DevSec: Continuous Patch and Security Assessment with InSpec

Transcript

1. DevSec: Continuous Patch and Security Assessment with InSpec Christoph Hartmann Lead Engineer Chef Software @chri_hartmann Patrick Münch IT-Security Consultant SVA GmbH @atomiczero111
2. $> whoami • IT-Security Consultant at SVA GmbH • Co-Founded Dev-Sec.io project • Penetration-Testing • Offensive Security Certified Professional • Offensive Security Certified Expert @atomiczero111 Patrick Münch atomic111
3. @chri_hartmann $> whoami Christoph Hartmann • Engineering Lead at Chef Software • Co-Founded Dev-Sec.io project • Co-Founder of VulcanoSec • Acquired by Chef Software • InSpec Creator chris-rock
4. Agenda Compliance DevOps
5. Join github.com/chef/inspec Join github.com/dev-sec
6. Challenges
7. The tip of the iceberg Heartbleed Shellshock WannaCry Cyber-Threat landscape
8. State of Security in 2014 • In 60% of cases, attackers can compromise organizations within minutes. • 99.9% of the exploited vulnerabilities were compromised more than a year after the vulnerability was published. • Ten vulnerabilities account for 97% of the exploits observed. Verizon Data Breach Report
9. OWASP Top 10
10. A5 – Security Misconfiguration Good security requires having a secure configuration defined and deployed for the application, frameworks, application server, web server, database server, platform, etc. Secure settings should be defined, implemented, and maintained, as defaults are often insecure. Additionally, software should be kept up to date. A9 – Using Components with Known Vulnerabilities Components, such as libraries, frameworks, and other software modules, run with the same privileges as the application. If a vulnerable component is exploited, such an attack can facilitate serious data loss or server takeover. Applications and APIs using components with known vulnerabilities may undermine application defenses and enable various attacks and impacts. OWASP Top 10
11. Source: http://content.time.com/time/covers/europe/0,16641,20020708,00.html
14. Regulatory Compliance PCI-DSS Gramm-Leach-Bliley Act HIPAA Dodd-Frank ISO Sarbanes-Oxley HITECH Grundschutz European Central Bank Regulations
15. Reporting of compliance activity is extensive EY – A time of evolution for compliance: laying foundations for future success
16. Huge scope remains for tapping into the power of technology EY – A time of evolution for compliance: laying foundations for future success
17. COMPLIANCE AND SECURITY Compliance Security
18. Automation
21. github.com/dev-sec
23. Scale
24. Scale
25. Scale
26. DevOps Cloud IoT
28. Compliance DevOps
29. Security & Compliance
32. Language Compliance DevOps Security
33. Compliance-Driven Infrastructure
34. Tradeoff: Speed vs Risk DevOps teams focus on faster innovation, potentially increasing risk InfoSec teams focus on mitigating risk, potentially reducing speed
35. Drivers for Compliance Security Reduce risk and protect business Liability Avoid negligence
36. QUALITY/COMPLIANCE RATE OF INNOVATION Scale Speed and Compliance
37. Detect Correct Compliance Continuous
38. Let’s talk about solutions github.com/dev-sec
39. Works with all DevOps tools e.g.
40. InSpec turns infrastructure testing, compliance and security requirements into code
41. Surface check #1: Know your security stance
42. Surface check Deep analysis #1: Know your security stance
43. • Operating Systems • DBs, AppServers • Apps • On-prem, Cloud, Hybrid, Containers Deep analysis #1: Know your security stance
44. Faulty assumptions #1: Know your security stance
45. Faulty assumptions #1: Know your security stance
46. • Prevent insecure production env. • Report and alert continuously • Provide proof Faulty assumptions #1: Know your security stance
47. Documentation SSH supports two different protocol versions. The original version, SSHv1, was subject to a number of security issues. Please use SSHv2 instead to avoid these.
