Actions Builderによるアクションのビジュアルプログラミング
Search
Daisuke Kobayashi
October 17, 2020
Programming
0
140
Actions Builderによるアクションのビジュアルプログラミング
GDG DevFest 2020 でお話した内容の資料です。
デモンストレーションとセットですので、Youtubeの動画も合わせてご覧下さい。
Daisuke Kobayashi
October 17, 2020
Tweet
Share
More Decks by Daisuke Kobayashi
See All by Daisuke Kobayashi
Google アシスタント アクション運用の知見あれこれ
covayashi
1
740
Transactions API
covayashi
6
2.9k
Other Decks in Programming
See All in Programming
git worktree × Claude Code × MCP ~生成AI時代の並列開発フロー~
hisuzuya
1
530
AI時代のソフトウェア開発を考える(2025/07版) / Agentic Software Engineering Findy 2025-07 Edition
twada
PRO
53
14k
Google Agent Development Kit でLINE Botを作ってみた
ymd65536
2
220
新メンバーも今日から大活躍!SREが支えるスケールし続ける組織のオンボーディング
honmarkhunt
3
4.3k
Is Xcode slowly dying out in 2025?
uetyo
1
250
PostgreSQLのRow Level SecurityをPHPのORMで扱う Eloquent vs Doctrine #phpcon #track2
77web
2
500
第9回 情シス転職ミートアップ 株式会社IVRy(アイブリー)の紹介
ivry_presentationmaterials
1
260
生成AIコーディングとの向き合い方、AIと共創するという考え方 / How to deal with generative AI coding and the concept of co-creating with AI
seike460
PRO
1
350
コードの90%をAIが書く世界で何が待っているのか / What awaits us in a world where 90% of the code is written by AI
rkaga
50
32k
地方に住むエンジニアの残酷な現実とキャリア論
ichimichi
5
1.5k
Rubyでやりたい駆動開発 / Ruby driven development
chobishiba
1
600
dbt民主化とLLMによる開発ブースト ~ AI Readyな分析サイクルを目指して ~
yoshyum
3
550
Featured
See All Featured
Stop Working from a Prison Cell
hatefulcrawdad
270
20k
Rebuilding a faster, lazier Slack
samanthasiow
82
9.1k
Mobile First: as difficult as doing things right
swwweet
223
9.7k
A Modern Web Designer's Workflow
chriscoyier
694
190k
Become a Pro
speakerdeck
PRO
28
5.4k
Bootstrapping a Software Product
garrettdimon
PRO
307
110k
How To Stay Up To Date on Web Technology
chriscoyier
790
250k
Fight the Zombie Pattern Library - RWD Summit 2016
marcelosomers
233
17k
CoffeeScript is Beautiful & I Never Want to Write Plain JavaScript Again
sstephenson
161
15k
[RailsConf 2023 Opening Keynote] The Magic of Rails
eileencodes
29
9.5k
Into the Great Unknown - MozCon
thekraken
39
1.9k
Statistics for Hackers
jakevdp
799
220k
Transcript
Actions Builderによる ビジュアルプログラミング
Daisuke Kobayashi Programmer Gurunavi 絵を描いたり ゲーム作ったり webサイト作ったり twitter.com/0rga 0rga.org
None
1.Actions Builder について 2.Actions Builder の解説とデモ 3.Actions SDK について(軽く) お話する事
Actions Builderについて
2020/6/17に Actions Builderが リリースされました
Actions Builderとは 概要 - Actions Builderとは、Actionsコンソールで直接開発、テ スト、およびデプロイができる、WebベースのIDE - グラフィカルインターフェイスを使用しており、会話の流れを 視覚化できる
- 自然言語理解(NLU)トレーニングデータの管理
Devices Dialogflow Google Assistant Actions Before
Devices Actions Builder Google Assistant Actions After
設計方針の大きな違い Dialogflow Actions Builder 会話の流れを 構築していく 会話の場面を作り 繋げていく
新しい概念 Scenes の登場 会話の場面(Scenes)を繋げて、会話を流れを作る Scenes A Scenes B Scenes C
Scenes D
Scenesのライフサイクルとループ処理 Scenes A On enter Conditions Slot filling Prompts Intent
Transition Scenes B
Scenesのライフサイクルとループ処理 Scenes A Conditions Slot filling Prompts Intent Transition Scenes
B - Scenesがアクティブ化されたときに1回だけ実行され るステップ - Webhookをトリガーするか、シーンの1回限りのセッ トアップを行うようにユーザーに促すことができる On enter
Scenesのライフサイクルとループ処理 Scenes A On enter Slot filling Prompts Intent Transition
Scenes B Conditions - 次のステップに進める前に、パラメータが特定の値を 持っているかどうかに基づいて、ロジックを実行でき るステップ - ロジック次第では、別のシーンに移動したり、会話を 終了できたりする
Scenesのライフサイクルとループ処理 Scenes A On enter Prompts Intent Transition Scenes B
Conditions - ユーザーの入力を収集するためのステップ - Slotを埋めようと、Scenesのライフサイクルが動く Slot filling
Scenesのライフサイクルとループ処理 Scenes A On enter Intent Transition Scenes B Conditions
Slot filling - これまでのステップで集めたキューを元に、ユーザに 発話するステップ Prompts
Scenesのライフサイクルとループ処理 Scenes A On enter Slot filling Prompts Transition Conditions
Intent - Scenesのループを終了するための遷移基準を、定義で きるステップ - 遷移しない場合、ループは Conditions に戻る Scenes B
Actions Builder の 解説とデモ
デモで作るもの 仕様 - じゃんけんが出来るアクション - アクション名は「じゃんけんマシーン」 - ユーザが止めるまで、じゃんけんは続く - じゃんけんマシーンがグーチョキパーの何を出すかはランダム
VUI 設計 こんにちは、じゃんけんマ シーンです。 じゃんけんをしますか? じゃーんけーん はい グー 私はチョキ、あなたはグー。 あなたの勝ち!
