Serverless in Production with CI/CD and End-to-End Tracing

Serverless in Production with CI/CD and End-to-End Tracing

London JavaScript Community, London, July 11th, 2017

In this session I will share some of the best practices to use serverless applications in production on AWS, using AWS CodeStar to set up your entire continuous integration and delivery toolchain in minutes, allowing you to start releasing code faster and supporting agile development. As your distributed application scales in size and complexity, we’ll see how to use AWS X-Ray, either in development or in production, to introduce end-to-end tracing capabilities and help identify performance bottlenecks, edge case errors, and other hard to detect issues .

Danilo Poccia

July 11, 2017
Tweet

More Decks by Danilo Poccia

Other Decks in Programming

Transcript

  1. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
    Danilo Poccia, Technical Evangelist
    @danilop
    Serverless in Production
    With CI/CD and End-to-End Tracing

    View Slide

  2. What is Serverless?

    View Slide

  3. Operations and management Scaling
    Provisioning and utilization Availability and fault tolerance
    Owning servers means dealing with ...

    View Slide

  4. AWS Lambda: Run code in response to events
    FUNCTION SERVICES (ANYTHING)
    Changes in
    data state
    Requests to
    endpoints
    Changes in
    resource state
    Node
    Python
    Java
    C#
    EVENT SOURCE

    View Slide

  5. No servers to provision
    or manage
    Scales with usage
    Never pay for idle Availability and fault
    tolerance built in
    Benefits of Lambda and serverless compute

    View Slide

  6. Example Serverless Application Architecture

    View Slide

  7. Web Applications and Backends

    View Slide

  8. Data Processing

    View Slide

  9. Data Processing

    View Slide

  10. Serverless IoT with AWS Lambda at iRobot

    View Slide

  11. AWS
    Lambda
    Amazon
    CloudFront
    Amazon
    S3
    Amazon
    DynamoDB
    Amazon
    Redshift
    Amazon
    Route 53 Amazon VPC
    Amazon
    CloudWatch
    AWS
    CloudFormation
    AWS
    CloudTrail
    AWS
    Config AWS IAM
    AWS KMS
    AWS WAF
    Amazon Cognito Amazon
    SNS
    Amazon API
    Gateway
    Amazon
    SQS
    Amazon
    Elasticsearch Service
    Amazon
    Kinesis
    Amazon
    QuickSight
    AWS IoT
    How iRobot leverages AWS

    View Slide

  12. API Gateway
    App requests
    over HTTPS
    CRUD
    operations

    View Slide

  13. IoT
    MQTT
    CRUD
    operations

    View Slide

  14. IoT
    MQTT
    MQTT
    Presigned
    URL
    Staging
    bucket

    View Slide

  15. Infrastructure as Code

    View Slide

  16. AWS CloudFormation brings:
    • Infrastructure as code
    • Easy to provision and manage a collection of related AWS resources
    • Input .yaml file and output provisioned AWS resources
    • Optimized for infrastructure
    AWS SAM:
    • CloudFormation extension optimized for serverless
    • New serverless resources: functions, APIs, and tables
    • Supports anything CloudFormation supports
    • Open specification (Apache 2.0)
    AWS Serverless Application Model (AWS SAM)

