How we build APIs @ Huddle

Transcript

1. View Slide

2. Yiannis Triantafyllopoulos
   How we build APIs @ Huddle


   View Slide

3. /agenda
   • Design
   • Hypermedia
   • Media types
   • Versioning
   • Testing
   • APIs in overall architecture


   View Slide

4. /design
   • Big design up front is dumb, no design up front is dumber
   • Documentation-driven design
   • Endpoints, verbs, status codes and examples
   • Feedback from everyone
   • Consult and validate during code review, arch review and manual
   testing
   • Use Wiki or Markdown because why not?
   • API != CRUD
   • Follow use cases, not database tables
   • Eat your own dog food


   View Slide

5. /hypermedia
   • One and only one entry point
   • Follow links from there
   • Nice URIs are cute but conceptually treat them as
   opaque strings
   • Avoid URI templates
   • /resource/{resourceId}/subresource/{subresourceId}


   View Slide

6. /hypermedia-entry-point
   GET /entry
   200 OK
   {
   „links‟:[
   {„rel‟:‟self‟,„href‟:‟…/users/42‟},
   {„rel‟:‟avatar‟,„type‟:‟image/jpg‟, „href‟:‟…‟
   {„rel‟:‟notifications-received‟,‟href‟:‟…‟}
   „membership‟:{
   …
   }
   }


   View Slide

7. /media-types
   • Contract between client and server on how to process
   the response
   • No application specifics here
   • Choice of generic vs. custom (link)
   • HAL
   • JSON-LD
   • JSON API
   • Collection+JSON
   •


   View Slide

8. /media-types
   • application/vnd.huddle.data+json
   • links
   • Represents an action that can be performed against a resource
   • actors
   • Represents a user who has performed an action against a
   resource e.g. owner, manager, assignee
   • Opt for a generic one if you can
   • If you have to define your own, make sure you separate it
   from your domain!


   View Slide

9. /media-types
   • “edit” link relation
   Example
   GET /resource/123
   200 OK { „self‟:‟/resources/123‟, „edit‟:‟/resources/123/edit‟ }
   GET /resources/123/edit
   200 OK { „name‟:‟foo‟ }
   PUT /resources/123/edit
   { „name‟:‟bar‟ }
   204 No Content


   View Slide

10. /versioning
    • URI
    • GET /api/v2/resources/123
    • URIs identify resources and therefore should never change
    • Headers
    • Custom request header
    • X-Api-Version
    • Custom media type
    • application/vnd.github.v3+json
    • Custom media type per resource
    • application/vnd.github.user.v3+json
    • Clients need to set the correct headers for every call


    View Slide

11. /versioning
    • Adding new links or resources doesn‟t break existing
    clients
    • Removing or renaming links or resources breaks
    existing clients
    • In practice though that doesn‟t happen very frequently
    • Make breaking changes early on in development so
    that you don‟t have to make them in production


    View Slide

12. /testing
    • Unit tests
    • Handler level
    • C# using MSpec
    • Acceptance tests
    • Outside-in, mostly happy path
    • Python using requests, contexts


    View Slide

13. /unit-test
    public class UserExists {
    Establish context => {
    user = new UserBuilder().WithName(“bob”).Persist();
    handler = new UserHandler(new SqlLiteRepository(), new Mock());
    };
    Because of => {
    response = handler.Get(user.Id);
    };
    It has_successful_response => response.StatusCode.ShouldEqual(200);
    It has_user_resource => response.View.Name.ShouldEqual(“bob”);
    }


    View Slide

14. /acceptance-test
    @context
    class WhenGettingAUser(PersistedResource):
    def given_a_user(self):
    self.name = „bob‟
    self.user = self.persistUser(name=self.name)
    def when_getting_the_user(self):
    self.retrievedUser = self.api.getResource(self.user.selfUri, User.fromJson)
    def then_the_user_is_returned(self):
    assert self.retrievedUser.name == self.name


    View Slide

15. /architecture
    • Hexagonal architecture (Alistair Cockburn)
    • API as a port
    • Framework as an adapter
    • CQRS
    • ViewBuilders and Queries for reads
    • Commands for everything else


    View Slide

16. /ports-and-adapters


    View Slide

17. /read-side
    readonly viewBuilder;
    readonly userQuery;
    public OperationalResult Get(int userId){
    var viewModel = userQuery.Execute(userId);
    if(viewModel == null){
    return new OperationResult.NotFound();
    }
    var userView = viewBuilder.Render(viewModel);
    return new OperationResult.OK(){ Resource = userView };
    }


    View Slide

18. /write-side
    readonly commandDispatcher;
    public OperationalResult Delete(int userId){
    var deleteCommand = new DeleteUserCommand(){
    UserId = userId;
    };
    commandDispatcher.Send(deleteCommand);
    return new OperationResult.NoContent();
    }


    View Slide

19. /the-end
    • APIs are use cases, design them for clients
    • Single entry point, follow links from there
    • Avoid versioning if you can
    • Test your port, not your stack


    View Slide

20. /thank-you
    • We‟re hiring!
    • https://talentcommunity.huddle.com/careers


    View Slide

21. View Slide
