1. Jenkins Quick Guide Alex Su
2. 1. Code (Version Control System): Git, SVN 2. Build (Continuous Integration): Travis, TeamCity, DroneCI, CircleCI, Bamboo, Jenkins 3. Test (Continuous testing, inspection): JMeter, Sonarqube 4. Package (Artifact repository): Artifactory 5. Configure & Release ( Change management, containerization ): Docker Compose 6. Infrastructure ( Orchestration, cloud ): Kubernetes, Mesos, AWS, GCP, Nexus 7. Monitor ( Manage the performance): ELK, Grafana, Netdata Jenkins is a continuous integration tool for DevOps
3. Why we choose Jenkins as our CI / CD tool 1. An open source tool with great community support. 2. Has 1000+ plugins to ease our work. 3. Easy to install and use. 4. Great integration with other DevOps tools (e.g., GitLab, Jira, Slack, Docker) 5. Easy to archive artifact and deploy with custom scripts.
4. How to Install Jenkins on CentOS 7 $ sudo yum -y install epel-release $ sudo yum -y install java-1.8.0-openjdk $ sudo yum -y wget $ wget -O /etc/yum.repos.d/jenkins.repo http://pkg.jenkins.io/redhat-stable/jenkins.repo $ rpm --import http://pkg.jenkins.io/redhat-stable/jenkins.io.key $ sudo yum -y install java-1.8.0-openjdk jenkins $ docker run -p 8080:8080 -p 50000:50000 -v /home/bagel:/var/jenkins_home jenkins # Method1: yum package manager # Method2: docker
5. Initial configuration 1. open browser 2. enter http://your_ip_address:8080
6. Install suggested Plugins Install suggested plugins (recommend)
7. Installing... If the installation failed, don’t worry, you can mange the plugins later
8. Create First Admin User
9. Welcome to Jenkins!!! Configurations Jenkins agents and job status Jenkins Job view
10. Install Plugins Jenkins > Manage Jenkins > Plugin Manager
11. Useful Jenkins Plugins I • Ansible Plugin - integrated with Ansible • Blue Ocean - a new user experience for Jenkins • Copy Artifact Plugin - copy artifacts from another project • Docker Plugin - integrates Jenkins with Docker • GitLab Plugin - allows GitLab to trigger Jenkins and display results in the GitLab UI • Jira Plugin - update JIRA issues by jenkins • Monitoring - monitor jenkins itself
12. Useful Jenkins Plugins II • Role-based Authorization Strategy - easy to manage team members’ authorization • Simple Theme Plugin - define the Jenkins themes by HTML , CSS and JavaScript • Slack Notification Plugin - publish build status to Slack channels • Git Plugin - integrates Git with Jenkins • GitHub Plugin - allows GitHub to trigger Jenkins builds • BitBucket Plugin - allows BitBucket to trigger Jenkins builds • Gitlab Merge Request Builder - integrates Jenkins with Gitlab to build Merge Requests
13. Useful Jenkins Plugins III • JIRA Trigger Plugin - triggers a build when a certain condition is matched in JIRA • SSH Plugin - executes shell commands remotely using SSH protocol • HTML Publisher Plugin - Publishes HTML Reports • Pipeline Plugin - orchestrate CI / CD pipeline, simple or complex. • Performance Plugin - capture reports from popular testing tools (e.g., JUnit, JMeter) • Job DSL - allows the programmatic creation of projects using a DSL • Allure Plugin - generate test report and attach it to build during Jenkins job run
14. Setup Jenkins Credentials: via SSH Jenkins > Credentials > System > Global credentials add your private key here
15. Setup Jenkins Credentials: via secret file update the secret file (e.g., pem file)
16. Setup Jenkins Credentials: via secret text fill secrete text
17. Setup Jenkins Credentials: via username with password fill the username and password
18. Jenkins Master-Slave Setup
19. Jenkins Master-Slave Setup Jenkins > Manage Jenkins
20. Jenkins Master-Slave Setup Jenkins > Manage Jenkins > Manage Nodes
21. Jenkins > Manage Jenkins > Manage Nodes > New Nodes Jenkins Master-Slave Setup
22. Edit Node Name
23. Node Configuration number of job executors Launch Method (recommend: via SSH)
24. Node Manage Page notice to clock difference and disk usuage
25. Create a Simple Jenkins Pipeline - 1 Jenkins > New item Click here
26. Create a Simple Jenkins Pipeline - 2 General Settings for Jenkins Job
27. Create a Simple Jenkins Pipeline - 3 Choose build triggers
28. Create a Simple Jenkins Pipeline - 4 Two ways to implement pipelines: • write pipeline script directly • Pull scripts from SCM (recommend: because the pipeline scripts can be stored in git repository)
29. Jenkinsfile • Pipeline supports two syntaxes, Declarative (introduced in Pipeline 2.5) and Scripted Pipeline. • Use apache groovy language to describe the pipeline. • You can use if, when, try/catch/finally or define helper functions to control the pipeline. pipeline { agent { docker 'maven:3-alpine' } stages { stage(“Stage 1”) { steps { sh 'mvn -B clean verify' } } } } Example of declarative pipeline
30. Write a Basic Jenkinsfile (Declarative syntax) stage 1 stage 2 assign a agent
31. Visualize the Pipeline in the Blue Ocean
32. Parallel stages in pipeline stage 1 stage 2
33. Parallel stages in pipeline
34. Handle try / catch / finally in pipeline try / catch / finally block
35. Handle try / catch / finally in pipeline
36. Push Artifacts
37. Pull Artifacts (Copy Artifact Plugin) Pull the artifact from “Jenkins-example” job, artifact name is “stage.zip” (filter function support regex), and the selectors is “lastSuccessful”
38. Add HTML Coverage Report (HTML Publisher Plugin)
39. Slack Notifications (Slack Notification Plugin)
40. Use Environments echo the variable
41. References • Jenkins Official Website • Jenkins User Documentation • Jenkins Plugins • Jenkins Wiki
