Introduction to Kubernetes

Introduction to Kubernetes

Getting started with Kubernetes Kubernetes is a very powerful container orchestration platform that is quickly gaining traction and gives you lots of benefits in deploying, running and scaling your microservice web application. But it has also a steep learning curve. In this talk I will introduce you to Kubernetes, why you would want to use it and all the tooling around Kubernetes with the help of practical examples.

Bastian Hofmann

April 20, 2018
Tweet

More Decks by Bastian Hofmann

Other Decks in Programming

Transcript

  1. Introduction to
    Kubernetes
    @BastianHofmann

    View Slide

  2. View Slide

  3. View Slide

  4. View Slide

  5. Container
    orchestration
    platform

    View Slide

  6. Deploy, run and
    scale your services
    in isolated
    containers

    View Slide

  7. Very Powerful

    View Slide

  8. Large community

    View Slide

  9. Lot’s of large
    company backers

    View Slide

  10. No vendor lock in

    View Slide

  11. Runs on

    View Slide

  12. AWS

    View Slide

  13. Azure

    View Slide

  14. Google Cloud
    Platform

    View Slide

  15. Bare metal

    View Slide

  16. Your laptop

    View Slide

  17. Minikube

    View Slide

  18. Included in Docker
    Desktop Clients

    View Slide

  19. Learning curve

    View Slide

  20. This talk is supposed
    to get you started

    View Slide

  21. I’m going to explain
    the basics

    View Slide

  22. I’ll start with
    deploying a simple
    PHP Web App

    View Slide

  23. and cover things
    like Logging,
    Monitoring,…

    View Slide

  24. But first

    View Slide

  25. Why containers?

    View Slide

  26. Services run in
    isolation

    View Slide

  27. Everything needed
    to run a service in
    one image

    View Slide

  28. Decouple
    Ops and Dev

    View Slide

  29. Make things …

    View Slide

  30. Easier to deploy

    View Slide

  31. Easier to upgrade
    system
    dependencies

    View Slide

  32. Easier to scale

    View Slide

  33. Easier to develop

    View Slide

  34. More performant
    than
    Virtual Machines

    View Slide

  35. View Slide

  36. FROM php:7.2-apache
    WORKDIR /var/www/html
    RUN apt-get update -y && \
    apt-get install -y --no-install-recommends \
    curl \
    rm -rf /var/lib/apt/lists/*
    COPY composer.* /var/www/html/
    ENV COMPOSER_HOME /tmp
    RUN composer install
    COPY . /var/www/html/
    EXPOSE 80
    ENTRYPOINT [“apache2”, “-DFOREGROUND”]

    View Slide

  37. docker build -t symfony-demo:2.0.0 .

    View Slide

  38. docker run -p 8080:80 symfony-demo:2.0.0

    View Slide

  39. Kubernetes helps
    you running
    containers

    View Slide

  40. OK, sold

    View Slide

  41. Let’s define some
    core concepts first

    View Slide

  42. Kubernetes
    Cluster

    View Slide

  43. Image
    • A docker image
    built from a
    Dockerfile that
    contains everything
    a service needs to
    run

    View Slide

  44. • A container runs a
    docker image.
    • Only 1 process
    can run inside of a
    container
    Container

    View Slide

  45. Pod
    • A group of 1 or more
    containers
    • Same port space
    • Ports are not
    accessible from
    outside of the pod

    View Slide

  46. Replica Set
    • Defines and
    manages how
    many instances
    of a pod should
    run

    View Slide

  47. Deployment
    • Manages
    updates and
    rollbacks of
    replica sets

    View Slide

  48. Service
    • Makes a port
    of a pod
    accessible to
    other pods

    View Slide

  49. Ingress
    • Makes a
    service
    accessible to
    the outside
    of
    Kubernetes

    View Slide

  50. Node
    • A physical server
    • Containers get
    distributed
    automatically

    View Slide

  51. ConfigMaps
    & Secrets
    • Configuration that
    can be mounted
    inside of a
    container

    View Slide

  52. Volumes
    • Volumes can be
    mounted into a
    container to access
    a ConfigMap, Secret
    or a folder on the
    host

