The Browser Hacker's Guide To Instant Loading

The Browser Hacker's Guide To Instant Loading

The web has lacked a predictable story for loading content efficiently in a way that gets you interactive in just a few seconds. Developers have a number of primitives to get there: preload, preconnect, prefetch, HTTP/2 server push, module loading, service workers. . .the list goes on. Yet the interaction between these different pieces of the web is still not well understood or explained.

So how do you preload content that is still going to be there when a user closes the tab and comes back to visit another time? How do you avoid keeping the main thread pegged with too much JavaScript? How much is too much to ship down the wire? Venture deep into the belly of the browser to uncover the secret to instantly loading anything—backed by data.

Addy Osmani shares data-driven techniques and performance patterns for efficiently loading content instantly and explains how to ship JavaScript bundles on mobile that don’t break the bank.

Presented twice at Fluent/Velocity 2017

Addy Osmani

June 24, 2017
Tweet

More Decks by Addy Osmani

Other Decks in Technology

Transcript

  1. loading is a user journey
    with many disparate expectations
    you’ve probably heard to REDUCE DNS LOOKUPS, REDUCE ROUND-TRIP TIMES, MINIMIZE REDIRECTS, ELIMINATE UNN

    View full-size slide

  2. USERS LOOK FOR VISUAL FEEDBACK TO reassure
    them everything is working as expected.

    View full-size slide

  3. first Interactive
    consistently Interactive

    View full-size slide

  4. Time to Interactive
    <5s
    on an average mobile
    device over 3G
    *2s on repeat-load a:er Service Worker registered
    GOAL

    View full-size slide

  5. 19s
    16s 420KB
    JavaScript Startup Performance, Double-Click Mobile Speed Matters report & the HTTP Archive
    The average web page on mobile in 2017
    UNTIL INTERACTIVE FULLY LOADED JAVASCRIPT

    View full-size slide

  6. PERFORMANCE
    JavaScript
    Start-up Start-up
    o o
    V8 Runtime Call Stats

    View full-size slide

  7. 1MB script
    (250KB minified)
    JS Parse Time On Mobile

    View full-size slide

  8. about:inspect in Chrome DevTools

    View full-size slide

  9. webpagetest.org/easy
    Moto G4 + 3G

    View full-size slide

  10. Code-splitting
    // Defines a “split-point” for a separate bundle
    require.ensure([], () => {
    const profile = require('./UserProfile', cb);
    });
    import('./UserProfile')
    .then(loadRoute(cb))
    .catch(errorLoading)
    Webpack 2+
    Webpack 1
    Also see Splittable, Closure Compiler
    or Browserify

    View full-size slide

  11. Do I need to split?
    Try Code Coverage
    in Chrome DevTools

    View full-size slide

  12. Tree-shaking
    // app.js
    import { a } from ‘./module.js’;
    // module.js
    export function a () {}
    export function b () {}

    View full-size slide

  13. Use babel-preset-env to only transpile code for browsers that need it
    {
    "presets": [
    ["env", {
    "targets": {
    "browsers": ["last 2 versions"]
    }
    }]
    ]
    }
    Only transpile what you need with

    View full-size slide

  14. Minify _everything_
    Babelified ES5 w/Uglify
    ES2015+ with Babili
    css-loader + minimize:true
    Code-splitting
    Dynamic import()
    Route-based chunking
    Tree-shaking
    Webpack 2+ with Uglify
    RollUp
    DCE w/ Closure Compiler
    Optimize “Vendor” libs
    NODE_ENV=production
    CommonsChunk + HashedModuleIdsPlugin()
    Transpile less code
    babel-preset-env + modules:false
    Browserlist
    useBuiltIns: true
    Scope Hoisting:
    Webpack 3
    RollUp
    Strip unused Lodash modules
    lodash-webpack-plugin
    babel-plugin-lodash
    Fewer Moment.js locales
    ContextReplacementPlugin()

    View full-size slide

  15. Plenty of lightweight options for mobile
    Lower total cost on size + parse times from the get-go

    View full-size slide

  16. Byte savings @

    View full-size slide

  17. Brotli
    Display Ads from Google now served
    using Brotli compression!
    40%
    Data-savings up to
    15% in aggregate over gzip
    https://developers.googleblog.com/

    View full-size slide

  18. Brotli
    Improved load time by 7% in India & 4% U.S
    bit.ly/linkedin-brotli
    Decreased the size of static assets by 20%
    bit.ly/dropbox-brotli
    17% improvement for largest JS bundles
    bit.ly/certsimple-brotli
    1.5 petabytes (million gigs) saved a day
    bit.ly/playstore-brotli

    View full-size slide

  19. WebP
    30% smaller than JPEG
    25% smaller than PNG

    View full-size slide

  20. WebP
    bit.ly/webp-format
    Serving over 43B image requests a day
    25-30%
    savings for WebP on average (26% lossless)
    Data Saver + Web Store

    View full-size slide

  21. WebP Conversion
    XNConvert
    Windows/Mac/Linux
    Can convert in batch
    Supports most formats
    Alternatively:
    imagemin
    Pixelmator
    ImageMagick
    GIMP
    Leptonica

    View full-size slide

  22. WebP Serving










    Or use the Accept header + .htaccess to serve WebP if a browser supports it and it exists on disk.

