Spring I/O 2023 - Barcelona

Many applications require some sort of secret, such as a database password, a certificate. The growing popularity of Kubernetes and cloud adoption has gotten the attention of attackers and raised the stakes for developers. There are many challenges of secrets management in spring-boot applications.

This session will summarise the different available patterns for securing cloud native application secrets. It will demo open-source secrets management solutions like Conjur for securing access, enforcing policy, and authenticating access requests. Now, developers and DevOps engineers search for the capabilities to properly secure secrets in DevOps Pipelines.

To do their job, developers need to write applications that require secure access to resources via secrets, and security teams need to mitigate risk. This can lead to contention between developers and security teams.

The Talk will cover the following topics:

-Increase the awareness of the vulnerabilities and risks. Remove No hard-coded credentials
-Simplify secrets management
-Introduction to the secret zero problem
-Secure all application types, everywhere with JWT and Cert Based Authentication
-Strong authentication and authorization - ABAC – apply least privilege
-When to use Sidecar and init container patterns to improve applications security in kubernetes ?
-What is the Secretless pattern?
-How to get full auditing and control by security team ?

Badr

May 23, 2023
Tweet

Other Decks in Technology

Transcript

  1. cyberark.com/devsecops
    Badr NASS LAHSEN
    Cyber Security Architecture & EMEA DevSecOps SME
    May 18th, 2023
    @bnasslahsen
    @nass_lahsen
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  2. cyberark.com
    Who
    Are
    We
    CyberArk is the global leader in privileged
    access management, a critical layer of
    IT security protecting access to data,
    infrastructure and applications across
    the enterprise, in the cloud and throughout
    the DevOps pipeline.
    3
    cyberark.com
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  3. cyberark.com
    cyberark.com
    Why Shift Security Left for Software
    Development
    How to manage Spring-Boot
    Applications Secrets?
    Summary and Q&A
    What is Application Identity Security?
    4
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  4. cyberark.com 5
    71%
    66%
    67%
    Millions
    Of organizations experienced an
    attack on their software supply
    chain in 2021
    Of attacks in 2020-2021
    compromised code
    Of organizations have not done a
    formal assessment or education
    on software supply chain risk
    Of organizations affected
    CyberArk, 2022 Identity Security Threat Landscape Report
    ENISA, Threat Landscape of Software Supply Chain attacks
    PWC, 2022 Global Digital Trust Insights
    5
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.
    * https://www.sonatype.com/resources/state-of-the-software-supply-chain-2021

