Resiliency and Availability Design Patterns

As presented at https://devone.at/speakers/#adrianhornsby

---
We have traditionally built robust software systems by trying to avoid mistakes and by dodging failures when they occur in production or by testing parts of the system in isolation from one another. Modern methods and techniques take a very different approach based on resiliency, which promotes embracing failure instead of trying to avoid it. Resilient architectures enhance observability, leverage well-known patterns such as graceful degradation, timeouts and circuit breakers. In this session, will review the most useful patterns for building resilient software systems and especially show the audience how they can benefit from the patterns.

Transcript

1. © 2019, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
   Resiliency and Availability Design
   Patterns
   Adrian Hornsby
   Sr. Technical Evangelist
   Amazon Web Services
   @adhorn


   View Slide

2. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
   Looks familiar?


   View Slide

3. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
   Distributed Systems are hard
   Amazon Twitter Netflix


   View Slide

4. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
   Resiliency: Ability for a system to handle and
   eventually recover from unexpected conditions


   View Slide

5. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
   Partial failure mode


   View Slide

6. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
   How do we build resilient software
   systems?


   View Slide

7. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
   People
   Application
   Network & Data
   Infrastructure


   View Slide

8. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
   Let’s talk about isolation and containment


   View Slide

9. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.


   View Slide

10. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Typical service application
    Compute
    Cell
    Storage


    View Slide

11. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Cell-based architecture
    Compute
    Cell 0
    Compute
    Cell n
    Regional Service
    Storage
    Compute
    Cell 1
    Storage Storage


    View Slide

12. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    REGIONAL
    SERVICE
    Zone A Zone B Zone C Zone A Zone B Zone C
    Zone A Zone B Zone C
    Z O N A L
    S E R V I C E
    Z O N A L
    S E R V I C E
    Z O N A L
    S E R V I C E
    S E R V I C E C E L L
    S E R V I C E C E L L
    S E R V I C E C E L L
    Zone A Zone B Zone C
    S E R V I C E
    C E L L
    S E R V I C E
    C E L L
    S E R V I C E
    C E L L
    S E R V I C E
    C E L L
    S E R V I C E
    C E L L
    S E R V I C E
    C E L L
    S E R V I C E
    C E L L
    S E R V I C E
    C E L L
    S E R V I C E
    C E L L
    W I T H O U T C E L L S W I T H C E L L S


    View Slide

13. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    System properties
    Cell 0
    Service
    Cell 1 Cell n
    • Workload isolation
    • Failure containment
    • Scale-out vs. scale-up
    • Testability
    • Manageability Cell n+1


    View Slide

14. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Let’s talk about blast radius


    View Slide

15. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.


    View Slide

16. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    X X X X X X X
    X
    ♤
    ♡
    ♢ ⚀ ⚁ ⚂ ⚃
    ♧
    ♢


    View Slide

17. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Cell-based architecture
    X
    X
    ♤
    ♡
    ♢ ⚀ ⚁ ⚂ ⚃
    ♧
    ♢


    View Slide

18. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Shuffle sharding
    X
    X
    ♤
    ♡
    ♢ ⚀ ⚁⚂ ⚃
    ♡ ♤ ♧
    ♢ ⚀⚂
    ♧ ⚁⚃
    ♢ ♢
    ♡ ♧
    ♢


    View Slide

19. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Shuffle sharding
    Nodes = 8
    Shard size = 2
    Combinations = 28
    Overlap % customers
    0 53.6%
    1 42.8%
    2 3.6%


    View Slide

20. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Shuffle sharding
    Nodes = 100
    Shard size = 5
    Combinations = 75 million!
    Overlap % customers
    0 77%
    1 21%
    2 1.8%
    3 0.06%
    4 0.0006%
    5 0.0000013%


    View Slide

21. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Shuffle sharding


    View Slide

22. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Better to react without reacting


    View Slide

23. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Region
    Availability zone a Availability zone b Availability zone c
    Application
    Lets take an application …


    View Slide

24. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Region
    Availability zone a Availability zone b Availability zone c
    Application
    Requires 8 Instances
    or containers


    View Slide

25. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Overload Failures


    View Slide

26. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Region
    Availability zone a Availability zone b Availability zone c
    Application


    View Slide

27. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Region
    Availability zone a Availability zone b Availability zone c
    Application
    Requires 6 Instances
    or Containers


    View Slide

28. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Let’s talk about timeouts, backoff &
    retries.


