Vulcain: HTTP/2 Server Push
 and the rise of client-driven REST APIs

Over the years, several formats have been created to fix performance bottlenecks of web APIs: the n+1 problem, over fetching, under fetching…
The current hipster solution for these problems is to replace the conceptual model of HTTP (resource-oriented), by the one of GraphQL.

It’s a smart network hack for HTTP/1… But a hack that comes with (too) many drawbacks when it comes to HTTP cache, logs, security…
Fortunately, thanks to the new features introduced in HTTP/2 and HTTP/3, it’s now possible to create REST APIs fixing these problems with ease and class.

Vulcain is a brand new Internet Draft allowing to create fast, idiomatic and client-driven REST APIs.
To do so, it relies on the Server Push feature introduced by HTTP/2+ and on the hypermedia capabilities of the HTTP protocol.

Better, Vulcain comes with an open source reverse proxy that you can put on top of any existing web API to instantly turn it into a Vulcain-compatible one!

HATEOAS is back, and it’s for the best!

Demo repository: https://github.com/dunglas/demo-vulcain-api-platform

E66449b8260b07a1cf51c5ab5eaa8180?s=128

Kévin Dunglas

November 21, 2019
Tweet

Transcript

  1. HTTP/2 Server Push
 and the rise of client-driven REST APIs

  2. @dunglas - vulcain.rocks Kévin Dunglas ❏ Founder of Les-Tilleuls.coop ❏

    Creator of Vulcain.rocks, Mercure.rocks, API Platform… ❏ Symfony Core Team Member @dunglas @ .social
  3. @dunglas - vulcain.rocks API, cloud, PHP and JS experts ✊

    Self-managed, 100% employee-owned 45 people, 1,000% growth in 6 years contact@les-tilleuls.coop Les-Tilleuls.coop
  4. @dunglas - vulcain.rocks What’s REST?

  5. @dunglas - vulcain.rocks « REST was developed […] primarily as

    a means for communicating Web concepts as we wrote the HTTP/1.0 specification and the initial HTTP/1.1 proposal. »
 - Roy T. Fielding
  6. @dunglas - vulcain.rocks REST: the Architectural Style of the Web

    ❏ client-server ❏ resource oriented ❏ stateless ❏ cacheable by clients and intermediaries ❏ layered (gateways and proxies) ❏ uniform interface (URI, HATEOAS…)
  7. RESTful Web Services

  8. @dunglas - vulcain.rocks REST Performance

  9. @dunglas - vulcain.rocks REST Performance ❏ REST is designed to

    solve performance and scalability problems at internet-scale ❏ REST relies on a powerful caching model: clients and intermediates can cache ❏ HTTP implements this model © Google
  10. @dunglas - vulcain.rocks The Under-Fetching and the N+1 Problems Not

    fetching enough data initially forces to issue subsequent requests, so creates waterfalls and increase latency. © Expedia Group
  11. @dunglas - vulcain.rocks The Over-Fetching Problem Generating and fetching too

    much data (data not used by clients) wastes bandwidth and computation power.
  12. GraphQL: an Alternative to REST « Fixing » its Perf

    Issues (among other things…)
  13. @dunglas - vulcain.rocks HTTP/2+

  14. @dunglas - vulcain.rocks HTTP/2: Making the Web Faster ❏ Binary

    protocol, multiplexing, prioritization ❏ Server Push of resources ❏ Headers compression ❏ HTTP/3: good bye TCP (perf, again)
  15. @dunglas - vulcain.rocks HTTP/2: Multiplexing © Narayan Prusty

  16. @dunglas - vulcain.rocks HTTP/2: Server Push

  17. @dunglas - vulcain.rocks HTTP/2 global support:
 95% of all internet

    users
  18. @dunglas - vulcain.rocks CloudWays Benchmark

  19. @dunglas - vulcain.rocks Fast and idiomatic client-driven REST APIs Introducing

    Vulcain
  20. None
  21. @dunglas - vulcain.rocks Pushing Relations

  22. @dunglas - vulcain.rocks Consuming Pushes in JavaScript const outboxResp =

    await fetch( "/outbox", { headers: { Preload: "/orderedItems/*/object" } } ); const outbox = await outboxResp.json(); outboxJSON.orderedItems.forEach(async activityURL => { // Returns immediately,
 // the resource has been pushed and is already in the push cache const activityResp = await fetch(activityURL); const activity = await activityResp.json(); // Returns immediately too const statusResp = await fetch(activity.object); // Do something with the status response... });
  23. @dunglas - vulcain.rocks Benefits ❏ Fixes the under-fetching and N+1

    problems ❏ Resources are downloaded in parallel (multiplexing) ❏ Granular HTTP cache (download only what isn’t in cache) ❏ Respects REST principles ❏ Leverages all features of the HTTP protocol ❏ cache, authorization, content negotiation, extensibility…
  24. @dunglas - vulcain.rocks Filtering Resources

  25. @dunglas - vulcain.rocks Other Capabilities ❏ Selector negotiation: ❏ extended