    View Slide

  5. cyberark.com
    Massive Breach at Uber in September 2022
    Outcome: Attacker gains broad administrative access to critical Uber IT systems
    Attack Path:
    • Phase 1: Attacker gains entry to Uber network via social engineering
    • Phase 2: Discover hard-coded secret in PowerShell script for PAM solution
    • Phase 3: Escalate privileges and spread the breach everywhere
    6
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  6. cyberark.com
    7
    * https://slsa.dev/spec/v0.1/threats
    https://labs.cyberark.com/anun/
    7
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  7. cyberark.com
    Developer
    Identity/Access Endpoint
    Test/Provision Run /Operate
    Build
    • Weak authentication
    • Authentication fatigue
    • Lack of credential rotation
    • Lack of audit
    • Over-permissioning
    • Local admin rights
    • Credential theft risk
    • High variability of unknown
    applications
    • Relaxed security policy
    • Exposed Credentials
    • Compromised OSS
    • Code Injection, Theft, and Tampering
    • Malicious Use of Interactive Access
    • Stolen Access Keys
    • Hijacked Compute/Resources
    • Exposed Data
    • Stolen IP
    CI/CD
    8
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  8. cyberark.com
    cyberark.com
    What is Application
    Identity Security?
    9
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  9. cyberark.com
    Machine Identities Outnumber Human Identities 45 to 1
    Human Accounts
    Apps and other
    non-human
    identities
    *From Global survey of 1,750 security
    decision makers
    45 Non-human Identities to 1
    human Identity (machines,
    applications, workloads, etc.)*
    10
    10
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  10. cyberark.com
    11
    SOLUTION
    SECRETS MANAGEMENT
    • Cannot rotate, track, audit, or enforce security policies
    • Are exposed in code repositories – Git.
    Hardcoded secrets =
    “breach waiting to happen”
    Secrets = privileged access for
    non-human identities
    • Credential, Access Key, SSH key, etc.
    • Apps use secrets to securely access IT and other resources.
    • If the attacker has the secret, they can access the resource.
    Secrets and other non-human credentials
    need to be protected
    11
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  11. cyberark.com
    Islands of Security
    Hiera Databags
    Vault
    Secrets Secrets
    Secrets
    Azure Key Vault Secrets Git Secret
    Azure
    DevOps GitHub
    Secrets Mgr /KMS Azure Key Vault Secrets Manager
    There are many ways to vault secrets,
    But:
    • Developers must learn multiple
    solutions
    • Hard to establish & share best-
    practices
    • Short-cuts often taken
    • SoD not enforced
    • GRC reporting is impossible
    12
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  12. cyberark.com
    13
    Most Frequent Audit Findings for Secrets
    … is that while there is frequently standardisation in the management of privileged
    human identities, the situation is very different in the non-human domain
    X No audit or logs
    X No rotation or Security governance
    X No centralized control
    APPS CI/CD CLOUD
    RPA
    X No visibility to security team (shadow IT)
    X Secrets stored in different vaults (some are not secure)
    X Hard coded credential in code or config files
    13
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  13. cyberark.com
    Challenge that enterprises face …
    14
    Where will the
    secrets live?
    What secret
    store?
    Will the
    application be
    ported?
    How will secrets
    management
    impact my
    applications?
    How can I increase
    my application’s
    security?
    How will I audit
    account usage?
    Will developers
    use the secrets
    management
    solution?
    14
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  14. cyberark.com
    15
    APP ID
    Create Auditable
    Identity for Apps
    Access is
    Authorized, Logged
    and Auditable
    Establish Identity
    to Applications
    Limits Discovery &
    Reduces Attack
    Surface
    Enables Compliance
    with Audit &
    Best Practices
    Removes Security
    Island Dilemma
    Regularly Perform
    Secrets Rotation
    No Updates to Files,
    Code or DBs when
    Secrets Rotated
    No Application
    Downtime Required
    to Rotate Secrets
    Removal of Hard-Coded
    Credentials
    Credential
    Rotation
    MFA Enforce Strong
    Authn for Apps
    Authn
    15
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  15. cyberark.com
    • Humans have built-in authentication
    support:
    –Built-in vault for passwords
    –Back-channels for MFA (e.g. phones)
    • Non-humans need a way to bootstrap
    identity authentication that doesn’t put
    credentials at risk
    • But how to manage that initial secret
    required by apps to bootstrap identity?
    • This is the Secret-Zero problem.
    Human Identity
    16
    16
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  16. cyberark.com
    • Strong Application Authentication - enable a secure way for applications running on various platforms
    to authenticate using a JSON Web Token (JWT) or a Certificate.
    • Support for advanced use cases - provide a generic and flexible authentication method based on the
    workload attributes.
    • Allow the organization to comply with protocol's security standards.
    • Provide an authentication endpoint to any modern workload which can identified with a JWT or a
    Certificate.
    • The authenticator is responsible for authenticating workloads / non-human identities and acting as an
    authorization layer to the secrets.
    • Easy to extend and adopt 17
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  17. cyberark.com
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.
    /
    conjur
    authn-azure
    auth-k8s
    tenant-1
    cluster-1
    Team2
    Vault
    data
    Team1
    Apps
    (hosts)
    Apps
    (hosts)
    Team3
    Apps
    (hosts)
    Team1-Safe
    Team2-Safe
    Team3-Safe
    managers managers managers
    consumers
    consumers
    consumers
    cluster-2
    Security admins
    Team admins
    Grants
    18
    18

