BASTA! Spring 2025: Semantic AI in Action: Architektur-Patterns für LLMs & Embeddings

Semantic AI als Schlüssel zur Integration von KI in eigene Lösungen. In diesem Vortrag zeigt Christian Weyer praxisnahe Architektur-Patterns und Ansätze für die Nutzung von Large und Small Language Models wie GPT oder Llama sowie Embedding-Modellen in modernen Software-Architekturen. Wichtige Konzepte wie Semantic Routing, Semantic Search & RAG, Structured Output und Observability werden anhand eines End-to-End-Systems mit mehreren Services und Client-Anwendungen demonstriert. Entwickler und Architekten erhalten einen pragmatischen Überblick über die mögliche Umsetzung in eigenen Projekten.

Transcript

1. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Christian Weyer | Co-Founder & CTO | Thinktecture AG | christian.weyer@thinktecture.com
2. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings LLM- ALL-THE-THINGS? 2
3. Language Models understand and generate semantically rich human language, transforming it into text or structured data for both humans and machines. ⚠ Non-deterministic: same input can lead to different outputs. Embedding Models capture semantic meaning by encoding human language into numerical vector representations, facilitating understanding, comparison, and retrieval for both humans and machines. ✅ Deterministic: same input always results in the same embedding. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings 3 🫱 🫲 Semantic AI Generative AI
4. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings MODELS FOR OUR SOFTWARE 4
5. § Language models (LLM, SLM) & embedding models (EM) in end-to-end architectures § EM enable semantic search & comparison § LM enable human language understanding via API calls § System prompt § User query Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Model integrations 5
6. § We rely on Language Model’s Language understanding NOT on its world knowledge❗ Semantic AI in Action Architektur-Patterns für LLMs & Embeddings ⚠ Important shoutout 6
7. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Classical applications & UIs 7
8. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Language-enabled “UIs” 8
9. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings 9 Sample solution - C4 system context diagram
10. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Sample solution - Technology stack 10 Services § Python as the go-to-platform for ML/AI/Gen-AI § Esp. for local model execution § But: Most of the logic could be implemented in any language/platform Clients
11. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings PATTERN LOCAL RAG [RETRIEVAL-AUGMENTED GENERATION] 11
12. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings “Talk to your data” Cleanup & Split Text Embedding Question Text Embedding Save Query Relevant Results Question Answ er LLM 12 Embedding Model Embedding Model 💡 Indexing / Embedding Question Answering .md, .docx, .pdf etc. “Lorem ipsum…?” 💡 Vector DB
13. § Frameworks § LangChain § Fastembed § Lightweight & efficient for generating text embeddings § Embedding model § jinaai/jina-embeddings-v2-base-de (local) § Vector store § PostgreSql (pgvector) vector store § LLM/SLM § Llama 3.3 70B on Cerebras (very fast) Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Technical implementation – Local RAG 13
14. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings PATTERN STRUCTURED OUTPUT 14
15. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Structured data from unstructured input – e.g. for API calling 15 “OK, when is my colleague CW available for a two- days workshop?” System Prompt (with employee data) + Schema / Function Calling (for structured output) Web API Availability business logic
16. § Frameworks § Pydantic § Instructor § Methodology § Schema with JSON Mode (not Function Calling) § SLM/LLM § Llama 3.3 70B on Cerebras (very fast) Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Technical implementation – Structured Output 16
17. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings PATTERN SEMANTIC GUARDING & ROUTING 17
18. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Semantics-based decisions for user interactions 18 Guarding (e.g. prompt injection) Routing (selecting correct target) “Lorem ipsum…?” Semantic Engine (Fine-tuned Language Model, Embedding Model) Target RAG 1 Target Structured Output & API Call Target … something else …
19. Guarding § Frameworks § llm-guard § HuggingFace Transformers § Model § deepset/deberta-v3-base- injection Routing § Frameworks § semantic-routing § Fastembed § Embedding model § BAAI/bge-small-en-v1.5 - local § Vector store § PostgreSql (pgvector) Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Technical implementation – Semantic Guarding & Routing 19
20. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings PATTERN / SOLUTION OBSERVABILITY 20
21. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Things can get… overwhelming 21
22. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings End-to-end tracing 22
23. § Methodology § Open Telemetry (OTel) § Frameworks § OTel Python packages § LogFire SDK § Tools § LogFire, LangFuse § Any OTel-enabled system Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Technical implementation - Observability 23
24. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings END-TO-END SOLUTION ILLUSTRATED 24
25. Semantic routing Semantic AI in Action Architektur-Patterns für LLMs & Embeddings "Talk to your systems"(for Availability info) 25 Web App / Watch App Speech-to-Text Internal Gateway (Python FastAPI) LLM / SLM Text-to-Speech Transcribe spoken text Transcribed text Check for experts availability with text Extract { experts, booking times } from text Structured JSON data (Function calling) Generate response with availability Response Response with experts availability 🔉 Speech-to-text for response Response audio Internal Business API (node.js – veeeery old) Query Availability API Availability When is CL…? CL will be…
26. Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Recap: Top Semantic AI patterns & solutions – in end-to-end software engineering 26 Local RAG Structured Output Semantic Guarding & Routing Insightful Observability 💡 Fun Fact: Large parts been built with AI-assisted Coding
27. Thank you! Christian Weyer https://thinktecture.com/christian-weyer christian.weyer@thinktecture.com 27
28. § Technology catalyst § AI-powered solutions § Pragmatic end-to-end architectures § Microsoft Regional Director § Microsoft MVP for AI § Google GDE for Web AI christian.weyer@thinktecture.com https://www.thinktecture.com Semantic AI in Action Architektur-Patterns für LLMs & Embeddings Christian Weyer Co-Founder & CTO @ Thinktecture AG
