RFID

A short and high-level intro into RFID

Transcript

1. Radio-frequency identification


   View Slide

2. Radio-frequency
   identification (RFID) is the
   wireless non-contact use of
   radio-frequency
   electromagnetic fields to
   transfer data, for the
   purposes of automatically
   identifying and tracking tags
   attached to objects.


   View Slide

3. Some tags require no
   battery and are
   powered and read at
   short ranges via
   magnetic fields
   (electromagnetic
   induction). Others use
   a local power source
   and emit radio waves
   (electromagnetic
   radiation at radio
   frequencies).


   View Slide

4. The tag contains
   electronically stored
   information which may be
   read from up to several
   meters away. Unlike a bar
   code, the tag does not
   need to be within line of
   sight of the reader and
   may be embedded in the
   tracked object.


   View Slide

5. RFID tags are used in
   many industries. An RFID
   tag attached to an
   automobile during
   production can be used
   to track its progress
   through the assembly
   line.


   View Slide

6. Pharmaceuticals can be
   tracked through
   warehouses.


   View Slide

7. Livestock and pets
   may have tags
   injected, allowing
   positive identification
   of the animal.


   View Slide

8. Since RFID tags can be attached to
   clothing, possessions, or even implanted
   within people, the possibility of reading
   personally-linked information without
   consent has raised privacy concerns.


   View Slide

9. An RFID system uses tags, or labels
   attached to the objects to be identified.
   Two-way radio transmitter-receivers called
   interrogators or readers send a signal to
   the tag and read its response. The readers
   generally transmit their observations to a
   computer system running RFID software or
   RFID middleware.


   View Slide

10. Configurations
    • Passive Reader Active Tag (PRAT)
    • Active Reader Passive Tag (ARPT)
    • Active Reader Active Tag(ARAT)


    View Slide

11. Passive Reader Active Tag (PRAT)
    • system that has a passive reader which
    only receives radio signals from active
    tags (battery operated, transmit only).
    The reception range of a PRAT system
    reader can be adjusted from 1-2,000
    feet. Thereby allowing for great flexibility
    in applications such as asset protection
    and supervision


    View Slide

12. Active Reader Passive Tag (ARPT)
    • system that has an active reader,
    which transmits interrogator signals
    and also receives authentication
    replies from passive tags


    View Slide

13. Active Reader Active Tag (ARAT)
    • system in which active tags are awoken
    with an interrogator signal from the
    active reader. A variation of this system
    could also use a Battery Assisted Passive
    (BAP) tag which acts like a passive tag
    but has a small battery to power the
    tag's return reporting signal.


    View Slide

14. References
    • http://www.mayang.com/textures/Manmade/images/Paper/circular_design_paper_9001.jpg
    • http://www.howstuffworks.com/gadgets/high-tech-gadgets/rfid.htm
    • http://en.wikipedia.org/wiki/Radio-frequency_identification
    • http://api.ning.com/files/QFSjLPszBbnu4qF4LUg1MkX3gTJZ56r8InPoj4NDdHlRRrnKvwJJh8r-
    ZsadTQIjeZA*JkeTesnkJwbAobFyj*Psutf-cl-k/RFIDcapsule.jpg
    • http://itgsonline.com/wp-content/uploads/2007/10/2006-03-30_-_hands1.jpg
    • http://en.wikipedia.org/wiki/Microchip_implant_(human)
    • http://images.pressplaytv.com.s3.amazonaws.com/2012/06/5be1ad9430c22e9f28210accb49a2951.jpg