    View Slide

  18. cyberark.com
    Identity Attribute Authenticator
    IAM Roles authn-iam
    Azure Resources authn-azure
    Namespace, Deployment, Stateful Set, Others authn-k8s
    OpenID Connect (OIDC) Identity Layer authn-oidc
    Google identity platform authn-gcp
    LDAP User Credentials authn-ldap
    Json web token authentication authn-jwt
    Leverage unique native capabilities of non-human identity for highest level of security
    Application
    Conjur
    19
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  19. cyberark.com
    1) Admin allow-lists app identity
    Options for identity granularity include (but not limited to):
    • Identity = Cluster/Namespace
    • Identity = Cluster/Namespace/Service Account
    2) Authenticator client in app pod submits CSR
    w/platform attributes to CyberArk Conjur
    3) CyberArk Conjur verifies attributes w/platform
    service
    4) CyberArk Conjur issues cert & key creds to
    authenticator client in app pod
    5) Authenticator client in app pod uses creds to
    authenticate, get CyberArk Conjur access token
    and shares via shared memory volume.
    Policy
    1
    2
    csr
    identity
    5
    access
    token
    4
    CyberArk
    Secrets Manager
    3 verify
    20
    20
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  20. cyberark.com
    cyberark.com
    How to manage
    Spring-Boot
    Applications Secrets?
    21
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  21. cyberark.com
    GOOD DEVELOPER EXPERIENCE IS IMPORTANT!
    SO IS COLLABORATION!
    Developers
    Security
    22
    22
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  22. cyberark.com
    APIs
    Conjur
    Spring Use Case
    1 authenticate get token get secret
    login request
    authenticate
    authorize
    authorize
    3 2 4
    short lived
    access token
    User
    Conjur
    provides
    Conjur policy
    Spring Security
    23
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  23. cyberark.com
    1. An application requests an identity token from
    a JWT provider
    2. The JWT provider sends a JWT back to the
    application
    3. The application sends an authentication
    request to CyberArk Conjur using the JWT
    Authenticator REST API.
    4. CyberArk Conjur fetches a public key from the
    JWT provider, by accessing the JWKS
    endpoint of the vendor. (jwks-uri or public-keys
    value)
    5. CyberArk Conjur attempts to authenticate and
    authorize the request. If successful, CyberArk
    Conjur sends a short-lived access token back
    to the application.
    6. The application can use the
    CyberArk Conjur token to retrieve secrets
    stored in Conjur (Summon/Conjur API
    APIs
    24
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  24. cyberark.com
    • Securing etcd—secret data is stored in etcd. By default, etcd data is not encrypted.
    • You can’t share the manifest file or push it into a repo.
    • Users who consume a secret can see its value.
    • Root exploit — anyone with root access on any node can read any secret.
    • No visibility or change management.
    • No built in rotation
    -> A tool for scanning Kubernetes cluster for risky permissions in Kubernetes's Role-based access control
    (RBAC) authorization model.
    https://github.com/cyberark/KubiScan 25
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  25. cyberark.com
    • Native ways to consume secrets for a great developer experience
    • Cloud-agnostic
    • One integration across all Kubernetes/OpenShift platforms that can be re-used everywhere
    Secrets Provider
    (Push to Kubernetes Secrets)
    Make the secrets available in
    Kubernetes Secrets
    Secrets Provider
    (Push to Files)
    Makes secrets available to the
    application as environment
    variables files on the pod
    memory
    Summon
    Fetches secrets and makes
    them available to the
    application as environment
    variables
    Native experience for
    developers that already use
    Kubernetes Secrets
    Easier deployment using HELM
    No code change to the
    application
    Supports rotations
    No code change required
    APIs
    Uses API calls to retrieve
    secrets
    Available APIs for Java, Ruby
    and Go
    Supports rotations
    Secretless Broker
