Droidcon NYC: Implementing the Paging Library

The Android Paging Library makes it easy to integrate complex paging behaviour, gradually loading small chunks of data at a time to help reduce usage of network bandwidth and system resources.

The library allows you to implement this behaviour using compositional components in a decoupled architecture making your code more reliable, scalable, and testable. Furthermore, you’ll be able to use familiar components such as LiveData or RxJava to interface with your existing architecture.

In this talk you’ll learn:
- how to integrate the PagedList component into your architecture
- how to implement a DataSource to load snapshots when necessary
- how to use BoundaryCallback to signal the end of available data
- how to integrate LiveData or RxJava to fit your project

Transcript

1. Implementing the Paging Library
   Droidcon NYC
   !
   @askashdavies


   View Slide

2. View Slide

3. Challenges
   @askashdavies


   View Slide

4. Up-To-Date
   @askashdavies


   View Slide

5. Large Data-Sets
   @askashdavies


   View Slide

6. Offline
   @askashdavies


   View Slide

7. State
   @askashdavies


   View Slide

8. Progress
   @askashdavies


   View Slide

9. !
   @askashdavies


   View Slide

10. ListView
    android:id="@+id/list_view"
    android:layout_width="match_parent"
    android:layout_height="match_parent" />
    @askashdavies


    View Slide

11. ArrayAdapter
    // extends BaseAdapter>
    list.adapter = ArrayAdapter(
    context,
    R.layout.simple_list_item_1,
    arrayOf("Kotlin", "Java" /* ... */)
    )
    @askashdavies


    View Slide

12. BaseAdapter
    class ListAdapter : BaseAdapter() {
    override fun getView(position: Int, convertView: View, container: ViewGroup) {
    val view = convertView ?: layoutInflater.inflate(
    R.layout.simple_list_item_1,
    container,
    false
    )
    convertView
    .findViewById(R.id.text1)
    .text = getItem(position)
    return convertView
    }
    }
    @askashdavies


    View Slide

13. BaseAdapter
    class ListAdapter() : BaseAdapter() {
    var items: List = emptyList()
    set(value) {
    field = value
    notifyDataSetChanged()
    }
    override fun getCount(): Int = items.size
    override fun getItem(position: Int): String = items[position]
    override fun getView(position: Int, convertView: View, container: ViewGroup) {
    /* ... */
    }
    }
    @askashdavies


    View Slide

14. Pagination
    @askashdavies


    View Slide

15. Paging
    OnScrollListener
    @askashdavies


    View Slide

16. BaseAdapter / ListView
    • Manages list of it's own data
    • Manages view inflation and configuration
    • Notify entire data set of change
    • Not capable of diffing items
    @askashdavies


    View Slide

17. RecyclerView
    @askashdavies


    View Slide

18. RecyclerView
    @askashdavies


    View Slide

19. Paging
    AsyncListUtil
    @askashdavies


    View Slide

20. Diffing
    DiffUtil / AsyncListDiffer
    @askashdavies


    View Slide

21. DiffUtil
    Myers Diff Algorithm
    medium.com/skyrise/the-myers-diff-algorithm-and-kotlin-observable-properties-69dfb18541b


    View Slide

22. ListAdapter
    @askashdavies


    View Slide

23. ListAdapter
    Immutability
    @askashdavies


    View Slide

24. ListAdapter
    submitList(...)
    @askashdavies


    View Slide

25. Migration
    ListAdapter
    @askashdavies


    View Slide

26. RecyclerView.Adapter
    class UserAdapter : RecyclerView.Adapter() {
    private var items: List = emptyList()
    override fun getItemCount() = items.size
    override fun onBindViewHolder(holder: ViewHolder, position: Int) {
    holder.bind(items[position])
    }
    override fun onCreateViewHolder(parent: ViewGroup, viewType: Int): RecyclerView.ViewHolder {
    /* ... */
    }
    fun updateList(items: List) {
    val result: DiffResult = DiffUtil.calculate(DiffCallback(this.items, items))
    result.dispatchUpdatesTo(this)
    }
    class ViewHolder(view: View) : RecyclerView.ViewHolder(view) {
    fun bind(item: User) {
    /* ... */
    }
    }
    }
    @askashdavies