    View Slide

29. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved.


    View Slide

30. https://dev.mysql.com/doc/connector-j/5.1/en/connector-j-reference-configuration-properties.html


    View Slide

31. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    User 1
    App DB
    Conn
    Pool
    INSERT
    Timeout client side = 10s Timeout backend side = default
    Retry INSERT
    Retry INSERT
    ERROR: Failed to get connection from pool
    Retry


    View Slide

32. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Set the timeouts through inheritance
    Timeout backend = Timeout client – time elapsed


    View Slide

33. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    User 1
    DB
    Conn
    Pool
    INSERT
    Timeout client side = 10s Timeout backend side = 10s – time elapsed
    Wait 2s before Retry
    Wait 4s before Retry
    Wait 8s before Retry
    Wait 16s before Retry
    Backoff between retries
    Backoff


    View Slide

34. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    No jitter With jitter
    https://aws.amazon.com/blogs/architecture/exponential-backoff-and-jitter/
    Simple Exponential Backoff is not enough: Add Jitter


    View Slide

35. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Adding Jitter


    View Slide

36. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Circuit Breaker
    • Wrap a protected function
    call in a circuit breaker
    object, which monitors for
    failures.
    • If failures reach a certain
    threshold, the circuit
    breaker trips.
    Producer Circuit Breaker Consumer
    Connection
    Monitoring
    Timeouts
    Breaking Circuit


    View Slide

37. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Let’s talk about load shedding.


    View Slide

38. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.


    View Slide

39. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.


    View Slide

40. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Cheaply reject excess work


    View Slide

41. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.


    View Slide

42. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Degrade & prioritize traffic
    with queues
    Worker
    Instance
    Worker
    Instance
    API
    Instance
    API
    Instance
    API
    Instance
    High Priority Queue
    Low Priority Queue


    View Slide

43. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Let’s talk about databases.


    View Slide

44. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Read / Write separation
    DB Instance DB instance read
    replica
    DB instance read
    replica
    DB instance read
    replica
    Instance Instance
    Instance
    Supports degradation through Read-Only mode


    View Slide

45. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Service Degradation & Fallbacks


    View Slide

46. https://twitter.com/redditstatus/status/1116204502703493120


    View Slide

47. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Transient state does not
    belong in the database.


    View Slide

48. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Let’s talk about chaos engineering.


    View Slide

49. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Fire Drills


    View Slide

50. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    GameDay at Amazon
    Creating Resiliency Through Destruction
    https://www.youtube.com/watch?v=zoz0ZjfrQ9s


    View Slide

51. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Chaos engineering
    https://github.com/Netflix/SimianArmy


    View Slide

52. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    Failure injection
    • Start small & build confidence
    • Application level
    • Host failure
    • Resource attacks (CPU, memory, …)
    • Network attacks (dependencies, latency, …)
    • Region attacks
    • People attack
    https://www.gremlin.com
    https://github.com/Netflix/SimianArmy https://chaostoolkit.org


    View Slide

53. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    "Chaos engineering is NOT about breaking
    things randomly without a purpose, chaos
    engineering is about breaking things in a
    controlled environment and through well-
    planned experiments in order to build
    confidence in your application to withstand
    turbulent conditions.”


    View Slide

54. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    And before we go.


    View Slide

55. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
    DON’T blame people for failure…


    View Slide

56. © 2019, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Confidential and Trademark
    Thanks you!
    @adhorn
    https://medium.com/@adhorn
    https://speakerdeck.com/adhorn/patterns-for-building-resilient-software-systems-2019


    View Slide