    Brokers the connection to the
    target resource
    No secrets delivered to the
    application
    No code changes required
    Supports rotations
    K8s
    Secrets Summon
    APIs
    Secretless
    Broker
    Push To
    Files
    26
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  26. cyberark.com
    27
    • Secrets Provider for
    Kubernetes
    1. cyberark-secrets-provider-for-k8s
    init container, starts and
    authenticates to the Follower using
    the Kubernetes Authenticator
    2. cyberark-secrets-provider-for-k8s
    init container reads all Kubernetes
    Secrets required by the pod
    3. For each mapped Kubernetes
    secret, the cyberark-secrets-
    provider-for-k8s init container:
    • Retrieves Conjur secrets
    • Updates the Kubernetes secret with the
    Conjur secret value
    4. cyberark-secrets-provider-for-k8s
    init container runs to completion
    5. Application container starts and
    consumes the Kubernetes Secrets
    K8s
    Secrets
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  27. cyberark.com
    28
    1. The Secrets Provider is deployed in the same
    Pod as your application container. The
    authentication container starts up and parses
    Pod annotations from a Kubernetes Downward
    API volume. The Pod annotations are organized
    in secret groups, with each secret group
    indicating to the Secrets Provider:
    2. The Secrets Provider authenticates to Conjur
    using the Kubernetes Authenticator.
    3. The Secrets Provider reads all Conjur secrets
    required across all secret groups.
    4. The Secrets Provider renders secrets files for
    each secret group, and writes the resulting files
    to a volume that is shared with your application
    container.
    5. The Secrets Provider container runs to
    completion.
    6. Your application container starts and
    consumes the secrets files from the shared
    volume.
    Push To
    Files
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  28. cyberark.com
    Summon
    3
    1 2
    1
    2
    3
    Summon invoked
    with authenticated
    identity
    Summon fetches
    secrets using
    identity
    Processes launched
    with secrets in
    environment
    Learn more at: https://cyberark.github.io/summon/
    29
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  29. cyberark.com
    30
    30
    Modern Solution Architecture
    Vault Credentials
    No Solution
    Hardcode Credentials
    Secretless Broker Architecture
    Isolate Applications
    Secure – manage credentials in
    vault with comprehensive audit
    Simpler – Developers can focus on writing code
    More Secure – Applications cannot leak what
    they don't have
    UserName = “app”
    Password = “y7qeF$1”
    Host = “10.10.3.56”
    ConnectDatabase(Host,
    UserName, Password)
    At Risk – Widely exposes
    credentials
    Potential for
    App to Leak
    Secrets
    Secretless
    Broker
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  30. cyberark.com
    cyberark.com
    Summary
    31
    Copyright © 2023 CyberArk Software Ltd. All rights reserved.

    View Slide

  31. cyberark.com
    üThink about secrets management across hybrid and multi cloud environments
    üSimplify secrets management with a uniform developer and security experience independent of cloud
    providers, tools
    üEnd-to-end encryption of secrets through mutual TLS (Transport Layer Security) using SPIFFE-
    compliant resource identifiers.
    üRobust authentication and authorization incorporating RBAC policies
    üIt’s important to have a federated governance to guarantee and all identities and provide autonomy to
    the development teams
    üRemember the overhead and the risks related to security islands
    üIdeally, credentials should not be exposed to any 3rd party and should reside only in memory
    üStrong container authentication based on its attributes
    üLeverage Applications Secrets rotation, to mitigate attack risks
    üYou should get full central audit trail of your secrets – Vendors Agnostic 32
    Demos: https://github.com/bnasslahsen/conjur-spring-boot-demos/tree/spring-io-23

    View Slide

  32. cyberark.com
    cyberark.com
    Q&A
    33

    View Slide

  33. cyberark.com
    cyberark.com
    Thank You
    34

    View Slide
