Static Code Analysis Using SSA

Presented at GopherCon 2015

Transcript

1. Static Code Analysis
   Using SSA


   View Slide

2. ‘go’ toolchain is great!


   View Slide

3. go build
   go test
   go fmt
   go get
   go vet
   go tool cover
   go tool pprof
   go -race


   View Slide

4. What’s the next step?


   View Slide

5. Code generation


   View Slide

6. go/ast
   go/doc
   go/parser
   go/printer
   go/scanner
   go/token


   View Slide

7. Over 1,000 packages import go/ast


   View Slide

8. The AST only shows the
   structure of code


   View Slide

9. Static Single Assignment
   Intermediate Representation


   View Slide

10. SSA
    IR


    View Slide

11. SSA IR shows
    how code flows


    View Slide

12. golang.org/x/tools/go/ssa


    View Slide

13. golang.org/x/tools/go/ssa
    Primary Author: Alan Donovan


    View Slide

14. View Slide

15. Only 5 projects import
    golang.org/x/tools/go/ssa


    View Slide

16. github.com/DanielMorsing/stackcheck
    github.com/go-llvm/llgo
    github.com/motemen/go-typeswitch-gen
    github.com/stripe/safesql
    github.com/tardisgo/tardisgo


    View Slide

17. Intermediate Representation
    Go
    IR
    Machine Code


    View Slide

18. IR is high level


    View Slide

19. IR is portable


    View Slide

20. x := 1
    y := 2
    x = x + y
    Static Single Assignment


    View Slide

21. x := 1
    y := 2
    x = x + y
    Static Single Assignment


    View Slide

22. x1
    := 1
    y1
    := 2
    x2
    = x1
    + y1
    Static Single Assignment


    View Slide

23. SSA makes
    analysis easier


    View Slide

24. Terminology


    View Slide

25. Program
    github.com/benbjohnson/foo
    github.com/benbjohnson/bar
    fmt os io


    View Slide

26. github.com/benbjohnson/foo
    type Bar
    type Baz
    func Bat()
    Package


    View Slide

27. func hello(name string) {
    if name == “” {
    fmt.Print(“name?”)
    name = readString()
    }
    fmt.Printf(“hello %s”, name)
    }
    Function


    View Slide

28. func hello(name string) {
    if name == “” {
    fmt.Print(“name?”)
    name = readString()
    }
    fmt.Printf(“hello %s”, name)
    }
    Basic Blocks


    View Slide

29. fmt.Print(“name?”)
    name = readString()
    Control Flow Graph (CFG)
    fmt.Printf(“hello %s”, name)
    false
    true
    if name == “”


    View Slide

30. func hello(name string) {
    if name == “” {
    fmt.Print(“name?”)
    name = readString()
    }
    fmt.Printf(“hello %s”, name)
    }
    Instructions


    View Slide

31. func hello(name string) {
    if name == “” {
    fmt.Print(“name?”)
    name = readString()
    }
    fmt.Printf(“hello %s”, name)
    }
    Values


    View Slide

32. SSA IR Primitives
    Alloc
    BinOp
    Builtin
    Call
    ChangeInterface
    ChangeType
    Const
    Convert
    DebugRef
    Defer
    Extract
    Field
    FieldAddr
    FreeVar
    Function
    Global
    Go
    If
    Index
    IndexAddr
    Jump
    Lookup
    MakeChan
    MakeClosure
    MakeInterface
    MakeMap
    MakeSlice
    MapUpdate
    NamedConst
    Next
    Panic
    Parameter
    Phi
    Range
    Return
    RunDefers
    Select
    Send
    Slice
    Store
    Type
    TypeAssert
    UnOp


    View Slide

33. What does it look like?


    View Slide

34. package main
    import (
    "flag"
    "fmt"
    "os"
    )
    func main() {
    // Parse CLI arguments.
    flag.Parse()
    if flag.NArg() == 0 {
    fmt.Println("usage: hello NAME")
    os.Exit(2)
    }
    // Extract name from args and say hello.
    name := flag.Arg(0)
    sayHello(name)
    }
    func sayHello(name string) {
    fmt.Printf("hello, %s!", name)
    }


