Elasticsearch Hands On Workshop

Hands-on Workshop Elasticsearch

www.elastic.co Copyright Elastic 2015 Copying, publishing and/or distributing without written
permission is strictly prohibited 2 Agenda • Introductions • Installation • Getting Data In • Search Theory Detour — Break (15 min) — • Full-text Search • Structured Search • Analytics with Aggregations • Wrap up

Introductions

permission is strictly prohibited 4 Why are we here? • Name • Company • Experience with Elasticsearch (Is using? Production?) • Your use case • What do you expect to learn? • Is there any specific topic that you are interested?

permission is strictly prohibited 5 Elastic Family Kibana Visualize and explore data Elasticsearch Store, search, analyze Logstash | ES-Hadoop | Beats Collect, parse and enrich data Marvel Monitor and manage Shield Secure and protect Found Elasticsearch as a Service Open Source Products Commercial Products Watcher Alert and notify Support Subscriptions Training Professional Services

permission is strictly prohibited 6 What is Elasticsearch? • Document-oriented search engine – JSON based, Apache Lucene • Schema Free – Yet enables control of it when needed • Distributed – Scales Up+Out, Highly Available • API centric & RESTful – Most functionality is exposed through an API

permission is strictly prohibited 7 What can it do? • Full-text search – Find all requests for /heavy-computation-required.html • Structured search – Find all 404 requests within a particular hour • Analytics – Return the average response time for all pages • Combined – Return the average response time for all requests between 1PM and 2PM for the page /heavy-computation- required.html • All in (near) realtime

permission is strictly prohibited 8 Agenda ✓ Introductions • Installation • Getting Data In • Search Theory Detour — Break (15 min) — • Full-text Search • Structured Search • Analytics with Aggregations • Wrap up

permission is strictly prohibited 9 Installation

permission is strictly prohibited 10 Basic glossary cluster a cluster consists of one or more nodes which share the same cluster name. Each cluster has a single master node which is chosen automatically by the cluster and which can be replaced automatically if the current master node fails. node a node is a running instance of elasticsearch which belongs to a cluster. Multiple nodes can be started on a single server for testing purposes, but usually you should have one node per server. at startup, a node will use multicast (or unicast, if specified) to discover an existing cluster with the same cluster name and will try to join that cluster.

permission is strictly prohibited 11 Network Comunication • HTTP – The HTTP transport, by default on ports [9200-9300) (it will automatically try and find a free port within the range) • Transport – The internal node to node transport communication, by default on ports [9300-9400) (it will automatically try and find a free port within the range). http.port: 9200 transport.tcp.port: 9300

permission is strictly prohibited 12 Lab 1: installation and execution • Install elasticsearch • Install marvel • Edit configuration file • Run elasticsearch • Test elasticsearch • Test marvel

permission is strictly prohibited 13 Lab 1: Step 1 # enter the elasticsearch directory cd elasticsearch # extract the elasticsearch package unzip elasticsearch-1.7.1.zip # result will be a directory: elasticsearch-1.7.1 # change directory cd elasticsearch-1.7.1 # verify the distribution content ls -lh # dir on Windows # you should see the following output -rw-r--r--@ 1 pmusa staff 11K Mar 23 15:00 LICENSE.txt -rw-r--r--@ 1 pmusa staff 150B Jun 9 14:31 NOTICE.txt -rw-r--r--@ 1 pmusa staff 8.5K Jun 9 14:31 README.textile drwxr-xr-x 12 pmusa staff 408B Jul 10 16:12 bin drwxr-xr-x 4 pmusa staff 136B Jul 28 14:56 config drwxr-xr-x 26 pmusa staff 884B Jul 10 16:12 lib

permission is strictly prohibited 14 Lab 1: Step 2 # install marvel from local file ./bin/plugin -i marvel -u file:///C:/path/to/marvel-latest.zip # or install marvel from network ./bin/plugin -i elasticsearch/marvel/latest # you should see the following output -> Installing marvel... Trying file:../../marvel/marvel-latest.zip... Downloading ....................DONE Installed marvel into .../elasticsearch/elasticsearch-1.6.0/plugins/marvel # check that the plugin was really installed ./bin/plugin -l # you should see the following output -rw-r--r-- 1 pmusa staff 34K Aug 18 20:14 LICENSE.txt drwxr-xr-x 6 pmusa staff 204B Aug 18 20:14 _site -rw-r--r-- 1 pmusa staff 72K Aug 18 20:14 marvel-1.3.1.jar