    View Slide

27. RecyclerView.Adapter
    class UserAdapter : RecyclerView.Adapter() {
    private var items: List = emptyList()
    override fun getItemCount() = items.size
    override fun onBindViewHolder(holder: ViewHolder, position: Int) {
    holder.bind(items[position])
    }
    override fun onCreateViewHolder(parent: ViewGroup, viewType: Int): RecyclerView.ViewHolder {
    /* ... */
    }
    fun updateList(items: List) {
    val result: DiffResult = DiffUtil.calculate(UserComparator(this.items, items))
    result.dispatchUpdatesTo(this)
    }
    class UserViewHolder(view: View) : RecyclerView.ViewHolder(view) {
    fun bind(item: User) {
    /* ... */
    }
    }
    }
    @askashdavies


    View Slide

28. DiffUtil.Callback
    class UserComparator(
    private val oldItems: List,
    private val newItems: List
    ) : DiffUtil.Callback() {
    override fun getOldListSize(): Int = oldItems.size
    override fun getNewListSize(): Int = newItems.size
    override fun areItemsTheSame(oldItemPosition: Int, newItemPosition: Int): Boolean {
    return oldItems[oldItemPosition].id == newItems[newItemPosition].id
    }
    override fun areContentsTheSame(oldItemPosition: Int, newItemPosition: Int): Boolean {
    return oldItems[oldItemPosition] == newItems[newItemPosition]
    }
    }
    @askashdavies


    View Slide

29. DiffUtil.Callback
    class UserComparator(
    private val oldItems: List,
    private val newItems: List
    ) : DiffUtil.Callback() {
    override fun getOldListSize(): Int = oldItems.size
    override fun getNewListSize(): Int = newItems.size
    override fun areItemsTheSame(oldItemPosition: Int, newItemPosition: Int): Boolean {
    return oldItems[oldItemPosition].id == newItems[newItemPosition].id
    }
    override fun areContentsTheSame(oldItemPosition: Int, newItemPosition: Int): Boolean {
    return oldItems[oldItemPosition] == newItems[newItemPosition]
    }
    }
    @askashdavies


    View Slide

30. DiffUtil.ItemCallback
    object UserComparator : DiffUtil.ItemCallback() {
    override fun areItemsTheSame(oldItem: User, newItem: User): Boolean {
    return oldItem.id == newItem.id
    }
    override fun areContentsTheSame(oldItem: User, newItem: User): Boolean {
    return oldItem == newItem
    }
    }
    @askashdavies


    View Slide

31. DiffUtil.ItemCallback
    object UserComparator : DiffUtil.ItemCallback() {
    override fun areItemsTheSame(oldItem: User, newItem: User): Boolean {
    return oldItem.id == newItem.id
    }
    override fun areContentsTheSame(oldItem: User, newItem: User): Boolean {
    return oldItem == newItem
    }
    }
    @askashdavies


    View Slide

32. RecyclerView.Adapter
    class UserAdapter : RecyclerView.Adapter() {
    private var items: List = emptyList()
    override fun getItemCount() = items.size
    override fun onBindViewHolder(holder: ViewHolder, position: Int) {
    holder.bind(items[position])
    }
    override fun onCreateViewHolder(parent: ViewGroup, viewType: Int): RecyclerView.ViewHolder {
    /* ... */
    }
    fun updateList(items: List) {
    /* ... */
    }
    class UserViewHolder(view: View) : RecyclerView.ViewHolder(view) {
    fun bind(item: User) {
    /* ... */
    }
    }
    }
    @askashdavies


