knative-tutorial

    ● Slack

    ○ https://slack.knative.dev

    ● Twitter

    ○ https://mobile.twitter.com/KnativeProject


    View Slide

  25. Thank you!

    Build servreless application on top of Kubernetes

    ServerlessDays Melbourne 2019 @Melbourne Museum by toshi0607


    View Slide
