  1. Using PDF in iOS Using PDF in iOS iOS All

    Stars 2 – Nov. 2016 Kaz Yoshikawa
  2. Using PDF in iOS Kaz Yoshikawa • Electricwoods LLC ୅ද

    / Digital Lynx Systems Inc. ෭୅ද • e-mail: kyoshikawa@electricwoods.com () • twitter: @codelynx • Working History • Adobe Systems (Tokyo) • Lionbridge (Tokyo) • Quark (Tokyo / Denver) • Hummingbird Communications (Mt. View, USA) • Fact International (Vancouver, Canada) • Perle Systems (Toronto, Canada), etc.
  3. Using PDF in iOS What is PDF?

  4. Using PDF in iOS PDF Reference sixth edition Adobe® Portable

    Document Format Version 1.7 November 2006 Adobe Systems Incorporated
  5. Using PDF in iOS Characteristics • Resolution Independent • Multiple

    Pages • Printing Quality • Color Models: RGB, CMYK • Protection
  6. Using PDF in iOS http://www.plda.cz/images/man/boxy-en.gif

  7. Using PDF in iOS Model

  8. Using PDF in iOS Outline entry Page Thumbnail image Annotations

    Bead Bead Thread Outline entry Content stream Thread Named destinations Article threads Interactive form Outline hierarchy Document catalog Page • • • • • • • • • • • • Page tree • • • • • • • • • • • •
  9. Using PDF in iOS Hello World %PDF-1.4 1 0 obj

    <</Type /Catalog /Pages 2 0 R>> endobj 2 0 obj <</Type /Pages /Kids [3 0 R] /Count 1>> endobj 3 0 obj<</Type /Page /Parent 2 0 R /Resources 4 0 R / MediaBox [0 0 500 800] /Contents 6 0 R>> endobj 4 0 obj<</Font <</F1 5 0 R>>>> endobj 5 0 obj<</Type /Font /Subtype /Type1 /BaseFont / Helvetica>> endobj 6 0 obj <</Length 44>> stream BT /F1 24 Tf 175 720 Td (Hello World!)Tj ET endstream endobj trailer <</Size 7/Root 1 0 R>> %%EOF Hello World!
  10. Using PDF in iOS PDF in Core Graphics

  11. Using PDF in iOS CGPDFDocument • init?(_ url: CFURL) •

    var numberOfPages: Int { get } • func page(at pageNumber: Int) -> CGPDFPage? • func unlockWithPassword(_ pw: UnsafePointer<Int8>) -> Bool
  12. Using PDF in iOS CGPDFPage • func getBoxRect(CGPDFBox) • var

    dictionary: CGPDFDictionaryRef? • var rotationAngle: Int32
  13. Using PDF in iOS CGContext • func drawPDFPage(_ page: CGPDFPage)

  14. Using PDF in iOS PDF Problems

  15. Using PDF in iOS PDFs are drawn
 upside down

  16. Using PDF in iOS YOUCANDOIT Sophie Houlden hasn’t spent a

    penny on tools to make her indie games – she just rolled up her sleeves and got on with it. Here she explains how it’s done… 18 | JULY 2010
  17. Using PDF in iOS BETA | GOING INDIE YOUCANDOIT Sophie

    Houlden hasn’t spent a penny on tools to make her indie games – she just rolled up her sleeves and got on with it. Here she explains how it’s done… 18 | JULY 2010 Core Graphics Coordinate Origin
  18. Using PDF in iOS BETA | GOING INDIE YOUCANDOIT Sophie

    Houlden hasn’t spent a penny on tools to make her indie games – she just rolled up her sleeves and got on with it. Here she explains how it’s done… 18 | JULY 2010 Origin Origin UIView coordinate
  19. Using PDF in iOS BETA | GOING INDIE YOUCANDOIT Sophie

    Houlden hasn’t spent a penny on tools to make her indie games – she just rolled up her sleeves and got on with it. Here she explains how it’s done… 18 | JULY 2010 Origin Origin ctx.translateBy(
 x: 0,
 y: rect.height)
  20. Using PDF in iOS 18 | JULY 2010 Origin Origin

    ctx.scaleBy(
 x: 1,
 y: -1)
  21. Using PDF in iOS BET A | GOING INDIE Y

    O U C A N D O I T S o p h i e H o u l d e n h a s n ’ t s p e n t a p e n n y o n t o o l s t o m a k e h e r i n d i e g a m e s – s h e j u s t r o l l e d u p h e r s l e e v e s a n d g o t o n w i t h i t . H e r e s h e e x p l a i n s h o w i t ’ s d o n e … 18 | JUL Y 2010 Origin Origin ctx.scaleBy(
 x: 1,
 y: -1)
  22. Using PDF in iOS BET A | GOING INDIE Y