    View Slide

33. ListAdapter
    class UserAdapter : ListAdapter(UserComparator) {
    private var items: List = emptyList()
    override fun getItemCount() = items.size
    override fun onBindViewHolder(holder: ViewHolder, position: Int) {
    holder.bind(items[position])
    }
    override fun onCreateViewHolder(parent: ViewGroup, viewType: Int): RecyclerView.ViewHolder {
    /* ... */
    }
    fun updateList(items: List) {
    /* ... */
    }
    class ViewHolder(view: View) : RecyclerView.ViewHolder(view) {
    fun bind(item: User) {
    /* ... */
    }
    }
    }
    @askashdavies


    View Slide

34. ListAdapter
    class UserAdapter : ListAdapter(UserComparator) {
    private var items: List = emptyList()
    override fun getItemCount() = items.size
    override fun onBindViewHolder(holder: ViewHolder, position: Int) {
    holder.bind(items[position])
    }
    override fun onCreateViewHolder(parent: ViewGroup, viewType: Int): RecyclerView.ViewHolder {
    /* ... */
    }
    fun updateList(items: List) {
    /* ... */
    }
    class ViewHolder(view: View) : RecyclerView.ViewHolder(view) {
    fun bind(item: User) {
    /* ... */
    }
    }
    }
    @askashdavies


    View Slide

35. ListAdapter
    class UserAdapter : ListAdapter(UserComparator) {
    override fun onBindViewHolder(holder: ViewHolder, position: Int) {
    holder.bind(items[position])
    }
    override fun onCreateViewHolder(parent: ViewGroup, viewType: Int): RecyclerView.ViewHolder {
    /* ... */
    }
    class ViewHolder(view: View) : RecyclerView.ViewHolder(view) {
    fun bind(item: User) {
    /* ... */
    }
    }
    }
    @askashdavies


    View Slide

36. ListAdapter
    @askashdavies


    View Slide

37. @askashdavies


    View Slide

38. Android JetPack
    Foundation Components
    @askashdavies


    View Slide

39. Android JetPack
    Architecture Components
    @askashdavies


    View Slide

40. Android JetPack
    Behaviour Components
    @askashdavies


    View Slide

41. Android JetPack
    UI Components
    @askashdavies


    View Slide

42. Android JetPack
    Paging Library
    @askashdavies


    View Slide

43. Android JetPack
    Paging Library
    • PagedListAdapter
    ⚙
    • PagedList
    "
    • DataSource / DataSource.Factory
    • BoundaryCallback
    $
    @askashdavies


    View Slide

44. @askashdavies


    View Slide

45. @askashdavies


    View Slide

46. @askashdavies


    View Slide

47. @askashdavies


    View Slide

48. @askashdavies


    View Slide

49. @askashdavies


    View Slide

50. @askashdavies


    View Slide

51. @askashdavies


    View Slide

52. @askashdavies


    View Slide

53. PagedList
    ❔
    @askashdavies


    View Slide

54. PagedList
    PagedList : List
    @askashdavies


    View Slide

55. PagedList
    PagedListBuilder
    • Data sources / cache management
    • Page size / prefetch distance
    • Offline characteristics
    • Loading behaviour
    @askashdavies


    View Slide

56. PagedList
    PagedListBuilder
    • LiveDataPagedListBuilder
    • RxPagedListBuilder
    • FlowPagedListBuilder1
    1 github.com/chrisbanes/tivi/blob/master/data-android/src/main/java/app/tivi/data/FlowPagedListBuilder.kt
    @askashdavies


    View Slide

57. PagedList
    LiveDataPagedListBuilder
    @askashdavies


    View Slide

58. PagedList
    LiveDataPagedListBuilder
    class UserRepository(private val service: UserService) {
    fun users(): LiveData> {
    /* ... */
    }
    }
    @askashdavies


    View Slide

59. @askashdavies


    View Slide

60. PagedList
    LiveDataPagedListBuilder
    class UserRepository(private val service: UserService) {
    fun users(): LiveData> {
    val factory: DataSource.Factory = service.users()
    return LivePagedListBuilder(factory, PAGE_SIZE).build()
    }
    companion object {
    private const val PAGE_SIZE = 20
    }
    }
    @askashdavies