permission is strictly prohibited 15 Lab 1: Step 3 # use your favorite text editor to edit the configuration file $EDITOR config/elasticsearch.yml # modify the following fields cluster.name: “es-<last 4 of your phone number>" discovery.zen.ping.multicast.enabled: false path.repo: "C:\\es_backups" # Change this to a writeable location # later, you can read and play with some other configs, such as: # node.name: ES001 # network.host: localhost # transport.tcp.port: 5000 # http.port: 5100 # bootstrap.mlockall: true # plugin.mandatory: marvel

permission is strictly prohibited 16 Lab 1: Step 4 # run in the foreground ./bin/elasticsearch # later, you can also experiment with running ES as a daemon by adding -d # ./bin/elasticsearch -d # Parameters can be passed during startup, such as cluster.name and paths # these settings will "overwrite" the config file value for this execution # ./bin/elasticsearch --cluster.name=test_cluster --path.logs=/tmp/

permission is strictly prohibited 17 Lab 1: Step 5 # test if elasticsearch is running curl localhost:9200 # or just open localhost:9200 in your browser # you should see a response like this { "status" : 200, "name" : "Sentry", "cluster_name" : "elasticsearch", "version" : { "number" : "1.6.0", "build_hash" : "cdd3ac4dde4f69524ec0a14de3828cb95bbb86d0", "build_timestamp" : "2015-06-09T13:36:34Z", "build_snapshot" : false, "lucene_version" : "4.10.4" }, "tagline" : "You Know, for Search" }

permission is strictly prohibited 18 Lab 1: Step 6 # open the following url in your favorite browser to see marvel http://localhost:9200/_plugin/marvel # For now, just check if it is working. We will explain marvel later.

permission is strictly prohibited 19 Agenda ✓ Introductions ✓ Installation • Getting Data In • Search Theory Detour — Break (15 min) — • Full-text Search • Structured Search • Analytics with Aggregations • Wrap up

permission is strictly prohibited 20 Getting Data In

permission is strictly prohibited 21 Basic glossary Document The fundamental unit of data in Elastisearch. This is what you “feed” into Elasticsearch. A document is modeled as a JSON object. { "from": "[email protected]", "to": [ "[email protected]", “[email protected]" ], "subject": "Hello!", "body": { "text": "Hi,\nWould one of you mind…" "html": "Hi,Would one of you mind…" } }

permission is strictly prohibited 22 Field data types • Core data types – string, number, boolean, datetime, binary (base64) • Complex types – Array, Object • Other types – geo_point, geo_shape, ip, multi-field

permission is strictly prohibited 23 Basic glossary Index An index can be seen as a named collection of documents. It is a logical namespace which maps to one or more primary shards and can have zero or more replica shards. Shard A shard is a single Apache Lucene instance. It is a low-level “worker” unit which is managed automatically. Shards are distributed across all nodes in the cluster, and can move automatically from one node to another in the case of node failure, or the addition of new nodes. There are two types of shards: primary and replica.

permission is strictly prohibited 24 Basic glossary Primary shard An index can have one or more primary shards (defaults to 5) and it is not possible to change this number after index creation. When you index a document, it is first indexed on the primary shard, then on all replicas of this shard. Replica shard Each primary shard can have zero or more replicas (defaults to 1). A replica is a copy of the primary shard, and serves two purposes: • Increase high availability - a replica is another copy of the data and will be promoted to a primary shard if the primary fails • Increase read throughput - get and search requests can be handled by primary or replica shards

permission is strictly prohibited 25 Create Index API Creating index a with 2 shards and 1 replica (a total of 4 shards) Creating index b with 3 shards and 1 replica (a total of 6 shards) curl -XPUT 'localhost:9200/a' -d '{ "settings" : { "number_of_shards" : 2, "number_of_replicas" : 1 } }' curl -XPUT 'localhost:9200/b' -d '{ "settings" : { "number_of_shards" : 3, "number_of_replicas" : 1 } }'

permission is strictly prohibited 26 node4 Node/Shard Allocation node1 a0 b1 b2 node3 b1 a0 node2 a1 b0 b0 a1 b2 Primary Replica • 4 node cluster distribution example:

permission is strictly prohibited 27 Mappings • The indexed data is based on document and fields • Mapping defines how these documents should be handled – how should the documents be indexed? – what are the data types of the document fields? – how to treat object-typed fields? – what are the relations between different types of docs? – how to handle document metadata? – define boosts per fields / document type

