Data Processing on Ray (SangBin Cho, Anyscale)

Machine learning and data processing applications continue to drive the need to develop scalable Python applications. Ray is a distributed execution engine that enables programmers to scale up their Python applications. This talk will cover some of the challenges we faced and key architectural changes we made to Ray over the past year to support a new set of large scale data processing workloads.

Transcript

1. Anyscale Data Processing on Ray SangBin Cho Software Engineer @ Anyscale
2. 01 02 03 Importance of general purpose systems for ML infrastructure Introduction to Ray and its previous limitations in data processing Ray’s architectural evolvement as a data processing backend What is this talk about?
3. Distributed apps will become the norm Anyscale • Software Engineer @ Anyscale • Ray Committer • Working on Ray 1+ year • Current focus: Data processing support on Ray Who am I?
4. Anyscale Motivation to support large scale data processing on top of Ray Why do we need a general-purpose system for data processing?
5. Distributed apps will become the orm Anyscale • ML jobs need complex compositions of systems • Feature processing in ETL clusters • Load data to training clusters and train it • Model tuning in separate tuning clusters Complexities in ML jobs ETL Cluster (Spark) Training cluster (Horovod) Tuning cluster (Ray Tune) Load & shuffle
6. Anyscale What are problems? • Job composition across multiple systems • Many different clusters • Not efficient (sometimes) • Intermediate layers are necessary (parquet files)
7. Anyscale What if there are general purpose systems? • Different “type” of workload in a single system • Remove complex job dependencies by logically grouping jobs • One system • Less maintenance burden, easier to debug • Optimization is possible • If clusters have enough memory, it can utilize that
8. Anyscale Why General purpose systems? Distributed apps will become the orm ETL Cluster Training cluster Tuning cluster Load & shuffle
9. Anyscale Why General purpose systems? Distributed apps will become the orm ETL library Training library Tuning library Load & shuffle General purpose Systems Distributed apps will become the orm ETL Cluster Training cluster Tuning cluster Load & shuffle
10. Distributed apps will become the norm Anyscale • Simple library for distributed computing • General purpose • An ecosystem of libraries • High performance What is Ray? (in a nutshell)
11. def read_array(file): # read ndarray “a” # from “file” return a def add(a, b): return np.add(a, b) a = read_array(file1) b = read_array(file2) sum = add(a, b) Function class Counter(object): def __init__(self): self.value = 0 def inc(self): self.value += 1 return self.value c = Counter() c.inc() c.inc() Class
12. @ray.remote def read_array(file): # read ndarray “a” # from “file” return a @ray.remote def add(a, b): return np.add(a, b) a = read_array(file1) b = read_array(file2) sum = add(a, b) @ray.remote class Counter(object): def __init__(self): self.value = 0 def inc(self): self.value += 1 return self.value c = Counter() c.inc() c.inc() Function → Task Class → Actor
13. @ray.remote def read_array(file): # read ndarray “a” # from “file” return a @ray.remote def add(a, b): return np.add(a, b) id1 = read_array.remote(file1) id2 = read_array.remote(file2) id = add.remote(id1, id2) sum = ray.get(id) @ray.remote(num_gpus=1) class Counter(object): def __init__(self): self.value = 0 def inc(self): self.value += 1 return self.value c = Counter.remote() id4 = c.inc.remote() id5 = c.inc.remote() Function → Task Class → Actor
14. Native Libraries 3rd Party Libraries universal framework for distributed computing Ray: Ecosystem
15. Anyscale Ray as a general purpose system Distributed apps will become the orm ETL Cluster (Spark on Ray) Training cluster (Horovod on Ray) Tuning cluster (Ray Tune) Load & shuffle (Hub)
16. Distributed apps will become the norm Anyscale • Very ML-focused. Lots of ML integration such as Huggingface, Horovod on Ray, and etc. • Strong at ML type of workloads, but not some of features for data processing at scale wasn’t supported. But, how was Ray last year?
17. Distributed apps will become the norm Anyscale • Very ML-focused. Lots of ML integration such as Huggingface, Horovod on Ray, and etc. • Strong at ML type of workloads, but not some of features for data processing at scale wasn’t supported. But, how was Ray last year? But it’s been improved a lot over the last half year
18. Distributed apps will become the norm Anyscale Better 3rd party integration with other data libraries • Dask on Ray demonstrated high performance in large scale (upto 4X cost saving) • First class integration with data libraries like Mars What’s enabled by this?
