Constraint Layout - Designing better UI

Implementing the best user experience should be one of the main concerns for an android developer. The user interface represents the first interaction a user has with the app and even though it must look nice, it should also have the best performance.
In this talk you will learn:
– the basic concepts about Constraint Layout
– how to convert challenging layouts into simpler ones using Constraint Layout and analyzing their performance
– animating views inside Constraint Layout
By the end of the talk, I hope, you will be more confident to write layouts using constraints or converting your current ones (where it makes sense).

Transcript

1. Constraint Layout Designing better UI Andrei Bacalu Constraint Layout Designing better UI
2. Why? Flexible Flat hierarchy Unbundled (com.android.support.constraint:constraint-layout:2.0.0-alpha2) Visual editor Performance Flexible Flat hierarchy Unbundled (com.android.support.constraint:constraint-layout:2.0.0-alpha2) Visual editor Performance depends
3. Relative positioning Centering positioning Circular positioning Bias Dimension constraints Chains Virtual helpers Animations Features (+constraint-layout:2.0.0-alpha2)
4. Subject view
6. <android.support.v7.widget.CardView> <FrameLayout> <LinearLayout android:orientation="horizontal"> <LinearLayout> </FrameLayout> </android.support.v7.widget.CardView>
7. <android.support.v7.widget.CardView> <FrameLayout> <LinearLayout android:orientation="horizontal"> <LinearLayout android:orientation="vertical" android:layout_weight="0.35"> </LinearLayout> <LinearLayout> </FrameLayout> </android.support.v7.widget.CardView>
8. <android.support.v7.widget.CardView> <FrameLayout> <LinearLayout android:orientation="horizontal"> <LinearLayout android:orientation="vertical" android:layout_weight="0.35"> <TextView/> </LinearLayout> <LinearLayout> </FrameLayout> </android.support.v7.widget.CardView>
9. <android.support.v7.widget.CardView> <FrameLayout> <LinearLayout android:orientation="horizontal"> <LinearLayout android:orientation="vertical" android:layout_weight="0.35"> <TextView/> <ImageView/> </LinearLayout> <LinearLayout> </FrameLayout> </android.support.v7.widget.CardView>
10. <android.support.v7.widget.CardView> <FrameLayout> <LinearLayout android:orientation="horizontal"> <LinearLayout android:orientation="vertical" android:layout_weight="0.35"> <TextView/> <ImageView/> <TextView/> </LinearLayout> <LinearLayout> </FrameLayout> </android.support.v7.widget.CardView>
11. <android.support.v7.widget.CardView> <FrameLayout> <LinearLayout android:orientation="horizontal"> <LinearLayout android:orientation="vertical" android:layout_weight="0.35"> <TextView/> <ImageView/> <TextView/> </LinearLayout> <RelativeLayout android:layout_weight="0.65"> </RelativeLayout> <LinearLayout> </FrameLayout> </android.support.v7.widget.CardView>
12. <android.support.v7.widget.CardView> <FrameLayout> <LinearLayout android:orientation="horizontal"> <LinearLayout android:orientation="vertical" android:layout_weight="0.35"> <TextView/> <ImageView/> <TextView/> </LinearLayout> <RelativeLayout android:layout_weight="0.65"> <RelativeLayout> <FrameLayout> <ImageView/> </FrameLayout> <ImageView android:visibility="gone"/> </RelativeLayout> </RelativeLayout> <LinearLayout> </FrameLayout> </android.support.v7.widget.CardView>