    O U C A N D O I T S o p h i e H o u l d e n h a s n ’ t s p e n t a p e n n y o n t o o l s t o m a k e h e r i n d i e g a m e s – s h e j u s t r o l l e d u p h e r s l e e v e s a n d g o t o n w i t h i t . H e r e s h e e x p l a i n s h o w i t ’ s d o n e … 18 | JUL Y 2010 Origin Origin ctx.scaleBy(
 x: 1,
 y: -1)
  23. Using PDF in iOS BETA | GOING INDIE YOUCANDOIT Sophie

    Houlden hasn’t spent a penny on tools to make her indie games – she just rolled up her sleeves and got on with it. Here she explains how it’s done… 18 | JULY 2010 Origin Origin
  24. Using PDF in iOS BETA | GOING INDIE YOUCANDOIT Sophie

    Houlden hasn’t spent a penny on tools to make her indie games – she just rolled up her sleeves and got on with it. Here she explains how it’s done… 18 | JULY 2010 Origin Origin let scale = min(
 rect.width/box.width,
 rect.height/box.height)

 ctx.scaleBy(
 x: scale, y: scale)
  25. Using PDF in iOS BETA | GOING INDIE YOUCANDOIT Sophie

    Houlden hasn’t spent a penny on tools to make her indie games – she just rolled up her sleeves and got on with it. Here she explains how it’s done… 18 | JULY 2010 Origin Origin ctx.drawPDFPage(
 page)
  26. Using PDF in iOS Code in Swift let box =

    page.getBoxRect(.cropBox) let rect = self.view.bounds ctx.translateBy(x: 0, y: rect.height) ctx.scaleBy(x: 1, y: -1) ctx.scaleBy(x: rect.width / box.width, y: rect.height / box.height) ctx.drawPDFPage(page)
  27. Using PDF in iOS Problem Out of memory!?

  28. Using PDF in iOS Dealing with CGPDFDocument • CGPDFDocument is

    originally designed for Desktop • It cashes internally, hard to control releasing caches… • Releasing CGPDFDocument on memory warning may be too late… • Releasing CGPDFDocument once in a while
  29. Using PDF in iOS Problem
 Zooming PDF Page within UIScrollView

  30. Using PDF in iOS Blurring when zoom!?

  31. Using PDF in iOS contentScaleFactor • OK – Device size

    like small contents • NG – Magazine / Newspaper like large contents • eg. 2048x1536 12MB — (4x zoom) — 8192 x 6144 48MB ⚠
  32. Using PDF in iOS Dummy Content View UIView PDFPageView UIScrollView

    Dummy
 ContentView Transparent
  33. Using PDF in iOS PDF view draws based on dummy

    view coordinate Zoom → dummy view pdf view
  34. Using PDF in iOS Convert rect from
 content dummy

    view override func draw(_ layer: CALayer, in ctx: CGContext) { UIGraphicsPushContext(ctx) ctx.saveGState() let box = page.getBoxRect(.cropBox) let rect = self.contentView.convert(self.contentView.bounds, to: self) ctx.translateBy(x: rect.minX, y: rect.minY) ctx.translateBy(x: 0, y: rect.height) ctx.scaleBy(x: 1, y: -1) ctx.scaleBy(x: rect.width / box.width, y: rect.height / box.height) ctx.drawPDFPage(page) ctx.restoreGState() UIGraphicsPopContext() } →
  35. Using PDF in iOS UIScrollView delegate func viewForZooming(in scrollView: UIScrollView)

    -> UIView? { return contentView } func scrollViewDidZoom(_ scrollView: UIScrollView) { self.pdfPageView.setNeedsDisplay() } func scrollViewDidScroll(_ scrollView: UIScrollView) { self.pdfPageView.setNeedsDisplay() }
  36. Using PDF in iOS Use draw(layer, in context)
 not draw(_

    rect) class PDFPageView: UIView { override func draw(_ layer: CALayer, in ctx: CGContext) { UIGraphicsPushContext(ctx) // drawing UIGraphicsPopContext() } override func setNeedsDisplay() { super.setNeedsDisplay() self.layer.setNeedsDisplay() } }
  37. Using PDF in iOS Problem Drawing PDF is too slow

  38. Using PDF in iOS 2.pdf Split a large PDF into


 smaller multiple pages paper.pdf 1.pdf 3.pdf
  39. Using PDF in iOS Double layers Low resolution bitmap image

    (fast) Native PDF
 drawing (slow)
  40. Using PDF in iOS Dummy Content View UIView PDFPageView UIScrollView