    JSON Pointer, XPath, CSS selectors, JMESPath… ❏ Support using Link preload headers and103 Early Hints as a fallback (cross-domain resources, HTTP/1…) ❏ Use query parameters instead of HTTP headers ❏ Support non-hypermedia APIs through OpenAPI
  26. @dunglas - vulcain.rocks The Vulcain Gateway Server

  27. @dunglas - vulcain.rocks The Vulcain Gateway Server ❏ Instantly turns

    any existing hypermedia or non-hypermedia API into a Vulcain-enabled API ❏ Gateway server (plug’n’play network intermediate) ❏ Free software (open source) ❏ Fast, written in Go ❏ Easy to install (static binary, Docker image) ❏ Best performance: implement the protocol directly at the app server layer
  28. @dunglas - vulcain.rocks Starting the Gateway Server

  29. @dunglas - vulcain.rocks Mapping a « Legacy » API

  30. @dunglas - vulcain.rocks Mapping a « Legacy » API #

    openapi.yaml openapi: 3.0.0 # ... paths: '/books/{id}': get: # ... responses: default: links: author: operationId: getAuthor parameters: id: '$response.body#/author' '/authors/{id}': get: operationId: getAuthor responses: default: # ... // /books/1984 { "title": "1984", "author": 1 // Not an URI } // /authors/1 { "givenName": "George", "familyName": "Orwell" }
  31. @dunglas - vulcain.rocks So… What About GraphQL?

  32. @dunglas - vulcain.rocks Vulcain vs GraphQL: Performance ❏ Unlike GraphQL,

    Vulcain sends each pushed resource in a separate HTTP/2 stream (multiplexing): related resources are sent in parallel ❏ Embedding resources is a forced push: the client receive the full JSON documents, even if it already has some parts of it ❏ With Vulcain, clients can cancel the push of resources they already have, saving bandwidth and improving performance
  33. @dunglas - vulcain.rocks But GraphQL is More Than That! ❏

    Query Language ❏ Type System ❏ Introspection ❏ Subscriptions ❏ Great tooling
  34. @dunglas - vulcain.rocks Type System and Introspection REST has that

    too… and a bit more! ❏ JSON-LD: internet-scale type system,
 built on top of RDF, W3C ❏ Hydra: hypermedia introspection system,
 built on top of JSON-LD, W3C ❏ OpenAPI: type system and introspection
  35. @dunglas - vulcain.rocks { "@context": "https://www.w3.org/ns/activitystreams", "type": "Person", "id": "https://social.example/alyssa/",

    "name": "Alyssa P. Hacker", "preferredUsername": "alyssa", "summary": "Lisp enthusiast hailing from MIT", "inbox": "https://social.example/alyssa/inbox/", "outbox": "https://social.example/alyssa/outbox/", "followers": "https://social.example/alyssa/followers/", "following": "https://social.example/alyssa/following/", "liked": "https://social.example/alyssa/liked/" }
  36. @dunglas - vulcain.rocks Subscriptions https://mercure.rocks

  37. @dunglas - vulcain.rocks Tooling ❏ GraphQL provides great client-side tooling

    and an unified Developer Experience, REST is still behind ❏ But because GraphQL uses HTTP as a black box: ❏ HTTP Cache servers (Varnish, Nginx…) ❏ standard WAF (ModSecurity…) ❏ HTTP logs analyzer (GoAccess, AWStats…) ❏ API Gateways (Kong, Gravitee…) are almost useless
  38. @dunglas - vulcain.rocks Tooling REST also has modern, easy to

    use client-side and server-side tooling: ❏ API Platform (PHP & JS): create JSON-LD APIs and smart React & Vue PWA, admin UIs, etc… in minutes! ❏ Graphiti (Ruby On Rails): create REST APIs in minutes ❏ Zeit’s SWR: React Hooks library for HTTP APIs leveraging concurrent rendering (perfect Vulcain’s companion) Vulcain works out of the box with all these tools!
  39. @dunglas - vulcain.rocks Using GraphQL to Query a Vulcain Server

    ❏ GraphQL is a convenient Query Language for APIs ❏ Write GraphQL queries client-side, and benefit from all the GQL ecosystem ❏ Use apollo-link-rest to convert the GQL query in a single REST+Vulcain request to the server Best of both worlds?
  40. @dunglas - vulcain.rocks Save the Web:
 Stop Centralizing!

