Migrating Shopify's Core Rails Monolith to Trilogy

Trilogy is a client library for MySQL-compatible database servers. It was open sourced along with an Active Record adapter by GitHub this past year. With promises of improved performance, better portability and compatibility, and fewer dependencies, Shopify’s Rails Infrastructure team decided to migrate our core Rails monolith from Mysql2 to Trilogy.

In this talk, we’ll embark on a journey involving database clients, Active Record adapters, and open source contributions. We’ll learn a bit about MySQL protocols, dig into how the Active Record adapter manages the Trilogy client under the hood, and look at some of the missing features we implemented as we moved from Mysql2 to Trilogy. Finally, we’ll discuss the end result of migrating to Trilogy, and the impact it had on Shopify’s monolith in production.

Transcript

1. Migrating shopify’s core
   rails monolith
   to trilogy
   Adrianna Chang - RailsConf 2023


   View Slide

2. Hi, i’m adrianna!
   Senior Software Engineer
   Based in Ottawa, ON 󰎟
   Working with Rails since 2016 ❤
   Rails Triage Team
   Passionate about OSS and
   making Rails more diverse!
   🏻 ♀
   ☀


   View Slide

3. View Slide

4. Trilogy db client
   1
   An overview of Trilogy, and why
   you might want to use it.
   Building a feature in trilogy
   2
   Adding a new feature to
   Trilogy that we needed for our
   application.
   Migrating to trilogy
   3
   Changes we made to our app code
   to get CI passing with Trilogy.
   Deploying trilogy
   4
   How we deployed a large
   change like this to production,
   and what the results were.
   On the agenda today


   View Slide

5. Running Trilogy in production


   View Slide

6. Part 1: the trilogy db client


   View Slide

7. Trilogy db client
   ● Custom implementation of MySQL protocol
   ● Supports most frequently used parts of the
   protocol
   ○ Authentication handshake
   ○ Ping, query, and quit commands
   ● Designed for flexibility, performance and ease of
   embedding
   Check out Matthew Draper’s article
   on GitHub’s engineering blog:
   https://github.com/github/trilogy
   ● MySQL database client with Ruby bindings
   ● Open sourced by GitHub in 2022


   View Slide

8. Why switch?
   ● Minimal dependencies required for compilation
   ○ No dependency on libmysqlclient / libmariadb, which means:
   ■ Simpler installation
   ■ Can eliminate client / server version mismatch issues
   ■ Minimizes times data must be copied when handling packets
   ● Designed to perform efficiently in context of Ruby VM
   ○ Conscious use of dynamic memory allocation
   ○ API designed to use non-blocking operations and IO callbacks where
   possible


   View Slide

9. CAVEATS
   ● A few incompatibilities with MySQL 8.0
   ● Not as feature-complete as Mysql2 / libmysqlclient
   ● Newly open-sourced library
   ○ Looking for an open source project to contribute to? Consider
   helping us out! 🫶


   View Slide

10. Trilogy +
    ● Repo: github/activerecord-trilogy-adapter
    ● Database config pointing to trilogy
    ● Gems: Trilogy DB client, Active Record
    adapter


    View Slide

11. Why shopify made the switch
    ● Better developer experience
    ● Speedups in query performance
    ● Strong maintainership
    ● Upstream Trilogy to rails/rails
    ● Make Trilogy a community standard


    View Slide

12. Part 2: adding a feature
    to the trilogy client


    View Slide

13. Mysql client / server protocol
    Client Server
    Connects
    Handshake packet
    Authentication packet
    OK or ERR
    ● Server listens for connections on TCP/IP port or
    local socket
    ● When a client connects, the client and server go
    through an authentication phase
    1) Server checks whether host is allowed to
    connect
    2) If allowed, server sends handshake packet
    3) Client sends back authentication packet
    4) Server verifies information, responds with OK
    (success) or ERR


    View Slide

14. Mysql client / server protocol
    Command packet
    Result
    Client Server ● If the authentication phase is successful,
    the client can enter query phase and
    issue commands
    ● Many type of commands:
    ○ COM_PING
    ○ COM_QUERY
    ○ COM_QUIT
    Examples of other types of commands
    available in the query phase:
    ● Server responds with result:
    ○ OK, EOF, ERR or result set


    View Slide

15. Protocol capabilities
    ● During the authentication phase, the client and
    server exchange info about what they’re able to
    do via a bitmask of protocol capabilities
    Client Server
    Connects
    Handshake packet
    Authentication packet
    OK or ERR
    Interested in learning more? Check out
    the MySQL docs on capabilities flags:
    ● Examples:
    ○ CLIENT_CONNECT_WITH_DB
    ○ CLIENT_SSL
    ○ CLIENT_MULTI_STATEMENT