13. <android.support.v7.widget.CardView> <FrameLayout> <LinearLayout android:orientation="horizontal"> <LinearLayout android:orientation="vertical" android:layout_weight="0.35"> <TextView/> <ImageView/> <TextView/> </LinearLayout> <RelativeLayout android:layout_weight="0.65"> <RelativeLayout> <FrameLayout> <ImageView/> </FrameLayout> <ImageView android:visibility="gone"/> </RelativeLayout> <RelativeLayout> <ImageView android:background="@drawable/ic_close"/> <TextView android:id="@+id/brands_description"/> <TextView android:id="@+id/first_brand"/> <RelativeLayout android:id="@+id/second_brand_layout"> <View android:id="@+id/first_brand_divider"/> <TextView android:id="@+id/second_brand"/> </RelativeLayout> <RelativeLayout android:id="@+id/third_brand_layout"> <View android:id="@+id/second_brand_divider"/> <TextView android:id="@+id/third_brand"/> </RelativeLayout> </RelativeLayout> </RelativeLayout> <LinearLayout> </FrameLayout> </android.support.v7.widget.CardView>
14. <android.support.constraint.ConstraintLayout> <LinearLayout android:orientation="vertical" android:layout_weight="0.35"> <TextView/> <ImageView/> <TextView/> </LinearLayout> <RelativeLayout android:layout_weight="0.65"> <RelativeLayout> <FrameLayout> <ImageView/> </FrameLayout> <ImageView android:visibility="gone"/> </RelativeLayout> <RelativeLayout> <ImageView android:background="@drawable/ic_close"/> <TextView android:id="@+id/brands_description"/> <TextView android:id="@+id/first_brand"/> <RelativeLayout android:id="@+id/second_brand_layout"> <View android:id="@+id/first_brand_divider"/> <TextView android:id="@+id/second_brand"/> </RelativeLayout> <RelativeLayout android:id="@+id/third_brand_layout"> <View android:id="@+id/second_brand_divider"/> <TextView android:id="@+id/third_brand"/> </RelativeLayout> </RelativeLayout> </RelativeLayout> </android.support.constraint.ConstraintLayout> <android.support.v7.widget.CardView> <FrameLayout> <LinearLayout android:orientation="horizontal"> <LinearLayout android:orientation="vertical" android:layout_weight="0.35"> <TextView/> <ImageView/> <TextView/> </LinearLayout> <RelativeLayout android:layout_weight="0.65"> <RelativeLayout> <FrameLayout> <ImageView/> </FrameLayout> <ImageView android:visibility="gone"/> </RelativeLayout> <RelativeLayout> <ImageView android:background="@drawable/ic_close"/> <TextView android:id="@+id/brands_description"/> <TextView android:id="@+id/first_brand"/> <RelativeLayout android:id="@+id/second_brand_layout"> <View android:id="@+id/first_brand_divider"/> <TextView android:id="@+id/second_brand"/> </RelativeLayout> <RelativeLayout android:id="@+id/third_brand_layout"> <View android:id="@+id/second_brand_divider"/> <TextView android:id="@+id/third_brand"/> </RelativeLayout> </RelativeLayout> </RelativeLayout> <LinearLayout> </FrameLayout> </android.support.v7.widget.CardView> <android.support.v7.widget.CardView> <FrameLayout> <LinearLayout android:orientation="horizontal"> <LinearLayout android:orientation="vertical" android:layout_weight="0.35"> <TextView/> <ImageView/> <TextView/> </LinearLayout> <RelativeLayout android:layout_weight="0.65"> <RelativeLayout> <FrameLayout> <ImageView/> </FrameLayout> <ImageView android:visibility="gone"/> </RelativeLayout> <RelativeLayout> <ImageView android:background="@drawable/ic_close"/> <TextView android:id="@+id/brands_description"/> <TextView android:id="@+id/first_brand"/> <RelativeLayout android:id="@+id/second_brand_layout"> <View android:id="@+id/first_brand_divider"/> <TextView android:id="@+id/second_brand"/> </RelativeLayout> <RelativeLayout android:id="@+id/third_brand_layout"> <View android:id="@+id/second_brand_divider"/> <TextView android:id="@+id/third_brand"/> </RelativeLayout> </RelativeLayout> </RelativeLayout> <LinearLayout> </FrameLayout> </android.support.v7.widget.CardView>