    View full-size slide

  23. Service Workers
    Inbox by Gmail
    10%
    improvement in Time-to-Interactive

    View full-size slide

  24. HTTP Caching Checklist
    Use consistent URLs and minimize resource churn
    Provide a validation token (ETag) to avoid transferring unchanged bytes
    Identify resources that can be cached by intermediaries (like CDNs)
    Determine the optimal cache lifetime of resources (max-age)
    Consider a Service Worker for more control over your repeat visit caching
    1.
    2.
    3.
    4.
    5.
    bit.ly/caching-checklist

    View full-size slide

  25. Let’s hack

    View full-size slide

  26. ResourceLoadPriorityVeryHigh

    View full-size slide

  27. ResourceLoadPriorityVeryHigh

    View full-size slide

  28. Original
    Everything is high priority
    Preloaded JS
    Preloaded CSS + fonts

    View full-size slide

  29. Original
    Everything is high priority
    JS + CSS is high priority
    CSS + fonts are high prio

    View full-size slide





  30. ..
    Link: 1.js; rel="preload"; as="script"

    View full-size slide

  31. bit.ly/prpl-paFern
    PRPL
    bit.ly/prpl-paFern

    View full-size slide

  32. HTTP/2 with 3G

    View full-size slide

  33. HTTP/2 + preload with 3G

    View full-size slide

  34. Express + HTTP/2 Push Headers
    const express = require('express'),
    let app = express();
    app
    .use('/js', express.static('js'))
    .get('/', function (req, res) {
    res.set('Link', `
    ; rel=preload; as='style',
    ; rel=preload; as='script',
    ; rel=preload; as='script'`)

    View full-size slide

  35. Alternatively: Track cache content using cookies
    if (supports_http2() && !http_cached('/app.js')) {
    header('link:; rel=preload; as=script’);
    setcookie('/app.js', 'is-cached', 0, '/');
    }

    View full-size slide

  36. Alternatively: Track cache content using cookies
    function http_cached($filename) {
    if ('is-cached' === $_COOKIE[$filename]) {
    return true;
    } else {
    return false;
    }
    }
    Try CASPer

    View full-size slide

  37. Repeat visit with Service Worker

    View full-size slide

  38. Next: Differential Serving based on
    browser compatibility?
    HTTP/1 works better when resources are concatenated (bundled)
    HTTP/2 works better when resources are more granular (unbundled)
    Serve an unbundled build for server/browser combinations supporting
    HTTP/2. Trigger delivery with or HTTP/2 Push
    Serve a bundled build to minimize round-trips to get the app running on
    server/browser combinations that don't support HTTP/2 Push

    View full-size slide

  39. Debugging: HTTP/2 Server Push in DevTools

    View full-size slide

  40. Debugging: HTTP/2 Server Push in DevTools

    View full-size slide

  41. HTTP/2 Server Push Rules Of Thumb
    Push just enough resources to fill idle network time, and no more.
    Push resources in evaluation-dependence order.
    Consider using strategies to track the client-side cache.
    Use the right cookies when pushing resources.
    Use server push to fill the initial cwnd. Consider
    preload links to reveal remaining critical resources.
    1.
    2.
    3.
    4.
    5.
    bit.ly/h2push
    PUSH

    View full-size slide

  42. PRPL In-A-Box
    Polymer App
    Toolbox
    PREACT
    CLI

    View full-size slide

  43. With Service Workers

    View full-size slide

  44. With HTTP/2 Server Push

    View full-size slide

  45. babel-preset-env + per-browser bundles

    View full-size slide

  46. babel-preset-env + per-browser bundles

    View full-size slide

  47. Twitter Lite

    View full-size slide

  48. Interactive in <5s on 3G

    View full-size slide

  49. Can we get fast 3G numbers
    across the board or regular
    3G?

    View full-size slide

  50. PRPL
    Push / Preload

    View full-size slide

  51. 18% improvement

    View full-size slide

  52. 36% improvement

    View full-size slide

  53. HTML Streaming
    reduced TTFB by 30%
    (200ms), increasing time
    user’s spent in the app.
    Nicolas Gallagher, Technical lead for Twitter Lite

    View full-size slide

  54. 4x improvement to
    render perf by using
    requestIdleCallback() to
    defer JS loading of
    images.
    Nicolas Gallagher, Technical lead for Twitter Lite

