From Happy Soup to Unlocked Packages

After the release of DCP packages, production environments are not just a single monolithic container of metadata. Learn how to split your production org metadata (happy soup) into multiple DCP unlocked packages to have a better software development life cycle. We will share and discuss strategies on how to approach to the most common scenarios.

Transcript

2. From Happy Soup to Unlocked Packages Aldo Fernandez Platform Architect Litify @aldoforce
4. Aldo Fernandez Platform Architect Litify @aldoforce aldoforce.com Breaking stuff since 2008
5. Agenda • Know your Happy Soup • SalesforceDX • Unlocked Packages • Identify, split and aggregate metadata • Foundation and Business Packages • Package Architecture • Dependency’s challenges
6. Sweet Potato with nutmeg and maple syrup
7. Happy Soup! Ingredients • All org’s metadata • Declarative customizations • Process • Flows • Validation Rules • SObjects • Workflows • …everything point-n-click • Programmatic customizations • Apex • Triggers • AppExchange Packages and Customizations = Monolithic Container
8. There’s nothing wrong with monoliths
9. my codebase: ~609 classes
10. SalesforceDX • Salesforce Development evolved • Modern Software Practice • Metadata and code are modular • Development is based on open standards • Flexible packaging support agile distribution model
11. SalesforceDX: packaging • Classic release lifecycle management • change sets, ant/IDE deployments, • packaging for ISVs • Modern release lifecycle management • Packaging for Customers: DCPs • Locked Packages (pilot) • Unlocked Packages (beta)
12. Unlocked Packages • AKA: 2GP, Unlocked DCP, • Fully supported by SalesforceDX • Encapsulated metadata container • Freedom to make changes after installed • Allow downgrading • Optionally can leverage namespaces(*) • Delegate change management
13. split in modular units happySoup -> unlocked packages How?
14. Understand your org’s metadata • What metadata do you have in your org? • Who needs it? • What critical process(es) are supported? • How dependency looks like? • Who is/was owner of what? #TIP: Create a Catalogue by Metadata Type
15. Identify key components Salesforce Customizations AppExchange Apps Custom Applications AppExchange Apps Customizations Utilities and Frameworks Integrations #TIP: Aggregate your metadata in Units
16. Refine your Units Modular Business Units: = Business Packages LeadGen Marketing OnBoarding Drawloop Portal MobileApp Base Units: = Foundation Packages Core Common
17. Drawloop Portal MobileApp Core LeadGen Marketing OnBoarding Drawloop Common Framework Renewals #TIP: Identify dependencies early Dependency graph
18. Foundation Packages • Core • Base package • Common interfaces • Your own frameworks • External libraries • No SObjects • Everyone depends on this • Common • Responsible for Standard Objects • Provide minimal information for all other objects • Doesn’t depend on ISVs packages • Only depends on: Core
19. Business Packages • Built over Core and Common • Limited responsibility • Leverage the use of Interfaces • Logic details should be hidden • Open design encouraging extensibility • Follow Enterprise Architecture Patterns
20. Package Architecture (I) • Follow strict naming conventions for classes • [PACKAGE]_[DESCRIPTOR] • Examples • Core_HttpRequestWrapper • COR_HttpRequestWrapper • …any combination • Why not leveraging namespaces? #TIP: “Let the metadata tell you where it belong and what’s its purpose“
21. Package Architecture (II) Selector/DB tier Domain tier Service tier Presentation tier API Services Unlocked Package Unlocked Package Unlocked Package Dependency Dependency Dependency
22. Dependency’s challenges • Dependency graph • Clean Interfaces design • Use Stub API for mocks and unit tests (forceDI) • Dynamic Field Binding on SOQLs • Dependency Injection Framework (forceDI) • Pub/Sub model for package’s communications (Platform Events)
23. CI/CD and scripting • CI provider for DevOps (Heroku Pipelines) • scratch orgs • automated testing • automated package build/deploy • Manage package dependencies from build script • Identify downstream and upstream packages
24. Futurology • CLI plugins to Manage Package Dependencies • Microservices Architectures • Open Source Libraries • Developers from other languages • Agile parallel development • Automated Code Reviews tools
25. Takeaways! • If your development life cycle process is not broken, don’t fix it! (however, do think about escalation) • Invest research time in DevOps and CI/CD • Understand how Custom Metadata Types will help resolve dynamic dependencies (ForceDI) • How your actual release management process works? Can you identify any issues? What’s the cost of change management? What’s the learning curve for DCPs?
26. Who to follow: • Andrew Fawcett @andyinthecloud [forceDI project, TDD and mocks article, DCPs] • John M. Daniel @ImJohnMDaniel [Modern ALM, DF18] • Doug Ayers @DouglasCAyers [forceDI, flows, lightning] • Fabien Taillon @FabienTaillon [DF18] • Zayne Turner @zaynelt [SalesforceDX Series] • Trailblazer Community Group: Packaging 2 Beta
27. Questions? Booth Duty: Today - 4.20pm-5.00pm
28. From Happy Soup to Unlocked Packages Aldo Fernandez Platform Architect Litify @aldoforce Thank you!!! #Forcelandia #HappySoup #UnlockedPackages #Uruguay #PuntaDreamin
