Adapting your app for Android 11 privacy changes

Security and Privacy have always been core to how the Android Framework is designed, and with every new release, a significant focus is being placed on improving the security and privacy of the Android platform. This presentation gives an overview of the most important updates on Android 11, which are aimed at making the platform more secure and the apps we develop more user privacy-centric. Will discuss how one permission, permissions auto reset, and changes to background location access drive towards this goal.

Transcript

1. GDG Location Adapting your apps for Android 11 privacy changes @jessica_sumyat
2. GDG Location Privacy changes
3. GDG Location Android 11: Brings greater protection to user data Data access auditing Permission changes Package visibility Foreground service types Scoped storage
4. GDG Location Permission changes
5. GDG Location
6. GDG Location
7. GDG Location
8. GDG Location
9. GDG Location Do I need to change anything to work with one-time permissions? Nothing! * * if you’re currently following permission best practices
10. GDG Location when { checkSelfPermission(...) == GRANTED -> { // Perform action. } shouldShowRequestPermissionRationale(..) -> { // Show in-context rationale. } else -> { requestPermissions(...) } }
11. GDG Location when { checkSelfPermission(...) == GRANTED -> { // Perform action. } shouldShowRequestPermissionRationale(..) -> { // Show in-context rationale. } else -> { requestPermissions(...) } }
12. GDG Location override fun onRequestPermissionsResult(...) { when (requestCode) { MY_PERMISSION_REQUEST_CODE -> { if ((grantResults[0] == PERMISSION_GRANTED)) { // Permission is granted. Perform action. } else { // Explain to user: feature isn't // available. } return } } }
13. GDG Location Location Permission is special it’s split in Foreground and Background access Foreground access (App is visible or running a Foreground Service with Location type) • ACCESS_COARSE_LOCATION • ACCESS_FINE_LOCATION (accurate location) Background access (i.e Geofence or WorkManager/AlarmManager in BG) • ACCESS_BACKGROUND_LOCATION
14. GDG Location Foreground location access ACCESS_COARSE_LOCATION or ACCESS_FINE_LOCATION •On all versions, this requests foreground access. •On pre-Android 10, background access is implied. ActivityCompat.requestPermissions( /* Activity */ this, /* Request BG alone */ arrayOf(ACCESS_COARSE_LOCATION), /* RequestCode */ 100 )
15. GDG Location Page has a limit similar to Deny Request ACCESS_BACKGROUND_LOCATIO N At some point ACCESS_COARSE_LOCATIO N My App Target API level 'R' If show rational is true: IN-CONTEXT UI (you define it) Background location access request incrementally only after Foreground has been granted
16. GDG Location Redirection to this screen is limited ACCESS_BACKGROUND_LOCATION ACCESS_COARSE_LOCATION My App Target API level 29 or lower All at once location request not possible after targeting Android 11
17. GDG Location Target API level 'R' Auto-reset permissions
18. GDG Location Target API level 'R' Auto-reset permissions Provide family safety Sync data Smart device connectivity app Paired to companion devices Settings.ACTION_APPLICATION_DETAILS_SETTINGS
19. GDG Location Data access auditing or: Why did my app use that data?
20. GDG Location Give users transparency to data access.
21. GDG Location Location Contacts Microphone Code Private data provided to app Unexpected private data use Dependencies Orphan code
22. GDG Location Callbacks on data access Feature tagging New APIs
23. GDG Location Location Contacts Microphone Code (e.g. == Stack traces) Private data Provided to app What code uses privata data?
24. GDG Location Code (e.g. == Stack traces) Private data Provided to app API provided mapping code <- private data What code uses privata data? Location Contacts Microphone
25. GDG Location Setting up data access operation callback val appOpsManager = getSystemService(AppOpsManager::class.java) ... appOpsManager.setOnOpNotedCallback(mainExecutor, appOpsCallback) Synchronous access Asynchronous access ...
26. GDG Location What feature uses private data? Dev provided mapping code <-> feature API provided mapping feature <- data access Navigation Explore Nearby shopping Find friends Default Location Contacts Microphone
27. GDG Location What feature uses private data? Dev provided mapping code <-> feature API provided mapping feature <- data access Navigation Explore shopping Find friends Default Location Contacts Microphone
28. GDG Location Using attribution context override fun onCreate(savedInstanceState: Bundle?) { attributionContext = createAttributionContext("find_friends") } ...argument for API calls val appOpsCallback = object : AppOpsManager.OnOpNotedCallback() { override fun onNoted(syncNotedAppOp: SyncNotedAppOp) { ... syncNotedAppOp.attributionTag } } “find_friends”
29. GDG Location New Foreground Service Types
30. GDG Location Companion device Media Projection Location Foreground Service Types Android 10 • Introduced the concept of types Sync Media Player Phone Call c Enforced to ensure accountability for access
31. GDG Location Foreground Service Types Android 11 Target API level 'R' <manifest> ... <service ... android:foregroundServiceType="camera" /> </manifest>
32. GDG Location Foreground Service Types Android 11 Target API level 'R' <manifest> ... <service ... android:foregroundServiceType="camera|microphone" /> </manifest>
33. GDG Location Foreground Service Types
34. GDG Location Package Visibility
35. GDG Location Seeing all installed apps packageManager.getInstalledPackages(0)
36. GDG Location Package visibility No change required in most cases! Target API level 'R' interact query PackageManager your app other apps