    View full-size slide

  55. Heavy image decode Lower image decode

    View full-size slide

  56. Adapt intelligently
    H
    E
    I
    G
    H
    T
    Size appropriately
    WIDTH
    IMAGE DECODE
    Compress carefully Take care with tools
    Prioritize critical images
    HIGH
    LOW
    Lazy-load the rest
    Choose the right format
    High-perf
    Images

    View full-size slide

  57. Data Saver Mode introduced up to 70% savings
    Next up: Save-Data client hint

    View full-size slide

  58. This is a headline
    Followed by a subhead
    This is body copy and it goes a little like this and Lorem ipsum
    dolor sit amet, consectetur adipiscing elit. This is body copy and
    it goes a little like this and Lorem ipsum dolor sit amet,
    consectetur adipiscing elit.
    Application Shell
    A skeleton representing the
    user interface that can be
    offline cached & instantly
    rendered on repeat visits.

    View full-size slide

  59. Before Service Worker
    After Service Worker

    View full-size slide

  60. Before code-splitting

    View full-size slide

  61. webpack-web.config.js
    const plugins = [
    // extract vendor and webpack's module manifest
    new webpack.optimize.CommonsChunkPlugin({
    names: [ 'vendor', 'manifest' ],
    minChunks: Infinity
    }),
    // extract common modules from all the chunks (requires no
    'name' property)
    new webpack.optimize.CommonsChunkPlugin({
    async: true,
    children: true,
    minChunks: 4
    })
    ];

    View full-size slide

  62. After code-splitting
    bit.ly/twitterlite-perf
    bit.ly/twitter-casestudy

    View full-size slide

  63. https://meowni.ca/font-style-matcher/

    View full-size slide

  64. https://www.zachleat.com/web/comprehensive-webfonts/
    “Comprehensive
    Web Fonts”

    View full-size slide

  65. type="font/woff">
    Link: ; rel=preload; as=font;
    type='font/woff'

    View full-size slide

  66. Heaviest use of rel=preload is for Web Fonts
    HTTPArchive

    View full-size slide

  67. Preloading Web Fonts = 50% (1.2s)
    improvement in time-to-text-paint

    View full-size slide

  68. Control font performance
    with font-display
    auto: uses whatever font display strategy the user-agent uses
    block: draws "invisible" text at first if the font is not loaded, but swaps
    the font face in as soon as it loads
    swap: draws text immediately with a fallback if the font face isn’t
    loaded, but swaps the font face in as soon as it loads
    fallback: font face is rendered with a fallback at first if it’s not loaded,
    but the font is swapped as soon as it loads
    optional: if the font face can’t be loaded quickly, just use the fallback
    Chrome 60

    View full-size slide

  69. bit.ly/font-subsetting

    View full-size slide

  70. https://fonts.googleapis.com/css?family=Inconsolata
    https://fonts.googleapis.com/css?family=Inconsolata&text=Hello
    Web Font Subsetting
    ~3KB
    ~880 bytes
    Supported by Google Fonts

    View full-size slide

  71. /* Small subset, normal weight */
    @font-face {
    font-family: whatever;
    src: url('reg-subset.woff')
    format('woff');
    unicode-range: U+0-A0;
    font-weight: normal;
    }
    The browser can also handle subsetting!
    https://jakearchibald.com/2014/minimising-font-downloads/
    /* Large subset, normal weight */
    @font-face {
    font-family: whatever;
    src: url('reg-extended.woff')
    format('woff');
    unicode-range: U+A0-FFFF;
    font-weight: normal;
    }
    Chrome 36
    Firefox 44

    View full-size slide

  72. CSS Font Loading API
    https://developers.google.com/web/fundamentals/performance/optimizing-content-efficiency/webfont-optimization
    const font = new FontFace("Awesome Font", "url(/fonts/awesome.woff2)", {
    style: 'normal', unicodeRange: 'U+000-5FF', weight: '400'
    });
    // don't wait for the render tree, initiate an immediate fetch!
    font.load().then(function() {
    // apply the font (which may re-render text and cause a page reflow)
    // after the font has finished downloading
    document.fonts.add(font);
    document.body.style.fontFamily = "Awesome Font, serif";
    // OR... apply your own render strategy here...
    });
    Chrome 35
    Firefox 41

    View full-size slide

  73. Web Font Loading Tips
    Understand the anatomy of a web font and how browsers load
    font-display: optional (i.e if you can’t do it fast, load a fallback)
    Minimize font downloads by limiting range of characters you’re loading
    Minimize FOIT by using
    If you need more control try out the Font Loading API
    1.
    2.
    3.
    4.
    5.
    https://meowni.ca/posts/web-fonts/

    View full-size slide

  74. Streams API
    bit.ly/streams-ftw
    Progressive Loading: HTML

    View full-size slide

  75. in body
    bit.ly/progressive-css
    Progressive Loading: CSS

    View full-size slide

  76. in body
    bit.ly/progressive-css
    Progressive Loading: CSS











    View full-size slide

  77. medium.com/reloading

    View full-size slide