    View Slide

16. ”MySQL supports the execution of a string
    containing multiple statements separated by
    semicolon (;) characters. This capability is
    enabled by special options specified either
    when you connect to the server [...] or after
    connecting by calling set_server_option().“
    MySQL docs on multi-statement
    execution support:
    Multi-statement support


    View Slide

17. Multi-statement support
    ”MySQL supports the execution of a
    string containing multiple
    statements separated by
    semicolon (;) characters. This
    capability is enabled by special options
    specified either when you connect to the
    server [...] or after connecting by calling
    set_server_option().“
    Multi-statement support


    View Slide

18. Protocol Capabilities
    ”During the authentication phase, the client and
    server exchange info about what they’re able to do.“
    Client Server
    Connects
    Handshake packet
    Authentication packet
    OK or ERR
    Flag: CLIENT_MULTI_STATEMENTS
    Hex Value: 0x10000
    When set, indicates that the client can send more than
    one statement in one query.
    Multi-statement support


    View Slide

19. Multi-statement support
    Multi-statement support


    View Slide

20. Multi-statement support
    ● Fixture insertion!
    ○ Reducing queries required to
    insert fixtures
    ● Multi-statement queries can be more
    performant
    ○ Shopify: ~1000 fixture sets,
    some with 100s of fixtures
    Multi-statement support
    Why does this matter for Rails?


    View Slide

21. ● #multi_statements_enabled?
    ○ Are multi-statements enabled?
    A look at the Mysql2 adapter in Rails…
    ● #with_multi_statements
    ○ Runs block in multi-statement
    context
    Multi-statement support


    View Slide

22. Multi-statement support


    View Slide

23. ● #execute_batch
    ○ Combines statements into smaller
    number of SQL strings
    ● #abandon_results!
    ○ Get connection back to usable state
    A look at the Mysql2 adapter in Rails…
    ○ Adds SQL chunks up up to
    @@max_allowed_packet
    Multi-statement support


    View Slide

24. Multi-statement support


    View Slide

25. MySQL docs on multi-statement
    execution support:
    ”MySQL supports the execution of a string
    containing multiple statements separated by
    semicolon (;) characters. This capability is
    enabled by special options specified either
    when you connect to the server [...] or
    after connecting by calling
    set_server_option().“
    Multi-statement support


    View Slide

26. Requirement #1: Initialize new clients with MULTI_STATEMENTS option set.
    @paarthmadan
    Multi-statement support


    View Slide

27. Multi-statement support


    View Slide

28. Multi-statement support


    View Slide

29. Multi-statement support


    View Slide

30. Multi-statement support
    Requirement #1: Initialize new clients with MULTI_STATEMENTS option set.


    View Slide

31. Requirement #2: Allow MULTI_STATEMENTS flag to be set after connecting.
    Multi-statement support


    View Slide

32. Reminder:
    C Extension
    Ruby
    Trilogy C API
    ● Commands in C API split into send_ and
    recv_ functions
    ● trilogy_set_option_send: builds set
    option packet and writes to socket
    Multi-statement support


    View Slide

33. C Extension
    Ruby
    Trilogy C API
    Builds a COM_SET_OPTION packet with the
    server option to set
    COM_SET_OPTION packet
    Result
    Client Server
    Multi-statement support


    View Slide

34. Multi-statement support
    C Extension
    Ruby
    Trilogy C API


    View Slide

35. Multi-statement support
    ● Commands in C API split into send_
    and recv_ functions
    ● trilogy_set_option_recv: reads
    response packet from server
    C Extension
    Ruby
    Trilogy C API


    View Slide

36. Calls #trilogy_set_option_send
    with the specified option
    ● Expose #set_server_option in Ruby
    Waits for response from server via
    #trilogy_set_option_recv
    Returns true on success, handles timeouts
    / errors
    Multi-statement support
    C Extension
    Ruby
    Trilogy C API
    ● In our C extension…


    View Slide

37. Requirement #2: Allow MULTI_STATEMENTS flag to be set after connecting.
    Multi-statement support


    View Slide

38. Multi-statement support
    ● #multi_statements_enabled?
    ○ Are multi-statements enabled?
    Now with the Trilogy adapter…
    ● #with_multi_statements
    ○ Runs block in multi-statement
    context


    View Slide

39. Multi-statement support


    View Slide

40. Multi-statement support


    View Slide

41. Original PR for
    multi-statement
    support in Trilogy:
    Support for
    setting server
    options in Trilogy:
    Adding multi-statement
    capabilities to Trilogy
    Active Record adapter:
    Multi-statement support