    View Slide

61. PagedList.Config
    LiveDataPagedListBuilder
    class UserRepository(private val service: UserService) {
    fun users(): LiveData> {
    val factory: DataSource.Factory = service.users()
    val config: PagedList.Config = PagedList.Config.Builder()
    .setPageSize(PAGE_SIZE)
    .build()
    return LivePagedListBuilder(factory, config).build()
    }
    companion object {
    private const val PAGE_SIZE = 20
    }
    }
    @askashdavies


    View Slide

62. PagedList.Config
    LiveDataPagedListBuilder
    class UserRepository(private val service: UserService) {
    fun users(): LiveData> {
    val factory: DataSource.Factory = service.users()
    val config: PagedList.Config = PagedList.Config.Builder()
    .setPageSize(PAGE_SIZE)
    .setInitialLoadSizeHint(50)
    .build()
    return LivePagedListBuilder(factory, config).build()
    }
    companion object {
    private const val PAGE_SIZE = 20
    }
    }
    @askashdavies


    View Slide

63. PagedList.Config
    LiveDataPagedListBuilder
    class UserRepository(private val service: UserService) {
    fun users(): LiveData> {
    val factory: DataSource.Factory = service.users()
    val config: PagedList.Config = PagedList.Config.Builder()
    .setPageSize(PAGE_SIZE)
    .setInitialLoadSizeHint(50)
    .setPrefetchDistance(10)
    .build()
    return LivePagedListBuilder(factory, config).build()
    }
    companion object {
    private const val PAGE_SIZE = 20
    }
    }
    @askashdavies


    View Slide

64. PagedList.Config
    LiveDataPagedListBuilder
    class UserRepository(private val service: UserService) {
    fun users(): LiveData> {
    val factory: DataSource.Factory = service.users()
    val config: PagedList.Config = PagedList.Config.Builder()
    .setPageSize(PAGE_SIZE)
    .setInitialLoadSizeHint(50)
    .setPrefetchDistance(10)
    .setEnablePlaceholders(false)
    .build()
    return LivePagedListBuilder(factory, config).build()
    }
    companion object {
    private const val PAGE_SIZE = 20
    }
    }
    @askashdavies


    View Slide

65. Placeholders
    Advantages
    • Continuous scrolling
    • Less abrupt UI changes
    • Scrollbars maintain consistency
    • Accurately indicate loading state
    @askashdavies


    View Slide

66. Placeholders
    Disadvantages
    • Irregular sized items cause UI jank
    • Prepare view holder without item
    • Data set must be quantifiable
    @askashdavies


    View Slide

67. PagedList.Config
    RxPagedListBuilder
    class UserRepository(private val service: UserService) {
    fun users(): Observable> {
    val factory: DataSource.Factory = service.users()
    val config: PagedList.Config = PagedList.Config.Builder()
    .setPageSize(PAGE_SIZE)
    .build()
    return RxPagedListBuilder(factory, config)
    .buildObservable() // or buildFlowable()
    }
    companion object {
    private const val PAGE_SIZE = 20
    }
    }
    @askashdavies


    View Slide

68. Coroutines
    FlowPagedListBuilder
    class UserRepository(private val service: UserService) {
    fun users(): Flow> {
    val factory: DataSource.Factory = service.users()
    val config: PagedList.Config = PagedList.Config.Builder()
    .setPageSize(PAGE_SIZE)
    .build()
    return FlowPagedListBuilder(factory, config).buildFlow()
    }
    companion object {
    private const val PAGE_SIZE = 20
    }
    }
    github.com/chrisbanes/tivi/blob/master/data-android/src/main/java/app/tivi/data/FlowPagedListBuilder.kt


    View Slide

69. DataSource.Factory
    @askashdavies


    View Slide

70. Paging ❤ Room
    @askashdavies


    View Slide

71. Paging ❤ Room
    @Dao
    interface UserDao {
    @Query("SELECT * FROM user")
    fun users(): DataSource.Factory
    }
    @askashdavies