  41. None
  42. @dunglas - vulcain.rocks

  43. None
  44. @dunglas - vulcain.rocks « The Web is intended to be

    an Internet-scale distributed hypermedia system […]. The Internet is about interconnecting information networks across multiple organizational boundaries. »
 - Roy T. Fielding
  45. @dunglas - vulcain.rocks The Threat of Data Centralization ❏ Facebook,

    Microsoft, Google, Apple… participated to NSA’s PRISM global mass surveillance program ❏ Cambridge Analytica manipulated the US election using Facebook data ❏ Facebook blocks pages of Kurdish organizations fighting ISIS ❏ GitHub blocks all Iranian users, including famous OSS contributors ❏ GitHub banned Tsunami Democràtic's app (pro Catalan-independence) Data centralization is harmful!
  46. None
  47. @dunglas - vulcain.rocks REST /
 Linked Data GraphQL server Origin

    Scientific community, to serve humanity Facebook, to serve its business Data access « Internet as a global database » Centralized information silos Interoperability Global and built-in Partial Best suited for Distributed systems Public APIs (« Open Data ») The World Wide Web Centralized systems Internal APIs
  48. @dunglas - vulcain.rocks // https://social.example/alyssa/posts/123 { "@context": "https://www.w3.org/ns/activitystreams", "type": "Note",

    // Not possible with a GraphQL server "to": ["https://chatty.example/ben/"], // reference to an external organization "attributedTo": "https://social.example/alyssa/", "content": "Say, did you finish reading that book I lent you?" } The power of Vulcain: GET https://social.example/alyssa/posts/123 Preload: /to Fields: /to, /content // Some hope for GraphQL? GraphQL-LD, HyperGraphQL: GQL as a query language for RDF
  49. The Rise of the Dweb

  50. @dunglas - vulcain.rocks The Rise of the Dweb REST, JSON-LD,

    schema.org, RDF, ActivityPub… ❏ Solid (by T. Berners-Lee): web decentralization, privacy by design ❏ : federated social network ❏ Mobilizon: federated Meetup-like ❏ PeerTube: federated video-streaming service ❏ NextCloud: federated file sharing service Vulcain works out of the box with all of them!
  51. @dunglas - vulcain.rocks And What About Symfony?!

  52. @dunglas - vulcain.rocks Vulcain, Symfony and API Platform The project:

    ❏ an app to send feedback to speakers, as in Lisbon 2018 The stack: ❏ Symfony + API Platform ❏ JSON-LD ❏ Varnish ❏ Vulcain
  53. @dunglas - vulcain.rocks The API Platform Distribution ❏ PHP +

    Symfony + API Platform ❏ Vulcain (master branch only) ❏ Varnish ❏ Postgres ❏ Docker and Kubernetes config github.com/dunglas/demo-vulcain-api-platform
  54. @dunglas - vulcain.rocks MakerBundle FTW!

  55. @dunglas - vulcain.rocks Our Vulcain API is Ready! A fully-featured

    API for the Dweb: ❏ JSON-LD + Hydra + schema.org ❏ Vulcain ❏ Varnish ❏ Mercure, auth, pagination, filters, validation, test framework, admin, React/Vue.js/Next.js generators…
  56. @dunglas - vulcain.rocks Benchmark ❏ Inject fixtures (using Alice) ❏

    10 conferences ❏ 100 sessions ❏ 100 feedback ❏ Fetch all the resources client-side
  57. @dunglas - vulcain.rocks Benchmark // Load ALL data from the

    API // Simulate more data dependencies than they really exist
 // to increase the waterfall effect console.time('download'); const conferences = await fetchJson('/conferences', { headers: { Preload: ‘/hydra:member/*/@id/ sessions/*/feedback/*' }}); for (const conferenceRel of conferences['hydra:member']) { const conference = await fetchJson(conferenceRel['@id']); // Fetch sessions for (const sessionURL of conference.sessions) { const session = await fetchJson(sessionURL); // Fetch feedback for (const feedbackURL of session.feedback) { const feedback = await fetchJson(feedbackURL) } } } console.timeEnd('download');
  58. @dunglas - vulcain.rocks Results: Vulcain kills the Waterfall effect ❏

    No Varnish, No Vulcain: 22,152 ms ❏ No Varnish, Vulcain: 9,704 ms ❏ Varnish, No Vulcain: 783 ms ❏ Varnish + Vulcain: 524ms ❏ Vulcain is 2.3x faster than API Platform without Vulcain ❏ Varnish is 28x faster than API Platform without Varnish ❏ The combination of Varnish and Vulcain is 42x faster than API Platform without Varnish, and without Vulcain ❏ The combination of Varnish and Vulcain is 1.5x faster than Varnish alone!
  59. Without Vulcain: 10.4s With Vulcain: 4.72s

  60. @dunglas - vulcain.rocks github.com/dunglas/demo-vulcain-api-platform Contains a benchmark using Symfony HttpClient!

    « All data retrieved in 0.85s »
  61. @dunglas - vulcain.rocks Summary Vulcain is: ❏ Fast (faster than

    GraphQL and JSON:API includes) ❏ Designed for the open web and interoperability at Internet-scale ❏ Easy to deploy ❏ Compatible with most existing tools ❏ Swagger/OpenAPI, log analyzers, Varnish, WAF, RDF… ❏ Can be supported in minutes by any web API ❏ including legacy RESTish APIs thanks to its OpenAPI support ❏ You can even use GraphQL to query a Vulcain API! Give it a try!
  62. Thank you! vulcain.rocks - @dunglas - les-tilleuls.coop and come at

    our booth!
