AWS에서 Kubernetes 실전 활용하기

By Ben

Transcript

1. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. 유병우 Buzzvil Kubernetes in Action on AWS
2. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Why Container orchestration tool? Why Kubernetes? Why Kops? Demo
3. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Why Container orchestration tool?
4. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Why Container? • State? • Relation? • History?
5. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Why Container? - Relation 격리된 공간 가상화 Overhead
6. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Why Container? - History # Use an official Python runtime as a parent image FROM python:2.7-slim # Set the working directory to /app WORKDIR /app # Copy the current directory contents into the container at /app ADD . /app # Install any needed packages specified in requirements.txt RUN pip install --trusted-host pypi.python.org -r requirements.txt # Make port 80 available to the world outside this container EXPOSE 80
7. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Why Container orchestration tool? EC2 Django EC2 Django EC2 Django EC2 Go EC2 Go EC2 Go 2 Apps + 2 AS Groups + 1 ALB Docker 도입 Django Go Application load balancer Nginx 3 Apps + 1 AS Groups Container orchestration tool 을 통해 이걸 해결해보자!
8. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Why Kubernetes?
9. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. 용어정리
10. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Cluster Cluster / Node / Pod
11. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. RC / Deployment / Service • ReplicationController (ReplicaSet) • 하나의 Pod 상태를 공유하는 Set • Deployment? • 업데이트! (RC 가 추가됨) • 어떻게 배포할지 설정 가능 How to expose them? Service
12. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Why Kubernetes? • Automatic binpacking • Horizontal scaling • Automated rollouts and rollbacks • Self-healing • Service discovery and load balancing
13. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Automatic binpacking
14. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Automatic binpacking Node 1 (4 CPU / 8G) 2 CPU / 2G Node 2 (4 CPU / 8G) 2 CPU / 2G 2 CPU / 2G 1 CPU / 2G
15. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Automatic binpacking Node 1 (4 CPU / 8G) 2 CPU / 2G Node 2 (4 CPU / 8G) 2 CPU / 2G 2 CPU / 2G 1 CPU / 2G
16. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Automatic binpacking Node 1 (4 CPU / 8G) 2 CPU / 2G 1 CPU / 2G Node 2 (4 CPU / 8G) 2 CPU / 2G 2 CPU / 2G 1 CPU / 2G
17. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Automatic binpacking Node 1 (4 CPU / 8G) 2 CPU / 2G Node 2 (4 CPU / 8G) 2 CPU / 2G 2 CPU / 2G 1 CPU / 2G 1 CPU / 2G
18. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Automatic binpacking 2 CPU / 16G 2 CPU / 4G 4 CPU / 8G 2 CPU / 2G 1 CPU / 2G 2 CPU / 16G 1 CPU / 4G 1 CPU / 8G 4 CPU / 8G 2 CPU / 2G 1 CPU / 2G 2 CPU / 16G 1 CPU / 4G 1 CPU / 8G 4 CPU / 8G 2 CPU / 2G 1 CPU / 2G 2 CPU / 16G 1 CPU / 6G 1 CPU / 2G 4 CPU / 8G 2 CPU / 2G 1 CPU / 2G 3 CPU / 4G 1 CPU / 8G
19. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Horizontal scaling
20. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Horizontal scaling
21. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Automated rollouts and rollbacks
22. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Automated rollouts and rollbacks https://kubernetes.io/docs/tutorials/kubernetes-basics/update-intro/
23. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Automated rollouts and rollbacks
24. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Self-healing
25. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Self-healing Node 1 App 1 App 2 Node 2 App 2 Node 3 App 3 Master Contoller Scheduler
26. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Self-healing Node 1 App 1 App 2 Node 2 App 2 Node 3 App 3’ Master Contoller Scheduler
27. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Self-healing Node 1 App 1 App 2 Node 2 App 2 Node 3 App 3 Master Contoller Scheduler
28. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Self-healing Node 1 App 1 App 2 Node 2 App 2 App 3 Master Contoller Scheduler
29. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Service discovery and load balancing
30. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Service discovery and load balancing {{service-name}}.{{namespace}}.svc.cluster.local
31. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Service discovery and load balancing • Internal • ClusterIP • External • LoadBalancer • NodePort
32. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Why Kops?
33. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Why kops? • AWS 위에 Kubernetes clusters 관리를 자동화 AWS AWS Kube
34. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Kube + α Why kops? • AWS 위에 Kubernetes clusters 관리를 자동화 S3 IAM VPC EC2 Route53
35. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Why kops? • AWS 위에 Kubernetes clusters 관리를 자동화 • 고가용성(Highly Available) Kubernetes Masters
36. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Why kops? • AWS 위에 Kubernetes clusters 관리를 자동화 • 고가용성(Highly Available) Kubernetes Masters • State-sync model (dry-runs & Idempotency) • kops create cluster --zones us-west-2a ${NAME} • kops update cluster ${NAME} --yes
37. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Demo
38. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Prerequisites • Install CLI tools – kops / kubectl • IAM permissions
39. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Demo • Cluster 구성 (1 master & 2 nodes) • Web app & Nginx proxy 구성 • External load balancer 구성 • Auto scaling 설정
40. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. VPC Overview Cluster Load balancer hello-go Pod Pod Pod Pod autoscaler Nginx Pod Cluster autoscaler
41. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. VPC Cluster 구성 Cluster Master Node Node
42. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Cluster 구성 • 환경변수 설정 • export AWS_ACCESS_KEY_ID=$(aws configure get aws_access_key_id) • export AWS_SECRET_ACCESS_KEY=$(aws configure get aws_secret_access_key) • export S3_BUCKET_NAME=k8s-state-test-honeyscreen-com • export KOPS_STATE_STORE=s3://${S3_BUCKET_NAME} • export CLUSTER_NAME=k8s-test.honeyscreen.com • export SSH_PUBLIC_KEY=~/.ssh/id_rsa.pub • export VPC={{VPC-ID}} • export CLUZTER_REGION=ap-northeast-2 • export CLUSTER_ZONE=${CLUZTER_REGION}a
43. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Cluster 구성 • S3 Bucket 만들기 / Cluster 생성
44. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Cluster 구성 • Cluster 확인 및 수정
45. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Cluster 구성 • Cluster 적용 • kops update cluster --name $CLUSTER_NAME –yes • Cluster 업데이트 • kops edit instancegroup nodes • kops update cluster --name $CLUSTER_NAME –yes
46. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Cluster 구성 • Dashboard 설치 • kubectl create -f https://raw.githubusercontent.com/kubernetes/kops/master/addons/kubernetes- dashboard/v1.8.1.yaml • http://api.k8s-test.honeyscreen.com/ui
47. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. VPC Web app & Nginx proxy 구성 Cluster hello-go Pod Pod Pod Nginx Pod
48. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Web app & Nginx proxy 구성 • Web app - hello-go • Source code • Return Git revision • Build • kube/app-hello-go.yaml • kube/svc-hello-go.yaml • Nginx proxy • kube/app-nginx.yaml • kube/svc-nginx.yaml
49. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Web app - hello-go • main.go
50. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Web app – build-docker.sh • hello
51. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Web app – kube/app-hello-go.yaml
52. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Web app – kube/svc-hello-go.yaml
53. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Web app – kube/app-nginx.yaml
54. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. VPC External load balancer 구성 Cluster Load balancer hello-go Pod Pod Pod Nginx Pod
55. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Web app – kube/svc-nginx.yaml
56. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. External load balancer 구성 • Expose Nginx to Load balancer • kube/svc-nginx.yaml • Load balancer 확인 • Route53 에서 sub domain 할당
57. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. deploy.sh
58. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. VPC Auto scaling 설정 Cluster Load balancer hello-go Pod Pod Pod Pod autoscaler Nginx Pod Cluster autoscaler
59. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Auto scaling - Pod • kube/hpa-hello-go.yaml
60. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Auto scaling - Cluster • kube/app-autoscaler.yaml
61. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Increase load
62. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Increase load
63. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Decrease load
64. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. Decrease load
65. © 2018, Amazon Web Services, Inc. or Its Affiliates. All rights reserved. References • Github https://github.com/urunimi/kube-sample/ • E-mail hovan@hovans.com ben.yoo@buzzvil.com We are hiring!
66. Q&A