permission is strictly prohibited 28 curl -XPUT 'localhost:9200/emails' -d '{ "settings" : { ... }, "mappings" : { "email" : { "properties" : { "from" : { "type" : "string", "index" : "not_analyzed" } } } } }' Mapping API Mapping for a specific document type Get the current mappings of a specific type: curl -XGET ‘localhost:9200/logstash-2014.03.11/_mapping/logs'

permission is strictly prohibited 29 Index API Target index name HTTP REST operation Document Document type curl -XPOST ‘localhost:9200/emails/email’ -d ' { "from": "[email protected]", "to": [ "[email protected]", “[email protected]" ], "subject": "Hello!", "body": { "text": "Hi,\nWould one of you mind…" "html": "Hi,Would one of you mind…" } }' • Adds a document to Elasticsearch and indexes it

permission is strictly prohibited 30 Lab 2: Document APIs • Create Index API - Define mapping • Index API - Index (store) a document • Get API - Retrieve a single document by its id • Update API - Modify an already indexed document • Delete API - Delete a document by its id • Bulk Index API - Index multiple documents in one request, which increases efficiency. The optimal number of documents depends on the particular cluster and use case

permission is strictly prohibited 31 Lab 2: Step 1 # open the following url in your favorite browser to see Sense http://localhost:9200/_plugin/marvel/sense/ Requests are sent to this ES node History Settings Help • Check the Help, there are interesting shortcuts! • You can use Sense from one node to query another!

permission is strictly prohibited 32 Lab 2: Step 2 # create and index and its mapping PUT emails { "mappings" : { "email" : { "properties" : { "from" : { "type" : "string", "index" : "not_analyzed" }, "to" : { "type" : "string", "index" : "not_analyzed" } } } } }

permission is strictly prohibited 33 Lab 2: Step 3 # index a single document POST emails/email { "from": "[email protected]", "to": [ "[email protected]", “[email protected]" ], "subject": "Hello!", "body": { "text": "Hi,\nWould one of you mind…" "html": "Hi,Would one of you mind…" } }

permission is strictly prohibited 34 Lab 2: Step 4 # retrieve a single document GET emails/email/{id}

permission is strictly prohibited 35 Lab 2: Step 5 # update a single document POST emails/email/{id}/_update { “doc”: { “subject”: “Greetings!” } }

permission is strictly prohibited 36 Lab 2: Step 6 # delete a single document DELETE emails/email/{id}

permission is strictly prohibited 37 Lab 2: Step 7 # bulk insert several documents POST emails/email/_bulk { “index”: { “_id”: 1 } } { "from": “[email protected]", "to": [ "[email protected]", “[email protected]" ], "subject": “Hello!", "body": { "text": "Hi,\nWould one of you mind…”, ”html": "Hi,Would one of you mind…” } } { “index”: { “_id”: 2 } } { "from": “[email protected]”, "to": [ "[email protected]", “[email protected]" ], "subject": “Re: Hello!”, "body": { "text": “Sure, no problem!” } } { “index”: { “_id”: 3 } } { "from": “[email protected]”, "to": [ "[email protected]", “[email protected]" ], "subject": “Re: Hello!”, "body": { "text": “Thanks, John!” } }

permission is strictly prohibited 38 Agenda ✓ Introductions ✓ Installation ✓ Getting Data In • Search Theory Detour — Break (15 min) — • Full-text Search • Structured Search • Analytics with Aggregations • Wrap up

permission is strictly prohibited 39 Search Theory Detour

permission is strictly prohibited 40 Index Term Locations

permission is strictly prohibited 41 Analysis The quick brown FOX jumped over the LAZY dog The quick brown FOX jumped over the LAZY dog the quick brown fox jumped over the lazy dog TOKENIZER LOWERCASE TOKEN FILTER ENGLISH STOPWORD TOKEN FILTER the quick brown fox over the dog jumped lazy ENGLISH STEMMING TOKEN FILTER jump lazi quick brown fox over dog

permission is strictly prohibited dog 42 Inverted Index jump lazi quick brown fox over 17 17 17 17 17 17 17 , 21 , 21

permission is strictly prohibited 43 Agenda ✓ Introductions ✓ Fundamental Concepts & Installation ✓ Getting Data In ✓ Search Theory Detour — Break (15 min) — • Full-text Search (TODO) • Structured Search (TODO) • Analytics with Aggregations (TODO) • Wrap up

permission is strictly prohibited 44 Full-text Search

permission is strictly prohibited 45 Search - Query DSL • Queries – Unstructured search, enables to query the data based on textual analysis (free text search). Queries score documents by relevancy (supports powerful custom scoring algorithms).