    View Slide

35. package main
    import (
    "flag"
    "fmt"
    "os"
    )
    func main() {
    // Parse CLI arguments.
    flag.Parse()
    if flag.NArg() == 0 {
    fmt.Println("usage: hello NAME")
    os.Exit(2)
    }
    // Extract name from args and say hello.
    name := flag.Arg(0)
    sayHello(name)
    }
    func sayHello(name string) {
    fmt.Printf("hello, %s!", name)
    }


    View Slide

36. package main
    import (
    "flag"
    "fmt"
    "os"
    )
    func main() {
    // Parse CLI arguments.
    flag.Parse()
    if flag.NArg() == 0 {
    fmt.Println("usage: hello NAME")
    os.Exit(2)
    }
    // Extract name from args and say hello.
    name := flag.Arg(0)
    sayHello(name)
    }
    func sayHello(name string) {
    fmt.Printf("hello, %s!", name)
    }


    View Slide

37. package main
    import (
    "flag"
    "fmt"
    "os"
    )
    func main() {
    // Parse CLI arguments.
    flag.Parse()
    if flag.NArg() == 0 {
    fmt.Println("usage: hello NAME")
    os.Exit(2)
    }
    // Extract name from args and say hello.
    name := flag.Arg(0)
    sayHello(name)
    }
    func sayHello(name string) {
    fmt.Printf("hello, %s!", name)
    }
    true


    View Slide

38. package main
    import (
    "flag"
    "fmt"
    "os"
    )
    func main() {
    // Parse CLI arguments.
    flag.Parse()
    if flag.NArg() == 0 {
    fmt.Println("usage: hello NAME")
    os.Exit(2)
    }
    // Extract name from args and say hello.
    name := flag.Arg(0)
    sayHello(name)
    }
    func sayHello(name string) {
    fmt.Printf("hello, %s!", name)
    }
    false


    View Slide

39. package main
    import (
    "flag"
    "fmt"
    "os"
    )
    func main() {
    // Parse CLI arguments.
    flag.Parse()
    if flag.NArg() == 0 {
    fmt.Println("usage: hello NAME")
    os.Exit(2)
    }
    // Extract name from args and say hello.
    name := flag.Arg(0)
    sayHello(name)
    }
    func sayHello(name string) {
    fmt.Printf("hello, %s!", name)
    }


    View Slide

40. package main
    import (
    "flag"
    "fmt"
    "os"
    )
    func main() {
    // Parse CLI arguments.
    flag.Parse()
    if flag.NArg() == 0 {
    fmt.Println("usage: hello NAME")
    os.Exit(2)
    }
    // Extract name from args and say hello.
    name := flag.Arg(0)
    sayHello(name)
    }
    func sayHello(name string) {
    fmt.Printf("hello, %s!", name)
    }


    View Slide

41. package main
    import (
    "flag"
    "fmt"
    "os"
    )
    func main() {
    // Parse CLI arguments.
    flag.Parse()
    if flag.NArg() == 0 {
    fmt.Println("usage: hello NAME")
    os.Exit(2)
    }
    // Extract name from args and say hello.
    name := flag.Arg(0)
    sayHello(name)
    }
    func sayHello(name string) {
    fmt.Printf("hello, %s!", name)
    }


    View Slide

42. $ ssadump -build=CPF -importbin .


    View Slide

43. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

44. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

45. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

46. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

47. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

48. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

49. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

50. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

51. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

52. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

53. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return
    true


    View Slide

54. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return
    false


    View Slide

55. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

56. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

57. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

58. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

59. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

60. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

61. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

62. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return
    ???


    View Slide

63. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

64. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

65. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

66. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

67. func main():
    0: entry P:0 S:2
    t0 = flag.Parse() ()
    t1 = flag.NArg() int
    t2 = t1 == 0:int bool
    if t2 goto 1 else 2
    1: if.then P:1 S:1
    t3 = new [1]interface{} (varargs) *[1]interface{}
    t4 = &t3[0:int] *interface{}
    t5 = make interface{} <- string ("usage: hello NAME":string) interface{}
    *t4 = t5
    t6 = slice t3[:] []interface{}
    t7 = fmt.Println(t6...) (n int, err error)
    t8 = os.Exit(2:int) ()
    jump 2
    2: if.done P:2 S:0
    t9 = flag.Arg(0:int) string
    t10 = sayHello(t9) ()
    return


    View Slide

68. Tools built on go/ssa


    View Slide

69. safesql


    View Slide

70. safesql
    • Written by Carl Jackson at Stripe.
    • Verifies that the query string arg is a compile time constant.
    • Helps to prevent SQL injection.