    View Slide

  53. Namespaces
    • Dedicated
    environment
    to deploy
    services in

    View Slide

  54. Docker registries

    View Slide

  55. Example

    View Slide

  56. PHP-FPM
    NGINX
    LINKERD
    STATSD
    MEM

    CACHED
    MONGO

    ROUTER
    PHP Application POD

    View Slide

  57. PHP-FPM
    NGINX
    LINKERD
    STATSD
    MEM

    CACHED
    MONGO

    ROUTER
    PHP Application POD
    ReplicaSet: 2 instances
    PHP-FPM
    NGINX
    LINKERD
    STATSD
    MEM

    CACHED
    MONGO

    ROUTER
    PHP Application POD

    View Slide

  58. PHP-FPM
    NGINX
    LINKERD
    STATSD
    MEM

    CACHED
    MONGO

    ROUTER
    ReplicaSet: 2 instances
    PHP-FPM
    NGINX
    LINKERD
    STATSD
    MEM

    CACHED
    MONGO

    ROUTER
    CONFIG
    WEB :80
    PHP Application POD PHP Application POD

    View Slide

  59. PHP-FPM
    NGINX
    LINKERD
    STATSD
    MEM

    CACHED
    MONGO

    ROUTER
    ReplicaSet: 2 instances
    PHP-FPM
    NGINX
    LINKERD
    STATSD
    MEM

    CACHED
    MONGO

    ROUTER
    CONFIG
    WEB :80
    https://php-app.k8s.foo.com:443/
    PHP Application POD PHP Application POD

    View Slide

  60. To interact with
    Kubernetes

    View Slide

  61. Tooling

    View Slide

  62. kubectl

    View Slide

  63. $ kubectl get pods

    View Slide

  64. NAME READY STATUS RESTARTS AGE
    kubernetes-dashboard-5b5bf59977-t9xb9 1/1 Running 2 9d
    nginx-ingress-controller-5549f5597c-97kcw 0/1 Running 2 9d
    nginx-ingress-default-backend-564d9d9477-tmnnr 1/1 Running 4 9d
    mysql-556c9b5bcb-5jdrt 1/1 Running 1 8d
    symfony-demo-5b75f5fc6-c7wr9 1/1 Running 0 8d
    symfony-demo-5b75f5fc6-jg8n4 1/1 Running 23 8d

    View Slide

  65. REST API

    View Slide

  66. $ kubectl proxy --port=8080
    $ curl http://localhost:8080/api/v1/namespaces/default/pods
    {
    "kind": "PodList",
    "apiVersion": "v1",
    "metadata": {
    "selfLink": "/api/v1/namespaces/default/pods",
    "resourceVersion": "336834"
    },
    "items": [
    {
    "metadata": {
    "name": "kubernetes-dashboard-5b5bf59977-t9xb9",
    "generateName": "kubernetes-dashboard-5b5bf59977-",

    View Slide

  67. kubernetes-
    dashboard
    https://github.com/kubernetes/dashboard

    View Slide

  68. View Slide

  69. Helm
    The package manager for Kubernetes
    https://helm.sh/

    View Slide

  70. $ helm install stable/wordpress

    View Slide

  71. Practical example

    View Slide

  72. Preparations

    View Slide

  73. Install Docker Client

    View Slide

  74. $ brew cask install docker

    View Slide

  75. View Slide

  76. Install helm

    View Slide

  77. $ brew install kubernetes-helm

    View Slide

  78. $ helm init

    View Slide

  79. Install
    kubernetes-dashboard

    View Slide

  80. ingress:
    enabled: true
    hosts:
    - kubernetes-dashboard.local.k8s

    View Slide

  81. $ helm install stable/kubernetes-dashboard
    -f kubernetes-dashboard.yaml

    View Slide

  82. Install
    nginx-ingress-controller

    View Slide

  83. rbac:
    create: true
    controller:
    hostNetwork: true

    View Slide

  84. $ helm install stable/nginx-ingress -f
    ingress-controller.yaml

    View Slide

  85. Let’s deploy the
    symphony demo
    app

    View Slide

  86. https://github.com/symfony/demo

    View Slide

  87. First the Dockerfile

    View Slide

  88. PHP

    View Slide

  89. Copy our code

    View Slide

  90. Build the project

    View Slide

  91. Composer install

    View Slide

  92. yarn install

    View Slide

  93. Build the image

    View Slide

  94. docker build -t symfony-demo:2.0.0 .