permission is strictly prohibited 46 Lab 3: Full-text search • Load a large dataset (twitter data) for full-text searching • Simple search via query string (?q=) • Simple search with Query DSL (match query) • Search across all fields (match query with _all) • Search across multiple fields (multi_match query) • Phrase search (match_phrase query) • Boolean search (bool query)

permission is strictly prohibited 47 Lab 3: step 1 # Note: replace "C:\\es_backups" with folder specified # in "path.repo" setting in $ES_HOME\config\elasticsearch.yml # Create the repo for the snapshot PUT _snapshot/twitter_data { "type": "fs", "settings": { "location": "C:\\es_backups", "compress": true } } # Copy and unzip file # Unzip twitter_data.zip insider C:\es_backups # You should end up with this folder: C:\es_backups\twitter_data # Do the restore POST /_snapshot/twitter_data/snapshot_1/_restore # Verify GET twitter/_count # Should show 2643 as the count

permission is strictly prohibited 48 Lab 3: step 2 # Simple search via query string GET twitter/_search?q=devops

permission is strictly prohibited 49 Lab 3: step 3 # Simple search with query DSL (match query) POST twitter/_search { "query": { "match": { "message": "devops" } } }

permission is strictly prohibited 50 Lab 3: step 4 # Search across all fields (match query with _all) POST twitter/_search { "query": { "match": { “_all": “expert devops" } } } # ... but using logical AND POST twitter/_search { "query": { "match": { “_all": { “query”: “expert devops”, “operator”: “and” } } } }

permission is strictly prohibited 51 Lab 3: step 5 # Search across multiple fields (multi_match query) POST twitter/_search { "query": { "multi_match": { "query": "devops", "fields": [ "message", "hashtags" ] } } }

permission is strictly prohibited 52 Lab 3: step 6 # Phrase search (match_phrase query) POST twitter/_search { "query": { "match_phrase": { "message": "expert devops" } } } # With slop distance of 1 term POST twitter/_search { "query": { "match_phrase": { "message": { "query": "expert devops", "slop": 1 } } } }

permission is strictly prohibited 53 Lab 3: step 7 # Boolean search (bool query) POST twitter/_search { "query": { "bool": { "must": [ { "match": { "message": "devops" } } ], "must_not": [ { "match": { "message": "pager" } } ] } } }

permission is strictly prohibited 54 Agenda ✓ Introductions ✓ Installation ✓ Getting Data In ✓ Search Theory Detour — Break (15 min) — ✓ Full-text Search • Structured Search • Analytics with Aggregations • Wrap up

permission is strictly prohibited 55 Structured Search

permission is strictly prohibited 56 Search - Query DSL • Filters – Structured search, enables narrowing the search context based on known document structure (no scoring and very fast).

permission is strictly prohibited 57 Lab 4: Structured search • Load a large dataset (census data) for structured searching • Term filter • Range filter • And filter • Bool filter • Geo distance filter • Geo bounding box filter

permission is strictly prohibited 58 Lab 4: Step 1 # Note: replace "C:\\es_backups" with folder specified # in "path.repo" setting in $ES_HOME\config\elasticsearch.yml # Create the repo for the snapshot PUT _snapshot/census_data { "type": "fs", "settings": { "location": “C:\\es_backups", "compress": true } } # Copy and unzip file # Unzip census_data.zip insider C:\es_backups # You should end up with this folder: C:\es_backups\census_data # Do the restore POST /_snapshot/census_data/snapshot_1/_restore # Verify GET census GET census/_count # Should show 250759 as the count

permission is strictly prohibited 59 Lab 4: Step 2 # Term filter POST census/_search { "query": { "filtered": { "filter": { "term": { "gender": "female" } } } } }

permission is strictly prohibited 60 Lab 4: Step 3 # Range filter POST census/_search { "query": { "filtered": { "filter": { "range": { "age": { "gte": 13, "lte": 19 } } } } } }

permission is strictly prohibited 61 Lab 4: Step 4 # And filter POST census/_search { "query": { "filtered": { "filter": { "and": [ { "term": { "gender": "female" } }, { "range": { "age": { "gte": 13, "lte": 19 } } } ] } } } }

permission is strictly prohibited 62 Lab 4: Step 5 # Bool filter POST census/_search { "query": { "filtered": { "filter": { "bool": { "should": [ { "term": { "gender": "female" } }, { "range": { "age": { "gte": 13, "lte": 19 } } } ], "must_not": [ { "term": { "zipcode": "68032" } } ] } } } } }