48. Scripting tools
49. The better way TESTING A REQUIREMENT
50. Standalone Usage $ inspec exec test.rb $ inspec exec test.rb -i vagrant.key -t ssh://root@172.17.0.1:11022 $ inspec exec test.rb -t winrm://Admin@192.168.1.2 --password super $ inspec exec test.rb -t docker://3cc8837bb6a8 describe sshd_config do its('Protocol') { should cmp 2 } end
51. Mapping of Compliance Document to InSpec
52. Compliance Language
53. apache apache_conf apt audit_policy auditd_conf auditd_rules bash bond bridge bsd_service command crontab csv dh_params directory docker docker_container docker_image etc_group file gem group groups grub_conf host http iis_site iis_website inetd_conf ini interface iptables json kernel_module kernel_parameter key_rsa launchd_service limits_conf login_defs mount mssql_session mysql mysql_conf mysql_session npm ntp_conf oneget oracledb_session os os_env package packages parse_config parse_config_file passwd pip port postgres postgres_conf postgres_session powershell ppa processes rabbitmq_config registry_key runit_service script security_policy service shadow ssh_config sshd_config ssl sys_info systemd_service sysv_service upstart_service user users vbscript windows_feature windows_registry_key windows_task wmi x509_certificate xinetd_conf yaml yum yumrepo zfs_dataset zfs_pool Built-in resources
54. Supported Operating Systems
55. InSpec Profiles Folder Structure
56. InSpec Profiles inspec.yml
57. $ inspec supermarket profiles == Available profiles: * apache2-compliance-test-tthompson thompsontelmate/apache2-compliance-test-tthompson * Apache DISA STIG som3guy/apache-disa-stig * chef-alfresco-inspec-mysql alfresco/chef-alfresco-inspec-mysql * chef-alfresco-inspec-tomcat alfresco/chef-alfresco-inspec-tomcat * chef-client-hardening sliim/chef-client-hardening * CIS Docker Benchmark dev-sec/cis-docker-benchmark * CVE-2016-5195 ndobson/cve-2016-5195 * DevSec Apache Baseline dev-sec/apache-baseline * DevSec Linux Baseline dev-sec/linux-baseline InSpec Supermarket
58. Demo: Deploy Website to Production Ubuntu Apache WebServer DevSec Static Website
59. github.com/dev-sec
60. DevSec InSpec Profiles Operating Systems DevSec Linux Baseline DevSec Linux Patch Baseline DevSec Windows Baseline DevSec Windows Patch Baseline DevSec SSH Baseline DevSec SSL/TLS Baseline CIS Distribution Independent Applications DevSec Nginx Baseline DevSec MySQL Baseline DevSec PHP baseline DevSec Apache Baseline DevSec PostgreSQL Baseline Application Runtimes DevSec OpenStack Baseline CIS Docker Benchmark CIS Kubernetes Benchmark
61. Linux Patch Benchmark Acme Inc include_controls ’linux-patch baseline’ depends: - name: linux-patch baseline InSpec Profile Management
62. Manage Baselines My CIS L1 (inspec overlay) CIS Lvl1 (xml base profile)
63. Manage Baseline Overlays Dev Production Test My CIS L1 (inspec overlay) CIS Lvl1 (xml base profile)
64. InSpec Profiles github.com/dev-se c DevSec Windows Patch Baseline DevSec Linux Baseline DevSec Windows Baseline DevSec Linux Patch Baseline
65. InSpec Profiles github.com/dev-sec github.com/chris-rock/acme-inspec-profil DevSec Windows Patch Baseline DevSec Linux Baseline DevSec Windows Baseline DevSec Linux Patch Baseline
66. InSpec Profiles DevSec Windows Patch Baseline DevSec Linux Baseline DevSec Windows Baseline DevSec Linux Patch Baseline github.com/dev-sec github.com/chris-rock/acme-inspec-profil
67. InSpec Profiles
68. Continuous Compliance Compliance DevOps
69. Continuous Compliance Scan for Compliance Build & Test Locally Build & Test CI/CD Remediate Verify
70. Further Resources inspec.io • Hands on tutorials • Extensive documentation • Code examples dev-sec.io • Security Baselines • Ansible, Chef & Puppet Hardening Modules • Documentation
71. Further Resources Compliance- und Sicherheitsanforderungen automatisieren und effizienter managen https://youtu.be/0aEYp15VP_M BSI-Compliance - SVA Experten-Tipp https://youtu.be/DTvtACNzLro
72. Join github.com/chef/inspec Join github.com/dev-sec
73. Contact Details Christoph Hartmann Engineering Lead Compliance eMail: chartmann@chef.io Twitter: @chri_hartmann Patrick Münch IT-Security Consultant eMail: patrick.muench@sva.de Twitter: @atomiczero111