    Dummy
 ContentView Low resolution bitmap image (fast) Native PDF
 drawing (slow) show/hide
  41. Using PDF in iOS Use fileURL
 avoid CGDataProvider • PDF

    file includes cross references • Cross references includes file offsets to objects • Using file offset to access objects faster than we think • Do not read whole file and feed to CGPDFDocument
  42. Using PDF in iOS Problem
 Bitmap looks different from rendered

    PDF
  43. Using PDF in iOS Drawn Image slides BETA | GOING

    INDIE YOUCANDOIT Sophie Houlden hasn’t spent a penny on tools to make her indie games – she just rolled up her sleeves and got on with it. Here she explains how it’s done… 18 | JULY 2010 BETA | GOING INDIE YOUCANDOIT Sophie Houlden hasn’t spent a penny on tools to make her indie games – she just rolled up her sleeves and got on with it. Here she explains how it’s done… 18 | JULY 2010 Bitmap drawing Native PDF drawing
  44. Using PDF in iOS Drawn Image slides BETA | GOING

    INDIE YOUCANDOIT Sophie Houlden hasn’t spent a penny on tools to make her indie games – she just rolled up her sleeves and got on with it. Here she explains how it’s done… 18 | JULY 2010 BETA | GOING INDIE YOUCANDOIT Sophie Houlden hasn’t spent a penny on tools to make her indie games – she just rolled up her sleeves and got on with it. Here she explains how it’s done… 18 | JULY 2010 Bitmap drawing Native PDF drawing
  45. Using PDF in iOS BETA | GOING INDIE YOUCANDOIT Sophie

    Houlden hasn’t spent a penny on tools to make her indie games – she just rolled up her sleeves and got on with it. Here she explains how it’s done… 18 | JULY 2010 Check origin!! page.getBoxRect(.crop) Origin * Box's minX, minY may not be zero
  46. Using PDF in iOS PDF in Depth

  47. Using PDF in iOS Useful Tools

  48. Using PDF in iOS PDF-Voyeur

  49. Using PDF in iOS Voyeur

  50. Using PDF in iOS PDF model

  51. Using PDF in iOS CGPDFObjectRef .dictionary CGPDFDictionaryRef OpaquePointer .array CGPDFArrayRef

    OpaquePointer .stream CGPDFContentStreamRef OpaquePointer .string CGPDFStringRef OpaquePointer .name UnsafePointer<Int8> UnsafePointer<Int8> .integer CGPDFInteger Int .real CGPDFReal CGFloat .boolean CGPDFBoolean UInt8 .null
  52. Using PDF in iOS Iterating CGPDFDictionary func PDFDictionary(_ dictionary: CGPDFDictionaryRef)

    -> [String: CGPDFObjectRef] {
 var context = [String: CGPDFObjectRef]()
 let contextRawPtr = UnsafeMutableRawPointer(&context) CGPDFDictionaryApplyFunction(dictionary, { (key, value, rawPtr) -> Void in if let key = String(validatingUTF8: key), let contextPtr = UnsafeMutablePointer<[String: CGPDFObjectRef]>( OpaquePointer(rawPtr)) { contextPtr.pointee[key] = value } }, contextRawPtr)
 return context } for (key, object) in PDFDictionary(catalog).enumerated() { print("\(key), \(object)") }
  53. Using PDF in iOS CGPDFObjectGetType WBSWBMVF$(1%'0CKFDU3FGǘ
 TXJUDI$(1%'0CKFDU(FU5ZQF WBMVF \ DBTFBSSBZ

     WBSPCKFDU$(1%'"SSBZ3FG OJM  $(1%'0CKFDU(FU7BMVF WBMVF BSSBZ PCKFDU  DBTFEJDUJPOBSZ  WBSPCKFDU$(1%'%JDUJPOBSZ3FG OJM  $(1%'0CKFDU(FU7BMVF WBMVF EJDUJPOBSZ PCKFDU  DBTFTUSFBN  DBTFTUSJOH  DBTFOBNF   DBTFJOUFHFS  DBTFSFBM   DBTFCPPMFBO  DBTFOVMMCSFBL ^
  54. Using PDF in iOS PDFScanner • Low level API •

    Scanner knows how to parse page content • PDF's operator
  55. Using PDF in iOS Problem
 Like to Search Text in

    PDF
  56. Using PDF in iOS Page –> Font MediaBox Resources Page

    Contents … Font … Tc1 Tc2 … subtype … …
  57. Using PDF in iOS Font Contents

  58. Using PDF in iOS Font Types Font Type Entries Type

    1 Name, BaseFont, FirstChar, LastChar, Widths, FontDescriptor, Encoding, ToUnicode, ... True Type Name, BaseFont, FirstChar, LastChar, Widths, FontDescriptor, Encoding, ToUnicode, … Type 3 Name, FontBBox, FontMatrix, CharProcs, FisrChar, LastChar, Widths, FontDescriptor, ToUnicode … Type 0 Name, BaseFont, CIDSystemInfo, FontDescriptor, DW, DW2, CIDToGIDMap, ❌ ToUnicode
  59. Using PDF in iOS A Page knows how to draw