19. Distributed apps will become the norm Anyscale Smoother Data processing <-> ML interoperability • Spark on Ray and Pytorch / TF integration • XGBoost on Ray (training) + Modin/Dask on Ray (feature processing) What’s enabled by this?
20. Distributed apps will become the norm Anyscale Building end-to-end ML pipeline in a single system • (training) XGBoost on Ray • (training) Horovod on Ray • (HP tuning) Ray Tune • (Data processing) Modin / Dask on Ray • (Data loading) Hub • (Serving) Ray Serve What’s enabled by this?
21. Distributed apps will become the norm Anyscale Run 3 workloads in a single script • Modin/Dask dataframe (feature processing) • XGBoost on Ray (training) • Ray Tune (hyperparameter tuning) Example code
22. Distributed apps will become the norm Anyscale Read dataframe using Modin Passing the dataframe to distributed dataset Training + hyperparameter tuning
23. Distributed apps will become the norm Anyscale Actor Actor Actor XGBoost on Ray Data Parallel Training Arbitrarily fine grained partitioning Hyperparameter tuning
24. Anyscale How Ray has evolved to support large scale data processing? Ray as a data processing backend
25. Distributed apps will become the norm Anyscale • ETL (Extract, Transform, Load) • ETL -> ML (Data ingest) • Analytics (Analyze data) • Streaming processing • And others... Type of Data Processing
26. Distributed apps will become the norm Anyscale • ETL (Extract, Transform, Load) • ETL -> ML (Data ingest) • Analytics (Analyze data) • Streaming processing Have focused on supporting ML pre-processing type of workload in the short-term What is the Ray’s short-term focus?
27. Distributed apps will become the norm Anyscale • Seamless distributed execution • Robust distributed memory management Requirements for data processing backend
28. Distributed apps will become the norm Anyscale • + Seamless distributed execution • - Robust distributed memory management What was supported by Ray before?
29. Distributed apps will become the norm Anyscale + Seamless distributed execution • Simple and straightforward execution model / APIs • Scalability / Fault tolerance • Distributed object store utilizing shared memory • High performance decentralized scheduler What was supported by Ray before?
30. Distributed apps will become the norm Anyscale - Robust distributed memory management • Scheduling doesn’t consider memory usage or locality information • Workloads failed when the data size > memory capacity • Ray cluster was crashed or deadlocked when there’s memory pressure What was supported by Ray before?
31. Distributed apps will become the norm Anyscale Focused on supporting the robust distributed memory management How? Make sure distributed shuffle works really well on top of Ray So, what have we done?
32. Distributed apps will become the norm Anyscale • A distributed dataset is usually stored in partitions, with each partition holding a group of rows • A shuffle is any operation over a dataset that requires redistributing data across its partitions Distributed shuffle
33. Distributed apps will become the norm Anyscale Distributed shuffle stresses data processing systems’ memory management layer Why focused on distributed shuffle?