    View Slide

  95. Demo

    View Slide

  96. Since it’s all local we
    don’t need to push it to
    a registry

    View Slide

  97. Now we have to tell
    Kubernetes what to do
    with the image

    View Slide

  98. Resources are defined
    in YAML or JSON

    View Slide

  99. Deployment

    View Slide

  100. kind: Deployment
    apiVersion: extensions/v1beta1
    metadata:
    name: symfony-demo
    spec:
    revisionHistoryLimit: 3
    template:
    metadata:
    labels:
    app: symfony-demo
    spec:
    containers:
    - name: symfony-demo
    image: symfony-demo:1.0.0
    imagePullPolicy: Never
    ports:
    - containerPort: 80

    View Slide

  101. containers:
    - name: symfony-demo
    image: symfony-demo:1.0.0
    imagePullPolicy: Never
    ports:
    - containerPort: 80
    livenessProbe:
    httpGet:
    path: /
    port: 80
    timeoutSeconds: 1
    initialDelaySeconds: 10
    readinessProbe:
    httpGet:
    path: /
    port: 80
    timeoutSeconds: 1

    View Slide

  102. Many more options
    configurable

    View Slide

  103. •Setting environment variables
    •Mounting volumes
    •Requesting resources
    •Defining upgrade strategies
    •Defining command
    •Configure networking
    •Configure affinities
    •LifeCycle events
    •…

    View Slide

  104. Service

    View Slide

  105. kind: Service
    apiVersion: v1
    metadata:
    name: symfony-demo
    spec:
    ports:
    -
    name: http
    port: 80
    targetPort: 80
    protocol: TCP
    selector:
    app: symfony-demo

    View Slide

  106. Ingress

    View Slide

  107. kind: Ingress
    apiVersion: extensions/v1beta1
    metadata:
    name: symfony-demo
    spec:
    rules:
    - host: symfony-demo.local.k8s
    http:
    paths:
    - path: /
    backend:
    serviceName: symfony-demo
    servicePort: 80

    View Slide

  108. Creating everything

    View Slide

  109. kubectl apply -f deployment/webapp.yaml

    View Slide

  110. View Slide

  111. Rolling
    Deployments

    View Slide

  112. kind: Deployment
    apiVersion: extensions/v1beta1
    metadata:
    name: symfony-demo
    spec:
    revisionHistoryLimit: 3
    template:
    metadata:
    labels:
    app: symfony-demo
    spec:
    containers:
    - name: symfony-demo
    image: symfony-demo:1.1.0
    imagePullPolicy: Never
    ports:
    - containerPort: 80

    View Slide

  113. kubectl apply -f deployment/webapp.yaml

    View Slide

  114. Demo

    View Slide

  115. These are the
    basics

    View Slide

  116. Let’s talk about
    some other
    interesting and
    important aspects

    View Slide

  117. There are other
    types of deploying
    things into
    Kubernetes

    View Slide

  118. DaemonSets

    View Slide

  119. Ensure that a pod
    runs once on every
    node

    View Slide

  120. Log collection
    daemon

    View Slide

  121. Monitoring agent

    View Slide

  122. Service mesh
    containers

    View Slide


  123. View Slide

  124. Basically works like
    deployments

    View Slide

  125. But roll out strategy
    is different

    View Slide

  126. CronJobs

    View Slide

  127. Regularly repeating
    jobs

    View Slide

  128. apiVersion: batch/v1beta1
    kind: CronJob
    metadata:
    name: cron-job
    spec:
    schedule: "*/1 * * * *"
    jobTemplate:
    spec:
    template:
    spec:
    containers:
    - name: cron-job
    image: your-cron-job
    restartPolicy: OnFailure

    View Slide

  129. How does
    Kubernetes work
    internally

    View Slide

  130. Service Discovery

    View Slide

  131. Within a pod

    View Slide

  132. Shared port
    namespace

    View Slide

  133. Separate file
    systems

    View Slide

  134. Separate process
    spaces

    View Slide

  135. Network wise
    everything behaves
    like localhost

    View Slide

  136. Between pods

    View Slide

  137. You have to expose
    ports with services

    View Slide

  138. kind: Service
    apiVersion: v1
    metadata:
    name: symfony-demo
    spec:
    ports:
    -
    name: http
    port: 80
    targetPort: 80
    protocol: TCP
    selector:
    app: symfony-demo