    MediaBox Resources Page Contents Font Tc2 dictionary array stream Drawing operators
  60. Using PDF in iOS Operators BT /F1 24 Tf 175

    720 Td (Hello World!)Tj ET Begin Text End Text Font Location Draw Text
  61. Using PDF in iOS Japanese Text BT /C2_0 1 Tf

    0 Tc 175 720 Td <30533093306B3061306F> Tj ET Font Location Draw Text
  62. Using PDF in iOS Decoding Method Case Decoding Method Has

    `ToUnicode` entry Parse `ToUnicode` entry No `ToUnicode` entry
 but WinAnsiEncoding Predefined Identity-H, Identity-V encoding
 No `ToUnicode` entry Using external CMap
  63. Using PDF in iOS Parsing `ToUnicode` entry

  64. Using PDF in iOS Adobe CMap and CIDFont Files Specification

    Version 1.0 11 June 1993 Adobe Developer Support Adobe Systems Incorporated ® ® ®
  65. Using PDF in iOS ToUnicode = CMap %!PS-Adobe-3.0 Resource-CMap /CIDInit

    /ProcSet findresource begin 12 dict begin begincmap /CIDSystemInfo 3 dict dup begin /Registry (Adobe) def /Ordering (Japan1) def /Supplement 6 def end def /CMapName /Adobe-Japan1-6 def /CMapVersion 1.005 def /CMapType 1 def /XUID [1 10 25614] def /WMode 0 def /CIDCount 23058 def 1 begincodespacerange <0000> <5AFF> endcodespacerange 91 begincidrange <0000> <00ff> 0 <0100> <01ff> 256 <0200> <02ff> 512 <0300> <03ff> 768 <0400> <04ff> 1024 … <5600> <56ff> 22016 <5700> <57ff> 22272 <5800> <58ff> 22528 <5900> <59ff> 22784 <5a00> <5a11> 23040 endcidrange endcmap CMapName currentdict
 /CMap defineresource pop end end ←Horizontal/Vertical ←code mapping
  66. Using PDF in iOS Using external Cmap


  67. Using PDF in iOS Adobe Japan 1-4 Identity-V No ToUnicode

    entry
  68. Using PDF in iOS

  69. Using PDF in iOS CMap: Adobe Japan 1-6

  70. Using PDF in iOS

  71. Using PDF in iOS

  72. Using PDF in iOS Problem
 Table of contents !?

  73. Using PDF in iOS Outline entry Page Thumbnail image Annotations

    Bead Bead Thread Outline entry Content stream Thread Named destinations Article threads Interactive form Outline hierarchy Document catalog Page • • • • • • • • • • • • Page tree • • • • • • • • • • • •
  74. Using PDF in iOS Left Intentionally Blank

  75. Using PDF in iOS Problem
 Tapping on Hyperlinks

  76. Using PDF in iOS Left Intentionally Blank

  77. Using PDF in iOS ZPDF

  78. Using PDF in iOS ZPDF • Tentative name • Swift

    base PDF library • Parsing PDF • Extracting text and glyph positions • Will be open source when ready • sorry — this could take years
  79. Using PDF in iOS

  80. Using PDF in iOS Text Edit InDesign MS Word

  81. Using PDF in iOS One more thing

  82. Using PDF in iOS Tips & Tricks Animation with PDF

  83. Using PDF in iOS Animation with PDF 0s 4s 6s

  84. Using PDF in iOS Multiple Page PDF page 1 page

    2 Timesheet
  85. Using PDF in iOS

  86. Using PDF in iOS

  87. Using PDF in iOS

  88. Using PDF in iOS

  89. Using PDF in iOS

  90. Using PDF in iOS Wrap Up

  91. Using PDF in iOS Wrap Up • Basic PDF format

    structure • Core Graphics PDF API • Fixing drawing upside down • Fixing runout of memory • Zooming PDF within UIScrollView
  92. Using PDF in iOS Wrap Up • Dealing with too

    slow drawing PDF page • Fixing drawing origin • Voyeur • Extracting text from PDF • ZKIT • Animation with PDF
  93. Using PDF in iOS Last Words • Likely it's hard

    to remember that many tricks and knowledges • What you have to remember is … ask "Kaz" kyoshikawa@electricwoods.com
  94. Using PDF in iOS Thanks