permission is strictly prohibited 63 Lab 4: Step 6 # Geo distance filter POST census/_search { "query": { "filtered": { "filter": { "geo_distance": { "distance": 1600, "distance_unit": "km", "location": { "lat": 41.25, "lon": -95.95 } } } } } }

permission is strictly prohibited 64 Lab 4: Step 7 # Geo bounding box filter POST census/_search { "query": { "filtered": { "filter": { "geo_bounding_box": { "location": { "top_left": { "lat": 42, "lon": -96 }, "bottom_right": { "lat": 41, "lon": -95 } } } } } } }

permission is strictly prohibited 65 Agenda ✓ Introductions ✓ Installation ✓ Getting Data In ✓ Search Theory Detour — Break (15 min) — ✓ Full-text Search ✓ Structured Search • Analytics with Aggregations • Wrap up

permission is strictly prohibited 66 Analytics with Aggregations

permission is strictly prohibited 67 Search - Aggregations • Enables slicing & dicing the data – Provides multi-dimensional grouping of results. e.g. Top URLs by country. • Many types available – All operate over values extracted from the documents - usually from specific fields of the documents, but highly customizable using scripts

permission is strictly prohibited 68 Lab 5: Aggregations • Value count aggregation • Aggregations without search results • Avg aggregation • Multiple levels of aggregations • Range aggregation • Geo distance aggregation • Multiple aggregations

permission is strictly prohibited 69 Lab 5: Step 1 # Value count aggregation POST census/_search { "aggs": { "location_count": { "value_count": { "field": "location" } } } }

permission is strictly prohibited 70 Lab 5: Step 2 # Aggregations without search results POST census/_search?search_type=count { "aggs": { "location_count": { "value_count": { "field": "location" } } } }

permission is strictly prohibited 71 Lab 5: Step 3 # Avg aggregation POST census/_search?search_type=count { "aggs": { "average_age": { "avg": { "field": "age" } } } }

permission is strictly prohibited 72 Lab 5: Step 4 # Multiple levels of aggregation POST census/_search?search_type=count { "aggs": { "average_age_by_zipcode": { "terms": { "field": "zipcode", "size": 10 }, "aggs": { "average_age": { "avg": { "field": "age" } } } } } }

permission is strictly prohibited 73 Lab 5: Step 5 # Range aggregation POST census/_search?search_type=count { "aggs": { "counts_by_age_group": { "range": { "field": "age", "ranges": [ { "to": 13 }, { "from": 13, "to": 20 }, { "from": 20, "to": 26 }, { "from": 26, "to": 46 }, { "from": 46, "to": 66 }, { "from": 66 } ] } } } }

permission is strictly prohibited 74 Lab 5: Step 6 # Geo distance aggregation POST census/_search?search_type=count { "aggs": { "donuts_around_omaha": { "geo_distance": { "field": "location", "origin": { "lat": 41.26, "lon": -96.01 }, "unit": "mi", "ranges": [ { "to": 10 }, { "from": 10, "to": 20 }, { "from": 20, "to": 30 }, { "from": 30, "to": 40 }, { "from": 40, "to": 50 }, { "from": 50, "to": 60 }, { "from": 60, "to": 70 }, { "from": 70, "to": 80 }, { "from": 80 } ] } } } }

permission is strictly prohibited 75 Lab 5: Step 4 # Multiple aggregations POST census/_search?search_type=count { "aggs": { "average_age": { "avg": { "field": "age" } }, "average_age_by_zipcode": { "terms": { "field": "zipcode", "size": 10 }, "aggs": { "average_age": { "avg": { "field": "age" } } } } } }

permission is strictly prohibited 76 Agenda ✓ Introductions ✓ Installation ✓ Getting Data In ✓ Search Theory Detour — Break (15 min) — ✓ Full-text Search ✓ Structured Search ✓ Analytics with Aggregations • Wrap up

Hands-on-Workshop Wrap Up

permission is strictly prohibited 78 Agenda ✓ Introductions ✓ Fundamental Concepts & Installation ✓ Getting Data In ✓ Search Theory Detour ✓ Full-text Search ✓ Structured Search ✓ Analytics with Aggregations ✓ Wrap up

permission is strictly prohibited 79 We <3 our community • https://www.elastic.co (Website) • https://www.elastic.co/learn (Learning Resources) • https://www.elastic.co/community/meetups (Meetups) • https://www.elastic.co/community/newsletter (News) • https://discuss.elastic.co/ (Discussion Forum) • https://github.com/elastic/ (Github) • IRC: #elasticsearch, #logstash, #kibana on freenode We like to help!!