15. Guideline • layout_constraintGuide_begin • layout_constraintGuide_end • layout_constraintGuide_percent <android.support.constraint.ConstraintLayout> <LinearLayout android:orientation="vertical" android:layout_weight="0.35"> <TextView/> <ImageView/> <TextView/> </LinearLayout> <RelativeLayout android:layout_weight="0.65"> <RelativeLayout> <FrameLayout> <ImageView/> </FrameLayout> <ImageView android:visibility="gone"/> </RelativeLayout> <RelativeLayout> <ImageView android:background="@drawable/ic_close"/> <TextView android:id="@+id/brands_description"/> <TextView android:id="@+id/first_brand"/> <RelativeLayout android:id="@+id/second_brand_layout"> <View android:id="@+id/first_brand_divider"/> <TextView android:id="@+id/second_brand"/> </RelativeLayout> <RelativeLayout android:id="@+id/third_brand_layout"> <View android:id="@+id/second_brand_divider"/> <TextView android:id="@+id/third_brand"/> </RelativeLayout> </RelativeLayout> </RelativeLayout> </android.support.constraint.ConstraintLayout> <android.support.constraint.ConstraintLayout> <LinearLayout android:orientation="vertical" android:layout_weight="0.35"> <TextView/> <ImageView/> <TextView/> </LinearLayout> <RelativeLayout android:layout_weight="0.65"> <RelativeLayout> <FrameLayout> <ImageView/> </FrameLayout> <ImageView android:visibility="gone"/> </RelativeLayout> <RelativeLayout> <ImageView android:background="@drawable/ic_close"/> <TextView android:id="@+id/brands_description"/> <TextView android:id="@+id/first_brand"/> <RelativeLayout android:id="@+id/second_brand_layout"> <View android:id="@+id/first_brand_divider"/> <TextView android:id="@+id/second_brand"/> </RelativeLayout> <RelativeLayout android:id="@+id/third_brand_layout"> <View android:id="@+id/second_brand_divider"/> <TextView android:id="@+id/third_brand"/> </RelativeLayout> </RelativeLayout> </RelativeLayout> </android.support.constraint.ConstraintLayout>
16. <android.support.constraint.ConstraintLayout> <android.support.constraint.Guideline android:orientation="vertical" app:layout_constraintGuide_percent="0.35"/> <TextView android:id="@+id/textView1"/> <ImageView android:id="@id/imageView"/> <TextView android:id="@id/textView2"/> <RelativeLayout> <FrameLayout> <ImageView/> </FrameLayout> <ImageView android:visibility="gone"/> </RelativeLayout> <RelativeLayout> <ImageView android:background="@drawable/ic_close"/> <TextView android:id="@+id/brands_description"/> <TextView android:id="@+id/first_brand"/> <RelativeLayout android:id="@+id/second_brand_layout"> <View android:id="@+id/first_brand_divider"/> <TextView android:id="@+id/second_brand"/> </RelativeLayout> <RelativeLayout android:id="@+id/third_brand_layout"> <View android:id="@+id/second_brand_divider"/> <TextView android:id="@+id/third_brand"/> </RelativeLayout> </RelativeLayout> </android.support.constraint.ConstraintLayout> Constraints • layout_constraintTop_toTopOf • layout_constraintTop_toBottomOf • • layout_constraintBottom_toBottomOf • layout_constraintBottom_toTopOf • • layout_constraintStart_toStartOf • layout_constraintStart_toEndOf • • layout_constraintEnd_toEndOf • layout_constraintEnd_toStartOf • • layout_constraintBaseline_toBaselineOf
17. <android.support.constraint.ConstraintLayout> <android.support.constraint.Guideline android:orientation="vertical" app:layout_constraintGuide_percent="0.35"/> <TextView android:id="@+id/textView1" app:layout_constraintEnd_toStartOf="@id/guideline" app:layout_constraintStart_toStartOf="parent" app:layout_constraintTop_toTopOf="parent"/> <ImageView android:id="@id/imageView” app:layout_constraintEnd_toEndOf="@id/guideline" app:layout_constraintBottom_toTopOf="@+id/textView2" app:layout_constraintTop_toBottomOf="@id/textView1" app:layout_constraintStart_toStartOf="parent"/> <TextView android:id="@id/textView2" app:layout_constraintEnd_toEndOf="@id/guideline" app:layout_constraintBottom_toBottomOf="parent" app:layout_constraintStart_toStartOf="parent"/> </android.support.constraint.ConstraintLayout>