もう一回じゃんけんしますか? じゃーんけーん… はい OK Google じゃんけん マシーンにつないで : :
Scenes 設計 じゃんけんをす るかどうか尋ね るシーン じゃんけんをす るシーン もう一度、 じゃんけんをす るかどうか尋ね
るシーン 「こんにちは、じゃんけん マシーンです」 会話終了 YES NO
下準備1 プロジェクトの作成
下準備2 アクション名の設定
こんにちは、じゃんけん マシーンです。 これを作る
Main invocation 概要 - ユーザーがアクションとの会話を開始するためのエントリーポ イント - ユーザーからの 「OK Google,
〇〇◦につないで」 と言うような invocation(呼び出し)に反応する部分
Main invocationの設定
こんにちは、じゃんけんマ シーンです。 じゃんけんをしますか? これを作る
Scenesの作成
Scenesの設定
じゃんけんをしますか? はい これを作る
Intents 概要 - アクションが理解できる、ユーザーの入力を定義できる - System intent と Custom intent
がある - Training phrases - ユーザの入力の定義の例の事 - Assistant NLU(自然言語理解)エンジンは、 Training Phrasesを拡張して、 他の類似したフレーズを含めることができる
Custom Intentの作成
ScenesにCustom Intent handlingを設定
はい じゃーんけーん グー これを作る
Custom Intent handlingで別Scenesに
Types 概要 - ざっくり言うと、Intentsの複数版。 - ユーザ入力の同義語を定義し判別できる。
// Custom Intent のイメージ { yes: ['はい', 'OK', 'YES', 'もちろん',
'オッケー', ... ] } // Types のイメージ { meat : { beef: ['牛肉', 'ビーフ', 'ステーキ', ... ], pork: ['豚肉', 'ポーク', 'とんかつ', ... ], chicken: ['鶏肉', 'チキン', 'から揚げ', ... ], } }
Typesの作成
Typesの設定
Slot fillingの設定
Slot fillingの設定
Conditionの設定
グー 私はチョキ、 あなたはグー。 あなたの勝ち! これを作る
Conditionの条件分岐の作成
私はチョキ、 あなたはグー。 あなたの勝ち! もう一回 じゃんけんしますか? これを作る
Conditionから別Scenesに
Conditionから別Scenesに
Scenesの設定
ScenesにCustom Intent handlingを設定
私はチョキ、 あなたはグー。 あなたの勝ち! ラ ン ダ ム に し た
い
Webhook Actions SDK Node.js Fulfillment Library
const { conversation } = require('@assistant/conversation'); const functions = require('firebase-functions');
const app = conversation({debug: true}); const jankenTypeName = { gu: 'グー', tyoki: 'チョキ', pa: 'パー' }; const judgeMap = { gu: { gu: 'あいこ!', tyoki: 'あなたの勝ち!', pa: 'あなたの負け!' }, tyoki: { gu: 'あなたの負け!', tyoki: 'あいこ!', pa: 'あなたの勝ち!' }, pa: { gu: 'あなたの勝ち!', tyoki: 'あなたの負け!', pa: 'あいこ!' } }; 新しいライブラリに
app.handle('janken', conv => { const actionChoice = ['gu', 'pa', 'tyoki'][Math.floor(Math.random()
* 3)]; const message = judgeMap[conv.session.params.chosenJankenType][actionChoice]; conv.add(`私は${jankenTypeName[actionChoice]}、あなたは ${jankenTypeName[conv.session.params.chosenJankenType]}、${message}`); }); exports.ActionsOnGoogleFulfillment = functions.https.onRequest(app); intent から handle に ask から add に
Actions SDK について
Actions SDK ファイルとコマンドラインの利点 - 手元の環境で作業が可能 - ファイルのバージョン管理が可能 - gactions コマンドで
pull / push が可能 - 独自のツールを適用可能
今回作ったデモを pull してきたもの
// Custom Intentでつくった「yes.yaml」 trainingPhrases: - そうだよ - そうです - もちろん
- それで - よろしく - おねがい - "YES" - OK - うん - はい
// Scenesでつくった「start.yaml」 intentEvents: - intent: "yes" transitionToScene: janken - handler:
staticPrompt: candidates: - promptResponse: firstSimple: variants: - speech: では、さようなら intent: "no" transitionToScene: actions.scene.END_CONVERSATION onEnter: staticPrompt: candidates: - promptResponse: firstSimple: variants: - speech: じゃんけんをしますか?
1.Actions Builderのグラフィカルインターフェ イスで、よりノンコーティングに。 2.Actions SDKで、より自由に。 まとめ
Thank you!