    View Slide

  17. AWSTemplateFormatVersion: '2010-09-09'
    Resources:
    GetHtmlFunctionGetHtmlPermissionProd:
    Type: AWS::Lambda::Permission
    Properties:
    Action: lambda:invokeFunction
    Principal: apigateway.amazonaws.com
    FunctionName:
    Ref: GetHtmlFunction
    SourceArn:
    Fn::Sub: arn:aws:execute-api:${AWS::Region}:${AWS::AccountId}:${ServerlessRestApi}/Prod/ANY/*
    ServerlessRestApiProdStage:
    Type: AWS::ApiGateway::Stage
    Properties:
    DeploymentId:
    Ref: ServerlessRestApiDeployment
    RestApiId:
    Ref: ServerlessRestApi
    StageName: Prod
    ListTable:
    Type: AWS::DynamoDB::Table
    Properties:
    ProvisionedThroughput:
    WriteCapacityUnits: 5
    ReadCapacityUnits: 5
    AttributeDefinitions:
    - AttributeName: id
    AttributeType: S
    KeySchema:
    - KeyType: HASH
    AttributeName: id
    GetHtmlFunction:
    Type: AWS::Lambda::Function
    Properties:
    Handler: index.gethtml
    Code:
    S3Bucket: flourish-demo-bucket
    S3Key: todo_list.zip
    Role:
    Fn::GetAtt:
    - GetHtmlFunctionRole
    - Arn
    Runtime: nodejs4.3
    GetHtmlFunctionRole:
    Type: AWS::IAM::Role
    Properties:
    ManagedPolicyArns:
    - arn:aws:iam::aws:policy/AmazonDynamoDBReadOnlyAccess
    - arn:aws:iam::aws:policy/service-role/AWSLambdaBasicExecutionRole
    AssumeRolePolicyDocument:
    Version: '2012-10-17'
    Statement:
    - Action:
    - sts:AssumeRole
    Effect: Allow
    Principal:
    Service:
    - lambda.amazonaws.com
    ServerlessRestApiDeployment:
    Type: AWS::ApiGateway::Deployment
    Properties:
    RestApiId:
    Ref: ServerlessRestApi
    Description: 'RestApi deployment id: 127e3fb91142ab1ddc5f5446adb094442581a90d'
    StageName: Stage
    GetHtmlFunctionGetHtmlPermissionTest:
    Type: AWS::Lambda::Permission
    Properties:
    Action: lambda:invokeFunction
    Principal: apigateway.amazonaws.com
    FunctionName:
    Ref: GetHtmlFunction
    SourceArn:
    Fn::Sub: arn:aws:execute-api:${AWS::Region}:${AWS::AccountId}:${ServerlessRestApi}/*/ANY/*
    ServerlessRestApi:
    Type: AWS::ApiGateway::RestApi
    Properties:
    Body:
    info:
    version: '1.0'
    title:
    Ref: AWS::StackName
    paths:
    "/{proxy+}":
    x-amazon-apigateway-any-method:
    x-amazon-apigateway-integration:
    httpMethod: ANY
    type: aws_proxy
    uri:
    Fn::Sub: arn:aws:apigateway:${AWS::Region}:lambda:path/2015-03-
    31/functions/${GetHtmlFunction.Arn}/invocations
    responses: {}
    swagger: '2.0'
    CF template example – API triggering Lambda
    AWSTemplateFormatVersion: '2010-09-09’
    Transform: AWS::Serverless-2016-10-31
    Resources:
    GetHtmlFunction:
    Type: AWS::Serverless::Function
    Properties:
    CodeUri: s3://flourish-demo-bucket/todo_list.zip
    Handler: index.gethtml
    Runtime: nodejs4.3
    Policies: AmazonDynamoDBReadOnlyAccess
    Events:
    GetHtml:
    Type: Api
    Properties:
    Path: /{proxy+}
    Method: ANY
    ListTable:
    Type: AWS::Serverless::SimpleTable
    AWS SAM example – API triggering Lambda
    AWS SAM: Less complexity, more power

    View Slide

  18. What is Continuous Integration?

    View Slide

  19. What is Continuous Integration?
    Automation Component + Cultural Component

    View Slide

  20. Continuous Integration Benefits
    Improve Developer
    Productivity
    Find and Address
    Bugs Quicker
    Deliver Updates
    Faster

    View Slide

  21. Set Up a Serverless CI/CD Pipeline on AWS
    AWS
    CodeCommit
    AWS
    CodeBuild
    AWS
    CodePipeline
    AWS
    CloudFormation
    Amazon
    S3
    GitHub
    AWS
    SAM
    Commit Build Deploy
    + Tests (CodeBuild or other services)
    + Manuals Approval (CodePipeline)
    + Multiple Environments (CodePipeline + CloudFormation)

    View Slide

  22. How to make it easier?

    View Slide

  23. AWS CodeStar New!

    View Slide

  24. New!
    AWS X-Ray

    View Slide

  25. Time for a demo J

    View Slide

  26. Build a Serverless Web Application
    https://aws.amazon.com/getting-started/serverless-web-app/

    View Slide

  27. JavaScript + AWS Mobile Hub
    Ionic + AWS MobileHub Starter Project
    https://github.com/ionic-team/ionic2-starter-aws
    Enhanced JavaScript development with AWS Mobile Hub
    https://aws.amazon.com/blogs/mobile/enhanced-javascript-development-with-aws-mobile-hub/
    Deploy a React App to S3 and CloudFront with AWS Mobile Hub
    https://aws.amazon.com/blogs/mobile/deploy-a-react-app-to-s3-and-cloudfront-with-aws-mobile-hub/
    Integrate the AWS SDK for JavaScript into a React App
    https://aws.amazon.com/blogs/mobile/integrate-the-aws-sdk-for-javascript-into-a-react-app/

    View Slide

  28. Conclusion
    Lambda is a fundamental
    component of modern
    application architectures
    It has a place in everything
    from data processing to
    simple web apps

    View Slide

  29. Thank you!
    @danilop

    View Slide