    View Slide

72. Paging ❤ Room
    @Dao
    interface UserDao {
    @Query("SELECT * FROM user")
    fun users(): DataSource.Factory
    }
    @askashdavies


    View Slide

73. @askashdavies


    View Slide

74. Remote Data Source
    Backend
    @askashdavies


    View Slide

75. Remote Data Source
    Index
    @askashdavies


    View Slide

76. DataSource
    • PositionalDataSource
    !
    • ItemKeyedDataSource
    "
    • PageKeyedDataSource
    #
    @askashdavies


    View Slide

77. PositionalDataSource
    PositionalDataSource
    • Able to scroll to different elements
    • Load pages of requested sizes
    • Load pages at arbitrary positions
    • Assumed ordering by integer index
    • Provide a fixed item count
    @askashdavies


    View Slide

78. PositionalDataSource
    PositionalDataSource
    • loadInitial()
    • requestedStartPosition
    • requestedLoadSize
    • pageSize
    • placeholdersEnabled
    • loadRange()
    • startPosition
    • loadSize
    @askashdavies


    View Slide

79. ItemKeyedDataSource
    ItemKeyedDataSource
    • Great for ordered data sets
    • Items can be uniquely identified
    • Item key indicates position
    • Detect items before or after
    @askashdavies


    View Slide

80. ItemKeyedDataSource
    ItemKeyedDataSource
    • getKey()
    • loadInitial()
    • requestedInitialKey
    • requestedLoadSize
    • placeholdersEnabled
    • loadAfter()
    • key
    • requestedLoadSize
    • loadBefore()
    • key
    • requestedLoadSize
    @askashdavies


    View Slide

81. PageKeyedDataSource
    PageKeyedDataSource
    • Common for API responses
    • GitHub
    • Twitter
    • Reddit
    @askashdavies


    View Slide

82. PageKeyedDataSource
    PageKeyedDataSource
    • loadInitial()
    • requestedLoadSize
    • placeholdersEnabled
    • loadAfter()
    • key
    • requestedLoadSize
    • loadBefore()
    • key
    • requestedLoadSize
    @askashdavies


    View Slide

83. @askashdavies


    View Slide

84. Architecture
    @askashdavies


    View Slide

85. @askashdavies


    View Slide

86. Database
    @askashdavies


    View Slide

87. Source of truth
    • Consistent data presentation
    • Simple process - need more, load more
    • Gracefully degrades on failure
    • Optionally refresh on observe
    @askashdavies


    View Slide

88. BoundaryCallback
    • Signals end of data from database
    • Triggers network load to populate
    • Provided to PagedListBuilder
    @askashdavies


    View Slide

89. BoundaryCallback
    PagedList.BoundaryCallback
    public abstract static class BoundaryCallback {
    public void onZeroItemsLoaded() { }
    public void onItemAtFrontLoaded(@NonNull T itemAtFront) { }
    public void onItemAtEndLoaded(@NonNull T itemAtEnd) { }
    }
    @askashdavies


    View Slide

90. Further Reading
    • Florina Muntenescu: Migrating to Paging Library
    youtube.com/watch?v=8DPgwrV_9-g
    • Chris Craik & Yigit Boyar: Manage infinite lists with RecyclerView and Paging
    youtube.com/watch?v=BE5bsyGGLf4
    -- ADB: Prefetch and Paging
    androidbackstage.blogspot.com/2018/10/episode-101-prefetch-and-paging.html
    • Android Paging Codelab
    codelabs.developers.google.com/codelabs/android-paging/#0
    • Google Samples: Paging with Network Sample
    github.com/googlesamples/android-architecture-components/tree/master/PagingWithNetworkSample
    • Chris Banes: FlowPagedListBuilder
    github.com/chrisbanes/tivi/blob/master/data-android/src/main/java/app/tivi/data/FlowPagedListBuilder.kt
    @askashdavies


    View Slide

91. Implementing the Paging Library
    bit.ly/github-repo-search
    bit.ly/paging-library
    @askashdavies


    View Slide

92. Happy Paging!
    @askashdavies


    View Slide