    View Slide

  139. Every service has a
    virtual IP address

    View Slide

  140. $ kubectl get service symfony-demo
    NAME TYPE CLUSTER-IP PORT(S) AGE
    symfony-demo ClusterIP 10.106.119.24 80/TCP 6d

    View Slide

  141. Discoverable in
    other containers by

    View Slide

  142. Environment
    Variables

    View Slide

  143. SYMFONY_DEMO_SERVICE_HOST=10.106.119.24
    SYMFONY_DEMO_SERVICE_PORT=80

    View Slide

  144. DNS

    View Slide

  145. $ nslookup symfony-demo
    Server: 10.0.0.10
    Address 1: 10.0.0.10
    Name: symfony-demo
    Address 1: 10.106.119.24

    View Slide

  146. $ curl http://symfony-demo

    View Slide

  147. Alternatively

    View Slide

  148. Service Mesh

    View Slide

  149. LinkerD
    https://linkerd.io/

    View Slide

  150. Istio
    https://istio.io/

    View Slide

  151. Conduit
    https://conduit.io/

    View Slide

  152. Runs as

    View Slide

  153. DaemonSet

    View Slide

  154. Sidecar container

    View Slide

  155. PHP-FPM
    NGINX
    LINKERD
    STATSD
    MEM

    CACHED
    MONGO

    ROUTER
    PHP Application POD

    View Slide

  156. PHP-FPM
    NGINX
    LINKERD
    STATSD
    MEM

    CACHED
    MONGO

    ROUTER
    PHP Application POD
    NODEJS LINKERD
    STATSD
    Other service POD
    NODEJS LINKERD
    STATSD
    Other service POD

    View Slide

  157. PHP-FPM
    NGINX
    LINKERD
    STATSD
    MEM

    CACHED
    MONGO

    ROUTER
    PHP Application POD
    NODEJS LINKERD
    STATSD
    Other service POD
    NODEJS LINKERD
    STATSD
    Other service POD

    View Slide

  158. PHP-FPM
    NGINX
    LINKERD
    STATSD
    MEM

    CACHED
    MONGO

    ROUTER
    PHP Application POD
    NODEJS LINKERD
    STATSD
    Other service POD
    NODEJS LINKERD
    STATSD
    Other service POD

    View Slide

  159. Benefits

    View Slide

  160. Advanced routing

    View Slide

  161. Prefer service in
    current
    namespace, fall
    back to default
    namespace

    View Slide

  162. Canary
    deployments

    View Slide

  163. A/B Testing

    View Slide

  164. Advanced
    monitoring

    View Slide

  165. View Slide

  166. Profiling

    View Slide

  167. Zipkin
    https://zipkin.io/

    View Slide

  168. View Slide

  169. Accessing
    Kubernetes from
    the outside

    View Slide

  170. Port forwarding
    through kubectl

    View Slide

  171. $ kubectl port-forward $POD_NAME 8080:80

    View Slide

  172. The ingress
    controller

    View Slide

  173. Nginx

    View Slide

  174. haproxy

    View Slide

  175. Istio

    View Slide


  176. View Slide

  177. A controller listens
    to all ingresses and
    routes traffic from
    the outside to the
    correct service

    View Slide

  178. kind: Ingress
    apiVersion: extensions/v1beta1
    metadata:
    name: symfony-demo
    spec:
    rules:
    - host: symfony-demo.local.k8s
    http:
    paths:
    - path: /
    backend:
    serviceName: symfony-demo
    servicePort: 80

    View Slide

  179. What about data?

    View Slide

  180. Storage

    View Slide

  181. Volumes

    View Slide

  182. https://kubernetes.io/docs/concepts/storage/volumes/

    View Slide

  183. apiVersion: v1
    kind: Pod
    metadata:
    name: test-pd
    spec:
    containers:
    - image: k8s.gcr.io/test-webserver
    name: test-container
    volumeMounts:
    - mountPath: /cache
    name: cache-volume
    volumes:
    - name: cache-volume
    emptyDir: {}