    View Slide

71. safesql
    func main() {
    // Open database.
    db, err := sql.Open("postgres", "dbname=db0")
    if err != nil {
    log.Fatal(err)
    }
    defer db.Close()
    // Retrieve color from CLI args.
    color := flag.Arg(0)
    // Execute query.
    db.Query("SELECT FROM widgets WHERE color = '" + color + "'")
    }


    View Slide

72. safesql
    func main() {
    // Open database.
    db, err := sql.Open("postgres", "dbname=db0")
    if err != nil {
    log.Fatal(err)
    }
    defer db.Close()
    // Retrieve color from CLI args.
    color := flag.Arg(0)
    // Execute query.
    db.Query("SELECT FROM widgets WHERE color = '" + color + "'")
    }
    User Input


    View Slide

73. safesql
    func main() {
    // Open database.
    db, err := sql.Open("postgres", "dbname=db0")
    if err != nil {
    log.Fatal(err)
    }
    defer db.Close()
    // Retrieve color from CLI args.
    color := flag.Arg(0)
    // Execute query.
    db.Query("SELECT FROM widgets WHERE color = '" + color + "'")
    }
    Ah! SQL Injection!


    View Slide

74. safesql
    $ safesql .
    Found 1 potentially unsafe SQL statements:
    - main.go:13:10
    Please ensure that all SQL queries you use are compile-time
    constants.
    You should always use parameterized queries or prepared statements
    instead of building queries from strings.


    View Slide

75. safesql
    const FavColor = “purple”
    func main() {
    // Open database.
    db, err := sql.Open("postgres", "dbname=db0")
    if err != nil {
    log.Fatal(err)
    }
    defer db.Close()
    // Execute query.
    db.Query("SELECT FROM widgets WHERE color = '" + FavColor + "'")
    }


    View Slide

76. safesql
    $ safesql .
    You're safe from SQL injection! Yay \o/


    View Slide

77. oracle


    View Slide

78. oracle
    • Provides insights about your code.
    • Even works with interfaces!
    • Uses pointer analysis to scan your whole program


    View Slide

79. oracle
    • What code calls a function
    • What code is called by a function
    • Trace possible paths to a function call from main()
    • Determine what implements an interface
    • Find who sends to & receives from a channel
    • Determine possible values of a pointer
    • Find other identifiers that refer to the same value


    View Slide

80. oracle
    callees


    View Slide

81. type I interface {
    Foo()
    }
    type T struct{}
    func (*T) Foo() {}
    type V struct{}
    func (*V) Foo() {}
    func doSomething(condition bool) {
    var x I = &T{}
    x.Foo()
    if condition {
    x = &V{}
    }
    x.Foo()
    }


    View Slide

82. $ oracle -pos main.go:#168 callees main.go
    main.go:24:7: this dynamic method call dispatches to:
    main.go:7:11: (*main.T).Foo


    View Slide

83. type I interface {
    Foo()
    }
    type T struct{}
    func (*T) Foo() {}
    type V struct{}
    func (*V) Foo() {}
    func doSomething(condition bool) {
    var x I = &T{}
    x.Foo()
    if condition {
    x = &V{}
    }
    x.Foo()
    }


    View Slide

84. $ oracle -pos main.go:#210 callees main.go
    main.go:24:7: this dynamic method call dispatches to:
    main.go:7:11: (*main.T).Foo
    main.go:11:11: (*main.V).Foo


    View Slide

85. oracle
    callers


    View Slide

86. type I interface {
    Foo()
    }
    type T struct{}
    func (*T) Foo() {}
    type V struct{}
    func (*V) Foo() {}
    func doSomething(condition bool) {
    var x I = &T{}
    if condition {
    x = &V{}
    x.Foo()
    }
    }


    View Slide

87. type I interface {
    Foo()
    }
    type T struct{}
    func (*T) Foo() {}
    type V struct{}
    func (*V) Foo() {}
    func doSomething(condition bool) {
    var x I = &T{}
    if condition {
    x = &V{}
    x.Foo()
    }
    }


    View Slide

88. $ oracle -pos main.go:#61 callers main.go
    main.go:7:11: (*main.T).Foo is not reachable in this program.