34. Distributed apps will become the norm Anyscale How does it work?
35. Distributed apps will become the norm Anyscale • Built-in shared memory based distributed object store • Originally developed by Ray and contributed to the Arrow project • Now backported to Ray again for optimization Ray architecture in a glance; Plasma store
36. Shared memory store Anyscale Plasma store Plasma store Machine A Shared memory store Machine B One plasma store per machine
37. Shared memory store Anyscale Plasma store Machine A Stores “Ray objects” in the shared memory with “zero copy read” support (object A is not copied to task / taskB’s memory). task Zero-copy read
38. Shared memory store Anyscale Plasma Store Object A Machine A Shared memory store Machine B Pull/push objects “on demand”
39. Distributed apps will become the norm Anyscale Locality aware scheduling • Ray scheduler calculates which machines will have the biggest input size that is already cached • Minimize objects are copied to multiple nodes Improvement 1: Scheduling improvement
40. Shared memory store Anyscale No Locality aware scheduling Object A Machine A Shared memory store Machine B
41. Shared memory store Anyscale No Locality aware scheduling Object A Machine A Shared memory store Machine B Needs to be copied
42. Shared memory store Anyscale Locality aware scheduling Object A Machine A Shared memory store Machine B
43. Distributed apps will become the norm Anyscale Locality aware scheduling • Ray scheduler calculates which machines will have the biggest input size that is already cached • Minimize objects are copied to multiple nodes Improvement 1: Scheduling improvement
44. Distributed apps will become the norm Anyscale Memory aware scheduling • Ray always tries to schedule tasks to nodes that have low memory usage Improvement 1: Scheduling improvement
45. Shared memory store Anyscale Memory aware scheduling Machine A memory usage: 30GB Shared memory store Machine B memory usage: 20GB
46. Shared memory store Anyscale Memory aware scheduling Machine A memory usage: 30GB Shared memory store Machine B memory usage: 20GB Prefer the machine using less memory
47. Distributed apps will become the norm Anyscale • To support out of core data processing • processing data that is too large to fit into a computer’s main memory. • Spill Ray objects from object store to external storage like disks or S3. • To support distributed shuffle workload, the system should be tolerant to more memory usage than the maximum memory capacity Improvement 2: Object spilling
48. Distributed apps will become the norm Anyscale Shuffle without object spilling
49. Distributed apps will become the norm Anyscale Shuffle without object spilling
50. Distributed apps will become the norm Anyscale Shuffle with object spilling (Map)
51. Distributed apps will become the norm Anyscale Shuffle without object spilling
52. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Map
53. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Map
54. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Create objects Map
55. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Map Distributed apps will become the norm
56. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Map
57. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Create Create Map
58. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Create Create Spill objects Map
59. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Create Create Map Spill objects
60. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Map Spill objects
61. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Map Spill objects
62. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Map Spill objects
63. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Map
64. Distributed apps will become the norm Anyscale Shuffle with object spilling (Reduce)
65. Distributed apps will become the norm Anyscale Shuffle without object spilling
66. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce
67. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce
68. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce
69. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce
70. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce Spill objects
71. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce Spill objects
72. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce
73. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce Restore objects
74. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce
75. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce
76. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce
77. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce
78. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce
79. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Shared-memory object store Worker slots Node Reduce
80. Distributed apps will become the norm Anyscale Ray respects a hard limit for the distributed object store • detecting when there is memory pressure • guaranteeing progress when applications run out of memory • e.g., evicting unnecessary objects from the store or spilling objects • Using admission control when scheduling tasks to limit the total memory used Improvement 3: Robust memory management
81. Distributed apps will become the norm Anyscale Ray respects a hard limit for the distributed object store • detecting when there is memory pressure • guaranteeing progress when applications run out of memory by taking actions • e.g., evicting unnecessary objects from the store or spilling objects • Using admission control when scheduling tasks to limit the total memory used Improvement 3: Robust memory management We will see this example
82. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ...
83. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ...
84. Shared-memory object store Worker slots Node Restore External object store (disk, S3, etc) ...
85. Shared-memory object store Worker slots Node Restore External object store (disk, S3, etc) ...
86. Shared-memory object store Worker slots Node Restore External object store (disk, S3, etc) ...
87. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ...
88. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... DEADLOCK
89. Distributed apps will become the norm Anyscale • Ray’s decentralized scheduler now is aware of memory usage of task inputs • Ray doesn’t schedule tasks if the task inputs require more memory than its capacity after it’s scheduled How did we solve the problem?
90. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ...
91. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Restore
92. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ...
93. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ...
94. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ...
95. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ... Restore
96. Shared-memory object store Worker slots Node External object store (disk, S3, etc) ...
97. Distributed apps will become the norm Anyscale For more detailed information, check out Ray whitepaper
98. Distributed apps will become the norm Anyscale + Ray became more viable data processing backend • + Seamless distributed execution • + Robust distributed memory management + We recently succeed to run 100TB distributed shuffle workload on top of Ray after all improvements. What is the current state of the art?
99. Takeaway: • Ray being able to support data processing will reduce complexities in ML jobs • There has been several improvements to make Ray a suitable data processing backend More about Ray: • Ray Github • Ray Discourse Career: Anyscale is hiring (anyscale.com) Thank you