    View Slide

  184. Persistent Storage

    View Slide

  185. You define a
    Persistent Volume,
    e.g. NFS

    View Slide

  186. Each pod can
    specify a Persistent
    Volume Claim

    View Slide

  187. And then mount
    the Claim into a
    Volume in a
    container

    View Slide

  188. https://kubernetes.io/docs/concepts/storage/persistent-
    volumes/

    View Slide

  189. Configuration

    View Slide

  190. Should not be
    included in the
    docker image

    View Slide

  191. ConfigMap

    View Slide

  192. Key/Value Store

    View Slide

  193. kind: ConfigMap
    apiVersion: v1
    metadata:
    name: special-config
    data:
    special-key: value
    bool-value: true

    View Slide

  194. Can be accessed
    in a pod through
    environment
    variables

    View Slide

  195. spec:
    containers:
    - name: test-container
    image: k8s.gcr.io/busybox
    command: [ "/bin/sh", "-c", "env" ]
    env:
    - name: SPECIAL_KEY
    valueFrom:
    configMapKeyRef:
    name: special-config
    key: special-key

    View Slide

  196. spec:
    containers:
    - name: test-container
    image: k8s.gcr.io/busybox
    command: [ "/bin/sh", "-c", "env" ]
    envFrom:
    - configMapRef:
    name: special-config

    View Slide

  197. Can be accessed
    through volumes

    View Slide

  198. spec:
    containers:
    - name: test-container
    image: k8s.gcr.io/busybox
    command: [ "/bin/sh", "-c", "ls /etc/config/" ]
    volumeMounts:
    - name: config-volume
    mountPath: /etc/config
    volumes:
    - name: config-volume
    configMap:
    name: special-config

    View Slide

  199. https://kubernetes.io/docs/tasks/configure-pod-container/
    configure-pod-configmap/

    View Slide

  200. Secret

    View Slide

  201. Storage for sensitive
    information

    View Slide

  202. https://kubernetes.io/docs/concepts/configuration/secret

    View Slide

  203. Figuring out what’s
    going on inside
    Kubernetes

    View Slide

  204. Monitoring

    View Slide

  205. Heapster

    View Slide

  206. https://github.com/kubernetes/heapster

    View Slide

  207. Takes metrics from
    Kubernetes and
    stores them in a
    monitoring solution

    View Slide

  208. InfluxDB

    View Slide

  209. Prometheus

    View Slide

  210. Grafana for
    displaying the data

    View Slide

  211. View Slide

  212. View Slide

  213. https://blog.kublr.com/how-to-utilize-the-heapster-influxdb-
    grafana-stack-in-kubernetes-for-monitoring-
    pods-4a553f4d36c9

    View Slide

  214. Logging

    View Slide

  215. kubectl logs

    View Slide

  216. $ kubectl logs symfony-demo-5b75f5fc6-c7wr9

    View Slide

  217. Log to
    stdout & stderr

    View Slide

  218. Automatically
    written to disk

    View Slide

  219. DaemonSet Log
    collector

    View Slide

  220. • Logstash
    • Fluentd
    • Filebeat

    View Slide

  221. Central log
    management

    View Slide

  222. View Slide

  223. https://www.elastic.co/blog/shipping-kubernetes-logs-to-
    elasticsearch-with-filebeat

    View Slide

  224. Scaling

    View Slide

  225. Manual Scaling

    View Slide

  226. kubectl scale
    --replicas=3
    deployment/my-app

    View Slide

  227. AutoScaling

    View Slide

  228. View Slide

  229. https://kubernetes.io/docs/user-guide/horizontal-pod-
    autoscaling/

    View Slide

  230. Summary

    View Slide

  231. Powerful

    View Slide

  232. Helpful

    View Slide

  233. Fast paced
    development

    View Slide

  234. https://gravitational.com/blog/kubernetes-release-cycle/

    View Slide

  235. Keep up to date

    View Slide

  236. Documentation

    View Slide

  237. https://kubernetes.io/docs/

    View Slide

  238. KubeCons

    View Slide

  239. https://www.youtube.com/channel/UCvqbFHwN-
    nwalWPjPUKpvTA

    View Slide

  240. http://speakerdeck.com/u/bastianhofmann

    View Slide

  241. http://twitter.com/BastianHofmann
    http://lanyrd.com/people/BastianHofmann
    http://speakerdeck.com/u/bastianhofmann
    [email protected]

    View Slide