    View Slide

89. type I interface {
    Foo()
    }
    type T struct{}
    func (*T) Foo() {}
    type V struct{}
    func (*V) Foo() {}
    func doSomething(condition bool) {
    var x I = &T{}
    if condition {
    x = &V{}
    x.Foo()
    }
    }


    View Slide

90. $ oracle -pos main.go:#98 callers main.go
    main.go:11:11: (*main.V).Foo is called from these 1 sites:
    main.go:22:8: dynamic method call from main.main


    View Slide

91. oracle
    pointsto


    View Slide

92. type T struct{}
    func (*T) Foo() {}
    type V struct{}
    func (*V) Foo() {}
    type I interface {
    Foo()
    }
    func doSomething(cond bool) {
    var x I = &T{}
    if cond {
    x = &V{}
    }
    fmt.Printf("x is %T\n", x)
    }


    View Slide

93. type T struct{}
    func (*T) Foo() {}
    type V struct{}
    func (*V) Foo() {}
    type I interface {
    Foo()
    }
    func doSomething(cond bool) {
    var x I = &T{}
    if cond {
    x = &V{}
    }
    fmt.Printf("x is %T\n", x)
    }


    View Slide

94. $ oracle -pos main.go:#168 pointsto main.go
    main.go:21:6: this I may contain these dynamic types:
    main.go:8:6: *T, may point to:
    main.go:21:14: complit


    View Slide

95. type T struct{}
    func (*T) Foo() {}
    type V struct{}
    func (*V) Foo() {}
    type I interface {
    Foo()
    }
    func doSomething(cond bool) {
    var x I = &T{}
    if cond {
    x = &V{}
    }
    fmt.Printf("x is %T\n", x)
    }


    View Slide

96. $ oracle -pos main.go:#206 pointsto main.go
    main.go:24:3: this I may contain these dynamic types:
    main.go:12:6: *V, may point to:
    main.go:24:9: complit


    View Slide

97. type T struct{}
    func (*T) Foo() {}
    type V struct{}
    func (*V) Foo() {}
    type I interface {
    Foo()
    }
    func doSomething(cond bool) {
    var x I = &T{}
    if cond {
    x = &V{}
    }
    fmt.Printf("x is %T\n", x)
    }


    View Slide

98. $ oracle -pos main.go:#244 pointsto main.go
    main.go:27:26: this I may contain these dynamic types:
    main.go:8:6: *T, may point to:
    main.go:21:14: complit
    main.go:12:6: *V, may point to:
    main.go:24:9: complit


    View Slide

99. gorename


    View Slide

100. gorename
     • Safely renames identifiers
     • Renames the declaration as well as references.
     • Even works across packages in GOPATH
     • Just uses go/types but it’s still cool
     • Intelligently prevents ambiguity and shadowing conflicts.


     View Slide

101. gorename
     func doSomething() {
     var x int
     if y := rand.Intn(10); y == 0 {
     x = 1
     }
     fmt.Printf("x is %d\n", x)
     }
     Shadowing Conflict


     View Slide

102. gorename
     $ gorename -from mypkg.doSomething::x -to y
     Shadowing Conflict


     View Slide

103. gorename
     mypkg.go:2:6: renaming this var "x" to "y"
     mypkg.go:4:3: would cause this reference to become shadowed
     mypkg.go:5:5: by this intervening var definition
     Shadowing Conflict


     View Slide

104. gorename
     package mypkg
     type Widget struct {
     Name string
     }
     ...
     type Woojit struct {
     Widget
     Floojit string
     }
     Ambiguity Conflict


     View Slide

105. gorename
     $ gorename -from mypkg.Widget -to Floojit
     Ambiguity Conflict


     View Slide

106. gorename
     main.go:8:2: renaming this field "Widget" to "Floojit"
     main.go:9:2: would conflict with this field
     Ambiguity Conflict


     View Slide

107. golang.org/x/tools


     View Slide

108. It’s just the beginning!
     There is so much to build!


     View Slide

109. Q&A
     @benbjohnson


     View Slide