37. GDG Location Unaffected common interactions getPackageInfo(getPackageName(), 0) your app Target API level 'R'
38. GDG Location Unaffected common interactions getInstalledPackages(0) your app system pkgs 'R' Target API level
39. GDG Location Unaffected common interactions your app 'R' IMAGE_CAPTURE Implicit intent Target API level
40. GDG Location Unaffected common interactions your app 'R' Target API level results another app
41. GDG Location Default behavior getPackageInfo("another.app", 0) NameNotFound Exception 'R' Target API level
42. GDG Location Query and interact with specific apps Declare package names in <queries> element of manifest to ‘see’ specific apps. <manifest> <queries> <package android:name="com.example.store" /> <package android:name="com.example.service" /> ... </queries> ... </manifest>
43. GDG Location Query and interact with apps based on intent filters Declare intents in <queries> element to ‘see’ apps that handle certain intents. <manifest> <queries> <intent> <action android:name="android.intent.action.SEND" /> <data android:mimeType="image/jpeg" /> </intent> </queries> ... </manifest>
44. GDG Location Interacting with all apps • Shouldn’t be necessary for most apps. • Available “Normal” permission that allows querying and interacting with all installed apps. <uses-permission android:name="android.permission.QUERY_ALL_PACKAGES"> Look for Google Play to provide upcoming guidelines for apps that need this permission. Let us know your use cases.
45. GDG Location Control how your intent is handled val url = "https://news.google.com" val intent = Intent(ACTION_VIEW, Uri.parse(url).apply { flags = FLAG_ACTIVITY_NEW_TASK } startActivity(intent)
46. GDG Location Control how your intent is handled val url = "https://news.google.com" val intent = Intent(ACTION_VIEW, Uri.parse(url).apply { flags = FLAG_ACTIVITY_NEW_TASK or FLAG_ACTIVITY_REQUIRE_NON_BROWSER } startActivity(intent) ActivityNotFoundException if no default native apps …. app can handle content on its own
47. GDG Location Testing package visibility adb shell pm log-visibility --enable your-package-name Enable package filtering (default on for debuggable apps) I/AppsFilter: interaction: PackageSetting{7654321 \ com.example.myapp/12345} -> PackageSetting{...} BLOCKED Sample logcat output
48. GDG Location Scoped Storage
49. GDG Location Introduced with Android 10 Separate storage into collections and limit broad access to shared storage •Better attribution •Protect app data •Protect user data Scoped Storage Shared storage Documents + other files Only accessible to apps via system picker Photo/Video/Music Audio Gated behind Files & Media Permission
50. GDG Location •Unrestricted media and downloads contributions •Only media collections can be read with the storage permission •Location metadata requires permission •System picker for all other file types •Reading or writing outside of collections requires the system picker Enforced by target SDK but with an option to opt out Scoped Storage in Android 10
51. GDG Location •Storage renamed to Files & Media •With targetSdkVersion=R ◦ WRITE_EXTERNAL_STORAGE and WRITE_MEDIA_STORAGE do not grant any additional write access. Storage permissions changes
52. GDG Location Media store API and bulk edit access •Improved consent UI for bulk edits •Supports operations ◦ Write access ◦ Designate media as “favorites” ◦ Put media into trash ◦ Delete access
53. GDG Location Media store API and bulk edit access val urisToModify = listOf(...some set of content:// URIs ...) val editPendingIntent = MediaStore.createWriteRequest(contentResolver, urisToModify) startIntentSenderForResult( editPendingIntent.intentSender, EDIT_REQUEST_CODE...) override fun onActivityResult(...) { ... when (requestCode) { EDIT_REQUEST_CODE -> if (resultCode == Activity.RESULT_OK) { ...Request granted...edit media }
54. GDG Location File access restrictions ACTION_OPEN_DOCUMENT_TREE root Android data obb Download
55. GDG Location File access restrictions ACTION_OPEN_DOCUMENT root Android data obb Download
56. GDG Location Enable native libraries and Java file APIs • Android 10 locked down file path access • All apps are recommended to use MediaStore • File path access is really a proxy into MediaStore • MediaStore enforcements maintained Direct file path access for media
57. GDG Location Other Important Changes
58. GDG Location Fine-grained Phone permissions call states ringing? idle? phone numbers generic info private READ_PHONE_STATE
59. GDG Location Fine-grained Phone permissions call states ringing? idle? phone numbers getLine1Number() getMsisdn() 'R' Target API level READ_PHONE_STATE READ_PHONE_NUMBE RS
60. GDG Location Fine-grained Phone permissions 'R' Target API level <!-- Request on Pre-Android 11 --> <uses-permission android:maxSdkVersion="29" android:name="android.permission.READ_PHONE_STATE" /> <!-- Request on Android 11+ --> <uses-permission android:name="android.permission.READ_PHONE_NUMBERS" />
61. GDG Location Non-system apps targeting Android 11: • Can no longer access MAC address for network interfaces ◦ NetworkInterface#getHardwareAddress() returns null for every network interface ◦ getifaddrs() response no longer includes MAC address information ◦ RTM_GETLINK NetLink requests are blocked • Can only list network interfaces that have an IP address set ◦ NetworkInterface#getNetworkInterfaces() and getifaddrs() return only network interfaces that have an IPv4 address • Can no longer use bind() on NETLINK_ROUTE sockets ◦ Supported alternative: use ConnectivityManager instead MAC Address Restrictions 'R' Target API level
62. GDG Location Wrap up
63. GDG Location Thank you!