    View Slide

42. Part 3: migrating to
    trilogy


    View Slide

43. Goal: have a green ci build with trilogy
    Step 1: Set application up to use Trilogy


    View Slide

44. Step 2: Address small API changes in client
    Goal: have a green ci build with trilogy
    Mysql2::Result
    Trilogy::Result


    View Slide

45. Goal: have a green ci build with trilogy
    Step 2: Address small API changes in client


    View Slide

46. Step 3: Handle error class changes
    Mysql2::Timeout
    Error
    Trilogy::Timeout
    Error
    Mysql2::Connection
    Error
    Trilogy::Connection
    Error
    Goal: have a green ci build with trilogy


    View Slide

47. Goal: have a green ci build with trilogy
    Step 3: Handle error class changes


    View Slide

48. Step 3: Handle error class changes
    Goal: have a green ci build with trilogy


    View Slide

49. Part 4: summit?
    Deploying trilogy to production


    View Slide

50. ● Core Rails application is a modular monolith
    Shopify Core
    ● BFCM 2022: 14 million queries per second at peak
    ● Database infrastructure
    ○ Database is horizontally partitioned
    ○ MySQL instances run on Google Cloud
    Platform VMs managed by Chef
    ○ ProxySQL
    ■ ~100 000 client connections to
    ~2000 backend connections


    View Slide

51. Step 1: Attempt to run Trilogy DB client on 1% of production
    ● Export ENV var on 1% of production pods
    ● Switch out adapter in config/database.yml based on ENV var


    View Slide

52. Step 1: Attempt to run Trilogy DB client on 1% of production
    ● Export ENV var on 1% of production pods
    ● Switch out adapter in config/database.yml based on ENV var
    ● Ensure application code supported both Mysql2 and Trilogy


    View Slide

53. Step 1: Attempt to run Trilogy DB client on 1% of production
    ● Separate CI pipeline for Trilogy
    ○ Too expensive!
    ● Remove Mysql2 test coverage
    ○ Not ideal, 99% of prod using Mysql2
    ● Half of CI on Trilogy, half with Mysql2
    ○ Difficult to spot bugs
    Decided to keep test coverage on
    Mysql2, and run CI against Trilogy
    daily
    How to run tests?


    View Slide

54. Step 2: Try running Trilogy on 50% of production



    View Slide

55. Step 2: Try running Trilogy on 50% of production
    What happened?!
    ● If client capabilities are different, ProxySQL
    needs to perform COM_CHANGE_USER
    ● ProxySQL keeps pool of backend connections
    Shopify Core
    Mysql2
    Trilogy
    COM_CHANGE_USER
    ● Using clients with different protocol options
    overwhelmed DB with change user commands


    View Slide

56. Step 2: Try running Trilogy on half of production
    ● Queried a ProxySQL pod’s connection list
    ● Mysql2 was setting CLIENT_MULTI_RESULTS, but Trilogy was not!
    Flag: CLIENT_MULTI_RESULTS
    Hex Value: 0x20000
    When set, tells the server it's
    capable of handling multiple result
    sets from a query.


    View Slide

57. Step 3: Attempt to run Trilogy subset of production… again
    ● Targeted 100% of single cluster instead of 50% of production
    ● Confirmed that the connection options matched between Trilogy and Mysql2
    ● Collected some metrics
    Request time:
    ● Mysql2: Avg 3.46 ms
    ● Trilogy: Avg 2.70ms
    ~22% faster


    View Slide

58. MySQL query time:
    ● Mysql2: Avg 1.49ms
    ● Trilogy: Avg 1.24 ms
    ~ 17% faster
    Step 3: Attempt to run Trilogy subset of production… again
    ● Targeted 100% of single cluster instead of 50% of production
    ● Confirmed that the connection options matched between Trilogy and Mysql2
    ● Collected some metrics


    View Slide

59. Step 4: Run Trilogy on 100% of production
    ● No issues running Trilogy at 100% on one of our European clusters
    ● Took the plunge and migrated fully to Trilogy
    ● Changed tests to run against Trilogy instead of Mysql2
    ● Success! 🎉


    View Slide

60. View Slide

61. surprise announcement…
    The Trilogy adapter will be available in Rails 7.1!


    View Slide

62. What’s next?
    ● Give Trilogy a try in a new application!
    ● Try migrating an existing application from Mysql2 to Trilogy.
    ● Consider contributing to the Trilogy client, or the adapter
    (now in Rails!)
    ● Flex your new MySQL knowledge on all your coworkers 😂


    View Slide

63. Thanks! ❤
    adriannakchang adriannachang.me Presentation template by Slidesgo,
    icons by Flaticon.
    @paarthmadan @eileencodes @casperisfine @matthewd @composerinteralia @jhawthorn @HParker @brianmario @tenderlove


    View Slide