18. Chains app:layout_constraintVertical_chainStyle="spread/spread_inside/packed" app:layout_constraintHorizontal_chainStyle="spread/spread_inside/packed" app:layout_constraintVertical_bias="0.2" app:layout_constraintHorizontal_bias="0.7"
19. Groups <android.support.constraint.Group android:id="@+id/groupId" android:layout_width="wrap_content" android:layout_height="wrap_content" app:constraint_referenced_ids="view1, view2, view3..." /> findViewById(R.id.groupId).setVisibility(GONE/VISIBLE/INVISIBLE);
20. Animations layout_1.xml layout_2.xml val constraintSet1 = ConstraintSet() val constraintSet2 = ConstraintSet() constraintSet1.clone(this, R.layout.layout_1) constraintSet2.clone(this, R.layout.layout_2) val transition = Slide(Gravity.START) TransitionManager.beginDelayedTransition(layoutParent, transition) constraintSet2.applyTo(constraintLayout)
21. Animations - MotionLayout <android.support.constraint.motion.MotionLayout <!--optional--> app:showPaths="true" app:layoutDescription="@xml/scene"> <View android:id="@+id/view"/> </android.support.constraint.motion.MotionLayout> <MotionScene> <Transition motion:constraintSetEnd="@+id/end" motion:constraintSetStart="@+id/start" motion:duration="1000" motion:interpolator="linear"> </Transition> </MotionScene> <MotionScene> <Transition motion:constraintSetEnd="@+id/end" motion:constraintSetStart="@+id/start" motion:duration="1000" motion:interpolator="linear"> </Transition> <ConstraintSet android:id="@+id/start"> </ConstraintSet> <ConstraintSet android:id="@+id/end"> </ConstraintSet> </MotionScene> <MotionScene> <Transition motion:constraintSetEnd="@+id/end" motion:constraintSetStart="@+id/start" motion:duration="1000" motion:interpolator="linear"> </Transition> <ConstraintSet android:id="@+id/start"> <Constraint android:id="@id/view" motion:layout_constraintBottom_toBottomOf="parent"...> </Constraint> </ConstraintSet> <ConstraintSet android:id="@+id/end"> <Constraint android:id="@id/view" motion:layout_constraintBottom_toBottomOf="parent" ... motion:layout_constraintVertical_bias="0.2"> </Constraint> </ConstraintSet> </MotionScene>
22. References widgets Specify sides Barrier <android.support.constraint.Barrier android:id="@+id/barrier5" android:layout_width="wrap_content" android:layout_height="wrap_content" app:barrierDirection="right" app:constraint_referenced_ids="textView2,textView" />
23. Layout manipulation: • Linear • Flow • * Others: horizontal layout, table layout Post-layout manipulation: • Layer (android.support.constraint.helper) • Circular reveal Rendering or decorating Helpers 2.0
24. Constrained Dimensions app:layout_constraintHorizontal_bias="0.0" app:layout_constraintHorizontal_chainStyle="packed" app:layout_constraintHorizontal_bias="0.0" app:layout_constraintHorizontal_chainStyle="packed" android:layout_width="0dp" app:layout_constraintHorizontal_bias="0.0" app:layout_constraintHorizontal_chainStyle="packed" android:layout_width="wrap_content" app:layout_constrainedWidth="true"
25. Cons? Editor: • difficult to reference ids for virtual helpers Designer: • generates not needed code • some rendering problems - id related Features: • 2.0 is not yet completed
26. Resources https://constraintlayout.com/ https://speakerdeck.com/camaelon @camaelon https://developer.android.com/reference/android/support/constraint/ConstraintLayout https://developer.android.com/topic/performance/rendering/optimizing-view-hierarchies https://medium.com/google-developers/introduction-to-motionlayout-part-i-29208674b10d https://android-developers.googleblog.com/2017/08/understanding-performance-benefits-of.html
